An Integrated Framework for Scenarios and State Machines

1
An Integrated Framework forScenarios and State
Machines
Rance
Cleaveland
Department of Computer Science
University of Maryland, College
Park

• Bikram Sengupta
• IBM Research
• India

2
Outline

• Background
• Motivation
• Triggered Message Sequence Charts (TMSCs)
• Communicating State Machines (CSMs)
• Acceptance Trees
• Combining TMSCs and CSMs
• An Integrated Framework
• Semantics
• Case Study
• Automated Resuscitation and Stabilization System
  (ARSS)
• Conclusions and Future Work

3
Motivation

• Heterogeneous specifications, featuring a mixture
  of high-level requirements and lower-level design
  artifacts, are motivated by several development
  methodologies
• In spiral system development processes,
  requirements elicitation and system design often
  proceed hand-in-hand
• Intermediate stages of refinement-based
  strategies contain a mixture of design elements
  and requirements
• UML supports notations for both requirements
  modeling and operational design
• However, research in the area of heterogeneous
  specifications has remained confined to the more
  theoretical domains of process algebra, temporal
  logic and mu-calculus
• We need to explore how these ideas may be adapted
  to more accessible notations used in practice
• We propose a framework for heterogeneous system
  specifications consisting of a mix of
• Higher-level scenario-based requirements,
  expressed as Triggered Message Sequence Charts
  (TMSCs)
• State-machine-based subsystem designs, given as
  Communicating State Machines (CSMs)

4
Triggered Message Sequence Charts (TMSCs)
Q
P
a
trigger
Conditional Scenario
b
action
terminates
extensible
Partial Scenario
5
Communicating State Machines
A2
A1
6
Acceptance Trees the must pre-order

• P ltmust Q, if Q is more deterministic than P

acceptance set

P1
P2
7
Combining TMSCs and CSMs

• TMSCs and CSMs both specify system behavior in
  terms of sequences of events that may occur
• A scenario shows only one possible interaction
  between instances, and is inherently incomplete
• Conditional and partial TMSC scenarios make the
  behavior even more incomplete
• In CSMs, the individual behavior of each instance
  is generally given over all interactions, hence
  they are more complete
• Any common account of TMSCs and CSMs should
• Be able to express both underspecified as well as
  fully specified behavior in a uniform manner
• Provide operators to weave together multiple
  scenarios and to allow networks of CSMs to be
  formed
• Prescribe when a CSM correctly implements a
  TMSC specification, or, more generally, when one
  heterogeneous specification refines another
• An acceptance tree-based framework will have the
  right ingredients
• Execution-based
• Behavior may be expressed at various levels of
  detail through acceptance sets
• Must-preorder may be used to check the
  relationship between scenarios, state-machines,
  and a mixture of these notations, once they are
  expressed as acceptance trees

8
Example From TMSCs to Acceptance Trees
abc
X
Y
9
A Common Framework

• H M (single TMSC)
• S (single ISM)
• X (variable)
• H H (communicating
  parallel comp)
• H H (interleaving
  parallel comp)
• H H (delayed choice)
• H H (internal
  choice)
• H /\ H (logical AND)
• H H (sequential
  composition)
• recX . H (recursive
  operation)

10
Semantics of Heterogeneous Expressions

• Combine acceptance trees of sub-expressions

• Semantics is compositional
• If P ltmust Q then P op R ltmust Q op R

11
Case Study Automated Resuscitation and
Stabilization System
12
Initial System Requirements
RB M1 M2 RP M3 M4 RD M5 M6
BS RB RP RD
RS BS /\ T1
13
Initial Design
C1
RB M1 M2 ltmust C1
C2
RB ltmust C1, RP ltmust C2, RD ltmust C3
BS RBRPRD ltmust C1C2C3
C3
14
Intermediate Heterogeneous Design
Initial Design ID
C1C2C3 ltmust ID ltmust ID /\ T1
15
Refined Design New Requirement
Refined Design RD
ID ltmust RD HS2 RD /\ T2
16
Final Design
RD /\ T2 ltmust FD
RS BS /\ T1 ltmust C1C2C3 /\ T1
ltmust RD ltmust RD /\ T2 ltmust FD
17
Conclusions

• Requirements and design phases often overlap in
  practice
• Need for a common framework that would allow
  requirements and design notations to
  inter-operate
• We presented a framework for heterogeneous
  specifications involving
• Requirements expressed as TMSCs
• Design elements represented as CSMs
• Semantics is based on acceptance trees
• Precise notion of refinement in terms of the
  must pre-order
• Supports principled evolution of higher-level
  requirements to lower-level operational
  specifications
• Future Work
• Extend framework to cater to other notations
• Synthesize state-machines from TMSC expressions
