An Approach for Implementing Efficient Superscalar CISC Processors

1
An Approach for Implementing Efficient
Superscalar CISC Processors
Shiliang Hu, Ilhyun Kim, Mikko Lipasti, James
Smith
Ilhyun Kim
2
Processor Design Challenges

• CISC challenges -- Suboptimal internal micro-ops.

• Complex decoders obsolete features/instructions

• Instruction count expansion 40 to 50 ? mgmt,
  comm
• Redundancy Inefficiency in the cracked
  micro-ops
• Solution Dynamic optimization
• Other current challenges (CISC RISC)
• Efficiency (Nowadays, less performance gain per
  transistor)
• Power consumption has become acute
• Solution Novel efficient microarchitectures

3
Solution Architecture Innovations
Software in Architected ISA OS, Drivers, Lib
code, Apps
Architected ISA e.g. x86

Dynamic Translation
Implementation ISA e.g. fusible ISA
HW Implementation Processors, Mem-sys, I/O
devices

• ISA mapping
• Hardware Simple translation, good for startup
  performance.
• Software Dynamic optimization, good for
  hotspots.

• Can we combine the advantages of both?
• Startup Fast, simple translation
• Steady State Intelligent translation/optimization
  , for hotspots.

4
Microarchitecture Macro-op Execution

• Enhanced OoO superscalar microarchitecture
• Process execute fused macro-ops as single
  Instructions throughout the entire pipeline
• Analogy All lanes ? car-pool on highway ? reduce
  congestion w/ high throughput, AND raise the
  speed limit from 65mph to 80mph.

3-1 ALUs
cache
ports
Fuse
bit
Decode
Wake-
Align
Retire
WB
RF
Select
EXE
MEM
Fetch
Rename
Fuse
up
Dispatch
5
Related Work x86 processors

• AMD K7/K8 microarchitecture
• Macro-Operations
• High performance, efficient pipeline
• Intel Pentium M
• Micro-op fusion.
• Stack manager.
• High performance, low power.
• Transmeta x86 processors
• Co-Designed x86 VM
• VLIW engine code morphing software.

6
Related Work

• Co-designed VM IBM DAISY, BOA
• Full system translator on tree regions VLIW
  engine
• Other research projects e.g. DBT for ILDP
• Macro-op execution
• ILDP, Dynamic Strands, Dataflow Mini-graph, CCG.
• Fill Unit, SCISM, rePLay, PARROT.
• Dynamic Binary Translation / Optimization
• SW based (Often user mode only) UQBT, Dynamo
  (RIO), IA-32 EL. Java and .NET HLL VM runtime
  systems
• HW based Trace cache fill units, rePLay, PARROT,
  etc

7
Co-designed x86 processor architecture
1
2

• Co-designed virtual machine paradigm
• Startup Simple hardware decode/crack for fast
  translation
• Steady State Dynamic software translation/optimiz
  ation for hotspots.

8
Fusible Instruction Set

• RISC-ops with unique features
• A fusible bit per instr. for fusing
• Dense encoding, 16/32-bit ISA
• Special Features to Support x86
• Condition codes
• Addressing modes
• Aware of long immediate values

F
10 b opcode
5b Rds
F
F
10 b opcode
5b Rsrc
F
16 bit opcode
5b Rsrc
5b Rds
10b Immediate / Disp
5b opcode
F
5b opcode
5b Rds
5b Immd
F
5b Rds
5b Rsrc
5b opcode
9
Macro-op Fusing Algorithm

• Objectives
• Maximize fused dependent pairs
• Simple Fast
• Heuristics
• Pipelined Scheduler Only single-cycle ALU ops
  can be a head. Minimize non-fused single-cycle
  ALU ops
• Criticality Fuse instructions that are close
  in the original sequence. ALU-ops criticality is
  easier to estimate.
• Simplicity 2 or less distinct register operands
  per fused pair
• Solution Two-pass Fusing Algorithm
• The 1st pass, forward scan, prioritizes ALU ops,
  i.e. for each ALU-op tail candidate, look
  backward in the scan for its head
• The 2nd pass considers all kinds of RISC-ops as
  tail candidates

10
Fusing Algorithm Example
x86 asm -----------------------------------------
------------------ 1. lea eax, DSedi
01 2. mov DS080b8658, eax 3. movzx ebx,
SSebp ecx ltlt 1 4. and eax, 0000007f 5.
mov edx, DSeax esi ltlt 0 0x7c
RISC-ops ----------------------------------------
------------- 1. ADD Reax, Redi, 1 2. ST
Reax, memR22 3. LD.zx Rebx, memRebp Recx
ltlt 1 4. AND Reax, 0000007f 5. ADD R17, Reax,
Resi 6. LD Redx, memR17 0x7c
After fusing Macro-ops --------------------------
--------------------------- 1. ADD R18, Redi, 1
AND Reax, R18, 007f 2. ST R18,
memR22 3. LD.zx Rebx, memRebp Recx ltlt 1 4.
ADD R17, Reax, Resi LD Rebx, memR170x7c

11
Instruction Fusing Profile

• 55 fused RISC-ops ? increases effective ILP by
  1.4
• Only 6 single-cycle ALU ops left un-fused.

12
Processor Pipeline
Reduced Instr. traffic throughout
Reduced forwarding
Pipelined scheduler

• Macro-op pipeline for efficient hotspot execution
• Execute macro-ops
• Higher IPC, and Higher clock speed potential
• Shorter pipeline front-end

13
Co-designed x86 pipeline frond-end
14
Co-designed x86 pipeline backend
15
Experimental Evaluation

• x86vm Experimental framework for exploring the
  co-designed x86 virtual machine paradigm.
• Proposed co-designed x86 processor A specific
  instantiation of the framework.
• Software components VMM DBT, Code caches, VM
  runtime control and resource management system
  (Extracted some source code from BOCHS 2.2)
• Hardware components Microarchitecture timing
  simulators, Baseline OoO Superscalar, Macro-op
  Execution, etc.
• Benchmarks SPEC2000 integer

16
Performance Evaluation SPEC2000
?
17
Performance Contributors

• Many factors contribute to the IPC performance
  improvement
• Code straightening,
• Macro-op fusing and execution.
• Reduce pipeline front-end (reduce branch penalty)
• Collapsed 3-1 ALUs (resolve branches addresses
  sooner).
• Besides baseline and macro-op models, we model
  three middle configurations
• M0 baseline code cache
• M1 M0 macro-op fusing.
• M2 M1 shorter pipeline front-end. (Macro-op
  mode)
• Macro-op M2 collapsed 3-1 ALUs.

18
Performance Contributors SPEC2000
19
Conclusions

• Architecture Enhancement
• Hardware/Software co-designed paradigm ? enable
  novel designs more desirable system features
• Fuse dependent instruction pairs ? collapse
  dataflow graph to increase ILP
• Complexity Effectiveness
• Pipelined 2-cycle instruction scheduler
• Reduce ALU value forwarding network significantly

• DBT software reduces hardware complexity
• Power Consumption Implication
• Reduced pipeline width
• Reduced Inter-instruction communication and
  instruction management

20
Finale Questions Answers
Suggestions and comments are welcome, Thank you!
21
Outline

• Motivation Introduction
• Processor Microarchtecture Details
• Evaluation Conclusions

22
Performance Simulation Configuration
?
23
Fuse Macro-ops An Illustrative Example
24
Translation Framework
Dynamic binary translation framework 1. Form
hotspot superblock. Crack x86 instructions into
RISC-style micro-ops 2. Perform Cluster Analysis
of embedded long immediate values and assign to
registers if necessary. 3. Generate RISC-ops
(IR form) in the implementation ISA 4.
Construct DDG (Data Dependency Graph) for the
superblock 5. Fusing Algorithm Scan looking for
dependent pairs to be fused. Forward scan,
backward pairing. Two-pass to prioritize ALU ops.
6. Assign registers re-order fused dependent
pairs together, extend live ranges for precise
traps, use consistent state mapping at superblock
exits 7. Code generation to code cache
25
Other DBT Software Profile

• Of all fused macro-ops
• 50 ? ALU-ALU pairs.
• 30 ? fused condition test conditional branch
  pairs.
• Others ? mostly ALU-MEM ops pairs.
• Of all fused macro-ops
• 70 are inter-x86instruction fusion.
• 46 access two distinct source registers,
• only 15 (6 of all instruction entities) write
  two distinct destination registers.
• Translation Overhead Profile
• About 1000 instructions per translated hotspot
  instruction.

26
Dependence Cycle Detection

• All cases are generalized to (c) due to Anti-Scan
  Fusing Heuristic

27
HST back-end profile

• Light-weight opts ProcLongImm, DDG setup, encode
  tens of instrs. each Overhead per x86
  instruction -- initial load from disk.
• Heavy-weight opts uops translation, fusing,
  codegen none dominates

28
Hotspot Coverage vs. runs
29
Hotspot Detected vs. runs
30
Performance Evaluation SPEC2000
?
31
Performance evaluation (WSB2004)
?
32
Performance Contributors (WSB2004)
33
Future Directions

• Co-Designed Virtual Machine Technology
• Confidence More realistic benchmark study
  important for whole workload behavior such as
  hotspot behavior and impact of context switches.
• Enhancement More synergetic, complexity-effective
  HW/SW Co-design techniques.
• Application Specific enabling techniques for
  specific novel computer architectures of the
  future.
• Example co-designed x86 processor design
• Confidence Study as above.
• Enhancement HW µ-Arch ? Reduce register write
  ports. VMM ? More dynamic optimizations
  in HST, e.g. CSE, software stack manager,
  SIMDification.
