1 Myology 1 (HS 113) Lecture 5 Bony Anatomy of the Vertebral Column 2 Gross Anatomy Osteology of the Spine 3 Spinal Anatomy
Spine is made up of 24 small bones (vertebrae) that are stacked on top of each other to create the spinal column.
Between each vertebra is a soft gel-like intervertebral disc that helps absorb pressure and keeps the bones from rubbing against each other.
Each vertebra is held to the others by groups of ligaments (connect bones to bones)
Tendons connect muscles to bones. There are also tendons that fasten muscles to the vertebrae.
The spinal column also has real joints (just like the knee or elbow or any other joints) called facet joints. The facet joints link the vertebrae together and give them the flexibility to move against each other.
The spine itself has three main segments
The cervical is the upper part of the spine made up of seven vertebrae.
The thoracic is the center portion of the spine consisting of 12 vertebrae.
The lower portion of the spine is called the lumbar spine consisting of five vertebrae.
5 (No Transcript) 6 Intervertebral Discs
Between adjacent vertebrae absorbs vertical shock
Permit various movements of the vertebral column
Fibrocartilagenous ring (Annulus fibrosis) with a pulpy center (Nucleus pulposus)
7 Normal Curves of the Vertebral Column
Curves in vertebral column function to
Maintain balance in the upright position
Absorb shock during walking and running
Protect spinal column from fracture
Thoracic and sacral are formed during fetal development
Cervical is formed when infant raises head at 4 months
Lumbar forms when infant sits up begins to walk at 1 year
8 (No Transcript) 9 Anatomy of a typical vertebrae
Large round portion of bone
Superior and inferior surfaces are roughened for attachment of intervertebral disc.
Neural Arch attached to the vertebral body consists of several parts
Pedicle two thick processes which project posteriorly from the body uniting with the laminae.
Vertebral notches upper and lower indentations on the pedical
Intervertebral Foramen Opening formed between adjacent vertebrae (when stacked) for the exiting of a single spinal nerve.
Laminae flat pieces of bone forming the posterior portion of the vertebral arch
Vertebral Foramen space between the vertebral arch and body containing the spinal cord adipose and areolar connective tissue
Vertebral (Spinal) Canal formed by all vertebral foramina of all vertebrae together.
Processes a total of 7 processes
Transverse process (2) extends laterally from the lamina pedicle junction functions for muscle attachment
Spinous process (1) extends posteriorly from the junction of the lamina functions for muscle attachment
Superior articulating process (2) articular processes that form joints with the vertebrae above
Inferior articulating process (2) articular processes that form joints with the vertebrae below
Facet the articulating surface of the articular process.
11 (No Transcript) 12 Cervical Spine
The cervical spine is made up of the first seven vertebrae in the spine.
It starts just below the skull and ends just above the thoracic spine.
The cervical spine has a lordotic curve (a backward C-shape)
The cervical spine is much more mobile than both of the other spinal regions.
Unlike the rest of the spine there are special openings in each transverse process in the vertebra in the cervical spine for the arteries supplying the brain.
All of the cervical vertebrae with the exception of C1 and C7 have a bifid spinous process.
Atypical Vertebrae C1 C2 and C7
Two vertebrae in the cervical spine the atlas and the axis differ from the other vertebrae because they are designed specifically for rotation. The 7th cervical vertebrae differs as it is marked by its large spinous process.
First cervical vertebra (Atlas)
Sits between the skull and the rest of spine.
Arches atlas does not have a vertebral body but does have a thick forward (anterior) arch and a thin back (posterior) arch.
Spinous process atlas has no spinous process
Lateral masses in place of a vertebral body the atlas has two lateral masses which support the skull.
Superior articular facets located on superior aspect of the facet articulating with the occipital condyles. This joint allows for movement as in nodding the head yes
Second cervical vertebra (Axis)
Odontoid process bony projection projecting upward from the body through the front of the ring of the atlas.
Allows rotation to the left and right
7th Cervical vertebra (Vertebra prominens)
C7 has a large non-bifid spinous process
15 Atlas and Axis 16 C3 through C6 Vertebrae
The remaining vertebrae (C3-C7) have the features of a more typical vertebrae (bodies spinous processes transverse processes lamina and pedicles).
17 (No Transcript) 18 Thoracic Spine
The thoracic spine is made up of the middle 12 vertebra of the spine.
These vertebrae connect to the ribs and form part of the back wall of the thorax (the ribcage area between the neck and the diaphragm).
The thoracic spine has very narrow thin intervertebral discs so there is much less movement allowed between vertebrae than in the lumbar or cervical parts of the spine.
The thoracic spines curve is called kyphotic because of its shape which is a regular C-shaped curve with the opening of the C in the front.
Larger and stronger bodies than in the cervical spine
Longer transverse spinous processes
Spinous processes are directed more inferior so that they overlap
Facets or demifacets on body articulating surfaces for the articulation with the head of rib
Facet full indentation on the body of the thoracic vertebrae
Demifacet half facet on the body of a thoracic vertebrae
Facets on transverse processes (T1-T10) for articulation with the tubercle of rib
20 (No Transcript) 21 (No Transcript) 22 Lumbar Spine
The lowest part of the spine
This area has five vertebrae.
Strongest largest vertebrae
Short thick spinous transverse processes
Serves as attachment points for back musculature
23 (No Transcript) 24 Sacrum
Triangular bone which curves anteriorly formed by the union of five sacral vertebrae serving as a foundation for the pelvic girdle
Sacral foramen Anterior and posterior sacral foramen allow passage of the sacral nerves
Sacral Ala (Wings) upper lateral portion of the sacrum formed by the fusion of transverse processes.
Median sacral crest posterior ridge formed by the fusion of sacral spinous processes
Sacral canal continuation of the vertebral canal. Ends as the sacral hiatus which is an opening for the last spinal nerve.
Articular surface on both lateral surfaces for articulation with the ilium of the pelvis.
In the female the sacrum is shorter wider and more curved between S2-S3
Also a triangular bone form by the fusion of four coccygeal vertebrae.
In the female the coccyx points inferiorly while in the male is points more anteriorly.
26 (No Transcript) 27 Palpation of the Spine Spinous process of the vertebrae (general) Seated have your partner flex their head and trunk slightly. Place your fingers along the centerline of the back and locate the long line of processes.your fingers slowly up and down the spine noting the different sizes prominences and spaces between the process a. Cervical spinous processes Supine locate the EOP and thenyour fingers inferior onto the neck. The first palpable spinous process will be C2 (recall C1 has a posterior tubercle). Continue palpating inferiorly gently until you reach the C7 spinous (the most prominent of the cervical spinous processes). Verify C7 by flexing your partners neck C7 will move superiorly while T1 will remain fixed. Inferior angle and T7 Prone locate the inferior angle of the scapulayour finger medially to the vertebral column. The spinous of T7 is in line with the inferior angle. Superior angle and T2 Prone locate the superior angle of the scapula your finger medially to the vertebral column. The spinous of T2 is in line with the superior angle. 28 Top of iliac crest and L4 Prone using the knife edge portion of your hand place your hands on the tops of the iliac crests. Then your thumbs medially meeting at the spine the spinous process of L4 can be felt as a large knob. Twelfth rib and T12 Prone locate the lowest rib (12th) and palpate the shaft of the rib back to the spinal column. The 12th rib may be lost as it passes under the large erector spinae musculature. Transverse processes of cervical vertebrae Supine place your fingers on the side of the neck below the ear lobes. Using the flat thumbpadsanteriorly and posteriorly to feel the ridge of the transverse processes. Note the tips of the individual TPs are not usually palpable as the pass anterior and inferior. Thoracic transverse process Prone locate a portion of the thoracic spinous processes. Move about 1 laterally and palpate through the thick erector spinae group for the knobby shaped transverse processes. Lumbar transverse processes Prone locate the lumbar spinous processes andabout 2 laterally. Slowly sink your fingers through the thick erector spinae muscle directing your pressure at a medial angle. Because of the thick muscle the individual process may not be palpable try to sense the solid ridge they form. 29
Cervical laminar groove Supine support the head with one hand and locate the cervical transverse process with the other hand. posteriorly off the transverse processes palpating the space between the transverse and the spinous processes which is the laminar groove.
Thoracic and lumbar laminar groove Prone locate the spinous processes of the thoracic vertebrae. With the other hand locate the transverse processes of the thoracic vertebrae. Using firm pressure palpate the area between these two landmarks. Work your way down the laminar groove to the lumbar spine. Note the thick muscle of the transversospinalis group.
Sternum Supine place your fingers on the center of the chest. Thensuperiorly toward the jugular notch at the top. Then move your fingers slightly lateral and palpate the sternoclavicular joints (confirm by having your partner move their upper extremity). Return to the sternum and palpate inferiorly onto the manubrium and body. Finallyyour fingers down onto the xiphoid process feeling the tip between the costal cartilages.
Ribs Supinelaterally from the sternum onto the costal cartilages. Roll off the cartilage into the spaces between. Follow the costal cartilages laterally on to the ribs.
