Financial Time Series

• Dave Elliman

2
For Example Tesco
3
What can we deduce

• The price declined from May to August and then
  recovered?
• The volume tends to be higher when price changes
  are faster?
• Tesco will go up a lot further?
• Tesco is very volatile?

4
What can we know?

• Things in the past
• The future is unknown. If you know how to
  predict the future please see me afterwards
• The average returns in the past have been µ per
  year. Call this the expected return but over
  what period?
• The price jumps about a lot, recently the
  standard deviation has been s. over what
  period?

5
What Finance Theory Assumes

• That returns have a mean level (the expected
  return) and if that is removed, what is left are
  random fluctuations drawn from a normal
  distribution.
• The standard deviation of the random variation is
  reasonably stable in time.
• In other words
• Trend return discount rate risk
• You cant predict the price tomorrow from
  historic information
• The future looks a lot like the past

6
Is any of this true?

• In stable periods to a first approximation it
  seems close
• The distribution is not normal (see todays
  worksheet)
• The volatility is not stable with time but occurs
  in bursts
• The future is not like the past at the moment!
• Dont expect figures from the real world to fit
  financial formulae too closely!

7
Predicting the future

• déjà vu Advice to a young boy
• Good guess Advice toTerri
• Astrology?
• Tea leaves?
• Augering? (flight of birds)
• Gipsy Rose Lee
• Technical analysis or Chartism

8
Tasseographers, astrologers?
9
The art of Tasseography (reading tea-leaves)
This means I am overdue for some happiness with
a woman.
I am about to make a fortune by means of
foresight about going downwards as a result of my
knowledge and learning. However there are some
obstacles ahead.
10
The art or science of Technical Analysis
11
Technical Analysis
http//www.investopedia.com/university/technical/t
echanalysis8.asp
Any truth in this?
12
Are there patterns in the stock market?
13
The Head and Shoulders
14
The Cup and Handle
15
The Double Bottom
16
Is this a head and Shoulders Pattern?
17
Is this a Double Bottom?
18
Pareidolia I
A face in the snow?
19
Pareidolia II
A face in the clouds?
20
Human psychological traitsApophenia
Confabulation

• Apophenia Seeing signs and symbols
• charged with significance in random or
• meaningless data.

eg The DaVinci Code!
Confabulation A plausible but imagined memory or
explanation that fills in gaps in what is
understood and remembered
21
Confabulation?

• The FTSE 100 closed above the psychologically
  important 5,000 mark, boosted by strong gains on
  Wall Street amid relief that a report showing a
  slowdown in manufacturing growth in May was not
  as grim as some had feared, dealers said.
• London shares were higher in early deals as
  strong gains in drinks giant SABMiller added to
  positive earnings news overnight from US
  bellwether IBM, dealers said.
• Meanwhile, in New York shares ended lower, with
  the Nasdaq and the SP 500 snapping a
  seven-session winning streak, after
  weaker-than-expected earnings from Citigroup
  prompted some investors to cash in on recent
  gains.

22
A Pattern is

• A member for a known set of categories
• A set of relationships between parts
• An emergent property of a system
• A property of a system that allow its description
  to be shortened

23
The FTSE 100 since 84 Again
24
Daily Returns are more convenient
25
The Conventional View

• A Random Walk with normally distributed step size
• For the FTSE 100
• Average 3.54x 10-4
• Standard Deviation 1.028 x 10-2

26
Do the simulated and actual returns look alike?
Could it be that established financial theory is
built on dubious assumptions?
27
Are there Harmonic Components?
28
Is there Momentum
29
The Kalman Filter is a Disappointment
The mean is very close to zero
30
Perhaps the EMH is right? BUT.

• Remember the connection between patterns and
  compression?
• If it is a random walk we would expect about the
  same compressibility

31
Can we compress the series?

• Represent as 1 one for ve return 0 for ve
  (drift removed)
• Compare with random series
• Use Markov arithmetic coder

YES! The real series is somewhat more
compressible lt 1 effect but consistently so over
30 years
These compression algorithms use quite a small
window So this is a short term effect
32
My lossy compression
33
My lossy compression
34
My lossy compression
35
My lossy compression
36
Keep splitting until max error lt T

• Represent a line as (?x, ?y)
• Are there less lines in a real series as opposed
  to a random one?
• Answer Yes! (about 3 to 5 less)
• Can we compress the real series more than a
  random one? (are the values of ?x and ?y less
  random than chance?)
• Answer Yes! (about 8 mode compression possible)

37
We need a Trading Strategy
Any ideas?
38
Sornettes Compression! (S P 500)
Nearly 3 years
39
We could try simulation.
40
The Assumptions are not Realistic

• Traders do not seek to be in the minority
• Traders are seeking profit so we use
• 4 Predictions Top Bottom Up -
  Down
• 3 States Long - Short Cash
• Scale-free influence network
• Influence increases with Volatility

41
But the Complexity of this new model is a big
disadvantage.
Octave Levenspiel says Give me four parameters
and I will model and elephant.
42
Can we synchronise our model to real market data?
Yes! It works some of the time.
43
The model predicts direction, and is more often
right than wrong
Take the best 10 of days and the model gives
odds of 5545 in your favour
44
The model is only a first prototype

• Others build a set of models and choose the best
• The feedback mechanism needs to be much improved.
  We are working on using an Ensemble Kalman Filter
  to achieve this
• It may be useful to add a market-maker to give
  greater liquidity.

45
Conclusions

• Markets sometime have a (perhaps small)
  deterministic component
• Our model seems to capture some part of the
  internal market state
• Prices move fastest when there is evidence of
  herding
• There are many ways in which our model could be
  improved

46
Can market be predicted?
What would happen if a successful pattern were
found?
47
What If a successful model was adopted?

• The odds would be changed in favour of those who
  used it
• The market would change and models would have to
  take account of the model and so on forever
• An arms race!

48
People see patterns everywhere But

• What would happen if such patterns were
  predictive and a significant volume of trading
  followed them?

49
The AutoCorrelation Function
Is a time series correlated with itself over some
time lag? Are there seasonal effects? Is the
advice Sell in May and go away! correct? Do
equities tend to rise on a Tuesday? You should
pick up a small ex-dividend effect What is the
autocorrelation function of a random walk?
50
Things to try

• Is there any periodicity? Try an auto-correlation
• Is there any dependence with a time lag?
  Cross-correlation
• SOX (Philadelphia) ? ARM.L made me some money!

51
Autocorrelation Function for White Noise
52
Calculating the Autocorrelation Function

• You can put the formula into Maple directly, but
  there is a faster way.
• The autocorrelation function is the same as the
  Fourier Transform of the Power Specrum. This may
  be worthwhile if the calculation is slow.

53
Any Questions?
