KrCCTV SPEED DOME CAMERAS

1
KrCCTV SPEED DOME CAMERAS
2006 Speed Dome Catalog
2
Worlds most silent PTZ speed dome camera
0.024 dome system accuracy with 1/8 micro step
Reliable ram-material 360 Endless rotation
Mechanical image stabilization Controlled
pan/tilt speed while zooming Power
misconnection protection function on RS-485
terminal Day night 24 privacy masking zones
(26X) 8 patterns available (total 480
seconds) 8 programmable group tours (each one
consisting of up to 60 preset steps with
different speed) 200 preset position with a
16-character label available for each position
with different speed steps 4 alarm input and 2
relay output Auto flip function Max 360/sec
Pan 250/sec tilt speed Digital slow
shutter Quick operation keys Communication
protocol system RS-485 Password protection
Voltage 24V AC Pelco-D, Pelco-P protocols
supported
Unit mm
3
Worlds most silent PTZ speed dome camera
0.024 dome system accuracy with 1/8 micro step
Reliable ram-material Mechanical and image
stabilization (26x) Controlled pan/ tilt speed
while zooming Power misconnection protection on
RS-485 terminal Built-in fan heater IP 66
water-resistant 1832VAC / 2A Anodized and
Chromate Aluminum material with anticorrosive
paint Only 40VA power requirement Various
mounting options Filter changeable (SNR) true
day night (26x) Digital slow shutter 24
privacy masking zones (26X) 8 patterns
available (total 480 seconds) Auto flip
function 200 presets 8 programmable group
tours (each one consisting of up to 60 presets
steps with different speed) 8 selectable areas
with 16 characters 4 alarm input and 2 relay
output Communication interface RS-485
Pelco-D, Pelco-P protocols supported
4
Accessories for Speed Dome Camera
CONTROLLER FOR SPEED DOME
3-Axis Controller
PTZ control Up to 255 DVR control by network
(optional) Preset position control LCD
monitor with blue screen Twist stick (3-axis)
zoom control Keyboard button- pan/tilt
control Menu driven user configuration,
password Select to 255 cameras from one
keyboard Multi-protocol built in RS-485/232
communication Joystick for fixed-speed and
variable speed control of pan/tilt units
5
KrCCTV Speed DomesThe Best in their Class
312x Zoom Magnification 26x (22x) optical zoom
lens combined with the 12x (10x) digital zooming
function provides a max. magnification of 312x
(220x). Users can even catch the smallest image
and enlarge it to identify the most minute detail.
Auto Flip Function The Auto-Flip feature
positions the camera for continuous viewing of
any subject that passes directly beneath the
dome. This function enables the dome to
automatically turn 180 when the camera tilts to
its lower limits.
26X
Mechanical Image Stabilization The image
stabilizer function minimizes the appearance of
shaky images caused by low-frequency vibration
and maintains a normal horizontal resolution. It
is useful for outdoor surveillance and traffic
monitoring applications.
24 Privacy masking zones Sometimes there are
sensitive areas within the field under
surveillance, such as an outdoor apartment
window or an indoor office. Our Privacy Area
Masking feature can quickly and easily create a
"mask" over these areas up to 24 zones,
restricting them from the operators view.
Day Night Capability Surveillance with optimum
picture is possible owing to Filter changeable
Day Night function and DSS function. Auto-IR
cut filter removable function is auto-controlling
the operation such as color picture plus infrared
cut filter during the day and black-and-white
picture plus filter elimination at night. (22X
model has DSS day night function only)
360 Quick Endless Rotation The 360 full pan
function moves through a max. 350/sec enabling
you to quickly pinpoint the spot you want to
watch. Tilt speed provides through a max.
250/sec on preset.
Built-in Fan Heater Outdoor housing is equipped
with fan and heater as a thermostat and
protecting the dome from a wide range of outside
temperatures. Fan is operated over 45? for
reducing heat and heater is operated below 10?
for preventing ice from forming on the outside
bubble.
Flexible 200 Preset Position Auto-Surveillance O
ur speed domes deliver surveillance coverage of a
wide area by pre-setting to a maximum of 200
positions this enables the user to preset the
area to be monitored at any time. Users need
only select the important sectors to be surveyed
carefully. Users can control the speed and
dwelling time of pan swing and tilt swing, and
the preset positions can be set by group tour
sequence. 8 Patterns Trace Allows manual
operation for about 480 seconds Auto Swing
Repeat pan and tilt between two preset position 8
Group Tours Switches and checks 64 presets on
each group tour
IP66 perfectly water-resistant Outdoor speed dome
is certificated IP66.
Anodizing, chromate aluminum material with
anticorrosive paint The housing is consisting of
anodizing, chromate material and anticorrosive
paint for preventing the aluminum body from
oxidization and salt corrosion.
6
Worlds most silent speed dome camera
Equipped with silent and smooth timing belt and
special gear, low-noisy-technology enhances
durable quality of the camera by reducing the
mechanical vibration. This camera is the
perfect match, both indoor and outdoor, for
demanding security applications. 0.024
dome system accuracy with 1/8 micro step With
0.024 technical accuracy, camera provides
excellent sensitive and delicate controlling
on preset mode by adapting 1/8 micro step and
twin gear system Reliable RAM-Material The
mechanical stabilization improves the durability
and long life time of the camera by using
reliable materials especially, stepping motor,
slip ring, timing belt and power condenser. This
camera case is made of fire resisting material
that approved UL grade 94 V-0. It is useful
for indoor environment concerning about the fire
accident Compensation function preset
position The function minimizes the appearance
of shaky images caused by low-frequency
vibration, wind and any impact and maintains a
normal horizontal resolution and sets the
starting point of pan/tilt on preset mode by
using joystick turning one time without turn off
the power of the camera. It is useful for
outdoor surveillance and traffic monitoring
applications. Slip Ring for long life time
(20milion rotate ring tested) Equipped with
slip ring is passed by up to 20 millions rotate
ring test within 6 months Power
misconnection protection on 485 terminals This
protection function prevents the communication
terminal from being out and trouble when power
source falsely connects to the RS-485
terminals. Hi speed dome got a patent for power
misconnection protection on RS-485 terminal
Filter changeable True Day/Night Surveillance
with optimum picture is possible owing to filter
changeable Day/Night (ICR block filter)
function and DSS. Auto IR cut filter
removable function is auto controlling the
operation such as color picture plus infrared
cut filter during the day and black and white
picture plus filter elimination at night

• Quick Operation Keys
• This camera provides quick functional keys in
  other to be
• easily controlled by any other controller or
  DVR.
• Various Surveillance Functions
• Auto Scan repeats pan and tilt between two
  preset
• positions with different speed and dwell time.
• 8 Group Tour up to 8 Programmable Group tours
• available and each group is consisting up to 60
  presets
• step with different speed and dwell time with
  16
• characters.
• 200 Preset positions up to 200 programmable
  preset
• positions are available with 16 characters
• 8 Patterns up to 8 programmable user-defined
  patters
• are available with 16 characters and each one
  is
• consisting 50 seconds, total 400
• 8 Sectors up to 8 programmable user-defined
  sectors are
• available with 16 characters

. . .
7
