What does it take to produce nearpeak MatrixMatrix Multiply

1
What does it take to produce near-peak
Matrix-Matrix Multiply

• Kamen Yotov
• Department of Computer Science
• Cornell University
• CS612 Lecture, 02/08/05

2
Approaches to fast MMM

• Traditional approach
• Hand-optimized code (e.g.) most native BLAS
• Problem costly and tedious to develop
• Alternatives
• Restructuring compilers
• General purpose generate code from high-level
  specifications
• Use architectural models to determine
  optimization parameters
• Performance of optimized code is not satisfactory
• Library generators
• Problem-specific (e.g.) ATLAS for BLAS, FFTW for
  FFT
• Use empirical optimization to determine
  optimization parameters
• Believed to produce optimal code

3
Outline

• ATLAS
• Hardware parameters
• Transformations
• Optimization parameters
• Modeling
• Experimental Results

4
Architecture
5
Architecture
6
Measure Machine Parameters

• Empirical Optimization
• L1Size similar to Saavedra Benchmark
• NR, FMA, Lh
• Not exact, used to bound the search space
• Model-driven
• Need exact values
• Uses X-Ray http//iss.cs.cornell.edu/Software/X-R
  ay.aspx

7
Architecture
8
Code Generation Compiler Perspective

• ATLAS is not a compiler
• Code Generator output equivalent to
• Cache-level blocking (tiling)
• NB
• Register-level blocking
• MU, NU, KU
• Scheduling software pipelining
• FMA, LS, FF, IF, NF
• Versioning
• Back-end compiler optimizations

9
Cache-level blocking (tiling)

• Tiling in ATLAS
• Only square tiles (NBxNBxNB)
• Working set of tile fits in L1
• Tiles are usually copied to continuous storage
• Special clean-up code generated for boundaries
• Mini-MMM
• for (int j 0 j
• for (int i 0 i
• for (int k 0 k
• Cij Aik Bkj
• NB Optimization parameter

10
Register-level blocking

• Register blocking is to mini-MMM what cache
  blocking is to MMM
• Very important for performance highest level of
  Memory Hierarchy
• Register file is a form of cache
• Fully associative
• Unit line size
• Optimal replacement
• Register file is under software control
• It is not transparent to software like normal
  caches
• Compilers allocate variables to registers,
  performs spills, etc.
• Compilers seldom allocate array elements to
  registers
• To block for the register file one needs
• Unroll the corresponding loops
• Scalarize array elements into variables

11
Register-level blocking (cont.)

• Micro-MMM
• A MUx1
• B 1xNU
• C MUxNU
• MUxNUMUNU registers
• Unroll loops by MU, NU, and KU
• Mini-MMM with Micro-MMM inside
• for (int j 0 j
• for (int i 0 i
• load Ci..iMU-1, j..jNU-1 into registers
• for (int k 0 k
• load Ai..iMU-1,k into registers
• load Bk,j..jNU-1 into registers
• multiply As and Bs and add to Cs
• store Ci..iMU-1, j..jNU-1
• Special clean-up code required if
• NB is not a multiple of MU,NU,KU
• MU, NU, KU optimization parameters

12
Scheduling
Computation
MemoryOperations

• FMA Present?
• Schedule Computation
• Using LS
• Schedule Memory Operations
• Using IF, NF,FF
• LS, IF, NF, FF optimization parameters

L1
L2
L3

LMUNU
13
Code GenerationOptimization Parameters

• Optimization parameters
• NB constrained by size of L1 cache
• MU, NU constrained by NR
• KU constrained by size of I-Cache
• FF, IF, NF constrained by number of outstanding
  loads
• FMA, LS related to hardware parameters
• Sensitive vs. insensitive parameters
• Similar parameters used by compilers

14
Architecture
15
ATLAS Search Strategy

• Multi-dimensional optimization problem
• Independent parameters NB, MU, NU, KU,
• Dependent variable MFLOPS
• Function from parameters to variables
• Is given implicitly
• Can be evaluated repeatedly
• One optimization strategy orthogonal line search
• Optimize along one dimension at a time
• Use reference values for parameters not yet
  optimized
• Not guaranteed to find optimal point, but might
  come close
• Specification of orthogonal line search
• Order in which dimensions are optimized
• Reference values for un-optimized dimensions at
  any step
• Interval in which line search is done for each
  dimension

16
Search for best NB

• Search in following range
• 16
• NB2
• In this search, use simple estimates for other
  parameters
• e.g. for KU test each NB candidate for
• Full K unrolling (KU NB)
• No K unrolling (KU 1)

17
Search for other parameters

• MU and NU
• Constraints
• 1
• MUNU MU NU
• Use best found NB from previous step
• KU
• KU 1, 4, 8, , NB/2, and NB
• LS
• 1
• FF, IF, and NF
• FF 0, 1
• 2
• 1

18
Architecture
19
Models for Optimization Parameters

• Optimization parameters
• NB
• Hierarchy of Models (follows)
• MU and NU
• MU NU MU NU LS
• KU
• maximize subject to L1 Instruction Cache
• LS
• LS (Lh ALU 1)/2
• FF, IF, NF
• FF0, IF2, NF2
• FMA
• hardware parameter

20
Models for NBNo capacity / conflict misses

• Tiles copied to contiguous memory
• Simplest model
• 3 NB2

21
Models for NBNo capacity misses / some
conflicts

• MMM
• for (int j 0 i j cij aik bkj
• Cache model
• Fully associative
• Line size 1 Word
• Optimal Replacement
• Bottom line
• NB2 NB 1
• One full matrix
• One row / column
• One element

22
Models for NBExtension for Line Size

• Line Size 1
• Spatial locality
• Array layout in memory matters
• Bottom line
• This is for JIK loop order, column major layout
• ATLAS uses this order / layout for Mini-MMM

23
Models for NBExtension for LRU Replacement

• Intuition
• Need more storage than optimal replacement
• Data needs to cool down in cache to be replaced
• This means smaller tiles
• MMM sample
• for (int j 0 i cij aik bkj
• Bottom line

24
Models for NBAccounting for intra-level
interactions

• Mini-MMM is not scalar operations underneath
• It is a sequence of Micro-MMMs, operating on
  register tiles
• So whenever we talked about rows and columns we
  should consider vertical and horizontal panels of
  register tiles instead!
• We can refine the model for NB as follows

25
Models for NBSummary

• Models of increasing complexity
• 3 x NB2 C
• Whole work-set fits in L1
• NB2 NB 1 C
• Fully Associative
• Optimal Replacement
• Line Size 1 word
• Line Size 1 word
• LRU Replacement
• Multi-level interactions

26
ModelsSummary

• This is the complete model
• It contains a small refinement for MU and NU on
  x86

27
Experimental Results

• Ten modern architectures
• Model did well on
• RISC architectures
• UltraSPARC did better
• Model did not do as well on
• Itanium 2
• x86 CISC architectures
• Sometimes substantial gap between
• ATLAS CGw/S
• ATLAS Unleashed

28
Sensitivity Analysis

• Sensitivity graphs are invaluable for tracking
  down performance problems
• Such graphs are useful for figuring out
  parameters in your homework!
• Example Sensitivity to NB
• Use ATLAS values for all parameters other than NB
• Vary NB and see how performance is affected
• Gives a 2D slice of a high-dimensional
  performance surface
• Similar for other parameters

29
Example Sensitivity Graphs
30
Complete MMM Results
Intel Itanium 2
AMD Opteron 240
SGI R12K
Sun UltraSPARC IIIi
