Cleaning and Shaping of the Root Canal System

1
Cleaning and Shaping of the Root Canal System

• Edit by Hou Tiezhou
• 02988088507

2
Objectives of Canal Preparation

• Start with the end in mind

3
Objectives of root canal preparation

• The root canal system must be
• Cleaned of its organic remnants
• Shaped to receive a three dimensional filling of
  the entire root canal space

4
Objectives of root canal preparation

• The canal is
• Cleansed primarily by irrigation
• Shaped primarily by instrumentation

5
Hence cleansing and shaping
6
Cleansing of the root canal

• Objectives
• Removal of organic debris
• Elimination of bacteria

7
Irrigation

• An ideal irrigant
• Is nontoxic
• Dissolves vital and necrotic tissue
• Is bactericidal
• Lubricates the canal
• Removes the smear layer

8
Sodium hypochlorite

• Dissolves vital and necrotic tissue
• Is bactericidal
• Lubricates the canal

9
Sodium Hypochlorite
Cannot be considered non-toxic!!!
10
Prolube
EDTA and carbamide peroxide in a water soluble
base
11
Prolube

• Facilitates placement of file
• Entraps debris
• Aids in removal of the smear layer

12
EDTA

• Chelating agent
• Effectively removes smear layer

13
Shaping of the root canal

• Canal shape produced by instrumentation
• Objective is a smooth tapered preparation

14
Shaping of the root canal
15
Instruments

• Instruments differ according to
• Metal
• Taper
• Tip design
• Cross sectional geometry
• Length of cutting blades
• Sizing

16
Metals

• Nickel titanium Stainless steel
• Excellen flexibility Less flexible
• Conforms to canal Straightens and
• curvature transports canal
• Plastic deformation Permanent deformation

17
Metals
Stainless steel files demonstrate permanent
deformation
18
Metals
Nickel titanium files demonstrate plastic
deformation
19
Taper

• Definition
• Increase in diameter per unit length

20
What is Taper?
D16
D1
0.96 mm diameter increase
21
What is taper?
22
Taper

• Taper of instruments in U of M file kit
• Stainless steel files 0.02 taper
• OS variable tapers ranging from 0.05 to 0.08
• Series 29 rotary Profiles 0.06 taper
• NiTi hand files 0.04 taper

23
Tip Design

• Non-cutting tip
• Bullet nose (60 degree) tip
• Smooth transition angle where tip meets flat
  radial lands

24
Tip Design

• Designed to follow a pilot hole
• Guides instrument through canal during preparation

25
Tip Design
26
Cross-sectional geometry

• Three radial lands
• Each contains bidirectional cutting edges
• Keep instrument centered in the canal
• Cutting edges scrape dentin

27
Cross sectional geometry
28
Cross sectional geometry
29
Cross sectional geometry

• Radial lands separated by three u-shaped flutes
• Provide space for accumulation of debris
• Moves debris out of canal

30
Length of cutting blade

• Traditionally 16 mm
• Orifice shapers 10 mm

31
Sizing of instruments

• ISO sizes
• Number refers to tip diameter in tenths of mm
• The tip diameter increases by 0.05 mm from sizes
  10 to 60, then by 0.10 mm

32
Sizing of instruments

• increase in diameter from 10 to 15 file is
  50
• Difference between 55 and 60 is only 9

33
Sizing of instruments

• Series 29
• Progressive 29 increase in tip diameter
• Instruments are better spaced
• More instruments in smaller sizes and fewer large
  instruments

34
Crown Down Technique

• The coronal portion is prepared before the apical
  portion
• Follows medical principle of cleansing before
  probing a wound

35
Crown Down Technique
36
Crown Down Technique

• Eliminates constrictions in the coronal region
• Reduces effect of canal curvature
• Improves tactile awareness during apical
  preparation

37
Crown Down Technique

• Allows more effective irrigation
• Removes majority of tissue and microbes before
  apical third is approached
• Reduces change in working length during apical
  preparation

38
Crown Down Technique

• Coronal third Orifice shapers
• Middle third 0.06 taper rotary Profiles
• Apical third 0.04 taper hand Profiles

39
Clinical Procedure

• Estimate working length
• Parallel radiograph
• Estimated working length is the distance from the
  reference point to the radiographic apex

40
Parallel Radiograph
41
Clinical Procedure

• Establish straight line access to apical third

42
Clinical Procedure

• Explore canal patency
• Ensure that canal is negotiable to radiographic
  apex
• Small file 10 K-file
• May need to precurve these SS files

43
Clinical Procedure

• Files used in a push/pull or quarter turn pull
  motion
• Never rotate these files through 360 degrees

44
Clinical Procedure
45
Clinical Procedure
46
Clinical Procedure

• Estimate canal size
• Radiographic appearance
• Crown/root morphology
• Standardized tables

47
Estimation of canal size
48
Estimation of canal size
See Table in manual
49
Clinical Procedure

• Actual WL determination
• Preparation should terminate at
• Apical constriction
• 1 mm short of radiographic apex

50
Clinical Technique

• Actual WL determination
• Radiograph
• Apex locator

51
Clinical Procedure
Actual Working Length Determination
52
Clinical Procedure
53
Clinical Procedure

• Apex Locator

54
Clinical Procedure

• Crown down cleaning and shaping of canals

55
Clinical Procedure

• This technique applies only to teeth ranging from
  18 23 mm in length
• Coronal third measurement is WL minus 8 mm
• Middle third measurement is WL minus 4 mm
• Apical third measurement is WL

56
Preparation of the coronal third

• Coronal third measurement is working length minus
  8 mm
• Prepared using Profile orifice shapers

57
Preparation of the coronal third

• Profile orifice shapers
• In sequence larger to smaller

58
Preparation of coronal third

• Measure WL minus 8 mm on largest OS
• Lubricate the canal with Prolube

59
Preparation of coronal third

• Rotate OS at 300 rpm
• Note Orifice shaper should be rotating at 300
  rpm before it is placed in the canal
• Advance the OS in 1 mm increments
• When resistance is encountered retract OS while
  still rotating
• Never force any instrument apically

60
Preparation of the coronal third

• This OS will not extend to WL minus 8 mm
• Irrigate copiously

61
Irrigation
62
Preparation of coronal third

• Move to next smallest OS
• This will extend further than previous
  instrument
• Repeat the steps described for largest OS
• Move to next smallest OS
• Continue this sequence until working length minus
  8 mm is reached

63
Preparation of coronal third

• Return to largest OS
• This will now extend further into the canal than
  it did previously
• Repeat this sequence until this (the largest) OS
  reaches WL minus 8 mm

64
Preparation of the coronal third

• Never force any instrument apically
• Irrigate after every instrument
• Use copious amounts of Prolube

65
Preparation of coronal third
66
Preparation of middle third

• Middle third measurement is WL minus 4 mm
• Prepared using 0.06 taper Series 29 rotary
  Profiles in sequence larger to smaller

67
Preparation of middle third
Prepared with 0.06 Series 29 NiTi rotary Profiles
68
Preparation of middle third

• Measure working length minus 4 mm on the largest
  0.06 taper series 29 rotary file
• Set green rubber stop at that length
• Lubricate the canal with Prolube

69
Preparation of middle third

• Rotate at 300 rpm
• File must be rotating at 300 rpm before it is
  placed in canal
• Advance file in 1 mm increments
• When resistance is encountered retract file while
  still rotating
• Copious irrigation with NaOCl

70
Preparation of middle third
71
Preparation of the apical third

• Prepare to actual working length
• Use 0.04 taper NiTi hand files in sequence
  smaller to larger

72
Preparation of apical third
73
Preparation of apical third

• Measure working length on 15 file
• Set rubber stop at that length
• Lubricate the canal with Prolube

74
Preparation of apical third

• Advance size 15 file to working length
• Rotate file through 360 degrees
• Irrigate copiously with NaOCl after each file

75
Preparation of the apical third

• Advance size 20 file to working length
• Continue through sequence, seating each file to
  working length

76
Preparation of apical third

• The largest file that extends to working length
  is the Master Apical file (MAF)
• For large canals minimum MAF 40 - 50
• For small canals minimum MAF 35 - 40

77
Master Apical File

• Take a radiograph with MAF in place. This
  confirms
• Length
• Placement

78
Mission accomplished

• Smooth tapered preparation
