Lecture 26 blood flow

1
Lecture 26 blood flow
2
Outline of class

• Visit to Neonatal ICU Dr Jack Dolcourt
• Next Thursday helicopter visit eye clinic
• Blood flow basic definition
• Gold Standard - Ficks Technique
• dye dilution thermal dilution
• Electromagnetic flow meter
• Ultrasound flow meter transit time
• Ultrasound flow meter doppler
• Plethysmography volume, impedance

3
Blood Flow

• Chapter 8 Webster
• Flow Volume / Time
• Typical Cardiac output 5 liters/minute
• Cardiac output of heart is controlled by input
  pressure

4
Ficks Law
Clinical measure uses Douglas bag and measure
oxygen concentration and consumption Integrating
Ficks equation gives bolus equation This is gold
standard and reference for other measures
5
Ficks Method or Ficks Law

• derivations

6
Dye dilution curve
7
EM flow probe theory
V 2a B v /100 (uv) Vvoltage B magnetic flux
density (gauss) aradius in cm v fluid velocity
(cm/sec)
8
Axial flow gives average velocity

• Given normal ranges of B and v, the V is very
  small (in uv)
• Flow in vessel is not uniform so equation must be
  intregrated
• If flow is axial (symmetric) around axis and the
  flow is laminar then v is the average flow. Which
  is what is desired

9
EM Flow probes various designs
10
EM flow probes
11
Catheter type Electromagnetic Flow Probe
12
System block diagram of EM Flow Meter
13
EM Flow source of errorflow patterns

• Flow has circulating currents
• Voltage is highly dependent on hematocrit
• Thickness and conductivity of vessel changes
  sensitivity
• Fit of probe and serous fluid short out signal
• Excitation methods errors due to induced voltages
  from changing magnetic fields

14
Sources of ErrorVessel walls
15
EM Flow meter stimulation waveforms
16
Ultrasound methods to measure flow

• Pulse transit method measure time it takes for
  pulse to transverse vessel and go back
• Doppler method change in reflected frequency
  due to movement of blood cells

17
Ultrasound pulse transit time equations
18
Transit time

• Assuming fluid velocity ltlt speed of sound
• T 2 D v cos theta / c 2
• Note that v is proportional to T
• Note, T is very small and hard to measure
  electronically

19
Doppler - fundamentals
20
Doppler - equations
21
Doppler Equations
22
Doppler Flow spectrum
23
Ultrasound system block diagram
24
Doppler comments

• Difference in frequency means velocity
• Larger difference means larger velocity
• Types of doppler
• Continuous wave
• Pulse
• Pulse range gate
• Quadrature analysis
• FFT methods
• Digital filtering methods

25
Limb volume changes flow
26
Impedance plethysmography

• 4 band method
• Measures breathing rates
• Possible 2D graphics
