LINUX RED HAT

• Presented by
• Lonnye Bower
• Chris Orona
• Fardin Khan

2
Summary

• Research for the Power Point presentation
  revealed that Linux is a free operating system
  that has been compared to and even rated better
  and faster than the Windows operating system.
  Additionally, Linux is very popular with software
  developers because of the many programming
  language compilers Linux is equipped with. One
  of the preferred features of Linux is the fact
  that one can run different applications at the
  same time on different desktops.
• Our original intentions for this project were to
  include an actual demonstration of the RedHat
  installation. Unfortunately, after many hours
  were invested in the attempt to install Linux, we
  were unsuccessful. We attribute the failed
  installation to incompatible hardware, and have
  not given up on the belief that Linux is easy to
  install. We plan on successfully installing
  Linux in the near
• future and will be happy to share our results
  with anyone
• interested.

3
Presentation Contents

• Intro
• About Linux
• Installation Requirements
• Installation Notes
• RedHat 6.2 Installation
• KDE
• Welcome to Linux
• Adding a Printer
• Resources
• Key Terms

4
Introduction
5
Introduction to Linux

• line-ucks or lih-nicks
• Created primarily by Linus Torvalds in 1991
• First commercial release was in March, 1992

6
Introduction to Linux (cont)

• Linux is an operating system very much like Unix
• Multi-tasking, multi-user
• Developed by several users to replace Minix
• Freely distributed, becoming more popular every
  day

7
Why Linux is so popular

• Free
• Reliable no crashes
• Simple to use and install
• Developer friendly
• Runs on several different platforms
• Allows older 386 and 486 processors to run much
  faster
• Can coexist with other OSs

8
About Linux
9
The Linux kernel

• Originally developed for the Intel 80386 CPUs
  protected mode
• Completely compatible with Unix standards
• Allows shared executables
• Supports demand paging
• Uses a unified memory
• Supports swap space

10
The Linux kernel (cont)

• Uses dynamically shared libraries extensively
• Allows full library linking
• Supports a number of file systems
• DOS
• OS/2
• Ideally suited for application development

11
The Linux kernel (cont)

• Includes several programming language compilers
• C
• C
• Fortran
• Pascal
• LISP
• Ada
• BASIC

12
Linux and DOS

• Linux provides a DOS emulator, allowing DOS
  applications to be executed
• WINE (Windows emulator)
• WABI
• Files can be transferred between the DOS and
  Linux file systems
• Linux can access DOS partitions on a
• hard disk directly

13
Linux and TCP/IP

• Provides complete TCP/IP networking software to
• Create a local area network
• Attach to an existing Ethernet LAN
• Connect to the internet

14
Linux environments

• Text-based
• Graphical user interface (GUI) called X or X
  Window
• Very popular, especially with users new to Linux
• KDE
• GNOME

15
Importance of Linuxs XFree86

• XFree86 is Linuxs GUI
• Easy to use
• Very similar to Windows environment
• Windows users can make easy transition
• Can install and run Windows applications

16
Installation Requirements
17
Linux installation requirements

• Minimum installation
• 80386SX or better
• 2 MB RAM
• Floppy disk drive
• 40MB hard drive
• Video card
• Monitor

18
Linux installation requirements (cont)

• Realistic installation
• Text based
• 80386 or better
• 8 MB RAM
• GUI based
• 80486 or Pentium class
• 16 MB RAM

19
Linux recommended hardware

• Motherboards - ISA, EISA, PCI, VESA
• RAM 2 MB will work, 16 is best
• Multi-user 4 MB per user
• Hard disk IDE, EIDE, ESDI, RLL, SCSI
• If using SCSI, only uses most common
• Video Almost any
• Mouse Any
• Tape Any SCSI

20
Linux recommended hardware (cont)

• Removable media Most SCSI
• Printer Almost any parallel or serial port
• Modem Most serial, if DOS can use it, Linux can
  too
• NIC 3Com, Novell, HP, Intel
• Clones are NOT recommended!

21
Linux distributions

• RedHat
• www.redhat.com
• Corel
• linux.corel.com
• Mandrake
• www.linux-mandrake.com
• Debian
• www.debian.org
• Caldera
• www.caldera.com

22
Where to get Linux

• CD-ROM
• Frys, Best Buy
• WWW
• www.redhat.com/commerce
• FTP or BBS
• ftp.redhat.com/pub/redhat/current
• Note There are many other places
• to get Linux!

23
Installation Notes
24
RedHat Linux 6.2 Installation Notes

• Before installation
• Check hardware compatibility!!!
• www.redhat.com/support/hardware
• Make sure you have enough disk space
• Decide which installation method to use
• CD-ROM
• Hard Drive
• Ftp
• Http

25
RedHat Linux 6.2 Installation Notes (cont)

• Decide how to start the installation
• Bootable CD-ROM
• Local media boot disk
• Included with Official RedHat Linux 6.2 set
• Network boot disk
• PCMCIA boot disk
• Used if CD-ROM drive is attached to PC
• through PCMCIA card

26
RedHat Linux 6.2 Installation Notes (cont)

• Decide which installation type you need
• Workstation
• Most appropriate for Linux newbies
• Server
• Most appropriate for Linux-based servers
• Custom
• Allows for the greatest flexibility
• Upgrade
• Upgrading to a newer version of RedHat

27
A Note on Workstation Installations

• There are two types available, we will choose KDE
  for this presentation
• GNOME
• www.gnome.org
• KDE
• www.kde.org

28
Installation methods

• CD-ROM we will use this method
• Requires a boot disk, a bootable CD-ROM, or a
  PCMCIA boot disk
• Hard drive
• If you have copied all RedHat Linux file to your
  hard drive
• Requires a boot disk or PCMCIA boot disk

29
Installation methods (cont)

• Ftp
• If installing directly from an FTP server
• Requires a network or PCMCIA boot disk
• Http
• If installing directly from an HTTP server
• Requires a network or PCMCIA boot disk

30
Making Installation Diskettes in DOS

• Insert RedHat CD into CD-ROM drive
• Insert blank, formatted disk into floppy drive
• Type the following
• C\ d
• D\ cd \dosutils
• D\dosutils rawrite
• Enter disk image source file name
  ..\images\boot.img
• Enter target diskette drive a
• Please insert a formatted diskette into drive A
  and
• press ENTER ENTER
• D\dosutils

31
RedHat 6.2 Installation

• KDE Workstation Install

32
RedHat Installation page 1

• Insert RedHat CD into CD-ROM drive
• After a short delay, a screen containing the
  boot prompt should appear
• Press ENTER to continue and install graphically
• The next screen will ask you to determine which
  installation
• method you would like to use

Note All screenshots courtesy of redhat.com
33
RedHat Installation page 2

• Choose the option for CD-ROM and select OK
• The installation program will probe your system
  and attempt to identify your CD-ROM drive
• Using a common CD-ROM drive will prevent any
  problems

34
RedHat Installation page 3

• The next screen will ask you to select a language
  Choose English and click Next

35
RedHat Installation page 4

• Choose the keyboard that best fits your system
  If no exact match, choose the best GENERIC match
  and click Next

36
RedHat Installation page 5

• Choose the mouse that best fits your system If
  no exact match, choose the best GENERIC match and
  click Next

37
RedHat Installation page 6

• Read over the help text in the left and then
  click Next

38
RedHat Installation page 7

• Choose to Install and select KDE Workstation and
  click Next

39
RedHat Installation page 8

• For ease of installation, continue with Automatic
  Partitioning and click Next
• Note everything will be erased!

40
RedHat Installation page 9

• Again, for ease of installation and use, leave
  defaults selected and click Next

41
RedHat Installation page 10

• Choose your Network device type, then enter your
  IP Address, Netmask, Network, and Broadcast
  addresses and click Next
• Unsure? Ask your network administrator

42
RedHat Installation page 11

• Choose your time zone by clicking on the map, ex.
  Pacific Tijuana, and click Next

43
RedHat Installation page 12

• Set the ROOT PASSWORD - Write it down and keep it
  in a secure place!
• You can add Users at this time too, then click
  Next

44
RedHat Installation page 14

• Continue with the option detected for your system
  and click Next

45
RedHat Installation page 15

• Choose the monitor that best fits your system -
  If none exist, choose the best GENERIC monitor
  and click Next

46
RedHat Installation page 16

• Continue with the video hardware detected for you
  unless you know it is incorrect (change it) and
  click Next
• You can test the Configuration
  if you are not sure.
• Make sure USE GRAPHICAL LOGIN
  is selected!

47
RedHat Installation page 17

• Almost done!!! Click Next
• If you would rather quit, this is your last
  chance! You can reboot and safely exit the
  installation now

Be sure to read the Caution Note!
48
RedHat Installation page 18

• At this point, you can sit back and relax while
  RedHat is installed
• Depending on the speed of your system, the
  installation will take from about 15 minutes to 1
  hour

49
RedHat Installation page 19

• Insert a blank, formatted disk into the floppy
  drive and click Next

50
RedHat Installation page 20

• Congratulations!!!
• You can now click Exit to reboot your system and
  start to use Linux

51
KDE
52
About the KDE Environment

• Desktop Similar to Windows desktop
• Main workspace of KDE environment
• Supports multiple desktops
• Panel Similar to Windows taskbar
• Serves as a quick launcher for applications and
  applets

53
More About the KDE Environment
You can find this file by opening
usr/kde/HTML/ default/kdehelp/main.html
54
Welcome To Linux
55
Welcome to Linux page 1

• Your KDE desktop

56
Welcome to Linux page 2

• The panel is very configurable
• You can add and remove applications which will
  allow you to access them easily
• You can easily hide the panel

57
Welcome to Linux page 3

• The KDE panel, features a quick launch button for
  an Xterm (similar to DOS prompt)
• You will see the shell prompt inside the newly
  created window
• root_at_localhost /root

Xterm button
58
Welcome to Linux page 4

• Taskbar
• Displays all running applications
• Usually located at the top of the screen, but can
  be moved

59
Welcome to Linux page 5

• Logging out from KDE sessions
• From the Main Menu Select the Logout item

60
Adding a Printer
61
Adding a Printer in Linux

• Open an Xterm window
• If not logged in as Root, type su at the prompt
  and then enter your root password
• Type printtool and press Enter
• The Printtool window will appear

62
Adding a Printer in Linux (cont)

• Select Add

63
Adding a Printer in Linux (cont)

• Select the type of printer to add and click OK
• Printtool will attempt
• to detect any printers
• attached to your
• parallel port

64
Adding a Printer in Linux (cont)

• Click OK to continue
• after your printer was
• detected

65
Key Terms

• Linux
• Kernel
• XFree86
• KDE
• Gnome
• RedHat
• Root
• Panel
• Xterm
• Taskbar
• Printtool

66
Linux Resources
67
Linux Resources

• For more information on Linux go to
• www.linux.com
• www.linux.org
• www.redhat.com
• www.maximumlinux.com
• www.li.org

68
Linux Resources (cont)

• For applications/software that are Linux
  compatible go to
• www.sun.com
• www.corel.com
• www.linuxapps.com
• www.linuxcentral.com/linux/apps/linapps.html
• www.m-tech.ab.ca/linux-biz
• charter.linuxberg.com

69
Thank You and Good Luck!

• If you have any questions regarding Linux and/or
  any part of this presentation, please feel free
  to email
• Lonnye Bower at Lonnye_at_aol.com
• Chris Orona at corona_at_calstatela.edu Fardin
  Khan at Fardin24_at_aol.com
