Selftuning Memory Management

1
Adaptive Query Processing Optimization
The survival of the fittest is the ageless law
of nature, but the fittest are rarely the strong.
The fittest are those endowed with the
qualifications for adaptation, the ability to
accept the inevitable and conform to the
unavoidable, to harmonize with existing or
changing conditions. source unknown
2
Memory Adaptive Operators

• Assign a fixed amount of memory to each operator
  inside queries
• Characteristics of each operator (sort hash
  join) are different
• Operator requirements depend on the input data
  size
• Need to know application workload to estimate
  memory needed at different points in time
• Give each operator an amount of memory based on a
  size estimate of its input data, e.g., sort 10GB,
  use 40MB sort 100GB, use 400MB
• The size estimates are made by the optimizer and
  can be inaccurate (off by orders of magnitude)
• The memory usage is not constrained by the
  workload
• An operator adapts its memory usage to respond to
  the memory demand in the system

3
Challenge Sort 1Gb of data with 1Mb of RAM
4 3
1 2
???
6 2
2 3
9 4
3 4
8 7
4 5
5 6
6 6
3 1
7 8
2
9
Main memory buffers
Disk
Disk
4
A Simpler Problem Combine Sorted Files
2 3
6 4
3 2
6 4
3 2
3
3 2
2
7 4
7 4
9 8
Output Buffer
Input Buffer
Main memory buffers
Disk
Disk
5
A Simpler Problem Combine Sorted Files
2 3
6
4 4
4
4 4
7 4
7
6 7
Output Buffer
9 8
Input Buffer
8 9
Main memory buffers
Disk
Disk
6
What if there are many more runs?
6 4
3 2
7 4
9 8
7 5
4 1
5 3
9 5
Main memory buffers
Disk
Disk
7
What if there are many more runs?
1 2 3 3 4 4 4 5 5 5 6 7 7 8 9 9
6 4
3 2
4 4
3 2
7 6
9 8
7 4
9 8
7 5
4 1
5 4
3 1
5 5
9 7
5 3
9 5
8
What if there are more memory?
6 4
3 2
7 4
9 8
7 5
4 1
5 3
9 5
Main memory buffers
Disk
Disk
9
What if there are more memory?
1 2
6 4
3 2
3
9 8
7 4
1
2 1
4 1
4
7 5
5 3
9 5
Main memory buffers
Disk
Disk
10
What if there are more memory?
1 2
6 4
6 4
3 3
9 8
7 4
3 3
4
7 5
5
9 5
Main memory buffers
Disk
Disk
11
Multi-way Merge Sort

• Given k sorted files (runs), we can merge them
  into larger sorted runs, and eventually produce
  one single sorted file.
• To sort a very large (unsorted) file, we can do
  it in 2 steps
• Generate sorted runs
• Merge sorted runs (we already know how to do
  this)

12
How to generate sorted runs?

• Read as many records as possible into memory
• Perform in-memory sort
• Write out sorted records as a sorted run
• Repeat the process until all records in the
  unsorted files are read

13
How to generate sorted runs?
7 2 8 3 4 4 6 5 9 5 4 1 7 3 9 5
Main memory buffers
Disk
Disk
14
How to generate sorted runs?
7 2
8 3
9 5 4 1 7 3 9 5
6 5
4 4
Main memory buffers
Disk
Disk
15
How to generate sorted runs?
2 3
4 4
9 5 4 1 7 3 9 5
7 8
5 6
Main memory buffers
Disk
Disk
16
How to generate sorted runs?
2 3 4 4 5 6 7 8
9 5 4 1 7 3 9 5
Main memory buffers
Disk
Disk
17
How to generate sorted runs?
2 3 4 4 5 6 7 8
1 3 4 5 5 7 9 9
Main memory buffers
Disk
Disk
18
Phase 1
Phase 2
Sorted runs
Unsorted file
Sorted file
19
Multi-way Merge Sort

• To sort a file with N pages using B buffer pages
• Phase 1 use B buffer pages. Produce ?N / B?
  sorted runs of B pages each.
• 1 pass (read write) over the file
• Phase 2 merge B-1 runs each time
• ? log B-1 ?N / B ? ? passes

20
Cost of Multi-way Merge Sort

• Number of passes 1 ? log B-1 ?N / B ? ?
• Cost 2N ( of passes)
• E.g., with 5 buffer pages, to sort 108 page file
• Phase 1 (pass 0) ?108 / 5? 22 sorted runs of 5
  pages each (last run is only 3 pages)
• Phase 2
• Pass 1 ?22 / 4? 6 sorted runs of 20 pages each
  (last run is only 8 pages)
• Pass 2 2 sorted runs, 80 pages and 28 pages
• Pass 3 Sorted file of 108 pages

21
Memory Adaptive External Sort

• In-memory sort phase
• While there is more input mem space
• Read data into buffer
• Sort the buffer
• Check/adjust mem
• In-memory merge phase
• If no more input this is first run
• Merge buffers to produce output and STOP
• If no more mem or this is the last run
• Write sorted run into temp table
• If there is more input
• Check/adjust memory
• Go to In-Memory sort phase
• External merge phase
• If there are multiple runs in temp table
• Check/adjust memory
• Merge them to produce the final results
• For multipe pass merge
• Check/adjust memory before each merge

22
In-memory Sort Phase
7 2 8 3 4 4 6 5 9 5 4 1 7 3 9 5
8 3 4 4 6 5 9 5 4 1 7 3 9 5
4 4 6 5 9 5 4 1 7 3 9 5
2 7
7 2
8 3
3 8
Main memory buffers
Disk
Disk
23
In-memory Sort Phase
2 7
4 4
9 5 4 1 7 3 9 5
5 6
3 8
Main memory buffers
Disk
Disk
24
In-memory Merge Phase
2 3 4 4 5 6 7 8
9 5 4 1 7 3 9 5
Main memory buffers
Disk
Disk
25
Hash-Join

• Partition both relations using hash fn h R
  tuples in partition i will only match S tuples in
  partition i.

• Read in a partition of R, hash it using h2. Scan
  matching partition of S, search for matches.

26
Observations on Hash-Join

• partitions k lt B (why?), and B-1 gt size of
  largest partition to be held in memory. Assuming
  uniformly sized partitions, and maximizing k, we
  get
• k B-1, and M/(B-1) B-1, i.e., B-1 must be gt

• If we build an in-memory hash table to speed up
  the matching of tuples, a little more memory is
  needed.
• In partitioning phase, readwrite both relns
  2(MN). In matching phase, read both relns MN
  I/Os.

27
Memory Adaptive Hash Join

• Partitioning Phase
• Split R into k partitions (k ltlt M) based on hash
  function h
• Each partition has at least one page
• Pages belonging to same partitions are chained up
• If memory is not enough, flush out some
  partitions (keeping at least one page)
• Split S into k partitions using h
• If a full partition of R is in memory, then can
  probe it immediately otherwise just write to
  output buffer
• It is possible that some of R partitions may
  still be flushed out at this time
• Need at least k pages
• Joining Phase
• For remaining partitions of R
• Read R partition and build hash table in memory
• Read corresponding S partition to probe
• If space is not enough, can further split into
  subpartitions recursively or use nested loops
  join (minimum requirement)
• Can acquire more memory if available

28
Query Optimization

• Query optimizer finds the best query evaluation
  plan
• For single table selection queries, it determines
  the best access plans
• For two-way joins, it determines the join methods
• For complex queries, it finds the cheapest plan
• What is the problem with traditional optimizer?
• Sometimes database optimizers choose query plans
  that are sub-optimal by orders of magnitude
• Errors in estimation (statistics)
• Assumptions in costing (independence of join
  attributes, uniform distribution)

29
Estimation Error

• select from R, S where R.aS.a and R.bgtK1 and
  R.cgtK2

s
s(R) actual
A
buffer
!
s(R) estimated
!
B
30
Single-Point Limitation
A
B
31
Re-optimization Overview

• Compute plan as normal
• Add check operators to plan to
• check when plan becomes sub-optimal
• check for significant discrepancies between
  estimated and observed values
• Execute and react approach
• Trigger re-optimization when checks fail
• Else, proceed

32
Choosing PlansOptimization vs. Re-Optimization

• Traditional optimizer chooses plan P

• Re-optimizer chooses same plan P and adds checks

33
Re-optimization Limitations

• Re-optimization is expensive(could avoid it by
  using robust plans)
• May lose partial work
• If start on P1 and re-optimize to P2, will repeat
  scan on R

P1 is risky! P2 is robust.
34
Re-optimization Limitations

• Limited information collected at run-time
• Only detects when to re-optimize
• E.g., detects that some selectivity gt 5
• But, future re-optimization needs more
  information
• E.g., what is the true value of selectivity?
• May thrash without that knowledge

35
Proactive Re-Optimization in a Nutshell

• If DBMS knows
• re-optimization can happen

It can (proactively) pick plans that are better
than picking a plan and then (reactively)
re-optimizing if something goes wrong.
It should try to avoid it
It can (proactively) collect statistics needed
for future re-optimization steps for the same
query.
It should plan for it
36
Proactive Re-optimization Architecture
Optimization
QUERY
2. Use bounding boxes to pick robust or
switchable plans
CATALOG
Execution
37
Bounding BoxesRepresenting Uncertainty

• Interval around estimate is
• wide if optimizer uncertain about estimate
• narrow if optimizer certain about estimate
• How is uncertainty measured?
• From the way the statistic is estimated, e.g.
• Histogram -gt very certain
• Multiplication of selectivities -gt uncertain
• Default guess -gt very uncertain
• Etc.

38
Bounding BoxesRepresenting Uncertainty

• Interval around estimate is
• wide if optimizer uncertain about estimate
• narrow if optimizer certain about estimate

S
Bounding box
high
est.
low
s(R)
high
estimated
low
39
Bounding BoxesPlan Costing and Pruning

• Costing - Computes three costs per each plan
  tree
• (2-dim bounding box using cardinality
  estimates from sub-plans)
• Pruning
• For each join subset and interesting order
• Finds 3 plans BestLow, BestEst, and BestHigh
• The plans with lowest CLow, CEst, and CHigh,
  respectively
• All others are pruned

Cost?
S
CHigh, cost here
CEst, cost here
CLow, cost here
HHJ
high
est.
low
s(R)
S
s(R)
high
estimated
low
40
Bounding BoxesOptimization and Execution

• Bounding boxes define what optimizer should plan
  for
• Goal of optimization
• Find a (set of) plan(s) that behaves well in
  bounding box
• At run-time
• If observed stats fall inside bounding box keep
  going
• Else, re-optimize

41
Switchable Plans Selecting Plans
BestEstP1
BestHighP2
BestLowP1

• At the end of plan enumeration there are three
  seed plans

• Four cases
• The seeds are the same plan
• One of the seeds is robust
• A switchable plan can be created from them
• No single plan, not robust, not switchable

42
Optimal Plan

• 1 Plan is optimal for all 3 points
• Choice is easy

43
Robust Plan

• 1 plan is, or close to, optimal for all 3 points
• 1 plan can be safely chosen

44
Switchable Plan

• There is a plan with close to optimal cost plan
  at each point
• Additional Requirements
• The decision can be deferred
• Actual statistics must lie within bounding box
• It is possible to switch between the plans

45
Switchable Plans

• Switchable Plan Goals
• Pick plan only after uncertainty resolved
• Do no lose or repeat work
• Plans are switchable if
• Have different root operator
• Have the same sub-plan for deep input of root
• Have the same base table as other input

E.g.
INLJ
Hash2
Hash3
Index Seek on T
Scan T
Scan T
Hash1
Hash1
Hash1
Scan R
Scan S
Scan R
Scan S
Scan R
Scan S
46
What if Seeds arenot Switchable?

• May still be able to generate other seeds from
  those seeds such that they are robust and
  switchable
• Pick a seed, and derives a set of plans that are
  switchable with that seed
• If one of the resultant plans cost is close to
  that of the other seeds, it can replace them as
  part of the switchable plans

47
Implementation of a Switchable Plan
Switchable Plan
T
Hash1
Scan R
Scan S

• Buffer tuples until a tuple random sample is
  obtained
• Compute estimate and pass it up to switch
  operator
• Switch operator instantiates correct operator
• No work lost or repeated

48
Observing Statistics at Run-Time

• Goal 1 Detect when to re-optimize
• Detect when outside bounding box
• Goal 2 Must be cheap
• To minimize impact on execution
• Goal 3 Must be quick
• To avoid spending time in wrong plan
• Goal 4 Must be accurate
• To avoid re-optimization thrashing

49
The IdeaRandom Sample Prefix

• Prefix output of operators with random sample of
  entire output

Normal output without random prefix
a
b
c
d
e
f
g
h
i
j
h
a
e
Output with random prefix

• When eos punctuation arrives system can
• Compute estimate based on random sample
• Determine if bounding box violation happened
• Use revised estimate in future re-optimization

50
ImplementingRandom Sample Prefixes

• Assume random samples of base relations
• For each relation R, there is an R_sample
• R_sample is a random sample of R
• Modified scan operator
• scan R_sample
• emit eos
• scan R skipping tuples in R_sample
• Similarly for indexed scan

51
ImplementingRandom Sample Prefixes - Joins

• Modified BNLJ and INLJ operators
• Pass eos from outer relation
• Ignore eos from inner relation
• True random sample of join if outer is FK side
• Hash join

eos
eos
Then, do second pass as in normal hash
Read S into memory until EOS of S
Read all of R, partition, probe S sample
Read rest of S, partition, probe R, output tuples
R
S sample
S
R sample
S sample
rest of R
rest of S
R
S
52
Wrap-up Example s(A)Cs(O)
Assume error in Estimate s(A)!
53
Conclusion

• Runtime adaptation is needed to achieve improved
  performance
• Memory adaptive algorithms are needed
• Re-optimization has to be carefully exploited to
  avoid thrashing
