Magnum Force System for Spray Painting

1

• Magnum Force System for Spray Painting

2

• Five major areas of concern with paint jobs

• Vehicle preparation
• The people
• The compressed air system
• The paint booth
• The paint itself

3

• Lint and dust float for days and always end up a
  problem in finishing.

4

• Wipes break down and leave fibers behind.
• Feather dusters breakdown and add unwanted
  particulate
• to finishes.

5
Cotton mops can be another source of
trouble.Sponge mop should be used.
6
Static voltage on primer/plastic filler causes
uneven coating in Electrostatic Painting.
7
Dust in the air can be chargedby static
electricity.The dust will be attracted to the
part being painted.
8
THE SOLUTION . . .
9
SIMCO Magnum Force System
10
SIMCO Magnum Force is an electrical Air Knife
System.It provides deep penetration with high
velocity ionized air.
11
Option 1 is blow-off only. Option 2 is blow-off
with ionized air.
12

Option 1 is blow-off only. Option 2 is blow-off
with ionized air.
13
Air and Ionizing Nozzles
Ionizing Air Knives
Complete System
14
Magnum Force can help to

• Remove lint and dust
• Remove static for even finish
• Remove moisture
• Reduce manpower

15
If you are using compressed air jets/ knife

• Magnum Force will reduce 30 to 70 of operating
  cost

16
Magnum Force System fast payback when compared
with Compressed Air System
17
Major benefits

• Less rework
• Better finish
• Higher output rate

18
Custom design Magnum Force Systems for
different sizes of substrate cleaning
19
(No Transcript)
20
Customer References
21
References for parts cleaning
22
