Data and Applications Security Developments and
Directions

• Dr. Bhavani Thuraisingham
• The University of Texas at Dallas
• Lecture 5
• Multilevel Secure Database Management Systems
• January 25, 2005

2
Outline

• What is an MLS/DBMS?
• Summary of Developments
• MLS/DBMS Designs and Prototypes
• Directions

3
What is an MLS/DBMS?

• Users are cleared at different security levels
• Data in the database is assigned different
  sensitivity levels--multilevel database
• Users share the multilevel database
• MLS/DBMS is the software that ensures that users
  only obtain information at or below their level
• In general, a user reads at or below his level
  and writes at his level

4
Why MLS/DBMS?

• Operating systems control access to files
  coarser grain of granularity
• Database stores relationships between data
• Content, Context, and Dynamic access control
• Traditional operating systems access control to
  files is not sufficient
• Need multilevel access control for DBMSs

5
Summary of Developments

• Early Efforts 1975 1982 example Hinke-Shafer
  approach
• Air Force Summer Study, 1982
• Research Prototypes (Integrity Lock, SeaView,
  LDV, etc.) 1984 - Present
• Trusted Database Interpretation published 1991
• Commercial Products 1988 - Present

6
Air Force Summer Study

• Air Force convened a summer study to investigate
  MLS/DBMS designs
• Then study was divided into three groups focusing
  on different aspects
• Group 1 investigated the Integrity Lock approach
  Trusted subject approach and Distributed approach
• Group 2 investigated security for military
  messaging systems
• Group 3 focused on longer-term issues such as
  inference and aggregation

7
Outcome of the Air Force Summer Study

• Report published in 1983
• MITRE designed and developed systems based on
  Integrity Lock and Trust subject architectures
  1984 - 1986
• Rome Air Development Center (RADC, now Air Force
  Research Lab) funded efforts to examine long-term
  approaches example SeaView and LDV both
  intended to be A1 systems
• RADC also funded efforts to examine the
  distributed approach
• Several prototypes and products followed

8
TDI

• Trusted Database Interpretation is the
  Interpretation of the Trusted Computer Systems
  Evaluation criteria to evaluate commercial
  products
• Classes C1, C2, B1, B2, B3, A1 and Beyond
• TCB (Trusted Computing Base Subsetting) for MAC,
  DAC, etc. (mandatory access control,
  discretionary access control)
• Companion documents for Inference and
  Aggregation, Auditing, etc.

9
Taxonomy for MLS/DBMSs

• Integrity Lock Architecture Trusted Filter
  Untrusted Back-end, Untrusted Front-end. Checksum
  is computed by the filter based on data content
  and security level. Checksum recomputed when data
  is retrieved.
• Operating Systems Providing Access Control/
  Single Kernel Multilevel data is partitioned
  into single level files. Operating system
  controls access to the filed
• Extended Kernel Kernel extensions for functions
  such as inference and aggregation and constraint
  processing
• Trusted Subject DBMS provides access control to
  its own data such as relations, tuples and
  attributes
• Distributed Data is partitioned according to
  security levels In the partitioned approach,
  data is not replicated and there is one DBMS per
  level. In the replicated approach lower level
  data is replicated at the higher level databases

10
Indignity Lock
11
Operating System Providing Mandatory Access
Control
12
Extended Kernel

13
Trusted Subject
14
Distributed Approach - I
15
Distributed Approach II
16
Overview of MLS/DBMS Designs

• Hinke-Schaefer (SDC Corporation) Introduced
  operating system providing mandatory access
  control
• Integrity Lock Prototypes Two Prototypes
  developed at MITRE using Ingres and Mistress
  relational database systems
• SeaView Funded by Rome Air Development Center
  (RADC) (now Air Force Rome Laboratory) and used
  operating system providing mandatory access
  control and introduced polyinstation
• Lock Data Views (LDV) Extended kernel approach
  developed by Honeywell and funded by RADC and
  investigated inference and aggregation

17
Overview of MLS/DBMS Designs (Concluded)

• ASD, ASD-Views Developed by TRW based on the
  Trusted subject approach. ASD Views provided
  access control on views
• SDDBMS Effort by Unisys funded by RADC and
  investigated the distributed approach
• SINTRA Developed by Naval Research Laboratory
  based on the replicated distributed approach
• SWORD Designed at the Defense Research Agency in
  the UK and there goal was not to have
  polyinstantiation

18
Some MLS/DBMS Commercial Products Developed
(late 1980s, early 1990s)

• Oracle (Trusted ORACLE7 and beyond)
  Hinke-Schafer and Trusted Subject based
  architectures
• Sybase (Secure SQL Server) Trusted subject
• ARC Professional Services Group
  (TRUDATA/SQLSentry) Integrity Lock
• Informix (Informix-On-LineSecure) Trusted
  Subject
• Digital Equipment Corporation (SERdb) (this group
  is now part of Oracle Corp) Trusted Subject
• InfoSystems Technology Inc. (Trusted RUBIX)
  Trusted Subject
• Teradata (DBC/1012) Secure Database Machine
• Ingres (Ingres Intelligent Database) Trusted
  Subject

19
Some Challenges Inference Problem

• Inference is the process of forming conclusions
  from premises
• If the conclusions are unauthorized, it becomes a
  problem
• Inference problem in a multilevel environment
• Aggregation problem is a special case of the
  inference problem - collections of data elements
  is Secret but the individual elements are
  Unclassified
• Association problem attributes A and B taken
  together is Secret - individually they are
  Unclassified

20
Some Challenges Polyinstantiation

• Mechanism to avoid certain signaling channels
• Also supports cover stories
• Example John and James have different salaries
  at different levels

21
Some Challenges Covert Channel

• Database transactions manipulate data locks and
  covertly pass information
• Two transactions T1 and T2 T1 operates at Secret
  level and T2 operates at Unclassified level
• Relation R is classified at Unclassified level
• T1 obtains read lock on R and T2 obtains write
  lock on R
• T1 and T2 can manipulate when they request locks
  and signal one bit information for each attempt
  and over time T1 could covertly send sensitive
  information to T1

22
Status and Directions

• MLS/DBMSs have been designed and developed for
  various kinds of database systems including
  object systems, deductive systems and distributed
  systems
• Provides an approach to host secure applications
• Can use the principles to design privacy
  preserving database systems
• Challenge is to host emerging secure applications
  including e-commerce and biometrics systems
