Title: Mineralogy


1
Mineralogy
  • Carleton College
  • Winter 2003

2
Lattice and its properties
  • Lattice An imaginary 3-D framework, that can be
    referenced to a network of regularly spaced
    points each of which represents the position of a
    motif.

3
Lattice and its properties
  • line lattice
  • plane lattice
  • space lattice
  • unit cell
  • primitive and non-primitive cells

4
Lattice and its properties
  • I can generate a lattice line from a lattice
    point by translating my lattice point with a
    vector (a)

5
Lattice and its properties
  • I can generate a lattice line from a lattice
    point by translating my lattice point with a
    vector (a)

6
Lattice and its properties
  • I can generate a lattice line from a lattice
    point by translating my lattice point with a
    vector (a)

7
Lattice and its properties
  • I can generate a lattice line from a lattice
    point by translating my lattice point with a
    vector (a)

8
Lattice and its properties
  • Plane lattice by introducing another vector b,
    that is not in the same direction as a, I can
    produce a plane lattice

9
Lattice and its properties
  • Space lattice, by introducing another vector c,
    which is not in the same plane as a and b, I can
    generate a space lattice

10
Unit Cell
  • The smallest representative unit of structure
    which when repeated in 3-D gives the whole
    crystal.

11
Structure
  • Nearly all minerals are crystalline solids
    composed of atoms or ions held in an orderly, 3-D
    array by inter atomic forces. Such array of
    atoms are called crystal structure and are
    characterized by periodic duplication of any
    grouping of atoms along any line through the
    structure.
  • In other wards the ordered arrangement of atoms
    or group of atoms within crystalline substance.

12
Unit Cell
  • How to choose a Unit cell from plane lattice?

13
Choice of a Unit Cell
14
Choice of a Unit Cell
  • Look at this pattern, it is produced by simple
    translations.
  • There are several possible choices for the Unit
    Cell.

15
Choice of a Unit Cell
16
Choice of a Unit Cell
17
Choice of a Unit Cell
18
Choice of a Unit Cell
  • A lattice point occurs where the corners of four
    cells meet, and therefore, 1/4 point per corner
    lies in a give cell (1/4 41)

19
Choice of a Unit Cell
  • Unit Cells that include one lattice point, such
    as A, and B are called primitive Cells.
  • Unit Cell C is Non-primitive.

20
Choice of a Unit Cell
  • Many different cells containing a single lattice
    point may be chosen.

21
Choice of a Unit Cell
  • How do you chose the Unit Cell?
  • To keep the translations short
  • To provide as highly specialized a lattice
    geometry as possible
  • To have the cell shape comparable with the shape
    of the crystal

22
Symmetry of a Lattice
  • Lets see what symmetry exist in a lattice for a
    moment and we will come back to Unit Cell

23
Elements of symmetry operations
  • Symmetry operations Movements performed on an
    object such that when completed, the object looks
    the same as when you started.
  • These include

24
Elements of symmetry
  • Translation
  • Reflection
  • Rotation
  • Inversion
  • Roto-inversion
  • Roto-reflection
  • Glide
  • screw axis

25
Elements of symmetry
  • What elements of repetition exist?
  • Translation

26
Elements of symmetry
  • What elements of repetition exist?
  • Reflection/Mirror
  • Mirror plane plane passed through object such
    that the images on opposite sides of the plane
    are mirror images of one another

27
Elements of symmetry
  • What elements of repetition exist?
  • Reflection

28
Elements of symmetry
  • What elements of repetition exist?
  • Rotation
  • Rotation Axis - An axis through the object,
    around which the object is rotated such that the
    original "motif" (or appearance) is repeated a
    specific number of times during 360 degrees

29
Elements of symmetry
  • What elements of repetition exist?
  • Rotation

30
Elements of symmetry
  • What elements of repetition exist?
  • Rotation of 90 degrees will give me..

31
Elements of symmetry
  • What elements of repetition exist?
  • Rotation of 90 degrees will give me..

32
Elements of symmetry
  • What elements of repetition exist?
  • Rotation of 90 degrees will give me..

33
Elements of symmetry
  • What elements of repetition exist?
  • Rotation of 90 degrees will give me..

34
Elements of symmetry
  • What elements of repetition exist?
  • Rotation of 90 degrees will give me..

35
Elements of symmetry
  • What elements of repetition exist?
  • Here is a different unit cell

36
Elements of symmetry
  • What elements of repetition exist?
  • Here is a different unit cell

37
Elements of symmetry
  • What elements of repetition exist?
  • Rotation of 60 degrees gives me another motif

38
Elements of symmetry
  • What elements of repetition exist?
  • Rotation
  • 1 axis 360 degrees
  • 2 axes 180 degrees
  • 3 axes 120 degrees
  • 4 axes 90 degrees
  • 6 axes 60 degrees

39
Elements of symmetry
  • What elements of repetition exist?
  • Inversion

40
Elements of symmetry
  • What elements of repetition exist?
  • Roto-inversion
  • first a rotation, then an inversion of 180 degrees

41
Elements of symmetry
  • What elements of repetition exist?
  • Roto-reflection

42
Elements of symmetry
  • What elements of repetition exist?
  • Glide

43
Elements of symmetry
  • What elements of repetition exist?
  • Glide

44
Elements of symmetry
  • What elements of repetition exist?
  • Glide

45
Elements of symmetry
  • What elements of repetition exist?
  • Glide

46
Elements of symmetry
  • What elements of repetition exist?
  • Glide

47
Elements of symmetry
  • What elements of repetition exist?
  • Glide

48
Elements of symmetry
  • What elements of repetition exist?
  • Glide

49
Elements of symmetry
  • What elements of repetition exist?
  • screw axis
  • This include translation and rotation together

50
Screw Axis
51
Unit Cell
  • Unit Cell parameters
  • a, b, c (sides)
  • a, b, g angles

52
Unit Cell
  • Unit Cell parameters
  • a, b, c sides
  • a, b, g angles

53
Translation Symmetry
  • A translation is simply moving an object in some
    direction (a, b, c) without a rotation. Hence a
    point (x, y, z) is translated to the point (xa,
    yb, zc).

54
Translation Symmetry
  • Crystalline materials have structures with
    translational symmetry. The unit cell of the
    crystal contains the smallest atomic group that
    is needed to define the structure under
    repetition.

55
Translational Nets in 2-D
  • There are five different ways to translate a
    point in two-dimensions. Here is the first
    simple net.

56
Translational Nets in 2-D
  • There are five different ways to translate a
    point in two-dimensions. Here is the second
    simple net.

57
Translational Nets in 2-D
  • There are five different ways to translate a
    point in two-dimensions. Here is the third
    simple net.

58
Translational Nets in 2-D
  • There are five different ways to translate a
    point in two-dimensions. Here is the fourth
    simple net.

59
Translational Nets in 2-D
  • There are five different ways to translate a
    point in two-dimensions. Here is the fifth
    simple net.

60
Translational Nets in 2-D (cont.)
  • The diamond net can also be defined in terms of a
    centered rectangular net with a1 a2 and g
    90degrees.
