Salim Abboud

1
Managing Municipal Wastes The Potential for
Carbon Sinks and Emission Offsets
By Salim Abboud Alberta Research Council, and
Jim Schubert City of Edmonton
2
Presentation Outline

• Municipal waste types
• GHG emissions and/or sinks associated with
  municipal waste processes (Municipal waste life
  cycle)
• The Carbon Cycle (Organic Waste Perspective)
• Waste emissions in relation total emissions
• Edmonton Waste Management Centre
• Wastes handles in Edmonton Types, volumes and
  potential GHG offsets and carbon sinks
• Composting of Organic Wastes
• Conclusions

3
Municipal Wastes

• Liquid Wastes (Wastewater)
• Solid Wastes

4
Wastewater

• Raw sewer and storm water treated through
• Pretreatment
• Primary
• Secondary
• Tertiary
• Sludges from primary and secondary treatment can
  be used to produce CH4 through anaerobic
  digestion
• Final solids are termed Biosolids or sewage sludge

5
Solid Wastes

• Recyclables
• Biosolids
• Municipal Solid Wastes (MSW)
• Residential
• Industrial and commercial (IC)
• Construction and Demolition (CD)

6
Life Cycle Analysis of Wastes
7
The Carbon Cycle (Organic Waste Perspective)
Atmosphere
CH4
CO2
CO2
CO2
CO2
CO2
CO2
CO2
Humus
Energy
CH4
CH4
Waste
Lagoon/Landfill
Anaerobic Digestion
Composting
Incinerator
8
In 1999, the waste sector accounted for nearly 5
of net GHG emissions.
9
In 1999, the waste sector accounted for nearly 4
of net GHG emissions
10
Municipal Wastes

• Edmonton as a an example of what can be done with
  Municipal Wastes, and the
• Edmonton Waste Management Centre

11
EDMONTON WASTE MANAGEMENT CENTRE
Olds
U of A
Other Municipality
ARC
ARC
Olds
Other Research Institutes ?
Researchers
NAIT
Facility
City of Edmonton
Issue/Opportunity Waste Management Research
U of A
NAIT
Other Organization
City of Edmonton
Fed. govt.
NSERC
Prov. govt

NRC
Mun. govt
Industry
Other ?
12
N
EDMONTON WASTE MANAGEMENT CENTRE CLOVER BAR SITE
13
(No Transcript)
14
Municipal Waste Processes Contributing to GHG
Emission Offsets or Carbon Sinks

• Anaerobic digestion of wastewater sludges
• Landfill gas recovery
• Recycling
• Composting
• Combustion

15
Anaerobic Digestion of Wastewater Sludges
16
Edmonton Gold Bar Wastewater Treatment Plant
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
Solid Wastes
21
(No Transcript)
22
Landfill Gas Recovery
23
(No Transcript)
24
Clover Bar Landfill Gas Recovery and Treatment
Plant
25
(No Transcript)
26
Recycling
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
Composting
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Composting

• Composting is the microbiological degradation of
  organic compounds into CO2, H2O and stable
  organic humus forms. Proper management of this
  process requires optimization of the following
• CN ratio of the feedstock
• H2O content of the composting mix
• Aeration
• Microorganisms

37
GHG Savings from Composting

• Avoidance of landfill CH4 emissions
• Carbon sequestration in soil
• Avoidance of chemical fertilisers and other
  chemical plant/soil additives
• Improved soil properties and related plant growth
• Rehabilitation of degraded land and mitigation of
  land degradation

38
Anthropogenic GHG Emissions from Composting

• Machinery
• handling material and turning windrows
• Shredding material
• screening
• transporting and
• applying composted products
• Electricity

39
Other GHG Emissions from Composting

• CO2
• CH4
• Overestimated in Canadian Inventory and in USEPA
  estimates
• recent results show much lower results
• N2O

40
Combustion
41
(No Transcript)
42
Conclusions

• Municipal Wastes have the potential to reduce GHG
  Emissions through
• GHG emission offsets, and
• Carbon Sinks
• The technology needed to achieve the above has
  been demonstrated and is currently optimized

43
Conclusions

• The city of Edmonton has achieved a landfill
  diversion rate of over 70 and if combustion is
  used, the rate rises to 95
• The city of Edmonton has the potential for over
  500000 MTCE of annual offsets and sinks which
  translates to 0.5 to 1.0 T/person/year
