Title: FACS Flow Cytometry Workshop


1
FACS Flow Cytometry Workshop
BIOPOLIS Flow Cytometry Facility
  • Biopolis
  • Singapore
  • 05 June 2007
  • John Daley
  • john_daley_at_dfci.harvard.edu

2
Flow Cytometry and the FACSAria
Singapore 2007
  • Teaching a new dog old tricks

John Daley john_daley_at_dfci.harvard.edu
3
Basics of Flow
(modern day alchemy)
  • Air
  • Fire
  • Water
  • INTELLIGENCE!

4
1977 vs. 2007
  • Air house 12lbs
  • Fire 500mW 488nm Blue laser H20 cooled LARGE
  • Water 1 liter 1xPBS
  • Jet in Air Nozzle (circle of fire)
  • Air self made 70lbs
  • Fire3-7 low power lasers from UV to deep red/
    Air cooled small/
  • Water 10 Liter dual 0.22u filtered PBS
  • Fixed Cuvette Nozzle

5
What hasnt changed
  • Laser stream intersection
  • Cell interrogation via hydrodynamic focusing
  • Droplet formation for sorting
  • Priority for cellular integrity

6
What has changed
  • Standard Multi Laser Excitation
  • Polychromatic Analysis
  • High Throughput 4 way cell sorting
  • Instrument automation routines
  • Expansion of applications
  • Instrument sophistication

7
FACSAria
8
FACSAria
9
Workshop Objectives
  • Share hands on experiences for users and
    operators
  • Highlight major elements of FACSAria
  • Optimize instrument utilization
  • Verify Experimental Set-ups
  • Minimize instrument down time
  • Have fun and learn something

10
The Chi of Flow Cytometry
  • Organization
  • Standardization
  • Observation
  • Implementation
  • Instrument ?

11
Turning a user into an operator ( and vice versa)
  • Fixed Cuvette
  • Ceramic Flow Cell
  • O ring stabilization
  • Clog Control
  • Compensation selection
  • Compensation correction
  • Dynamic Sorting

12
Fixed Cuvette/nozzle tip
  • Keep windows clean
  • Know thy nozzle tip
  • Correct droplet strobe pattern
  • Backup tip with o-ring
  • Proper nozzle reseat techniques
  • Camera clean
  • Static neutralization
  • 70 vs. 100 micron tip

13
Compensation Selection
  • Why Compensate
  • Beads vs. cells
  • Auto compensation
  • gt100 compensation
  • Compensation minimization
  • Exceptions to the rules

14
AGENDA
  • Introduction Instrument Overview
  • 4 Way Sorting
  • SP Analysis on murine bone marrow
  • Ca flux on murine splenocytes
  • Case studies in FACS analysis and sorting
  • Discussion

15
FACSAria StartupProcedures
  • Remove protective Cover
  • Lift up Flow cell access door
  • Turn on Aria and laser
  • Wait for Acquisition dashboard to connect to
    instrument
  • Run instrument start up (do long clean once a
    week for sterilization of lines and plenums)
  • Turn on stream should look like day before
  • Lower flow cell access door
  • Turn on sweet spot
  • Warm up for 5-10 minutes
  • Check sheath fill if necessary
  • Change waste tank with back up tank

16
General Sort Set Up
  • Open Accudrop experiment ( preset experiment or
    new experiment template)
  • Run Accudrop
  • note FSC-A and FSC-H/SS-A and SS-H/and APC-Cy7
    A and APC-CY7-H note position using title
    letter positions adjust area scaling if necessary
  • Adjust flow rate to 2000-2800/sec with setting no
    greater than 3
  • Note location of beads with respect to preset
    regions adjust red laser time window to maximal
    signal. Go below and above, note starting time
    value
  • Set P1 region on FSC-A histogram to include
    entire scatter region, verify that sort mode is
    set to fine tune and press sort button and press
    cancel for waste drawer to open
  • Press optical window button and adjust sort
    timing so that at least 95 of beads fall in left
    sort box on stream camera display
  • Note drop 1 value and place in box on droplet
    stream area settings
  • Unload tube and run facs clean for 1-2 minutes to
    sterilze for next sort

17
FACSAria 4 Way Sorting
  • Verify 4 good side streams deflecting to each
    tube. If not fine adjust tip to get satellite
    merger, clean plates, nozzle tip area, strobe
    area and nozzle tip with ddH20- dry with
    q-tip/kimwipe and q-tip static guard to remove
    residual saline, replace o-ring if leaky. (Drop
    pressure by 10 pounds in emergency and reset drop
    delay and timing windows if outer side streams
    can not deflect far enough out)
  • Run bead test sort if necessary
  • Run mouse spleen spike bead test sort if
    necessary
  • Actual Sort Run freshly PRE-FILTERED sample to
    get adequate distribution profile Set up
    template, remove unnecessary parameters, run auto
    comp if necessary, adjust Area scaling , gate out
    doublets, set non-overlapping sort windows, use
    population hierarchy to confirm appropriate
    subpopulation derivation, put windows in sort box
    set mode to preset optimal sort settings(0 32 0)
    turn on test streams, verify stable and well
    separated, turn off test streams, adjust flow
    rate to 1, press sort and listen for waste drawer
    to open. Verify drawer open if not certain. Put
    in appropriate tubes (e.g. eppendorf, or 5ml
    culture tubes)
  • Once sorting begins verify side streams on camera
    , temperature set to desired value, sample
    agitation on, adjust droplet charging if
    necessary to get tightest center stream,monitor
    gap value for stability, increase flow rate
    gradually by 1-2 unit increments to desired flow
    rate, note flow rate versus coincidence rate,
    adjust to get maximal yield with minimal
    coincidence adjust window extension width lower
    to get less electronic aborts . Ideal rates for
    purity and sorting and reasonable coincidence
    19-23K/sec
  • Note ratio of each 4 side streams , (70u tip with
    above sort precision sorts at a volume of 1
    million per ml), remove most frequent population
    when tube is about 85 full , do while sort is
    going lift flow nozzle access door to stop
    streams temporarily. Replace tube as quickly as
    possible, lower door and resume sorting
  • Monitor drop stability, sample volume and side
    streams. Adjust sort gating regions if necessary.
    Listen for spark gap arcing within deflection
    plate area, as well as center stream drift
    outside waste catcher
  • Monitor flow rate, if drops down up rate to 11
    and back down to 4-5 see if rate is restored, if
    not unload sample, PRINT SORT REPORT, revortex
    sample, look for clumps, filter if necessary and
    reload sample with flow rate of 1. Reactivate
    sort and increase flow rate gradually back to
    previous flow rate.
  • Run sample till no volume left, print sort
    report, rinse lines, and reanalyze sorted
    fractions if desired (recommended)

18
4 way Bead sort to check Instrument Accuracy
Protocol
  • Beads needed
  • 1 Accudrop cat345249
  • 2 Calbrite APC cat 340487
  • 3 Sphero Rainbow Fluorescent particles
    3.0-3.4um(mid range FL1) cat 556298
  • 4   "           "                "
    "            "          ( brighter?)     cat
    556291
  •
  •
  • First click on new experiment icon and used
    default pmt setting 250, 300, 500,etc.....
  • and made single graphs of all pmts  log  except
    FALS and two parameter of Hoechst blue vs. APC
    Cy7
  •
  • Second Add a few drops of each bead to separate
    tube add 1xpbs(200ul)    and run/
    record 5,000-10,000events
  •
  • Third     Adjust  APC Cy7 down to 385 volts when
    run Accudrop  to get beads on scale. Use
    Biexponential display option
  •
  • Four mix beads together one at a time and run
    and gate on where peak showed up on apccy7 vs.
    hoechst blue histogram (that way can see where
    each bead  size scattered  based on color gating)
  •
  • Fifth mixed all beads together and create
    four  distinct sort regions on  APC-CY7 vs.
    Hoechst Blue graph and did a four way sort for
    about 4 minutes sorted about 1.2 million.  Use
    custom sort precision settings which is  0 32 0
    (VERY VERY IMPORTANT!) I did not have them very
    concentrated and sorted at 11 flow rate (bad for
    core stream)
  •  reanalyze each fraction with a pbs wash between
    each tube.

19
Simple Four Way bead Sort
20
4 way bead sort Spiked with Fixed Murine Spleen
cells
21
Murine Hematopoietic Stem Cell/Progenitor Sort
22
SP Analysis and Sorting
  • Create SP experiment template Hoechst
    blue/Hoechst red/PI/FA/FSC/and SSC with
    appropriate single and two parameter histograms
    including all Area and H parameters. FSC and SSC
    width parameters also selected. If phenotyping is
    desired, select appropriate fluorescent
    parameters. Check that 450 and 670 filters are in
    Trigon and 635lp dichroic filter is in slot. (
    Initially)Make sure signal processing is going to
    correct pmt, test by removing filter and noting
    signal response.
  • Run UV bead standard, verify median fluorescence
    intensity and CV value from previous bead
    standard run and preset region window values,
    check UV laser dealy time window verify optimal
    timing by going up and down from preset value by
    2-4 units. Note starting time window value prior
    to changing. Adjust if necessary.
  • Recheck Sort delay with Accudrop and do a test
    sort with Accudrop and uv bead mix to verify UV
    channel is being delayed correctly ( usually not
    necessary). Make sure all systems are ice cold.(
    sample station and collection holder)
  • Run SP controls and sample . Adjust Scatter and
    Fluorescent PMT voltages so that scatters are on
    scale and controls are set to appropriate scale
    location. Use log Ho blue and red to see overall
    DNA cell cycle distributions, check UV timing
    window and see if increased signal can be
    observed by increasing window timing slightly, if
    not return to original setting. Gate on PI
    negative population and do a drill down to a HO
    blue (y Axis) vs. HO red (Y axis) profile .
    Switch HO BLUE to Linear and adjust voltage so
    that G0/G1 peak is at channel 100,000 note cell
    cycle profile Increase HO BLUE PMT voltage so
    that G0/G1 linear HO-Blue peak is centered up
    around channel 200,000 and G2/M peak is off
    scale. Adjust HO-Red sample so that its G0/G1
    peak position is also around 200,000 or so. Let
    Stream stabilize at lower flow rate settings(1-2)
    for a minute or two to counter effects of
    initial sample boost., then record at least
    100,000 PI negative gated events. Repeat with
    verapamil or reserpine control samples. Look for
    SP tail or hook below and slightly to left of
    G0/G1 cluster. Better to adjust concentration
    than to raise flow rate value. Aliquot sample in
    multiple small tubes
  • If population is identified set up sort gates for
    sp and non- SP areas and sort. Small eppendorf
    vial collection tubes pre-coated and filled
    30-65 with appropriate media is recommended.
    Remember sorted concentration is approximately
    one million/ml so be sure to not overfill
    collection vessel.
  • Reanalysis of sorted population can be conducted
    if desired. Note however that sorted fractions
    may pump out Hoechst dye while being sorted and
    will also lose dye while being collected in a non
    Hoechst containing media collection vial.
  • Check with investigator about how cells were post
    sort and what results were obtained to aid in
    improving future sorts

23
UV Bead StandardFluoresbrite BB Carboxylate
Microspheres 4.5µmPolysciences
LOG
LINEAR
Hoechst Blue PMT 225 Volts
24
FACSARIA SORPUV LASER
25
Calcium Flux on Murine Splenocytes
  • Check Filters on UV Trigon Indo Violet405nmBP,
    Indo Blue530nmBP with 505LP dichroic
  • Run UV bead standard adjust timing if necessary
  • Set up Calcium flux experiment template. Use FSC
    vs. SSC/SSC vs., Time versus ratio (25,50 and
    75),Indo Blue vs. Indo Violet (LOG vs. LOG),
    relevant Immunofluorescent Histograms and time
    vs. ratio of subpopulations if necessary
  • Check to see that sample station temperature is
    set to Off, 20C, or 37C depending on desired
    temerature. Check to see sample agitation is set
    to 300 rpm
  • Run controls( unstained, indo alone, single
    color, etc) set up compensation, adjust ratio so
    that resting population 25 ratio is at 40,000
    to50,000 value. Use worksheet histogram zoom in
    to zoom in on time versus ratio histogram
  • Actual Flux RUN set stopping time to 30
    seconds, set events to recort to 1million or 2.5
    million, load indo1 loaded sample, after boost
    waitfor 5 seconds or so and press record, after
    record is done, unload sample, LIFT NOZZLE ACCESS
    DOOR, RESET TIME TO 270 SECONDS,ADD
    STIMULI,VORTEX BRIEFLY,LOAD SAMPLE ,, PRESS
    RECORD, PRESS APPEND, COUNT 5 SECONDS, LOWER
    NOZZLE ACCESS DOOR, and continue run.
  • Sit back and relax
  • Transfer files to post analysis program to
    calculate percent responding and relative
    increase in calcium concentration. Use FloJo ,or
    create regions using Diva software and statistics
    export in Excel spreadsheet

26
Ca flux with Indo 1-AM
Useful to study heterogeneity within Defined
subpopulations
  • -Ratio metric Dye Normalizes for cell size
    variability
  • As well as laser power fluctuations over time
  • -Very sensitive to slight shifts within
    populations
  • Ultraviolet excited can be used with many visibly
    excited
  • fluorochromes

27
Calcium Flux
  • Method to get Gap in Time vs. ratio Histogram (
    Lift Cover/reset time stop/append file/close
    cover after 5 seconds)

28
FACSAria UV ApplicationsCalcium Flux Kinetic
Assays
Ionomycin
29
Calcium Flux on T cell subpopulations
FACSAria SORP 20Mw 355nm UV Laser
10ug GAM IgG1
30
Case Studies in FACSAnalysis and Sortingto be
provided by participants
  • Actual samples
  • Virtual samples
  • Viable Cell Cycle with HO33342 on dual stained
    GFP/DsRed cells
  • Treg Various compensation methods
  • Biexponential data displays

31
GFPDsRedHoechst 33342Viable Cell Cycle
32
Fluorescent proteins
33
Multiple Gating strategies help identify low
frequency functional subpopulations
34
Multicolor(5) Minor populations Four way
sorting Treg Story
CD45ra FITC CD127 PE CD25 PE-CY5 CD4 PE-CY7 CD3
PAC BLUE
35
Treg Post Sort Reanalysis
36
POST SORT REANALYSIS HUMAN PBL CD3CD4 CD45RA
CD45RA-
Treg/Teffector/ --
98.4
99.4
97.1
99.9
37
Discussion
  • Instrument Specific
  • Essentials
  • Clog Control
  • Flow Cytometry in General
  • Anything else

THANK YOU!
38
FACSAria Essentials
39
Clog ControlLevel I
  • Lift Cover
  • Open door check for spray
  • Instrument clean-gt Contrad 2 times
  • Turn on stream
  • Door open check for stream
  • Check for strobe droplet recovery
  • Check for red laser intercept spot
  • If none of above go to Level II

40
Clog ControlLevel II
  • Clean table/ organize tools
  • Remove tip/ remove o-ring
  • Remove cam/ dry excess fluid
  • Visual check tip with 10x obj if poss.
  • Ultrasonicate 10 sec minimal ddH20
  • Kim wipe/Vacuum air dry tip/ visual check orifice
  • Reseat o-ring with q-tip and ddH20
  • Place back in nozzle/cam up/ check o-ring
  • Turn stream on/ verify Level I recovery steps
  • Hand adjust nozzle cam to restore droplet pattern

41
Clog ControlLevel III
  • Repeat Level I and II for 2-5 minutes
  • Replace o-ring
  • Repeat Level I and II
  • Remove plates
  • Remove nozzle/ run pure stream
  • Turn off stream/ clean all saline/H20
    rinse/static guard spray/ turn on stream if ok /
    turn off stream/reseat plates/ turn on stream
    apply level I / look for arcing / turn on sweet
    spot/ check test streams/ look for stable strobe
    stream
  • Yell at user for not filtering sample
  • Re filter sample if visually looks particulate
  • Replace nozzle
Write a Comment
User Comments (0)
About PowerShow.com
