Encoding

1
Signal Encoding
E. Amir Ezzat Amir.ezzat_at_rashpetco.com
2
Encoding Techniques

• Digital data, digital signal
• Analog data, digital signal
• Digital data, analog signal
• Analog data, analog signal

3
Encoding and Modulation Techniques
4
Digital Signaling Versus Analog Signaling

• Digital signaling
• Digital or analog data is encoded into a digital
  signal
• Encoding may be chosen to conserve bandwidth or
  to minimize error
• Analog Signaling
• Digital or analog data modulates analog carrier
  signal
• The frequency of the carrier fc is chosen to be
  compatible with the transmission medium used
• Modulation the amplitude, frequency or phase of
  the carrier signal is varied in accordance with
  the modulating data signal
• by using different carrier frequencies, multiple
  data signals (users) can share the same
  transmission medium

5
Digital Signaling

• Digital data, digital signal
• Simplest encoding scheme assign one voltage
  level to binary one and another voltage level to
  binary zero
• More complex encoding schemes are used to
  improve performance (reduce transmission
  bandwidth and minimize errors).
• Examples are NRZ-L, NRZI, Manchester, etc.
• Analog data, Digital signal
• Analog data, such as voice and video
• Often digitized to be able to use digital
  transmission facility
• Example Pulse Code Modulation (PCM), which
  involves sampling the analog data periodically
  and quantizing the samples

6
Analog Signaling

• Digital data, Analog Signal
• A modem converts digital data to an analog signal
  so that it can be transmitted over an analog line
• The digital data modulates the amplitude,
  frequency, or phase of a carrier analog signal
• Examples Amplitude Shift Keying (ASK), Frequency
  Shift Keying (FSK), Phase Shift Keying (PSK)
• Analog data, Analog Signal
• Analog data, such as voice and video modulate the
  amplitude, frequency, or phase of a carrier
  signal to produce an analog signal in a different
  frequency band
• Examples Amplitude Modulation (AM), Frequency
  Modulation (FM), Phase Modulation (PM)

7
Digital Data, Digital Signal

• Digital signal
• discrete, discontinuous voltage pulses
• each pulse is a signal element
• binary data encoded into signal elements

8
Periodic signals

• Data element a single binary 1 or 0
• Signal element a voltage pulse of constant
  amplitude
• Unipolar All signal elements have the same sign
• Polar One logic state represented by positive
  voltage the other by negative voltage
• Data rate Rate of data (R) transmission in bits
  per second
• Duration or length of a bit Time taken for
  transmitter to emit the bit (Tb1/R)
• Modulation rate Rate at which the signal level
  changes, measured in baud signal elements per
  second. Depends on type of digital encoding used.

9
Interpreting Signals

• Need to know
• timing of bits when they start and end
• signal levels high or low
• factors affecting signal interpretation
• Data rate increase data rate increases Bit Error
  Rate (BER)
• Signal to Noise Ratio (SNR) increase SNR
  decrease BER
• Bandwidth increase bandwidth increase data rate

• encoding scheme mapping from data bits to signal
  elements

10
Comparison of Encoding Schemes

• signal spectrum
• Lack of high frequencies reduces required
  bandwidth,
• lack of dc component allows ac coupling via
  transformer, providing isolation,
• should concentrate power in the middle of the
  bandwidth
• Clocking
• synchronizing transmitter and receiver with a
  sync mechanism based on suitable encoding
• error detection
• useful if can be built in to signal encoding
• signal interference and noise immunity
• cost and complexity increases when increases
  data rate

11
Encoding Schemes
Positive level (5V) Negative level (-5V)
Positive level (5V)No line signal (0V)Negative
level (-5V)
12
Encoding Schemes
13
NonReturn to Zero-Level (NRZ-L)

• Two different voltages for 0 and 1 bits
• Voltage constant during bit interval
• no transition, i.e. no return to zero voltage
• more often, negative voltage for binary one and
  positive voltage for binary zero

14
NonReturn to Zero INVERTED (NRZI)

• Nonreturn to zero inverted on ones
• Constant voltage pulse for duration of bit
• Data encoded as presence or absence of signal
  transition at beginning of bit time
• transition (low to high or high to low) denotes
  binary 1
• no transition denotes binary 0

15
Advantages and disadvantages of NRZ-L, NRZI

• Advantages
• easy to generate
• good use of bandwidth
• Disadvantages
• dc component
• lack of synchronization capability
• Unattractive for signal transmission applications

16
Multilevel BinaryBipolar Alternate Mark
Inversion (AMI)

• Use more than two levels (three levels, positive,
  negative and no line signal)
• Bipolar-AMI
• zero represented by no line signal
• one represented by positive or negative pulse
• one pulses alternate in polarity
• no loss of sync if a long string of ones
• long runs of zeros still a problem
• no net dc component
• lower bandwidth
• easy error detection

17
Multilevel BinaryPseudoternary

• Binary one represented by absence of line signal
• Binary zero represented by alternating positive
  and negative pulses
• No advantage or disadvantage over bipolar-AMI
• Each used in some applications

18
Multilevel Binary Issues

• Advantages
• No loss of synchronization if a long string of
  1s occurs, each introduce a transition, and the
  receiver can resynchronize on that transition
• No net dc component, as the 1 signal alternate in
  voltage from negative to positive
• Less bandwidth than NRZ
• Pulse alternating provides a simple mean for
  error detection
• Disadvantages
• receiver distinguishes between three levels A,
  -A, 0
• a 3 level system could represent log23 1.58
  bits
• requires approx. 3dB more signal power for same
  probability of bit error

19
Theoretical Bit Error Rate (BER) For Various
Encoding Schemes
20
Manchester Encoding

• has transition in middle of each bit period
• low to high represents binary one
• transition serves as clock and data
• high to low represents binary zero
• used by IEEE 802.3 (Ethernet) LAN standard

21
Differential Manchester Encoding

• midbit transition is clocking only
• transition at start of bit period representing
  binary 0
• no transition at start of bit period representing
  binary 1
• used by IEEE 802.5 token ring LAN

22
Advantages and disadvantages of Manchester
Encoding

• Advantages
• synchronization on mid bit transition (self
  clocking codes)
• has no dc component
• has error detection capability (the absence of an
  expected transition can be used to detect errors)
• Disadvantages
• maximum modulation rate is twice NRZ
• requires more bandwidth

23
Modulation Rate versus Data Rate

• Data rate (expressed in bps)
• Data rate or bit rate R1/Tb1/1µs1Mbps
• Modulation Rate (expressed in baud) is the rate
  at which signal elements are generated
• Maximum modulation ratefor Manchester is
  D1/(0.5Tb)2/1µs2Mbaud

24
Scrambling

• Use scrambling to replace sequences that would
  produce constant voltage
• These filling sequences must
• produce enough transitions to maintain
  synchronization
• be recognized by receiver replaced with
  original
• be same length as original
• Design goals
• have no dc component
• have no long sequences of zero level line signal
• have no reduction in data rate
• give error detection capability

25
B8ZS and HDB3
26
Bipolar with 8-Zero Substitution (B8ZS)

• To overcome the drawback of the AMI code that a
  long string of zeros may result in loss of
  synchronization, the encoding is amended with the
  following rules
• If 8 zeros occurs and the last voltage pulse was
  positive, then the 8 zeros are encoded as
  0000
• If zeros occurs and the last voltage pulse was
  negative, then the 8 zeros are encoded as
  0000

27
High Density Bipolar-3 zeros (HDB3)

• The scheme replaces strings with 4 zeros by
  sequences containing one or two pulses
• In each case, the fourth zero is replaced with a
  code violation (V)
• successive violations are of alternate polarity
