How to Program Homelink Gate Opener

1
How to Program Homelink Gate Opener

• Gate motors

2
Programming your HomeLink system can be done in
just minutes from your driver's seat, as long as
you have your gate opener remote or access to the
motor, and you can have the system ready to use
immediately.
3
1. Enter the car with your gate remote and press
and hold the two outer buttons on your HomeLink
onboard system. 2. Hold for about 20 seconds and
release the buttons once the LED light on the
system begins blinking.
4
3. Turn your key in your ignition to the "Acc"
position. 4. Hold your gate remote three inches
from the onboard system and press and hold the
button you wish to program on your onboard system.
5
5. Repeatedly press the open button on your
remote every two seconds until the LED light on
the system begins flashing more rapidly. Release
the button on your onboard system. 6. Press and
hold the button you just programmed on the
onboard system again until the LED light glows
solid.
Source http//www.ehow.com/how_6786356_program-
homelink-gate-opener.html
