Engineering of Biological Processes Lecture 2: Biosynthesis

1
Engineering of Biological ProcessesLecture 2
Biosynthesis

• Mark Riley, Associate Professor
• Department of Ag and Biosystems Engineering
• The University of Arizona, Tucson, AZ
• 2007

2
Objectives Lecture 2
Biosynthetic processes (anabolic) Precursors for
structural and functional compounds Case studies
- proteins cholesterol
3
Anabolic processes

• Biosynthesis builds larger molecules from
  smaller ones
• formation of cellular components
• amino acids for proteins
• storage of sugars (glycogen)
• nucleic acids
• lipids and hormones
• cholesterol and vitamins
• growth and mineralization of bone and increase of
  muscle mass.

http//www.doegenomestolife.org/technology/protein
production.shtml
4
Integration of metabolism

• Universal energy currency
• ATP generated by oxidation of fuel molecules
  (glucose, fatty acids, amino acids)
• Biosynthesis vs. degradation
• NADH primary reducing power for degradative
  reactions
• NADPH is the major electron donor in reductive
  biosyntheses
• Biosynthetic and degradative pathways are almost
  always distinct
• Biomolecules are constructed from a small set of
  building blocks (often components of catabolic
  cycles)

5
Is ATP a high energy compound?

• No, it has an intermediate level of energy
  compared with other biological molecules.
• The DG for hydrolysis is intermediate compared to
  that for other reactions.
• The energy released in cleaving ATP is used to
  support reactions that are normally
  thermodynamically unfavorable.

6
Example

• Synthesis of glutamine from glutamate
• Glutamate- NH4 Glutamine
• DG 14.2 kJ/mol not thermodynamically
  favored
• 2 step process
• Glutamate- ATP 5 Phosphoglutamate
  ADP
• 5 Phosphoglutamate NH4 Glutamine Pi
• Overall
• Glutamate- ATP NH4 ADP Glutamine
  Pi
• DG -16.3 kJ/mol

7
Manufacturing biological products

• Cell
• Environment (T, pH, flow, O2)
• Nutrients (sugars, amino acids)
• Control scheme
• nutrient feeding, product removal, cell growth
• Bioseparation train
• Integration plan
• how does this all work?

8
How to stimulate production of desired compounds

• Generate a lot of precursor molecules
• Turn off degradative pathways and / or pathways
  which consume precursor to make other products

9
Hormones - molecular signals that switch
metabolism

• Classic anabolic hormones include
• Growth hormone
• IGF1 and other insulin-like growth factors
• Insulin
• Testosterone
• Estrogen
• Classic catabolic hormones include
• Cortisol
• Glucagon
• Adrenaline and other catecholamines
• Cytokines

10
Amino acids are precursors for many biomolecules

• Building blocks for proteins (of course)
• Purines (adenine, Base A in DNA)
• Pyrimidines (cytosine, Base C in DNA)
• Histamine (potent vasodilator)
• Nicotinamide (NAD)
• The amino acid glycine acetate is used to form
  porphyrins (heme groups, hemoglobin)

11
Formation of AAs

• Non-essential amino acids
• formed by fairly simple reactions
• Essential amino acids
• produced through complex pathways
• humans and most mammals do not have the necessary
  enzymes to produce these

12
Anabolic processes - Biosynthesis
Glucose
Glucose 6-Phosphate
Phosphogluconate
Fructose 6-Phosphate
Fructose 1,6-Bisphosphate
Glyceraldehyde 3-Phosphate
Glyceraldehyde 3-Phosphate
Phosphoenolpyruvate
Acetaldehyde
Pyruvate
Lactate
TCA cycle
Acetyl CoA
Acetate
Ethanol
Citrate
Oxaloacetate
Isocitrate
Malate
a-Ketoglutarate
Fumarate
Succinate
13
(No Transcript)
14
Amino acid biosynthesis is regulated by feedback
inhibition
15
Types of feedback control

• 1) Sequential feedback control

Inhibited by Y
Inhibited by Z
16
Protein production

• Central dogma of biology
• DNA ? RNA ? Protein
• Proteins are composed of 20 base amino acids
  arranged in a specific sequence
• After being produced, proteins must fold properly
  (a-helices, b-sheets) and be post-translationally
  modified (phosphoryl, carboxy, carbohydrates).

17
Steps in protein production

• DNA is transcribed by RNA polymerase generating
  an mRNA sequence
• In prokaryotes, the mRNA requires no further
  processing
• Since prokaryotes lack a nucleus, transcription
  and translation to protein occur in a common
  compartment
• Translation often begins before mRNA synthesis
  has been completed
• In eukaryotes, the mRNA receives a 5 cap, 3
  poly-A tail, and is spliced to remove introns
  from the primary RNA transcript

18
Steps in protein production

• Protein synthesis is performed by the ribosome
  which reads the base sequence of the mRNA
• Ribosomes in bacteria add 20 amino acids / sec.
• Ribosomes are composed of 2/3 RNA and 1/3 protein
  making them really ribozymes
• In general, the synthesis of most protein
  molecules can occur in 20 sec 5 min, although
  multiple ribosomes may act on each mRNA, thus
  speeding production.

19
Steps in protein production

• Proteins must fold into the proper 3-D shape in
  order to be functional.
• Secondary structures
• a-helix, b-sheet, b-turn, random coil
• Folding begins while the protein is being
  synthesized.
• Molecular chaperones help guide the folding of
  many proteins.
• Classified as heat shock proteins (hsp60, hsp70)
• Recognize exposed hydrophobic patches on proteins
  and serve to prevent protein aggregation
  (hydrophobic protein-protein interactions)
• Synthesized at higher rates after cells are
  exposed to elevated temperatures.

20
Steps in protein production

• Incompletely folded proteins are digested and
  degraded
• Ubiquitin-conjugation marks proteins for
  degradation
• Roughly 1/3 of all newly made proteins are marked
  for degradation using quality control processes.
• Some proteins (and their activity) are controlled
  by a regulated rate of destruction
• Mitosis related proteins

21
Abnormally folded proteins

• Proteins that are not properly folded can cause
  disease in humans
• Prion disease
• Creutzfeldt-Jacob disease (CJD)
• Bovine spongiform encephalopathy (BSE- mad cow)
• Alzheimers disease (20 M people)
• Forms amyloid b plaques
• Mis-folded (or un-folded) proteins which are
  remarkably resistant to proteolysis

22
Kinetics of protein folding

• Proteins do not fold by trying all of the
  available possible conformations (takes MUCH too
  long).
• Must be some rational process through which
  proteins fold
• Many small, monomeric proteins show wide
  variation in folding rates, from microseconds to
  seconds.
• What determines the rate of folding?
• chain length ( of amino acids)
• topology (shape and structure formed)
• Proteins with similar shapes (topology) may have
  different amino acid sequences and so have
  different folding rates

23
Kinetics of protein folding

• Consider a protein with 100 AA's (residues).
• If each residue can assume 3 different positions,
  the total number of structures is 3100 5x1047.
• If it takes 10-13 seconds to test each structure,
  the protein would reach its native configuration
  in 1.6x1027 years.

24
Kinetics of protein folding

• 3 state
• unfolded, intermediate (partially folded), folded
• this was the long standing assumption of how
  proteins searched through the possible folded
  states
• the intermediate can consist of microdomains that
  are properly folded
• 2 state
• unfolded, folded
• stable intermediates are not a prerequisite for
  the fast, efficient folding of proteins and may
  in fact be kinetic traps and slow the folding
  process.

25
2 state model
PU PN 1
PN is the fraction of protein in its native state
N PU is the fraction of protein in the unfolded
state U. The folding rate is kf the unfolding
rate is ku.
26
What controls the amount of protein produced?

• The answer depends on what type of protein you
  are trying to produce
• Is it constitutively produced?
• Is it linked to the cell's normal metabolic or
  reproductive properties?
• Have you engineered the microbe to generate the
  protein? If so, what kind of promoter is used
  and how is it induced?

27
Inhibitors of protein synthesis

• Many of the most effective antibiotics work by
  inhibiting protein synthesis in prokaryotic cells
• Tetracycline blocks binding of aminoacyl tRNA
• Streptomycin prevents chain elongation
• Chloramphenicol blocks peptidyl transferase
• Erythromycin blocks translocation of ribosomes
• Cycloheximide - blocks translocation of ribosomes
  (but only in eukaryotes)

28
Biosynthesis of lipids and hormones

• Biological membranes are composed of
• phosphoglycerides
• sphingolipids
• cholesterol

29
Cholesterol is synthesized from acetyl coenzyme A
(acetyl CoA)
Acetate ? mevalonate ? isopentenyl pyrophosphate
? C2 C6 C5 squalene ?
cholesterol C30 C27
Squalene is composed of 6 isoprene (C5) units.
Synthesis of mevalonate is the committed step in
the process. This reaction is the site of
feedback regulation.
30
Cholesterol synthesis

• Cholesterol can be obtained through the diet or
  produced in the liver
• An adult on a low cholesterol diet typical will
  produce 800 mg of cholesterol per day
• Most mammalian cells (except liver) do not
  produce cholesterol, but need to uptake from
  their environment
• The liver is the primary source of cholesterol,
  but some is also made in the intestine

31
Cholesterol uptake

• Triacylglycerols (fat), cholesterol, and other
  lipids obtained from the diet are carried from
  the intestine to adipose tissue and liver by
  large chylomicrons (80-500 nm in size).
• Their density is low (lt 0.94 g/ml) because they
  are rich in triacylglycerols and low in protein
  (lt2).

32
Plasma lipoproteins carry fat and cholesterol
into cells

• Lipoprotein Core lipids Mechanisms of lipid
  delivery
• Chylomicron triacylglycerol hydrolysis by
  lipoprotein lipase
• Very low density
• lipoprotein (VLDL) triacylglycerols hydrolysis
  by lipoprotein lipase
• Intermediate-density receptor-mediated
  endocytosis by
• lipoprotein (IDL) cholesterol esters liver
  and conversion to LDL
• Low-density receptor-mediated endocytosis by
• lipoprotein (LDL) cholesterol esters liver
  and other tissues
• High-density transfer of cholesterol esters to
• lipoprotein (HDL) cholesterol esters IDL and
  LDL

33
High-density lipoprotein (HDL)

• Circulate continuously in plasma
• Contain an enzyme,
• phosphatidyl choline cholesterol acyltransferase
• that converts free cholesterols to cholesterol
  esters
• aids in the transport of cholesterol

34
Low density lipoprotein (LDL)

• The LDL receptor on the cell surface controls the
  uptake of LDL
• The cholesterol content of cells having an active
  LDL pathway is regulated by
• injected and released cholesterol suppresses
  production of new LDL receptors
• the LDL receptor itself is subject to feedback
  regulation

35
Biosynthesis of cholesterol

• Acetoacetyl CoA Acetyl CoA ? mevalonate CoA
• C4 C2 C6
• mevalonate 3 ATP ? isopentyl pyrophosphate
  CO2 Pi 3 ADP
• C6 (C5, contains 2 Pi)
• 3 isopentyl pyrophosphate ? farnesyl
  pyrophosphate
• C5 C15
• 2 farnesyl pyrophosphate ? squalene 4 Pi
• C15 C30
• squalene ? cholesterol 3 CO2
• C30 C27

36
Steroid hormones are derived from cholesterol
Cholesterol (C27)
Pregnenolone (C21)
Progestagens (C21)
Glucocorticoids (C21)
Androgens (C19)
Mineralocorticoids (C21)
Estrogens (C18)
37
(No Transcript)
38
How to stimulate production of hormones

• Generate a lot of cholesterol
• By
• Turning off degradative pathways or pathways
  which consume precursor to make other products

39
HW 1 questions

1. What kind of cell would you use to produce
   androstenedione? Your answer should describe the
   attributes of such a cell (don't just state, "a
   cell that produces andro"). An answer longer
   than 4 sentences is too much.
2. Producing cholesterol is an energy intensive
   process. How much energy (in terms of of ATP
   molecules) is consumed in producing one
   cholesterol molecule from a source of glucose?
