UDP

1
UDP TCP
2
UDP

• UDP is an unreliable transport protocol that can
  be used in the Internet
• UDP does not provide
• flow or error control
• connection management
• guaranteed in-order packet delivery
• UDP is almost a null transport layer

3
UDP Frame Format
32 bits
Source Port
Destination Port
UDP length
UDP checksum (optional)
Data
4
Why UDP?

• Packet oriented
• Not a byte stream, packet integrity
• No connection needs to be set up
• Throughput may be higher because UDP packets are
  easier to process, especially at the source
• The user doesnt care if the data is transmitted
  reliably
• The user wants to implement own transport
  protocol
• E.g. For video

5
The Internet Transport Layer

• The Internet supports two transport layer
  protocols
• The Transport Control Protocol (TCP) for reliable
  service
• The Unreliable Datagram Protocol (UDP)

6
TCP

• TCP provides the end-to-end reliable connection
  that IP alone cannot support
• The TCP connection primitive is known as the
  socket
• A socket may be viewed as a bi-directional pipe
  between two hosts
• Connecting a socket requires a destination IP
  address and a port number

7
TCP Ports

• Ports allow a host to maintain more than one
  connection to a single host
• All port number less than 1024 are reserved for
  standard services like
• Telnet
• FTP
• Email
• News
• etc. (See a UNIX /etc/services file for more)

8
The TCP Protocol

• Frame format
• Connection management
• Flow control
• Congestion control

9
4.1.1 TCP Frame Format
32 bits
Source Port
Destination Port
Sequence Number
Acknowledgement number
Window Size
HL
F I N
S Y N
R S T
P S H
A C K
U R G
Checksum
Urgent Pointer
Options (0 or more 32-bit words)
Data
10
TCP Frame Fields

• Source Destination Ports
• 16 bit port identifiers for each packet (65536
  ports)
• Sequence number
• The packets unique sequence ID
• Acknowledgement number
• The sequence number of the next packet expected
  by the receiver

11
TCP Frame Fields (contd)

• Window size
• Specifies how many bytes may be sent after the
  first acknowledged byte
• Checksum
• Checksums the TCP header and IP address fields
• Urgent Pointer
• Points to urgent data in the TCP data field

12
TCP Frame Fields (contd)

• Header bits
• URG Urgent pointer field in use
• ACK Indicates whether frame contains
  acknowledgement
• PSH Data has been pushed. It should be
  delivered to higher layers right away.
• RST Indicates that the connection should be
  reset
• SYN Used to establish connections
• FIN Used to release a connection

13
Connection Control

• The transport layer must provide higher layers
  with the illusion of an end-to-end connection,
  especially in connectionless packet networks
• Required functions
• Connection setup
• Connection tear-down

14
TCP Connection Establishment

• Three-way Handshake

Host A
Host B
SYN (seqx)
SYN (seqy, ACKx1)
SYN (seqx1, ACKy1)
15
Setting up a Transport Layer Connection

• When an application in one host wants to
  communicate with an application in another host,
  it must set up a transport layer connection to
  that application
• Why a three-way handshake?
• Setting up a connection is not as easy as it seems

16
Setting up a Transport Layer Connection

• Naïve (bad) approach
• Source host sends a connection setup packet to
  the destination host
• Destination host acknowledges the connection
  setup packet, and the connection is considered
  set up

Host A
Host B
Connection Request
Time
Accept Connection
17
Problems with the Naïve approach

• Duplicate connection request or accept
  connection packets in the network
• How can CR and AC packets be duplicated in the
  first place, though?

18
Duplicate Packet Problem

• Consider a network experiencing long delays
  (perhaps due to congestion)

New CR generated after the first one timed
out
A
B
R
R
R
First CR is just arriving to B after being
delayed by congested routers
Result B thinks two connections have been
requested by A
19
Solving the Duplicate Packet Problem

• Introduce sequence numbers and a 3-way handshake
• Sequence numbers must cycle through a large range
  of numbers to make sure there are never two
  packets in the network with the same sequence
  number

20
Three-way Handshake Case 1

• Successful connection

Host A
Host B
CR (seqx)
ACK (seqy, ACKx)
DATA (seqx, ACKy)
21
Three-way Handshake Case 2

• Duplicate Connection Request

Host A
Host B
duplicate
CR (seqx)
ACK (seqy, ACKx)
REJECT (ACKy)
22
Three-way Handshake Case 3

• Dulicate CR and duplicate ACK

Host A
Host B
duplicate
CR (seqx)
ACK (seqy, ACKx)
duplicate
DATA (seqx, ACKz)
REJECT (ACKy)
23
Three-way Handshake Case 4

• Simultaneous Open

Host A
Host B
CR (seqx)
CR (seqx)
ACK (seqy, ACKx)
24
Connection Tear-Down

• Two types of connection tear-down
• Asymmetric Release
• Either host may terminate the connection
• TCP Symmetric Release
• Both sides keep a unidirectional connection to
  the other
• For each connection, the source tears it down
  when no more packets will be sent

25
Problem 1 Loss of Data

• In asymmetric tear-down, data may be lost

Host A
Host B
CR
ACK
DATA
DATA
DR
Lost data
26
Problem 1 Loss of Data (contd)

• Partial solution
• Use 3-way handshake for connection tear-down
• Destination host starts a timer after it receives
  a disconnect request (DR)
• The destination finally releases the connection
  once its acknowledgement is also acknowledged
• If no return acknowledgement arrives within the
  time-out interval, the connection is disconnected

27
Problem 2 Lost tear-down requests

• What if all disconnect requests are lost?

Host A
Host B
DR
Timeout Retry
DR
DR
Timeout Retry
DR
Timeout Retry
Timeout Give up and close connection to B
Connection to A is still open
28
Problem 2 Lost tear-down requests (contd)

• Solution
• Require a host to close a connection if no
  packets have been received for a specified amount
  of time
• Hosts transmit keep-alive packets to keep a
  connection open when they have no data to send

29
TCP Connection Tear-down

• Two double handshakes

Host A
Host B
FIN (seqx)
ACK (ACKx1)
A-gtB torn down
FIN (seqy)
ACK (ACKy1)
B-gtA torn down
30
Flow and Error Control

• The transport layer, like the data link layer,
  must provide a flow-controlled and
  error-controlled link
• The data link layer is hop-by-hop (node-to-node),
  while the transport layer is end-to-end
• The same flow and error control protocols used in
  the data link layer may be used with the
  transport layer
• One additional concern packet resequencing

31
Sliding Window with Out of Order Arrivals

• Sender side window is unaffected by out of order
  reception of packets at the receiver
• Receiver side window, however, behaves
  differently when packets are able to arrive out
  of order
• New techniques required

32
Handling Out-of-Order Packet Arrivals

• Consider a sliding window protocol, size 2
• Receiver Side Window

No packets have arrived
Packet 0 arrives (Generate ACK for packet 0)
Packet 2 arrives out of order
Packet 1 arrives (Generate ACKs for packets 1
and 2)
33
Handling Out-of-Order Packet Arrivals (contd)

• Procedure for receiver-side sliding window
• Packets with sequence numbers outside the sliding
  window are discarded
• When a packet arrives out of order, place a mark
  by the packets sequence number in the window
• When the first packet in the sliding window
  arrives, adjust the start of the sliding window
  up to the next unmarked sequence number.
  Generate acknowledgements for each of the
  sequence numbers the sliding window just passed.

34
Hypothetical TCP session

• (1)remus tcpdump -S host scullyKernel
  filter, protocol ALL, datagram packet
  sockettcpdump listening on all devices
• 151522.152339 eth0 gt remus.4706 gt
  scully.echo S 12642965041264296504(0) win 32120
  ltmss 1460,sack OK,timestamp 71253512 0,nop,wscale
  0gt 151522.153865 eth0 lt scully.echo gt
  remus.4706 S 875676030875676030(0) ack
  1264296505 win 8760 ltmss 1460gt151522.153912
  eth0 gt remus.4706 gt scully.echo .
  12642965051264296505(0) ack 875676031 win 32120

remus telnet scully 7 A ltreturngt A
35
Example TCP session
Timestamp
Source IP/port
Dest IP/port
Packet 1 151522.152339 eth0 gt remus.4706 gt
scully.echo S 12642965041264296504(0) win 32120
ltmss 1460,sackOK,timestamp 71253512 0,nop,wscale
0gt (DF)
Flags
Packet 2 151522.153865 eth0 lt scully.echo gt
remus.4706 S 875676030875676030(0) ack
1264296505 win 8760 ltmss 1460)
Options
Packet 3 151522.153912 eth0 gt remus.4706 gt
scully.echo . 12642965051264296505(0) ack
875676031 win 32120
Window
Start Sequence Number
Acknowledgement Number
End Sequence Number
36
TCP data transfer
Packet 4151528.591716 eth0 gt remus.4706 gt
scully.echo P 12642965051264296508(3) ack
875676031 win 32120
data
Packet 5 151528.593255 eth0 lt scully.echo gt
remus.4706 P 875676031875676034(3) ack
1264296508 win 8760
bytes
37
TCP Flow Control

• TCP uses a modified version of the sliding window
• In acknowledgements, TCP uses the Window size
  field to tell the sender how many bytes it may
  transmit
• TCP uses bytes, not packets, as sequence numbers

38
TCP Flow Control (contd)
Important information in TCP/IP packet headers
Number of bytes in packet (N)
Sequence number of first data byte in packet (SEQ)
N
SEQ
Send
Window size at the receiver (WIN)
Sequence number of next expected byte (ACK)
ACK bit set
ACK
WIN
Recv
Contained in IP header
Contained in TCP header
39
TCP Flow Control (contd)
Receivers buffer
Receiver
Sender
Application does a 2K write
0
4K
Empty
ACK 2048 WIN 2048
Application does a 3K write
Full
Sender is blocked
Application reads 2K
ACK 4096 WIN 0
ACK 4096 WIN 2048
Sender may send up to 2K
40
TCP Flow Control (contd)
Piggybacking Allows more efficient
bidirectional communication
Data from A to B
ACK for data from B to A
N
SEQ
ACK
WIN
A
B
N
SEQ
ACK
WIN
Data from B to A
ACK for data from A to B
41
TCP Flow Control Problems

• The Small Packet Problem
• Occurs when the source sends many small packets
• The Silly Window Syndrome
• Occurs when the destination reads a small number
  of bytes at a time from its buffer

42
The Small Packet Problem (SPP)

• Consider an interactive application where the
  source host sends each keystroke one at a time to
  the destination host
• Each keystroke is 1 byte. After adding TCP/IP
  overhead, a 41-byte packet is generated
• When the destination receives the packet, it
  returns a 40-byte acknowledgement packet
• When the destination removes the byte from its
  buffer, a 40-byte window update packet is sent
• Some applications echo the typed character back
  to the source, creating another 41-byte packet

43
Small Packet Problem (contd)
Receivers buffer
Receiver
Sender
Application does a 1B write
0
4K
Empty
ACK 1 WIN 4095
Application reads 1 B
ACK 1 WIN 4096
Empty
Application does a 1B write
ACK 2 WIN 4095
Application reads 1 B
ACK 2 WIN 4096
Empty
etc.
44
How TCP Solves the SPP

• Nagles Algorithm
• When data is sent one byte at a time, send only
  the first byte
• Buffer all remaining bytes until the first one is
  acknowledged
• After receiving the acknowledgement, send all the
  buffered bytes in one packet
• This algorithm reduces the amount of bandwidth
  required to support interactive applications

45
Nagles Algorithm
Receivers buffer
Receiver
Sender
Application does a 1B write
0
4K
Empty
Application does 15 1B writes
ACK 1 WIN 4095
Application reads 1 B
ACK 1 WIN 4096
Empty
Application does 24 1B writes
ACK 16 WIN 4080
Application reads 15 B
ACK 16 WIN 4096
Empty
etc.
46
Problems with Nagles Algorithm

• Works find if protocol is round trip oriented
• Send packet, wait for response
• What if protocol has several small packets?
• Type ahead with telnet over a slow link.
• X-windows data (plot point, draw-line)
• Socket option to turn off Nagle in Unix.

47
Silly Window Syndrome (SWS)

• Consider an application where the source sends in
  large blocks of data but the destination reads
  bytes from its buffer 1 byte at a time
• Each time the destination reads a byte from its
  buffer, it returns a window update to the source
• The source sees that it is only free to send 1
  more byte so it sends a single byte
• This process repeats itself until all the data
  has been sent, 1 byte at a time

48
Silly Window Syndrome (contd)
Receivers buffer
Receiver
Sender
Application does a 4K write
0
4K
Empty
Sender blocked
Full
ACK 4096 WIN 0
Application does a 1K write
Application reads 1 B
ACK 4096 WIN 1
4095
Full
ACK 4097 WIN 0
Application reads 1 B
ACK 4097 WIN 1
4095
etc.
49
How TCP Solves the SWS

• Clarks Solution
• Prevent the receiver application from reading
  only 1 byte from its TCP buffer
• The receiver application should only read from
  the TCP buffer when it has sufficient application
  buffer space to handle a larger chunk of data
• The sender may also help by refusing to send
  small data packets

50
TCP Retransmission

• When a packet remains unacknowledged for a period
  of time, TCP assumes it is lost and retransmits
  it
• TCP tries to calculate the round trip time (RTT)
  for a packet and its acknowledgement
• From the RTT, TCP can guess how long it should
  wait before timing out
• RTT computation not part of the TCP specification!

51
Round Trip Time (RTT)
Time for data to arrive
Network
Time for ACK to return
RTT Time for packet to arrive at destination
Time for ACK to return from
destination
52
RTT Calculation
Receiver
Sender
0.9 sec
RTT
ACK 2048
2.2 sec
RTT 2.2 sec - 0.9 sec. 1.3 sec
53
Smoothing the RTT measurement

• First, we must smooth the round trip time due to
  variations in delay within the network
• SRTT a SRTT (1-a) RTTarriving ACK
• The smoothed round trip time (SRTT) weights
  previously received RTTs by the a parameter
• a is typically equal to 0.875

54
Calculating the Retransmission Timeout Interval

• The timeout value is then calculated by
  multiplying the smoothed RTT by some factor
  (greater than 1) called b
• Timeout b SRTT
• This coefficient of b is included to allow for
  some variation in the round trip times.

55
Smoothing the RTT measurementExample
Initial SRTT 1.50 a 0.875, b 4.0
RTT Meas.
SRTT
Timeout
1.5 s
1.50
b1.50 6.00
1.0 s
1.50a 1.0(1- a) 1.44
b1.44 5.76
2.2 s
1.44a 2.2(1- a) 1.54
b1.54 6.16
1.0 s
1.54a 1.0(1- a) 1.47
b1.47 5.88
0.8 s
1.47a 0.8(1- a) 1.39
b1.39 5.56
3.1 s
2.0 s
56
Problem with RTT Calculation
Receiver
Sender
Sender Timeout
RTT?
ACK 2048
RTT?
57
Karns Algorithm

• Never update RTT measurements based on
  acknowledgements from retransmitted packets

58
Another Problem with RTT Calculation

• RTT measurements can sometimes fluctuate severely
• smoothed RTT (SRTT) is not a good reflection of
  round-trip time in these cases
• Solution Use Jacobson/Karels algorithm
• Error RTT - SRTT
• SRTT SRTT (a Error)
• Dev Dev d (Error - Dev)
• Timeout SRTT (b Dev)

59
Jacobson/Karels AlgorithmExample
Initial SRTT 1.50, Dev 0 a 0.125, d 0.25,
b 4.0
Error RTT - SRTT SRTT SRTT (a Error) Dev
Dev d (Error - Dev) Timeout SRTT (b
Dev)
RTT Meas.
SRTT
Error
Dev.
Timeout
1.5 s
1.50
0.0
0.00
1.50
1.0 s
1.44
-0.50
0.13
1.94
2.2 s
1.54
0.76
0.28
2.67
1.0 s
1.47
-0.54
0.35
2.85
0.8 s
1.39
-0.67
0.43
3.09
3.1 s
2.0 s
60
TCP Congestion Control

• Recall Network layer is responsible for
  congestion control
• However, TCP/IP blurs the distinction
• In TCP/IP
• the network layer (IP) simply handles routing and
  packet forwarding
• congestion control is done end-to-end by TCP

61
TCP Congestion Window

• TCP introduces a second window, called the
  congestion window
• To determine how many bytes it may send, the
  sender takes the minimum of the receiver window
  and the congestion window
• Example
• If the receiver window says the sender can
  transmit 8K, but the congestion window is only
  4K, then the sender may only transmit 4K
• If the congestion window is 8K but the receiver
  window says the sender can transmit 4K, then the
  sender may only transmit 4K

62
TCP Congestion Control

• The TCP Congestion Control algorithm makes use
  of
• Slow Start
• Congestion Avoidance (Linear Increase Thresholds)

63
TCP Slow Start

• TCP defines the maximum segment size as the
  maximum size a TCP packet can be (including
  header)
• TCP Slow Start
• Congestion window starts small, at 1 segment size
• Each time a transmitted segment is acknowledged,
  the congestion window is increased by one maximum
  segment size

64
TCP Slow Start (contd)
Congestion Window Size
Event

1K A sends 1 segment to B B ACKs the
segment 2K A sends 2 segments to B B ACKs both
segments 4K A sends 4 segments to B B ACKs all
four segments 8K A sends 8 segments to B B
ACKs all eight segments 16K and so on
65
TCP Slow Start (contd)

• Congestion window size grows exponentially (i.e.
  it keeps on doubling)
• Packet losses indicate congestion
• Packet losses are determined by using timers at
  the sender
• When a timeout occurs, the congestion window is
  reduced to one maximum segment size and
  everything starts over

66
TCP Slow Start (contd)
Timed out Transmissions
Congestion window
Transmission Number
1 Maximum Segment Size
67
TCP Slow Start (contd)

• TCP Slow Start by itself is inefficient
• Although the congestion window builds
  exponentially, it drops to 1 segment size every
  time a packet times out
• This leads to low throughput

68
TCP Linear Increase Threshold

• Establish a threshold at which the rate increase
  is linear instead of exponential to improve
  efficiency
• Algorithm
• Start the threshold at 64K
• Start the congestion window size at 1 segment
  size
• Increase the congestion window size exponentially
  using slow start until the threshold is reached
• Once the threshold is passed, only increase the
  congestion window size by 1 segment size for each
  congestion window of data transmitted
• If a timeout occurs, reset the congestion window
  size to 1 segment and set threshold to 1/2 of
  MIN(sliding window, congestion window)

69
TCP Linear Increase Threshold
Example Maximum segment size 1K
Timeout occurs when MIN(sliding window,
congestion window) 40K
Congestion window
Thresholds
40K
32K
20K
1K
Transmission Number
70
TCP Fast Retransmit

• Another enhancement to TCP congestion control
• Idea When sender sees 3 duplicate ACKs, it
  assumes something went wrong
• The packet is immediately retransmitted instead
  of waiting for it to timeout

71
TCP Fast RetransmitExample
Receiver
Sender
MSS 1K
ACK of new data
ACK 2048 WIN 31K
Duplicate ACK 1
ACK 2048 WIN 30K
Duplicate ACK 2
ACK 2048 WIN 29K
Fast Retransmit occurs (2nd packet is
now retransmitted w/o waiting for it to timeout)
Duplicate ACK 3
ACK 2048 WIN 28K
ACK 2048 WIN 27K
ACK 7168 WIN 26K
72
TCP Fast Recovery

• Yet another enhancement to TCP congestion control
• Idea Dont do a slow start after a fast
  retransmit
• Instead, use this algorithm
• Drop threshold to 1/2 of MIN(sliding window,
  congestion window)
• Set congestion window to threshold 3 MSS
• For each duplicate ACK (after the fast
  retransmit), increment congestion window by MSS
• When next non-duplicate ACK arrives, set
  congestion window equal to the threshold

73
TCP Fast RecoveryExample
Sender
SW29K,TH15K, CW20K
Continuing with the Fast Retransmit Example...
SW28K,TH15K, CW20K
ACK 2048 WIN 28K
Fast Retransmit Occurs
MSS1K Sliding Window (SW) Congestion Threshold
(TH) Congestion Window (CW)
SW28K, TH10K, CW13K
ACK 2048 WIN 27K
SW27K, TH10K, CW14K
ACK 7168 WIN 26K
SW26K, TH10K, CW10K
74
TCP recovery algorithm

• Should know because
• Behavior of TCP connections varies with timeout
  algorithm
• Many applications use TCP
• HTTP(Browsers), FTP, Chat rooms
• TCP timeouts can make the network seem slow, but
  really its the Timeout algorithm
