CANSAC in Context other fire air quality
activities
Doug Fox fox_at_cira.colostate.edu Al
Riebau ariebau_at_fs.fed.us
2
CANSAC in Context

• FCAMMS Fire Air Quality research activities
• West-wide demonstration of BlueskyRAINS
• Findings Recommendations
• Fires regional impact on air quality
• Emissions, Monitoring Modeling
• Some suggested potential directions for CANSAC

So. Cal. 10/03 MODIS/Aqua- NRL
3
What are FCAMMS?

• National Fire Plan Forest Service RD
• informally coordinated research activities
• Focused on providing real-time, high-resolution
  met simulations for fire smoke application
  tools
• Requiring
• Research capacity building
• Modern computational capabilities
• Improved cooperation with Universities other
  Agencies.

4
Fire physics
MODIS WRF-Chem
BlueSky RAINS
Local Smoke
User driven products
Weather DS tools
5
FCAMMS fire research

• PSW
• Long term forecasting
• CANSAC.
• Eastern
• FireTech
• Haines index.
• Southern
• Fire Weather index
• Storm effects.

• Rocky Mountain
• MODIS fire footprints
• Weather planner
• FARSITE data files.
• PNW
• Lightening potential.

6
FCAMMS air quality research

• Rocky Mountain
• WRF-Chem fire
• Bluesky Westwide.
• PNW
• BlueskyRAINS.
• PSW
• CMAQ fires.

• Eastern
• Bluesky
• CMAQ.
• Southern
• Bluesky GIS
• PB series
• CMAQ.

7
Satellite Observation tools
8
EPA AirNow
Navy Aerosol Analysis and Prediction
Air Quality Forecasting
NOAA ARL
NWS Eastern O3
9
(No Transcript)
10
(No Transcript)
11
BlueSkyRAINS WEST 2005 Fire Season demo

• Fire data
• Wildfire locations fuels from ICS-209 forms
• Emissions from CONSUME/EPM.
• Meteorology modeling
• 36 12 km MM5 west wide, LAPS initialization
• 12 4 km MM5 northwest. NCEP Eta GFS
  initialization
• Smoke Dispersion modeling
• CalPuff
• Display
• RAINS Web based GIS functionality.

12
BlueSkyRAINS WEST 2005 Fire Season demo

• Evaluations
• Ground level smoke concentrations
• Field studies (Gila NF Salmon-Challis NF)
• Usability of BSR outputs
• Telephone (14) Web site survey.
• Findings Recommendations
• Continue regional FCAMMS applications
• Continue research
• Terrain/Met emissions plume rise evaluations
• Improve understanding of potential users needs.

13
Fire influences point observations
Data supplied by VIEWS web services
14
Fires contribution to regional air quality

• RPO fire emissions
• Using monitoring data to apportion fire sources
• UC Riverside WRAP RMC CMAQ modeling
• 2002 with without fire.

15
Regional Planning Organizations
16
Inter-RPO Wildfire EI
Acres Burned Tons PM2.5
4.5 Mil Total 1.1
Mil Total
Note WRAP Inter-RPO acres blackened is less
than WRAP Phase II perimeter acres (5.27
million acres).
17
WRAP emissions of PM 2.5 types of fires
WFU approximately 81,000
18
(No Transcript)
19
Apportioning Fire Methodologies

• OC/EC Edge analysis
• IMPROVE Data suggest an Urban ratio 2-4 and a
  Fire ( SOA) dominated ratio 9 or higher.
• Setting urban 2.3 fire 9 calculating of
  fire OC
• Likely to be upper bound because fire OC includes
  SOA.
• Trajectory mass balance regression (TrMB)
• Obtain fire occurrence data (location, size,
  time)
• Parameterize fires contribution to site OC by
  summing distance weighted trajectory fire grids
  intersections
• Regress OC against the fire surrogate variable
• Calculate Fire OC contribution
• Likely to be lower bound because of limited fire
  occurrence data transport approximations.

20
OC/EC Edge analysis OC/EC ratios
2000
2001
2002

• Maps of annual OC/EC ratios for 2000 2002.
• Maps are scaled the same in all years, black is
  where OC/EC is less than 2.3, red where it is
  greater than 9.

21
TrMB calculations
IMPROVE sites
Fire grids
ATAD Trajectories

• Gridded fire occurrence data serve as surrogates
  for fire emissions
• IMPROVE data provide known receptor aerosol mass
  concentrations
• ATAD back trajectories select fires that impact
  IMPROVE sites
• Blue hatched regions indicate the area swept by
  four daily back trajectories arriving at Gila
  Cliffs National Monument on IMPROVE sampling days
  in August, 2000.

22
Apportioning Fires contribution results (mg/m3)

• Fire Apportioned OC Results
• OC/EC edge analysis (all biogenics)
• West 0.6 East 0.9
• TrMB Regression (wildfires)
• West 0.3 East 0.4
• Current OC from IMPROVE
• West 1.0 East 1.7
• RHR regulationsnatural background
• West 0.3 East 1.0

OCM 1.4OC, avg. organic 70C
23
Modeled annual average natural fire
contributions to extinction for 2002 (WRAP
attribution report, March, 2005)
http//wrapair.org/forums/aoh/ars1/report.html
Modeled annual average anthropogenic fire
contributions to extinction for 2002 (WRAP
attribution report, March, 2005)
http//wrapair.org/forums/aoh/ars1/report.html
24
Pilot Program to DemonstrateMM5/CMAQ Forecasting
System

• Gail Tonnesen, Zion Wang
• College of Engineering
• Center for Environmental Research and Technology
• UC Riverside
• Riverside, CA 92507

25
Fire Forecasting

• Goal demonstrate the feasibility of
• operating an Eulerian air quality model in
  forecast mode
• for predicting the effects of prescribed burning
  on air quality
• Models used
• Meteorology model MM5 v3.6.2
• Emissions model SMOKE
• Air Quality Model CMAQ v.4.4

26
Fire Forecasting Approach

• Five sequential steps in the MM5/CMAQ air quality
  forecasting system
• meteorological modeling (forecast) with MM5
• meteorological preprocessing, MM5gtCMAQ
• emissions processing (meteorological data are
  needed to calculate plume rise)
• producing IC/BC/JPROC
• air quality modeling
• post-processing presentation of simulation
  results

27
Emissions Inventory

• Categories of emissions used
• area sources
• point sources
• mobile sources (on-road non-road)
• fire (agricultural, wild fire, prescribed
  burning)
• road dust
• offshore
• biogenics
• Mexico Emissions Inventory

28
MM5/CMAQ Forecast ResultsOzone
Base Case
Impact from Rx Fire
Base Case Fire
29
MM5/CMAQ Forecast ResultsOzone
Base Case
Impact from Rx Fire
Base Case Fire
30
MM5/CMAQ Forecast ResultsOzone
Base Case
Impact from Rx Fire
Base Case Fire
31
MM5/CMAQ Forecast ResultsOzone
Base Case
Impact from Rx Fire
Base Case Fire
32
MM5/CMAQ Forecast ResultsOzone
Base Case
Impact from Rx Fire
Base Case Fire
33
MM5/CMAQ Ozone Difference
34
MM5/CMAQ Forecast ResultsOrganic Carbon Aerosol
35
MM5/CMAQ Forecast ResultsOrganic Carbon Aerosol
36
MM5/CMAQ Forecast ResultsOrganic Carbon Aerosol
37
MM5/CMAQ Forecast ResultsOrganic Carbon Aerosol
38
MM5/CMAQ Forecast ResultsOrganic Carbon Aerosol
39
MM5/CMAQ Organic Carbon Diff
40
Potential directions for CANSAC

• Bluesky developments
• Ozone impacts model

41
Integrate CANSAC products with PFIRS AQMIS
42
predict Ozone PM2.5 impacts from fire
43
Thank You

• Questions
• Doug Fox
• fox_at_cira.colostate.edu
