Schematron Data Validation

1
Schematron Data Validation

• An open framework
• Presented By Chris Clark and Dr. Yunhao Zhang

2
Topics

• What is Schematron?
• Business rules and Schematron rules
• Schematron validation process
• Exchange Network Schematron extensions
• Implementation and Tools
• Guidance and recommendations.
• Conclusion

3
Schematron

• An XML schema language
• Combines powerful validation capability with
  simple syntax
• Based on XSLT and XPath
• Open Source Implementation
• An ISO standardISO/IEC 19757 - DSDL Document
  Schema Definition Language

4
Schematron Advantages

• Direct mapping from business rules to validation
  rules.
• Easier to design and deploy.
• Moves data validation from application
  programming logic to a shared service with a
  centralized rule set (rule sharing)
• Natural language descriptions of error conditions
  and solutions.
• Highly extensible using XPath expression
  extensions.

5
Schematron and XLST
XML Doc
Error Report
XSLT Processor
XSLT Rules

• Transform an XML document into an error report
  using XSLT. Rules are coded in style sheets.

6
Business Rules
7
Business Rules

• RuleId A unique identifier for the business
  rule.
• XmlElement XML element the rule is imposed upon.
• Test Conditions Conditions the data element must
  meet or not meet.
• Error Description The error message when the
  rule is fired.

8
Schematron Rules

• A Schematron rule has three major parts
• The context The element a rule applies to. - The
  XML element in the bus. rule.
• An assertion A statement about an element,
  usually an Xpath expression. - The error
  condition in the bus. rule).
• A result A statement to be reported if an
  assertion fails (or succeeds). The error
  description in the bus. rule.

9
Schematon Rule Example
ltrule context"aqsObservationDate"gt ltassert
test"neienCheckDate(string(.),'', '19570101',
'Today', 0)"gt AQS23Error ObservationDate
(ltvalue-of select"."/gt) must be in proper
YYYYMMDD format and in the range Jan 1, 1957
through today. lt/assertgt lt/rulegt
10
Recommended Error Format

• RuleId The business rule Id in the business rule
  table.
• ErrorType This is the type of error - Error,
  Warning, Critical, or some custom error level.
• Element Full Path This is the complete path with
  the element name, leading to the offending
  element
• Error Description The error description. It must
  contain the offending value.

11
Quality Assurance Services

• The Exchange Network has been using the
  Schematron technology since 2003.
• QA services are shared web services for data
  validation using both schema and Schematron.
• Many data flows are currently using Schematron
  validations NEI, AQS,OWWQX, UIC, VERIFY
• QA services can be accessed from all
  applications.
• Service description is available
  athttps//tools.epacdxnode.net/xml/validator.wsd
  l.

12
Flow Data Validation Process
Well-form Check
Schema validation
Rule validation
Error Report
XML Doc
XML Parser
Schema Validator
XSLT Processor
Schemas
Schematron Rules
13
Exchange Network Schematron Extensions

• Table Lookup Check whether a value is in a
  predefined database table.
• Date Format and Range Verify if a date string in
  a correct format and within the specified range.
• Regular Expression Compare a value against a
  specified format.

14
Schematron with Extensions
Error Report
XML Doc
XSLT Processor
XSLT
Xpath Extension
Schematron Processor
Meta Schemas
FRS
Registry Info
SRS
Registry Info
Schematron Rules
Regular Expression
15
Current Implementation

• A set of web services.
• Provides both schema validation and Schematron
  validation.
• Has synchronous and asynchronous modes.
• Supports table lookups to any database tables.
• Can process compressed or uncompressed xml
  document.
• Accessible to any nodes, applications or users.
• Node client 2007 is integrated with QA services.

16
Schematron Guidance Document

• Business Rules and Requirements
• Schema and Schematron
• Schematron Rule Development
• Schematron Extensions
• Regular Expression Support
• Schematron Software Developer Kit
• Data Quality Assurance Services
• Using QA Server for Schema Validation
• Using QA Server for Schematron Validation
• Deploying New Schematron Rules

17
Conclusion

• Streamlined data validation is crucial to
  successful data exchange
• Rules should be defined with schemas
• Data validation should happen as early as
  possible
• Technologies and tools are available for boosting
  data quality
• Schematron is a recommended design approach
