Modelling Prosody for Speech Synthesis: example from Polish

1
Modelling Prosody for Speech Synthesis example
from Polish

• Dominika Oliver
• IGK Colloquium
• 22 July 2004

2
Outline

• Goal
• prosodic modelling for TTS
• Review of past studies
• intonational investigations
• Current state
• latest modelling results

3
TTS Cycle
Text Processing Text Normalisation
names,abbrev.,numbers Linguistic Analysis
morphology,syntax,semantics
Text Input (raw or annotated)
Phonetic Analysis Grapheme-to-Phoneme
Conversion rules, dict.
Prosodic Analysis Pitch, Phrasing Duration
Modelling
Prosodic Analysis Pitch, Phrasing Duration
Modelling
Speech Synthesis Voice Rendering
4
TTS Cycle

• Prosodic analysis/modelling
• Prosodic components (focus, stress, duration
  etc.)
• Prosodic phrasing
• Intonation accent types, pitch contour

5
Overview

• Procedure
• Resources
• Modelling techniques
• Modelling prosody
• Problems solutions
• Suggested improvements

6
Procedure

• Prosodic modelling shopping list
• Language specific intonation description
• Accent type and placement prediction F0
  generation methods
• Research and evaluation tool (Festival)

7
Language specific intonation description

• Quantitative analysis of Polish intonation
  (accent types)
• Standard description of Polish intonation
  (Jassem, 1961, 1984, Demenko, 1999)
• Falling HL, HM, ML, xL
• Rising LM, MH, LH
• Level MM
• Rise-fall LHL
• Broad-Narrow Focus/Peak alignment study (Andreeva
  and Oliver, 2003)

8
Accent types

• Falling

9
Accent types

• Rising

10
Overview

• Procedure
• Resources
• Modelling techniques
• Modelling prosody
• Problems solutions
• Suggested improvements

11
Resources

• Speech corpora PoInt (Polish Intonation
  Database) (Karpinski, 2001)
• 350MB, multi-speaker (40)
• read, (semi)-spontaneous
• Transcribed
• Syllable based IPA segmental
• Syllable based prosodic annotation

12
Resources

• PoInt Prosodic transcription
• Tone heights xH, H, M, L, xL
• Phrase boundary indication

13
Resources

• Falling

14
Resources

• Rising

15
Resources

• Festival TTS (Black Taylor, 1998)
• a general multi-lingual speech synthesis system
• offers a full text to speech system
• environment for development and research of
  speech synthesis techniques

16
Overview

• Procedure
• Resources
• Modelling techniques
• Modelling prosody
• Problems solutions
• Suggested improvements

17
Modelling techniques

• Default prosodic assignment from simple text
  analysis
• Hand-built rule-based system hard to modify and
  adapt to new domains
• Corpus-based approaches (Sproat et al 92)
• Train prosodic variation on large labeled corpora
  using machine learning techniques

18
Modelling techniques accent type/placement
prediction

• Classification and regression trees (CART)
  (Breiman, Friedman, Olshen Stone 1984, 1993)
• In speech synthesis widely used to model
• segment durations (e.g. Riley 1992)
• accent prediction (Syrdal, Hirschberg,McGory,
  Beckman 2001)
• pitch contour generation (Dusterhoff 1997,
  Dusterhoff, Black, Taylor 1999)

19
Modelling techniques - F0 prediction

• Linear regression (Black Hunt, 1996) used e.g.
  for F0 contour prediction/generation
• find the appropriate F0 target per syllable based
  on available features trained from data
• predicted variable (p) can be modelled as a sum
  of a set of weighted real-valued factors
• p w0 w1f1 w1f1 w1f1 wnfn
• factors (fi) - parameterised properties of the
  data
• weights (wi) - trained usually using a stepwise
  least squares technique

20
Prerequisite

• F0 normalisation (Ladd, 1995, Clark, 2003)
• (PoInt 40 speakers, mixed sex)
• -where is f0 mean and is the f0
  standard deviation of the utterance
• -the rescaling uses standard deviation and
  mean f0 of the database

21
Overview

• Procedure
• Resources
• Modelling techniques
• Modelling prosody
• Problems solutions
• Suggested improvements

22
Modelling

• Steps
• Building the utterance structure of the database
  speech files
• Incorporating database intonation labelling
• Extracting features for accent prediction and f0
  generation
• Building CART model
• PoInt intonation labels
• Building LR model
• 3 points per syllable
• Incorporating model parameters into voice
  description

23
Modelling - accent type/placement prediction

• Model based on PoInt
• multiple speaker (male, female)
• Accent inventory (L, H, M)
• Accent prediction method CART
• Features (31)
• POS window
• Position of candidate syllable in word and
  sentence
• Stress information window etc.

24
Results accent prediction

• train set (total 963 correct 897 93.146 )
• test set (total 1070 correct 996 93.084)

25
Modelling - F0 prediction/generation

• F0 generation Linear regression
• Features
• accent type
• POS window
• Position of candidate syllable in word and
  sentence
• Stress information window etc.

26
Results F0 shape prediction
27
Overview

• Procedure
• Resources
• Modelling techniques
• Modelling prosody
• Problems solutions
• Suggested improvements

28
Potential problems

• Data
• not enough tokens to learn from
• Annotation inconsistencies (noisy data, messy
  accent class assignment )
• Inappropriate technique / suboptimal feature set

29
Potential data problems
30
Potential data problems
31
Potential data problems
32
PoInt Analysis

• Peak alignment

33
Addressing data issues

• F0 tracking errors
• Identifying outliers / annotation inconsistencies
• Re-classifying accent types

34
When everything else fails blame it on the data

• Labelling errors
• Unmarked disfluencies/wrong reading
• Phonemic labelling
• Missing phrasing
• No indication of sentence mode in annotation
• Inconsistent labelling
• Misleading transcription description
• No independent labellers

35
Data fixes

• Automatically identifying outliers /annotation
  inconsistencies
• Statistic analysis of acoustic parameters
• Manual data inspection
• Insertion of phrase boundaries
• Marking of disfluencies
• Aligning speech with text
• Deriving Gold Standard (hard)

36
Accent classification studies

• Hierarchical clustering (Klabbers van Santen
  2004)
• Linear regression (Keller Zellner Keller, 2003)
• EM bagging boosting (Sun, 2002)
• HMMs
• (Kumpf, King 2004)
• (Blackburn ,Vonwiller, and King, 1993)
• (Batliner et al 1999, 2001)
• (Maragoudakis 2003, Zervas 2004)
• (Chan, Feng, Heinen, and Niederjohn 1994)

37
Accent type re-classification

• Two stage procedure
• Self-organising maps (Kohonen 1982,1995) (Kaski,
  1997)(Vesanto Alhoniemi, 2000)
• create set of data representative prototype
  vectors
• projection of prototypes onto low dimensional
  space
• Hierarchical agglomerative clustering (HAC)
• method for good candidates for map unit clusters
  cut the dendrogram where there is a large
  distance between two clusters

38
Acoustic data parameterisation

• Accent type classification
• (Demenko, 1999)
• Difference between start F0 (first vowel) and F0
  extreme value (on a vowel or consonant)
• Difference between F0 extreme value and end point
  F0
• Difference between F0 max and F0 min
• Difference between utterance mean F0 and mean F0
  for all utterances by the same voice
• Difference between utterance min F0 and global
  mean min F0 for the same voice

39
Accent type re-classification

• Clusters description

40
Accent type re-classification

• Clusters characteristics

41
Accent type re-classification
42
New results Accent placement prediction

• train data
• test data

43
New results Accent type prediction

• train data
• test data

44
Evaluation

• self-organised maps - potential method for
  categorisation
• the results relatively successful and consistent
• the data pre-processing - most critical phase
• automatic training phase requires solid and
  consistent preparations (manual)

45
Overview

• Procedure
• Resources
• Modelling techniques
• Modelling prosody
• Problems solutions
• Suggested improvements

46
Need for better data

• Based on problems encountered
• Further analysis of clusters
• A large amount of data from a single speaker
  (primary need)
• A large amount of prosodic variation
• A balanced set of pitch events
• Clear speech which can be easily tracked
• Complex prosodic structure

47
Suggested improvements

• Model modification
• More data e.g. Peak Alignment study
• Separate models for different sentence types (Y/N
  Quest/Statements)
• Re-estimation of parameters based on new
  intonationally rich data

48
Next

• Closer inspection of automatically assigned
  accent classes (clusters)
• Evaluation perception experiments

49

• The End
