Detailed information about Biomass Briquetting Plant Project

1
Jay Khodiyar Machine Tools
2

• About Jay Khodiyar Machine Tools
• Jay Khodiyar Machine Tools is founded in 1994.
• Jay Khodiyar Machine Tools is manufacturing
  machine which is used for Produce Briquettes.
• We are manufacturing these
  machines-
• Briquetting Machine - Jumbo -90
• Briquetting Machine - Supreme-75
• Briquetting Machine - Super -65
• Biomass Crusher /Shedder Machine
• Biomass Turbo Dryer CTD 60

3

• Conti
• We are Manufacturer, Exporter and Supplier of top
  quality Biomass Briquetting Plant, Biomass
  Crusher, Biomass Dryer and Rotary Dryer which
  enables to create green fuel projects and
  Eco-friendly Environment.
• This briquettes are made from forestry waste . In
  this briquettes making process no any binder is
  used but only forestry waste is used.
• Through such briquetting plant project we can
  save the Global environment and can produce
  green energy.

4

• How to Briquette the Bio-mass?
• This is the briquetting process of making
  Bio-mass Briquettes.
• first raw material is grind using biomass
  crushing machine .
• And then need to dryer so used to dryer machine .
• And then this material is turn into briquetting
  machine which is ready to final product that is
  display in image.

5
(No Transcript)
6

• Jumbo-90
• This model is biggest rather then supreme 75 and
  super 65.
• In this model not require to 10mm sized raw
  material but it is used 25mm size raw material.
• Its production capacity of briquettes is high.
• It delivers finished products briquettes in 90mm
  diameter.
• Its Maintenance cost is lower.

7

• Supreme -75
• This model is used 10mm size raw material.
• If raw material is not in this form so, need the
  crusher machine is used for converting raw
  material in to powdery form.
• It delivers finished products briquettes in 75mm
  diameter.
• Its output range of briquettes production is
  800-1000 kg/hr.

8

• Super -65
• This model is used 10 mm sized raw material so,
  in this model also need to crushing machine.
• This is the first model when we start our
  journey.
• It delivers finished products briquettes in 65mm
  diameter.
• Its output range for briquettes production is
  700-850 kg/hr.

9

• Biomass Crusher Machine
• This model is used for grinding of row material
  in briquetting process.
• Row material like Groundnut Shell, Wood Chips,
  Wood Waste, Tree Bark ,Sugarcane Trash , Palm
  Waste etc.
• Wood shredder machine is also known as cutter or
  crushing machine.

10

• Turbo Dryer CTD 60
• This is used for drying process of raw material
  in briquetting process.
• Row material is not directly used in above three
  model, If in raw material moisture level is high.
• so, need to dry the raw material .

11

• Raw Material

Peanut Shell
Coconut Waste
Bagasse
Coffee Husk
Saw Dust
Corn Cobs
12
Benefits Of Bio-Mass Briquettes
Rising demand due to rising cost of fossil fuel
Pollution free because there is no sulfur
Content
Tax benefits and incentives
Renewable source of fuel and energy
Earlier viability
Benefits
Contain high density
Related rules
Easy mobility and transportation
13
Contact Us
Jay Khodiyar Machine Tools, Samrat Industrial
Area, Street No.2, Kaneriya Oil
Industries, Gondal Road, Rajkot, Gujarat. 360004
Call Us 91-7600000018
Web http//briquetting.net/
http//www.jaykhodiyar.com/
Thank You
