Case Study – Power Station Steam (Boiler) Feed Pump Lube Oil

1
Case Study Power Station Steam (Boiler) Feed
Pump Lube Oil
2

• BioKem recently completed a lubrication
  purification role at one of Australias large
  coal fired power stations. BioKem had previously
  assisted the Plant during a shutdown however
  this call was urgent due to a significant anomaly
  occurring in one of their Steam (Boiler) Feed
  Pump oil tanks.Lubricant Caltex Regal RO 32

3
The Problem

• In-house lube oil lab reports revealed an ISO
  4406 trend of 20/18/14 (NAS 9) over a 12 month
  period, peaking at 22/19/15 (NAS 11) when they
  flagged it. This is definitely out of spec for a
  Steam Feed Pump lube tank, even using a Group 1
  mineral oil.

4

• A large quantity of sludge was removed from the
  on-board strainers. It was later determined that
  the on-board filtration and coalescer system was
  not working correctly and the filter housings
  also held a lot of sludge.

5
(No Transcript)
6

• The site had already had a failure of a 28,000
  control valve system that was suspected to be
  from the contaminated oil and continued operation
  of the unit in this state, was a concern.

7
The Challenge

• The main consideration from the Plant engineering
  team was to stay online and correct the
  contamination problem ASAP. A reasonable solution
  could have been to dump the oil and refresh the
  lube system with a fresh charge of 7,000 of oil.
  This would have involved the unit being offline
  so was not preferred! Also, filling with (new)
  unpolished oil, which is supplied nominally
  around 21/18/15 (NAS 10) was not going to help.

8

• Considering the urgent nature of the project,
  BioKem mobilised on a Sunday, to be onsite 600
  am Monday morning, completing safety inductions
  and site requirements. We deployed a low profile
  140l/min Vacuum Dehydration Oil Purification
  System (VDOPS) suited for this constrained
  environment.

9
(No Transcript)
10

• Tasked with correcting the SFPT lube oil ISO
  4406, and identifying the contaminants, BioKem
  established a mobile laboratory to patch test
  samples whilst onsite.An additional challenge
  was the tank ports, at 1 diameter, that were too
  small to flow the required 140 LPM of our
  purification rig which has 2 connections.

11

• The BioKem VDOPS rig, with a flow capacity of 140
  LPM or 8,400l/hr, vacuum dehydration, 2 µm
  filtration, centrifuge and heating. The compact
  design and low profile of this rig allow us to
  stage it right next to the Boiler Feed Pump Tank.

12
(No Transcript)
13
Purification Tasks

• For the 7,000l tank, circulating at 140 LPM, a
  complete cycle is every 50 minutes, we estimated
  up to three days of purification, operating
  24hrs, to correct the ISO 4406 from 22/19/15 (NAS
  11), to a healthy 16/14/12 (NAS 5).times the
  intelligent maintenance costs. It doesnt get
  much better than

14
