Energy in a Cell

1

• Energy in a Cell

2
All Cells Need Energy

• Cells need energy to do a variety of work
• Making new molecules.
• Building membranes and organelles.
• Moving molecules in and out of the cell.
• Movement.

3
Where Does A Cell Get Energy?

• Food is broken down to a form the cell can use.
• Extra energy is stored in an ATP molecule, a
  nucleotide.

4
What Is ATP?

• ATP adenosine triphosphate is a molecule made
  up of an adenine, ribose, and 3 phosphate groups.

Adenine
phosphate groups
Ribose
5
How Does ATP Work?

• Energy is stored in the bond between the second
  and third phosphate group.
• When the bond is broken, energy is released and
  ADP is formed.

Adenine
Ribose
6
ATP Energy Currency

• Within a cell, formation of ATP from ADP and
  phosphate occurs over and over, storing energy
  each time.
• As the cell uses energy, ATP breaks down
  repeatedly to release energy and form ADP and
  phosphate.

7
Making Energy

• Cells make energy in two ways
• Photosynthesis takes place in the chloroplasts.
• Respiration takes place in the mitochondria.

8
Photosynthesis

• Autotrophs make their own food by trapping light
  energy and converting it to chemical energy
  (carbohydrates).

9
Photosynthesis

• Using light from the sun, plants combine water
  and carbon dioxide to make sugar .

• General Equation
• 6CO2 6H2O energy C6H12O6 6O2
• Reactants Products

10
Photosynthesis

• 2 Reactions
• Light Reactions
• Calvin Cycle

11
Photosynthesis

• Light Reactions Light energy is converted to
  chemical energy to split hydrogen from water.
• Takes place in the grana of the chloroplasts (the
  coin-like stacks of sacs).
• Byproducts are oxygen, NADPH, and ATP.

12
Photosynthesis

• Calvin Cycle ATP and NADPH from the light
  reactions are used along with CO2 to form a
  simple sugar (glucose).
• Takes place in the stroma of the chloroplasts
  (the liquid filling).
• Byproducts are C6H12O6 (glucose), ADP, and NADP
  (which return to the light reactions).

13
Sunlight
O2
Photosystem I II
H2O
ATP
NADP ADP
NADPH
CO2
Calvin cycle
Glucose
CHLOROPLAST
14
Chemosynthesis

• Some autotrophs can convert inorganic substances
  to energy.
• Most are adapted to live in conditions where
  there is no oxygen.
• Marshes.
• Lake sediments.
• Digestive tracts of mammals.
• Deep in the ocean.

15
(No Transcript)
16
Respiration

• The process of breaking down food molecules to
  release energy.
• Occurs in the mitochondria.
• Two types
• Aerobic requires oxygen.
• Anaerobic requires an absence of oxygen.

17
Respiration

• Two types of anaerobic respiration
• Fermentation occurs when bacteria break down
  plants (vegetables and fruit) and release alcohol
  or vinegar.
• Lactic Acid Fermentation occurs in muscles a
  buildup of lactic acid causes soreness.

18
Respiration

• Steps
• Glycolysis
• Citric Acid Cycle
• Electron Transport Chain

19
Respiration

• Glycolysis glucose is split to form pyruvate.
• Takes place in the cytoplasm of the cell.
• ATP is a byproduct.

20
Respiration

• Citric Acid Cycle pyruvate is used to build
  citric acid (a carbon compound), which is broken
  down to release ATP.
• Takes place in the cristae (the folded membrane
  in the mitochondrion).
• CO2 is released, and NADH carries hydrogen ions
  to the electron transport chain.

21
Respiration

• Electron Transport Chain hydrogen ions are
  stripped of their energy, and large amounts of
  ATP are formed.
• Takes place in the inner membrane of the
  mitochondrion.
• The used ions are combined with oxygen to form
  H2O.

22
Heat
Electron Transport System
O2
ATP
H2O
NADH
NAD
CO2
citric acid cycle
Glucose
ATP
Pyruvate
MITOCHONDRION
ATP
23
Sunlight
Heat
O2
Photo- System I
Photo- system II
Electron Transport System
ATP
H2O
ATP
NADP ADP
NADPH
NAD
NADH
CO2
Calvin
Citric Acid
Cycle
Cycle
ATP
Glucose
Pyruvate
CHLOROPLAST
MITOCHONDRION
24
Sunlight
Heat
O2
Photo- System I
Photo- system II
Electron Transport System
ATP
H2O
ATP
NADP ADP
NADPH
NAD
NADH
Calvin
CO2
Cycle
Citric Acid
Cycle
ATP
Glucose
CHLOROPLAST
MITOCHONDRION
25
