Real time DSP

1
Real time DSP

• Professors
• Eng. Julian S. Bruno
• Eng. Jerónimo F. Atencio
• Sr. Lucio Martinez Garbino

2
Discrete Time Fourier Transform
DTFT
3
Discrete Fourier Series (I)
4
Discrete Fourier Series (II)
5
Discrete Fourier Series (III)
DTFT of periodical signal
DFS coefficients
6
Discrete Fourier Transform (I)
xm is an aperiodic sequence
Sampling ?k2pk/N
DFS
7
Discrete Fourier Transform (II)
8
Discrete Fourier Transform (III)
0 k N-1
0 n N-1
The inherent periodicity is always present
Propierties Circular Shift of a Sequence
Circular Convolution
9
Sampling the Fourier Transform
DTFT
Sampling
DFT
DFS
10
DFT Propierties
Circular Shift of a Sequence
Circular Convolution
The circular convolution corresponding to
X1kX2k is identical to the linear convolution
corresponding to X1(ejw)X2(ejw) if N, the length
of the DFTs, satisfies N L P - 1 .
11
Implementing Linear Time-Invariant Systems Using
the DFT
xn
yn xn hn
12
Overlap-addmethod
yrn xrn hn
13
Overlap-savemethod
yrn xrn hn
14
Understanding the DFT Equation

• In this example we have a 4 samples signal and we
  use DFT to get its frequency representation.
• The result for each frequency component is
  obtained after computing 8 real sums and
  multiplications.

15
DFT example (I)

• Consider a signal formed with 2 sinusoidal, one
  of 1 KHz and the other of 2 KHz and a phase shift
  of ¾p.
• N 8 samples.
• Fs 8000 samples/s.
• Fs/N 1Khz
• First computations are showed in detail.

16
DFT example (II)
17
DFT example (III)
18
DFT example (IV)

• Here we show the final result in both
  representations formats.
• The complex DFT outputs for m1 to m(N/2)-1 are
  redundant with frequency output values form
  mgt(N/2)
• We can see an even symmetry in Magnitude and Real
  representations, while an odd symmetry in
  Imaginary and Phase.
• It can be verified the amplitude and phase
  relationship between the sinusoidal components,
  but absolute values?

Fixed point DSP
19
DFT Leakage (I)
Leakage is an unavoidable fact of life when we
perform the DFT on real world finite-length time
sequences

• If there are frequency components that are not
  integer multiples of fres, we got leakage.
• Leakage evidences the effect of sampling during
  finite (and rectangular) time window.

20
DFT Leakage (II)

• As can be seen, the sinc function is always
  present, but only evidenced when frequency
  components are not integer multiples of fres.
• The DFT output is a sampled version of the
  continuous spectral

21
Time Windowing (I)

• The only fact of considering a finite length time
  sequence, is equivalent to convolve a sinc with
  all frequency samples.
• If we use a window, we will convolve with the
  spectrum this window.
• The net effect of windowing is a better spectral
  estimation, reducing leakage and picket fence
  effect.

22
Time Windowing (II)

• Spectral analysis
• Equivalent Noise Bandwith
• Processing Gain
• Overlap Correlation
• Scalloping Loos
• Worst Case Processing Loss
• Minimun Resolution Bandwidth

23
Equivalent Noise Bandwith
24
Processing Gain
25
Overlap Correlation
26
Picket fence effect

• The picket fence effect is a manifestation of
  applying DFT over a finite time sequence.
• The net effect of windowing is a smoothed
  frequency response of a sinc at each frequency
  index.

27
Minimun Resolution Bandwidth
28
Time Windowing (II)
The window selection is a trade-off between main
lobe widening, first sidelobe levels, and how
fast the sidelobes decrease with increased
frequency.
29
Goertzel Algorithm
The Goertzel algorithm is a digital signal
processing technique for identifying frequency
components of a signal, published by Dr. Gerald
Goertzel in 1958
If you implement the Goertzel algorithm L times
to detect L different tones, Goertzel is more
efficent than FFT when Llt log2N
30
Goertzel Algorithm Implementation
31
Zoom FFT
32
Zero Stuffing

• Zero stuffing is a way of increasing frequency
  resolution.
• The spectrum visualized corresponds to the
  convolution of a sinusoidal and a rectangular
  signal.
• Thus, the underlying spectrum of the sinusoidal
  is distorted by a sinc.
