Techwin-China Presenting Products

1
Techwin China

• A Fast Leading Company In Electronic Market.

www.techwin-china.com
Call on - 86-571-88284299
2
About Us

• Techwin (China) is the leading supplier of test
  and measurement instrument for the wireless and
  wire line communications in the world. Our
  products cover not only for research, development
  and manufacturing, but also for installation.
• Our products and Service are exported to
  worldwide (More than 100 Countries and Regions)
  and we create a Great Value for our annual sales,
  and continue the rapid growth all the time.

www.techwin-china.com
Call on - 86-571-88284299
3
Our Products

• Our products cover not only for research,
  development and manufacturing, but also for
  installation. The Products as below -

• Products -
• Signal Generator
• Spectrum Analyzer
• Vector Network Analyzer
• Power Measurement
• Fiber Laser
• Fiber Amplifier
• Laser Source
• Pump and Signal Combiner
• Fusion Splicer
• Fiber Testing Instrument
• Cable and Antenna Analyzer
• Cables
• Thermal Stripper

www.techwin-china.com
Call on - 86-571-88284299
4
Equipment's with images

• 1. Signal Generator-Signal generators, also
  known variously as function generators, RF and
  microwave signal generators, pitch generators,
  arbitrary waveform generators, digital pattern
  generators or frequency generators, are
  electronic devices that generate repeating or
  non-repeating electronic signals.
• 2. Spectrum Analyzer - A spectrum analyzer is a
  laboratory instrument that displays signal
  amplitude (strength) as it varies by signal
  frequency. The frequency appears on the
  horizontal axis, and the amplitude is displayed
  on the vertical axis.
• 3. Power Measurement - Power measurement in AC
  circuits can be quite a bit more complex than
  with DC circuits for the simple reason that phase
  shift complicates

Call on - 86-571-88284299
www.techwin-china.com
5
4. Vector Network Analyzer - vector network
analyzer. A VNA is a test system that enables the
RF performance of radio frequency and microwave
devices to be characterized in terms of network
scattering parameters, or S parameters. 5. Fiber
Laser- A fiber laser or fiber laser is
a laser in which the active gain medium is an
optical fiber doped with rare-earth elements such
as erbium, ytterbium, neodymium, dysprosium,
praseodymium, thulium and holmium.  6. Fiber
Amplifier- Fiber amplifiers are
optical amplifiers based on optical fibers as
gain media. In most cases, the gain medium is a
glass fiber doped with rare earth ions such as
erbium (EDFA erbium-doped fiber amplifier),
neodymium, ytterbium (YDFA), praseodymium, or
thulium.
Call on - 86-571-88284299
www.techwin-china.com
6
7. Laser Source- A laser is a device that
emits light through a process of optical
amplification based on the stimulated
emission of electromagnetic radiation. The term
"laser" originated as an acronym for "light
amplification by stimulated emission of
radiation. 8. Pump and Signal Combiner- Beam
Combiner, Pump And Signal Combiner is used to
combines the 6Fiber-couple multi-mode pump to
maximize the pump power, Techwin-China is one of
the biggest brand who makes available the
products you want at the best prices. 9. Fusion
Splicer- Fusion Splicer is the Product which
makes fuses the two different copper wire with
the fiber, and the quality fusion splicer is only
available by Techwin-China. And you can also buy
Fusion Splicer, Fiber Splicer, Fibre Fusion
Splicer at very cheap cost with best quality.
Call on - 86-571-88284299
www.techwin-china.com
7
10. Fiber Testing Instrument- As network speeds
and bandwidth demands increase, distance and loss
limitations have decreased, making fiber optic
cabling certification more important than ever.
Inspecting Fiber Optic Cable for Light Loss 11.
Cable and Antenna Analyzer- Cable and Antenna
Analyzer TW3300 has advantages of fast measuring
speed, high measurement accuracy, small size,
light weight, battery power, touch screen
operation and adjustable backlighting. 12.
Cables-Cables used in different areas are like,
PLC Splitter, Fiber Coupler, FAST Connector
etc. 13. Thermal Stripper- The best ever
quality Thermal Wire Stripper is providing by the
Techwin-China and which is a quality based
product without damaging the Core wire it strips
out the Teflon, Kapton.
Call on - 86-571-88284299
www.techwin-china.com
8

• Techwin equipment is used by technical and
  non-technical staff in all phases of manufacture,
  installation and maintenance. Typical
  applications are to verify, test, certify and
  repair fiber optic systems in telecom, datacom,
  defense and automotive applications. Our
  universal connector easily is adapted to a
  variety of popular connector styles.

Call on - 86-571-88284299
www.techwin-china.com
9
We appreciate the time you took to view our
Presentation. We are much interested to work with
you
Contact us -
Phone no. - 86-571-88284299 Email id -
techwinchina_at_gmail.com Web mail -
www.techwin-china.com
