Factors For Finding The Perfect Transformer

1
Abbott Technologies
PRESENTS
Factors For Finding The Perfect Transformer
2
Voltage

• Transformer possess both input and output
  voltage.
• Vary based on what machines are being powered by
  this transformer.
• Check if required voltage is mismatching.

3
Phase

• Transformers come in two varieties i.e single and
  three phase.
• Single phase is used for small appliances like
  kitchen blenders.
• Three phase is commonly used in large scale
  Industries.

4
Frequency

• Based on power supply and the input and output
  frequencies .
• The output frequency
• Can changed using a frequency converter.
• Used when trying to power international
  appliances.

5
KVa Rating

• Vary the max load of a transformer.
• calculated based on the primary winding voltage
  and current values.
• Maximum load is a critical feature for
  transformer.

6
Purpose

• There are two types of transformers.
• K factors Transformers
• focus on heat reduction.
• Isolation Transformer
• Specialized in power supplying.

7
Work Environment

• Construction of transformer depends on the
  environment in which it is going to work.
• Outdoor transformers have different construction
  from indoor ones.
• Humidity, temperature, precipitation and wind
  speed should be kept in mind.
• Certain safety guidelines must be followed during
  working at different workplace.

8
Size

• Specific standard size as per requirement.
• Few are compact and strong depends on the
  availability of space.

Standard and Certification

• Transformers will have to comply to standards.
• Outdoor Transformer are safe compare to indoor
  ones.
• Seal should be checked prior to use.

9
Wire configuration

• Can have wiring arranged in different fashions.
• Three phase transformers coming in star, delta,
  or interconnected star set ups.
• Wiring styles can be mixed and matched for
  further specialization.

10
Abbott Technologies
8203 Vineland Ave. Sun Valley, CA 91352 Sales
[phone] Tech. Support [phone]
Fax [phone]
For more information visit
http//abbott-tech.com
11
Thank You
