Title: Steering systems


1
MDARIF I DDhananjay Rao
  • By

2
Types of Steering SystemgtMechanical
Steering,gtHydraulic power steering
AndgtElectric Power Steering
3
  • Mechanical steering

4
  • Mechanical Steering was introduced in worlds
    first car it was invented by Karl Benz and
    Daimler

5
In 40s 50s in big vehicles there was no power
steering.It was difficult to drive Big vehicles
like, Buses,Trucks
6
  • Tractors
  • Truck

7
Hydraulic Power Steering System Components
8
Working of Hydraulic Power Steering
9
Advantages Disadvantages Advantages1. easy
to turn big vehicles in low speed, Disadvantages
1. oil leakage,2. back stroke,3. more
maintenance,4. less mileage.
10
Electric Power Steering
11
What is Electric power steering system ?
  • Electrically powered steering uses an electric
    motor to drive either the power steering
    hydraulic pump or the steering linkage directly.
    The power steering function is therefore
    independent of engine speed, resulting in
    specific energy savings.

12
Electric power steering system
  • Hydraulic power steering system uses hydraulic
    pump Which is run by electric motor.
  • Where as, in EPS system electric motor is
    directly attached to steering rack via gear
    mechanism (no pump or fluid)

13
Electric Motor Location Types
  • COLUMN TYPE
  • PINION TYPE
  • RACK TYPE
  • DOUBLE PINION TYPE

14
EPS system consists of-
  • Torque Sensor
  • E C U ( Electronic Control Unit )
  • Electric Motor
  • Reduction Gear

15
Operational Mechanism Of EPS
16
Classification of EPS
  • The E P S system literally means that steering
    operation is entirely done by electronic
    /electrical means and no mechanical linkage
    exists between steering wheel and steered rod
    wheels.
  • Basically two formations are possible, they are,
  • Using Steering Wheel Control
  • Using Joystick Control

17
Electronic Control System
  • Sensors
  • Positive Sensors
  • Digital Positive Sensors
  • Speed Sensors
  •
  • E C U ( Electronic Control Unit )
  • Actuators
  • Power Supply

18
Construction and Working
19
Construction and Working (Contd)
20
Comparison between EPS and HPS
  • Simple in Design
  • Lighter in Weight
  • Require less maintenance as hydraulic fluid is
    not used
  • Gives better responses at different speed
  • Because of less problem faults thus, it is
    durable than H P S
  • More mileage

21
ADVANTAGES
  • Increased reliability
  • Improved fuel economy
  • As hydraulic fluid is not needed it is
    environment friendly
  • Simplify Design
  • Using joystick only one hand is sufficient to
    drive the vehicle
  • Self-diagnostic systems makes maintenance easy
    and cheap
  •

22
APPLICATIONS
  • E P S can be incorporated into all passenger car
    and truck platforms. Since this system is compact
    and lightweight, it finds wide application in
    sports cars. Similar type of system is employed
    In India on Maruti-Suzuki Versa Van, ZenVXI, and
    Wagonr LXI etc.
  • Electric power steering can be found on the
    Acura NSX (Which was the first production car
    with this feature), the Honda S2000, Toyota Prius
    and Toyota RAV4,plus numerous. GM models
    including 2004-2009 Chevrolet Malibu, 2005-2009
    Chevrolet Cobalt and Equinox, 2006-2009 Chevrolet
    HHR, 2005-2009 Pontiac G6 (except the
    convertible, GTP and 2007 GT models), 2006-2009
    Pontiac Torrent, 2007-2009 Pontiac G5, 2002-2009
    Saturn VUE, and 2003-2008 Saturn 10N.

23
