Bivariate Regression and Correlation

1
Bivariate Regression and Correlation

• Lecture 5

2
Analytic Tool

• Answer the following
• Suppose that you have a sample of 64 individuals,
  the sample mean is 20, the sample standard
  deviation is 16.
• Can you reject the null hypothesis that the
  sample mean is less than or equal to zero at the
  .05 significance level?
• Can you reject the null hypothesis that the
  sample mean is less than or equal to 18 at the
  .05 significance level?

3
Answer to the Analytic Tool

• Suppose that you have a sample of 64 individuals,
  the sample mean is 20, the sample standard
  deviation is 16.
• The critical value of the t-statistic at the .05
  significance level with 63 degrees of freedom is
  about 1.6.
• To determine whether the sample mean is
  significantly different from zero, we calculate
• t (20 0) / (16 / 8) 20 / 2 10
• Since t gt 1.6, we can reject the null
  hypothesis.
• To determine whether the sample mean is
  significantly different from 18, we calculate
• t (20 18) / (16 / 8) 2 / 2 1
• Since t lt 1, we cannot reject the null
  hypothesis.

4
Agenda

• Today we will begin to learn how to investigate
  the relationship between two continuous
  variables.
• You will learn
• 1) how to graphically present the relationship
  between two variables
• 2) how to measure the correlation between two
  variables

5
Review

• Thus far, we have learned how to conduct three
  general types of hypothesis tests.
• 1) Hypothesis tests concerning the sample mean
  of a continuous random variable.
• e.g. Is the mean income in the U.S. greater
  than 40,000?
• 2) Hypothesis tests concerning the difference in
  the means of two samples of a continuous random
  variable.
• e.g. Is the mean income for men greater than
  the mean income for women?
• 3) Hypothesis tests concerning the independence
  of two categorical variables.
• e.g. Are race and vote choice independent?

6
Introduction

• Suppose that you have two continuous variables
  measured for the same observation over a number
  of samples.
• You would like to whether these two samples are
  related.
• How would you proceed based on what youve been
  taught so far?

7
Possible Methods (based on what weve covered so
far)

• Option 1. Split one of the variables at some
  critical value (say the median). Then test for a
  difference in the means of the samples for the
  second variable above and below the critical
  value.
• e.g. Test whether cities with large percent
  increases in govt expenditures had higher or
  lower percent changes in unemployment than cities
  with small percent changes in govt expenditures.
• Option 2. Divide both categories into smaller
  sets (say quartiles or quintiles). Then perform a
  chi-squared test to see if those categories are
  independent.

8
Graphical Representation of the Data

• One way to analyze relationships between two
  continuous variables is with a scatterplot.
• A scatterplot is a type of diagram that displays
  the covariation of two continuous variables as a
  set of points on a Cartesian coordinate system.

9
Interpretation of the Scatterplot
A Positive Relationship between the two variables
occurs when an increase in the variable
represented on the x-axis corresponds to an
increase in the variable represented on the
y-axis.
A Negative Relationship between the two variables
exists when an increase in the variable
represented on the x-axis corresponds to a
decrease in the variable represented on the
y-axis.
10
Interpretation of the Scatterplot
A curvilinear relationship exists if the effect
of a change in the variable on the x-axis has a
different effect on the variable represented
along the y-axis, depending on the value of x (or
y).
No relationship exists if a change in the
variable represented along the x-axis does not
correspond to a change in the variable along the
y-axis
11
Group Analytic Tool Group

• How would you device a statistic to determine
  whether there was a positive or negative
  relationship?

12
Covariance

• Covariance is a statistical measure of the
  relationship between two samples of two
  variables.
• Cov( X , Y ) ? ( Yi Mean(Y) ) ( Xi
  Mean(X) )
• N 1
• If your relationship is positive, then the
  covariance will be positive large values of X
  will be associated with large values of Y and
  small values of X will be associated with small
  values of Y.
• If your relationship is negative, then the
  covariance will be negative large values of X
  will be associated with small values of Y and
  small values of X will be associated with large
  values of Y.
• If there is no relationship, then the covariance
  is zero large values of X will be associated
  with both large and small values of Y and small
  values of X will be associated with both large
  and small values of Y.

13
Computing the Covariance

• Note that the equation for covariance can be
  defined multiple ways
• The intuitive expression
• Cov( X , Y ) ?( Yi Mean(Y) ) ( Xi
  Mean(X) )
• N 1
• Is equivalent to
• Cov( X , Y ) N ?(Xi Yi) (?Xi )(?Yi)
• (N 1)N
• The second expression may be easier to use for
  calculations in Excel.
• Note It is useful to calculate results yourself
  rather than with Excels canned function
  because (at least with my version), Excel assumes
  that it is estimating the covariance of two
  populations and uses n as a denominator rather
  than n-1.

14
Comments on Covariance

• Covariance is a very good indicator of the
  direction of the relationship between two
  variables.
• Covariance is not a good measure of the
  magnitude of the relationship. This is because
  covariance is sensitive to the scale of the
  variables under investigation.
• Note you can see this if you simply multiply
  both variables by a constant and compare the
  covariances.
• So, it is not proper to compare the covariances
  from two different data sets to see if the
  relationship is stronger in one case than the
  other.
• How would you improve covariance to make your
  findings less sensitive to scale?

15
Correlation

• Correlation is a statistical measure of
  association closely related to covariance.
• The correlation coefficient, denoted RXY or just
  R, is defined as
• RXY ?( Yi Mean(Y) ) ( Xi Mean(X) )
  ?( Xi Mean(X) )2 ?( Yi Mean(Y) )2
• Covariance (X , Y ) Standard
  Deviation(X) Standard Deviation (Y)
• RXY by definition can only take values between -1
  and 1.
• The larger the absolute value of RXY stronger the
  relationship between X and Y. If RXY 1, then X
  and Y are positively related and X is a perfect
  predictor of Y.
• If If RXY -1, then X and Yare negatively
  related and X is a perfect predictor of Y.
• If RXY 0, then X and Y are unrelated.

16
Correlation cont.

• RXY by definition can only take values between -1
  and 1.
• The larger the absolute value of RXY stronger the
  relationship between X and Y. If RXY 1, then X
  and Y are positively related and X is a perfect
  predictor of Y (and Y is a perfect predictor of
  X).
• If RXY -1, then X and Yare negatively related
  and X is a perfect predictor of Y (and Y is a
  perfect predictor of X).
• If RXY 0, then X and Y are unrelated.Overview
• Give the big picture of the subject
• Explain how all the individual topics fit together

17
Comments on Correlation

• The correlation coefficient provides a very
  useful summary of the relationship between X and
  Y.
• But, it takes real effort to use a knowledge of
  the correlation coefficient and the value of X
  (or Y) to make prediction about the value of Y
  (X).
• Additionally, correlation does not imply
  causation.
• e.g. In our original example, do changes in govt
  expenditures cause changes in employment or do
  changes in unemployment cause changes in govt
  expenditures?

18
Getting at Causation

• When we do statistical analyses, we generally
  have to make assumptions about what constitutes a
  cause and what constitutes an effect.
• That is, we make a formal statement about our
  hypothesized relationship like
• Yi f(stuff), where Y is the dependent variable
  and stuff is the set of independent variables.
• If we are clever, we can estimate the effect of
  stuff (and thats what we will be talking about
  for the next few weeks) to test whether it has a
  statistically significant influence on Y.
• If we are really clever, can we test for
  causality as well? How?

19
Getting at Causation cont.

• In order for a variable to be a cause, it is
  necessary (but not sufficient) for the variable
  to occur prior to the effect.
• Possible Research Designs to Examine Causality.
• - For a dependent variable that doesnt change
  much
• Measure a stable set of individual-level
  characteristics (e.g. race, gender, parents value
  for the dependent variable), then examine which
  stable characteristics explain variation in your
  sample.
• - For a dependent variable that does change
• Measure the dependent variable and the
  independent variables at time t, retake the
  measurements for the same sample at time t1,
  then examine whether changes (stability) in the
  independent variables led to changes (stability)
  in the dependent variable. (Note ideally, youd
  show that changes in X occurred before changes in
  Y)
• - For a dependent variable that does change
• Cohort Analysis
