ECG BASICS- CONDUCTION TISSUE

1
ECG Basics-Conduction tissue within Heart and
disorders

• Dr. Md.Toufiqur Rahman
• MBBS, FCPS, MD, FACC, FESC, FRCP,
• FSCAI, FAPSIC, FAPSC
• Associate Professor of Cardiology
• National Institute of Cardiovascular Diseases
• Sher-e-Bangla Nagar, Dhaka-1207

2
Dr. Md.Toufiqur Rahman MBBS, FCPS, MD,FACC,
FESC, FRCP, FSCAI, FAPSIC, FAPSC
3
Conduction Tissue
4
Normal Rhythm ECG
5
Leads of ECG
6
Precordial Leads
7
Pathology of conduction tissue
8
Sinoatrial block
Sinus rhythm for three beats, then a 'sinus
pause' P waves arrowed The expected P wave is
not seen, but the SA node must have
beendepolarized because the next P wave appears
at the predicted time
9
First degree block
Sinus rhythm PR interval is constant (360 ms)
10
Second degree block (Mobitz type 2)
Sinus rhythm with a normal PR interval One P
wave (arrowed) is not followed by a QRS complex
11
Second degree block (Wenckebach)
Three beats with progressively longer PR
intervals are followed by a non-conducted P wave
(arrowed) The next PR interval is short, but
this is followed by a longer PR interval and then
another non-conducted beat
12
Second degree block (21)
The conducted beats have a normal PR interval
Alternate P waves are not followed by a QRS
complex
13
Complete (third degree) block
No relationship between P waves (arrowed) and
QRS complexes The QRS complexes are normal,
indicating that the origin of ventricular
depolarization is within the His bundle The
ventricular rate is 30/min
14
Complete (third Degree) block
No relationship between P waves (arrowed) and
QRS complexes Wide QRS complexes Ventricular
rate of 22/min
15
