Ultimate guide for Range of EOT Crane

1
Pioneer Manufacturer of Range of EOT Crane
TO
More information about EOT Crane, Log on to
http//www.eotcranes.in/
2
1. About SHREE KRISHNA ENGINEERING CO

• With all other company in the industry busy
  manufacturing goods and products, we step into
  the market as a Manufacturer and Supplier of
  Material Handling Equipment in the year 1995.
• This was done to provide a totally dependable
  solution for the problems related to progress,
  protection and usage of various materials.
• We make this possible by offering a all-inclusive
  range of products, like, Eot Crane, Double Girder
  Eot Crane, Chain Hoists, EOT Trolleys (Crab),
  Goods Lifts, Jib Cranes etc. This whole range is
  manufactured using the best quality raw material
  sourced from the trusted vendors of the industry.

• This make our products have superior quality and
  some of the unmatched features like tough
  construction, durability, ability to bear loads
  and anti-corrosive body.

More information about EOT Crane, Log on to
http//www.eotcranes.in/
3
1.1 About SHREE KRISHNA ENGINEERING CO

• With base in Gujarat, we are engaged in the
  business of offering Double Girder EOT Cranes,
  Electromagnet Disc Brakes, Hydraulic Products
  Equipment, Single Girder EOT Cranes and other
  such Material Handling Equipment.
• With a semi-automated production set up, our firm
  is making products in an excellent speed and
  ultimately meeting demands of clients based in
  the market.
• Further, with perfect amalgamation of our
  dexterous professionals and sound amenities, we
  have been able to become prime choice of numerous
  industries like Bearing, Foundry, Paper, Mine and
  Minerals. Our products and fair business
  practices surpass the clients' expectations and
  make them trust as well as deal with us.

More information about EOT Crane, Log on to
http//www.eotcranes.in/
4
2. What is EOT Crane?

• EOT Crane is short form of Electric Overhead
  Travelling Crane.
• Cranes are Industrial machine and used for
  material movement at variety of places like
  construction sites , production halls, assembly
  lines ,power station ,railways yards , heavy
  industries and many more.
• EOT Cranes design features vary widely according
  to their major operational specification like
• Type of motion of crane structure
• Weight to be lifted type of load
• Location of the crane
• Geometric Features
• Operating regimes
• Environmental condition etc

More information about EOT Crane, Log on to
http//www.eotcranes.in/
5
2. Type of EOT Crane

• EOT Crane are basically of following type
• Single Girder EOT Crane The Single girder EOT
  Crane consists of Single bridge girder supported
  on two end trucks. It has a trolley hoist
  mechanism that runs on the bottom flange of
  bridge girder.
• Double Girder EOT Crane The double girder eot
  crane consists of two bridge girder supported on
  two end trucks and the trolley runs on rails on
  the top of bridge girders
• Gantry Cranes These cranes are essentially the
  same as regular cranes except that the bridge for
  carrying the trolley or trolleys is rigidly
  supported on two or more legs running on fixed
  rails or other runway.
• Monorail For application such as production
  assembly or service assembly line , only a
  trolley hoist is required. the Hoisting mechanism
  is same as single girder eot crane and only
  difference that Monorail crane does not have
  movable bridge and the trolley run on fixed
  girder.
•

More information about EOT Crane, Log on to
http//www.eotcranes.in/
6
3. Photograph of Different Type of EOT Crane
Single Girder EOT Crane
Double Girder EOT Crane
More information about EOT Crane, Log on to
http//www.eotcranes.in/
7
3.1 Photograph of Different Type of EOT Crane
Gantry Crane
More information about EOT Crane, Log on to
http//www.eotcranes.in/
8
Let us See Single girder eot crane and Double
Girder EOT Crane in successive slide.
More information about EOT Crane, Log on to
http//www.eotcranes.in/
9
4. Single Girder EOT Crane

• Single girder EOT Crane generally have maximum
  span in between 20 and 50 feet with maximum lift
  of 15-50 feet
• They can handle the 1 to 20 tons
• Single girder eot crane generally use to handle
  the light to moderate load and cost effective for
  use as standby crane .
• Single girder cranes reduce the total crane cost
  on crane components, runway structure and
  building.

More information about EOT Crane, Log on to
http//www.eotcranes.in/
10
4.1 Salient Features of Single Girder EOT Crane

• Designed manufactured in accordance with
  defined industry standards
• Motors used are especially designed for crane
  duty and finds suitability in work area demands
  of frequent starting, reversing and braking
• Motors available in totally enclosed dust proof
  construction
• Gear boxes body fabricated using MS Plate
• Presence of precision engineered hob cut helical
  / spur gears and pinions to deliver optimum usage
• All gears pinions running on anti-friction type
  ball/roller bearings in enclosed oil bath for
  providing constant splash lubrication
• Designed for optimum wear resistance for smooth
  operations
• Modular design electrical panel that is easy to
  install and maintain
• Comes with provision of safety limit switches for
  all motions
• Comes with primer paint and synthetic enamel
  paint finish for corrosion resistance
• Available in different load capacities from 1 ton
  to 20 ton.

More information about EOT Crane, Log on to
http//www.eotcranes.in/
11
5. Double Girder EOT Crane

• Double girder Eot Cranes are faster , with
  maximum bridge speeds , torlley speeds and hoist
  speeds approaching 350 FPM ,150 FPM and 60 FPM
  respectively
• They can lift up to 100 tons.
• These can be utilized at any capacity where
  extremly high hook lift is required because the
  hook can be pulled up between girders
• they are also highly suitable where the crane
  needs to be fitted with walkways ,lights, cabs
  ,magnet cable reels or other special equipments.

More information about EOT Crane, Log on to
http//www.eotcranes.in/
12
5.1 Salient Features of Double Girder EOT Crane

• Simple and precise design ensuring minimum dead
  weight, Wheel Load Headroom and easy to maintain
• Safe and reliable hoisting and traveling
• Higher efficiency to save power
• Fail safe type brakes (which are applied when
  power supply is off and release when power supply
  is on.)
• All motion are protected with limit switches
• Rubber buffers are provided to extra protection
  against collision in case of limit switch failure
• Dustproof panel box with reputed make switch gear
  or as per customers' approval
• 110 V Control voltage selected for protection of
  Crane operator against any electrical shock

More information about EOT Crane, Log on to
http//www.eotcranes.in/
13
5.2 Salient Features of Double Girder EOT Crane

• With electrical Interlocking to prevent
  simultaneous operation of opposite motion
• Available with Radio remote Control operated type
• Available in Class-I, Class-II,Class-III, and
  Class-IV, Duty
• Designed as per Indian Standard IS 807 IS 3177
• These are designed especially with mechanical
  means for Traveling in both directions and
  raising and lowering a load by electrical
• Our product consists of structures, wheels,
  gearboxes, wire rope, electrical motors, panels
  and hooks assembly and are known fore their
  higher efficiency which in turn saves power.

More information about EOT Crane, Log on to
http//www.eotcranes.in/
14
6. Contact us
SHREE KRISHNA ENGINEERING CO Plot No. 58/3, Shad
No. 16, 17, Shyam Estate, Kiran Industries Road,
Nr. Bank Of India, B/h. B.R. Pipes, Phase - 1,
Vatva, G.I.D.C.Ahmedabad -382445 Mr. Maulik Patel
(91)-9723550623 Mr. Dipak Patel
(91)-8490820820 E-Mail skecrane_at_yahoo.in info_at_
eotcranes.in Website http//www.eotcranes.in/
