Web Cache Replacements

1
Web Cache Replacements

• ???
• ?????
• ????
• ykchang_at_mail.ncku.edu.tw

2
Introduction

• Which page to be removed from its cache?
• Finding a replacement algorithm that can yield
  high hit rate.
• Differences from traditional caching
• nonhomogeneity of the object sizes
• same frequency and different size, favor smaller
  objects if consider only hit rate,
• Byte hit rate

3
Introduction

• Other consideration
• transfer time cost
• Expiration time
• Frequency
• Measurement metrics?
• admission control?
• When or how often to perform the replacement
  operations?
• How many documents to remove?

4
Measurement Metrics

• Hit Rate (HR)
• requests satisfied by cache
• (shows fraction of requests not sent to server)
• Volume measures
• Weighted hit rate (WHR) Byte Hit Ratio
• client-requested bytes returned by proxy (shows
  fraction of bytes not sent by server)
• Fraction of packets not sent
• Reduction in distance traveled (e.g., hop count)
• Latency Time

5
Three Categories

• Traditional replacement policies and its direct
  extensions
• LRU, LFU,
• Key-based replacement policies
• Cost-based replacement policies

6
Traditional replacement

• Least Recently Used (LRU) evicts the object which
  was requested the least recently
• prune off as many of the least recently used
  objects as is necessary to have sufficient space
  for the newly accessed object.
• This may involve zero, one, or many replacements.

7
Traditional replacement

• Least Frequently used (LFU) evicts the object
  which is accessed least frequently.
• Pitkow/Recker evicts objects in LRU order, except
  if all objects are accessed within the same day,
  in which case the largest one is removed.

8
Key-based Replacement

• The idea in key-based policies is to sort objects
  based upon a primary key, break ties based on a
  secondary key, break remaining ties based on a
  tertiary key, and so on.

9
Key-based Replacement

• LRUMIN
• This policy is biased in favor of smaller sized
  objects so as to minimize the number of objects
  replaced.
• Let the size of the incoming object be S. Suppose
  that this object will not fit in the cache.
• If there are any objects in the cache which have
  size at least S, we remove the least recently
  used such object from the cache.
• If there are no objects with size at least S,
  then we start removing objects in LRU order of
  size at least S/2, then objects of size at least
  S/4, and so on until enough free cache space has
  been created.

10
Key-based Replacement

• SIZE policy
• In this policy, the objects are removed in order
  of size, with the largest object removed first.
• Ties based on size are somewhat rare, but when
  they occur they are broken by considering the
  time since last access. Specifically, objects
  with higher time since last access are removed
  first.

11
Key-based Replacement

• LRU-Threshold is the same as LRU, but objects
  larger than a certain threshold size are never
  cached.
• Hyper-G is a refinement of LFU, break ties using
  the recency of last use and size.
• Lowest Latency First minimizes average latency
  by evicting the document with the lowest download
  latency first.

12
Cost-based Replacement

• Employ a potential cost function derived from
  different factors such as
• time since last access,
• entry time of the object in the cache,
• transfer time cost,
• object expiration time and so on.
• GreedyDual-Size (GD-Size) associates a cost with
  each object and evicts object with the lowest
  cost/size.
• Hybrid associates a utility function with each
  object and evicts the one has the least utility
  to reduce the total latency.

13
Cost-based Replacement

• Lowest Relative Value evicts the object with the
  lowest utility value.
• Least Normalized Cost Replacement (LCN-R) employs
  a rational function of the access frequency, the
  transfer time cost and the size.
• Bolot/Hoschka employs a weighted rational
  function of transfer time cost, the size, and the
  time last access.

14
Cost-based Replacement

• Size-Adjusted LRU (SLRU) orders the object by
  ratio of cost to size and choose objects with the
  best cost-to-size ratio.
• Server-assisted scheme models the value of
  caching an object in terms of its fetching cost,
  size, next request time, and cache prices during
  the time period between requests. It evicts the
  object of the least value.
• Hierarchical GreedyDual (Hierarchical GD) does
  object placement and replacement cooperatively in
  a hierarchy.

15
GreedyDual

• GreedyDual is originally proposed by Young and
  Tarjan, concerned with the case when pages in a
  cache have the same size but incur different
  costs to fetch from a secondary storage
• A value H is initiated with each cached page p
  when a page is brought into cache.
• H is set to be the cost of bringing p into the
  cache
• the cost is always nonnegative.
• (1) Page with the lowest H value (minH) is
  replaced and (2) then all pages reduce their H
  values by minH

16
GreedyDual

• If a page is accessed, its H value is restored to
  the cost of bringing it into the cache
• Thus the H values of recently accessed pages
  retain a larger portion of the original cost than
  the pages that have not been accessed for a long
  time
• By reducing the H values as time goes on and
  restoring them upon access, GreedyDual integrates
  the locality and cost concerns in a seamless
  fashion

17
GreedyDual-Size

• Setting H to cost/size upon accesses to a
  document, where cost is the cost of bringing the
  document and size is the size of the document in
  bytes
• call this extended version as GreedyDual-Size
• The definition of cost depends on the goal of the
  replacement algorithm cost is set to
• 1 if the goal is to maximize hit ratio
• the downloading latency if the goal is to
  minimize average latency
• network cost if the goal is to minimize the total
  cost

18
GreedyDual-Size

• Implementation
• Need to decrement all the pages in cache by
  Min(q) every time a page q is replaced, which may
  be very inefficient
• Improved algorithm is in the next page
• Maintaining a priority queue based on H
• Handling a hit requires O(log k) time and
• Handling an eviction requires O(log k) time since
  in both cases the queue needs update

19
GreedyDual-Size

• Algorithm GreedyDual (document p)
• / Initialize L ? 0 /
• If p is already in memory,
• H(p) ? L cost(p)/size(p)
• If p is not in memory,
• while there is not enough room in memory for
  p,
• Let L ? min H(q) for all q in
  cache
• Evict q such that H(q) L
• Put p into memory set H(p)?Lcost(p)/size(p)

20
Hybrid Algorithm (HYB)

• Motivated by Bolot and Hoschka's algorithm.
• HYB is a hybrid of several factors, considering
  not only download time but also number of
  references to a document and document size. HYB
  selects for replacement the document i with the
  lowest value of the following expression

21
HYB

• Utility function is defined as follows
• Cs is the estimated time to connect to the server

• bs is the estimated bandwidth to the server
• Zp is the size of the document
• np is the of times document has been referenced
• Wb and Wn are constants that set the relative
  importance of the variables bsand np, respectively

22
Latency Estimation Algo. (LAT) REF

• Motivated by estimating the time required to
  download a document, and then replace the
  document with the smallest download time.
• Apply some function to combine (e.g., smooth)
  these time samples to form an estimate of how
  long it will take to download the document
• keeping a per-document estimate is probably not
  practical.
• Alternative keep statistics of past downloads on
  a per-server basis, rather than a per-document
  basis. (less storage)
• For each server j, the proxy maintains an
• Clatj estimated latency (time) to open
  connection to server
• Cbwj estimated bandwidth of the connection (in
  bytes/second),

23
Latency Estimation Algo. (LAT) REF

• When a new document is received from server, the
  connection establishment latency (sclat) and
  bandwidth for that document (scbw) are measured ,
  the estimates are updated as follows
• clatj (1-ALPHA) clatj ALPHA sclat
• cbwj (1-ALPHA) cbwj ALPHA scbw
• ALPHA is a smoothing constant, set to 1/8 as it
  is in the TCP smoothed estimation of RTT
• Let ser(i) denote the server on which document i
  resides, and si denote the document size. Cache
  replacement algorithm LAT selects for replacement
  the document i with the smallest download time
  estimate, denoted di
• di clatser(i) si/cbwser(i)

Replacement Algorithm
24
Latency Estimation Algo. (LAT)

• One detail remains
• a proxy runs at the application layer of a
  network protocol stack, and therefore would not
  be able to obtain the connection latency samples
  sclat.
• Therefore the following heuristic is used to
  estimate connection latency. A constant CONN is
  chosen (e.g., 2Kbytes). Every document that the
  proxy receives whose size is less than CONN is
  used as an estimate of connection latency sclat.
• Every document whose size exceeds CONN is used as
  a bandwidth sample as follows
• scbw download time of document current value
  of clatj.

25
Lowest Relative Value (LRV)

• time from the last access t for its large
  influence on the probability of a new access
• the probability of a new access conditioned to
  the time from the last access can be expressed as
  (1 - D(t))
• of previous accesses i this parameter allows
  the proxy to select a relatively small number of
  documents with a much higher probability of being
  accessed again
• document size s This seems to be the most
  effective parameter that make a selection among
  documents with only one access

26
Distribution of interaccess times, D(t)
27
Prob. Density function of interaccess times, d(t)
28
Lowest Relative Value (LRV)

• We compute the probability that a document is
  accessed again, Pr(i, t, s), as follows
• Pr(i, t, s) P1(s)(1 - D(t)) if i 1
• Pr(i, t, s) Pi (1 D(t)) otherwise
• Pi conditional probability that a document is
  reference i1 times given that it has been
  accessed i times
• P1(s) Percentage of size s with at least 2
  accesses
• D(t) density distribution of times between
  consecutive requests to the same document,
  derived as D(t) 0.035log(t1) 0.45(1 - e
  )

29
Lowest Relative Value (LRV)
30
Lowest Relative Value (LRV)
31
Performance from Pei Cao

• Use hit ratio, byte hit ratio, reduced latency
  and reduced hops
• reduced latency the sum of downloading latency
  for the pages that hit in cache as a percentage
  of the sum of all downloading latencies
• reduced hops the sum of the network costs for
  the pages that hit in cache as a percentage of
  the sum of the network costs of all Web pages
• model network cost of each document as hops
• Web server has hop value 1 or 32 we assign 1/8
  of servers with hop value 32 and 7/8 with hop
  value 1
• The hop value can be thought of either as the
  number of network hops traveled by a document or
  as the monetary cost associated with the document

32
Performance from Pei Cao

• GD-Size(1) sets cost of each document to be 1,
  thus trying to maximize hit ratio
• GD-Size(packets) sets the cost for each document
  to 2size/536, i.e. estimated number of network
  packets sent and received if a miss to the
  document happens
• 1 packet for the request, 1 packet for the reply
  and size/536 for extra data packets assuming a
  536-byte TCP segment size.
• It tries to maximize both hit ratio and byte hit
  ratio
• Finally GD-Size(hops) sets the cost for each
  document to the hop value of the document trying
  to minimize network costs

33
Performance from Pei Cao

• See Caos paper page 4

34
Weighted Hit Rate

• Results on best primary key are inconclusive
• Most references are from small files, but most
  bytes are from large files
• Why Size?
• Most accesses are for smaller documents
• A few large documents take the space of many
  small documents
• Concentration of large inter-reference times

35
Exp. 3 Partitioning Cache by Media

• Idea
• Do clients that listen to music degrade the
  performance of clients using text and graphics?
• Could a partitioned cache with one portion
  dedicated to audio, and the other to non-audio
  documents increase the WHR experienced by either
  audio or non-audio documents?
• Simulate
• cache size 10 of max needed
• two partitions audio and non-audio

36
Exp. 4 Partitioning Cache by Media

• In Experiment 4,
• a one-level cache with SIZE as the primary key
• random as the secondary key
• three partition sizes dedicate 1/4, 1/2, or 3/4
  of the cache to audio
• the rest is dedicated to non-audio documents.

37
Exp. 4 Partitioning Cache by Media
38
Exp. 4 Partitioning Cache by Media
39
Problems to solve

• Certain sorting keys have intuitive appeal.
• The first is document type. A sorting key that
  puts text documents at the front of the removal
  queue would insure low latency for text in Web
  pages, at the expense of latency for other
  document type.
• The second sorting key is refetch latency. To a
  user of international documents, the most obvious
  caching criteria is one that caches documents to
  minimize overall latency.
• A European user of North American documents would
  preferentially cache those documents over ones
  from other European servers to avoid using
  heavily utilized transatlantic network links.
  Therefore a means of estimating the latency for
  refetching documents in a cache could be used as
  a primary sorting key.

40
Problems to solve

• caching dynamic documents. Cache is only useless
  for dynamic documents if the document content
  completely changes otherwise a portion but not
  all of the cached copy remains valid.
• allow caches to request the differences between
  the cached version and the latest version of a
  document.

41
Problems to solve

• For example, in response to a conditional GET a
  server could send the diff" of the current
  version and the version matching the
  Last-Modified date sent by the client or a
  specific tag could allow a server to fill-in a
  previously cached static query response form."
• Another approach to changing semi-static pages
  (i.e., pages that are HTML but replaced often) is
  to allow Web servers to preemptively update
  inconsistent document copies, at least for the
  most popular.

42
Randomized Strategies

• These strategies use randomized decisions to find
  an object for replacement.

43
Randomized Strategies
Randomized Strategies

• 1. RAND
• This strategy removes a random object.
• 2. HARMONIC Hosseini-Khayat 1997
• RAND uses equal probability for each object,
  HARMONIC removes from cache one item at random
  with a probability inversely proportional to its
  specific cost cost ci/si .

44
Randomized Strategies
Randomized Strategies

• 3. LRU-C and LRU-S Starobinski and Tse 2001.
• LRU-C is a randomized version of LRU.
• Let Cmaxc1,cN be the maximum of the access
  costs of all N objects of a request sequence.
• Let ci ci/cmax be the normalized cost for
  object i. When an object i is requested, it is
  moved to the head of the cache with probability
  ci otherwise, nothing is done.

45
Randomized Strategies
Randomized Strategies

• LRU-S uses the size instead of the cost. Let
  smins1,sN be the size of the smallest objects
  among the N documents, and di smin/si be the
  normalized density of object i.
• LRU-S acts as LRU with probability di otherwise
  the cache state is left unmodified.
• Furthermore, Starobinski and Tse 2001 proposed
  an algorithm which deals with both varying-size
  and varying-cost objects.
• The following quantities were defined
• Upon a request for object i, this algorithm
  performs the same operation as LRU with
  probability and with will leave the
  cache state unmodified.

46
Randomized Strategies
Randomized Strategies

• 4. Randomized replacement with general value
  functions Psounis and Prabhakar 2001.
• This strategy draws N objects randomly from the
  cache and evicts the least useful object in the
  sample. The usefulness of a document can be
  determined by any utility function. After
  replacing the least useful object, the next M(M lt
  N) least useful objects are retained in memory.
• At the next replacement, N - M new samples are
  drawn from the cache and the least useful of
  these N-M and M previously retained is evicted.
  The M least useful of the remaining are stored in
  memory and so on.

47
Randomized Strategies Summary
Randomized Strategies

• 1. Randomization presents a different approach
  to cache replacement.
• 2. Randomized strategies try to reduce the
  complexity of the replacement process without
  sacrificing the quality too much.

48
Admission control

• If we store the response in cache or not?
• First time not save

49
Admission control

• heuristic to make this decision the most
  frequently accessed objects recently will most
  likely be accessed again. The words frequently
  and recently imply that access frequency of
  objects and a decay function applied on frequency
  are needed.
• an extra space called URL memory cache is
  introduced to store URLs and the associated
  access frequency of the requested objects.

50
Admission control

• If the requested object is cacheable, the process
  of storing the object in disk cache is delayed
  until the same object is accessed again. (Or we
  can say that cacheable objects are not stored in
  disk cache unless they have been accessed before.
  )
• Since the access stream is infinite, the size of
  URL cache must be limited. A replacement policy
  is also needed in URL cache.

51
Admission control operations

• Cache hits
• The operations are similar to the original
  algorithm.
• In addition to unused non-cacheable objects and
  hot objects in memory cache, the cacheable
  objects without disk copies are also the
  candidates for replacement in memory cache.
• Consider the case that a copy of the requested
  object exists in memory cache but not in disk
  cache.
• The reference count associated with the requested
  object in memory cache is incremented by one and
  the data is then stored in disk cache.
• If the evicted objects from memory cache are
  cacheable, its URL along with its reference count
  is then stored in URL cache.

52
Admission control operations

• Cache misses for cacheable objects
• If the requested object is cacheable, the caching
  algorithm checks
• (1) if its URL is not stored in URL cache.
• Replacement operations are performed for
  allocating enough space for holding the requested
  object.
• The URL of the replaced object is now stored in
  URL cache along with its reference count.
• The replacement operations in URL cache must be
  performed.
• The evicted URLs from URL cache are released.
• The requested object itself is not stored in disk
  cache at this moment. Thus, no replacement in
  disk cache is needed.

53
Admission control operations

• Cache misses for cacheable objects
• (2) if the URL of the requested object is stored
  in URL cache,
• its associated record in URL cache is removed,
  the requested object is stored in disk cache, and
  the reference count is set to one.
• Similarly, the replacement operations in disk
  cache must be performed. The URLs of the evicted
  objects from disk cache are stored in URL cache
  and again the replacement operations in URL cache
  are performed.

54
Admission control operations

• Cache misses for no-cacheable objects
• For a cache miss, if the object is non-cacheable,
  the operations are similar to original algorithm.
  If the evicted object from memory cache is
  cacheable and it does not exist in disk cache,
  its URL along with the reference count is stored
  in URL cache.
• Notice that the proposed approach may lose some
  possible hits on the disk cache when objects are
  accessed the second time. However, it removes all
  the disk activity that disk cache stores the
  objects that will not be accessed again before
  evicted.

55
Admission control

• Efficient Management of URL Cache
• A separate hash table similar to that in
  memory/disk cache is used in URL cache to support
  efficient search for the URL of requested object.

• The MD5 of URL is employed as the search key.
• We employ a replacement policy that is based on
  the URL access frequency.
• The least frequently accessed entry in URL cache
  is first selected for replacement.
• A priority queue with access frequency as the key
  is a suitable implementation for such replacement
  policy.

56
Admission control

• Efficient Management of URL Cache
• Each entry of the URL cache records the MD5 of
  URL, access frequency, and a few pointers for
  facilitating priority queue and hash table data
  structures.
• The required memory space for each entry in URL
  cache is constant.
• The size of hash table and priority queue itself
  is small and does not depend on the number of
  entries hashed, thus can be ignored.
• Based the size of the UC trace we studied in this
  paper, keeping all the URLs of the requests from
  one-day period in URL cache is reasonable. This
  accounts for 400k URLs. Therefore, assuming 80
  bytes is needed for each entry in URL cache, 32
  MB of the memory space is needed for the URL
  cache.

57
hit ratio h(S)
0.7
CHU
0.65
heff(S)
HR
h(S)
0.6
0.55
1
2
4
8
32
16
58
Removal frequency

• On-demand Run policy when the size of the
  requested document exceeds the free room in a
  cache. (take time to do the removal)
• Periodically Run policy every T time units, for
  some T.
• If removal is time consuming
• Both on-demand and periodically Run policy at
  the end of each day and on-demand (Pitkow/Recker
  13).

59
On-demand

• Two arguments suggest that overhead of simply
  using on-demand replacement will not be
  significant.
• First, the class of removal policies maintains a
  sorted list. If the list is kept sorted as the
  proxy operates, then the removal policy merely
  removes the head of the list for removal, which
  should be a fast and constant time operation.
• Second, a proxy server keeps read-only documents.
  Thus there is no overhead for writing-back" a
  document, as there is in a virtual memory system
  upon removal of a page that was modified since
  being loaded.

60
How many to remove

• Removal process is stopped when the free cache
  area equals or exceeds the requested document
  size.
• Replace documents until a certain threshold
  (Pitkow and Recker's comfort level) is reached.
