Title: ECE 662 Microwave Devices


1
ECE 662Microwave Devices
  • Microwave Materials,
  • Diodes and Transistors
  • February 3, 2005

2
(No Transcript)
3
(No Transcript)
4
Two-Terminal Negative Resistance Devices
Varactor small pn diodes that are operated as
nonlinear capacitors In the reverse bias region
5
Application of Negative Resistance Devices
6
Varactor
  • Varactor Variable reactor
  • Use of voltage-variable properties (such as
    capacitance) of reversed-biased p-n junctions
  • Reverse biased depletion capacitance is given by
    Cj (Vb VR)-n or Cj (VR)-n for VR gtgt Vb,
    where n ? for a linearly graded junction and n
    ½ for an abrupt junction.
  • Can further increase the voltage sensitivity by
    using a hyperabrupt junction having an exponent n
    greater than ½.

7
Charge Depletion Regions
8
Charge Depletion Regions
9
Varactor
  • Present applications mostly for harmonic
    generation at millimeter and sub millimeter wave
    frequencies and tuning elements in various
    microwave applications.
  • A common varactor is the reversed biased Schottky
    diode.
  • Advantages low loss and low noise.
  • Produces only odd harmonics when a sinusoidal
    signal is applied, so a frequency tripler can be
    realized without any second harmonic.

10
Varactor
11
Varactor Frequency Multipliers
  • Provide LO power to sensitive millimeter and
    sub-millimeter wavelengths receivers.
  • Schottky doublers can deliver 55 mW at 174 GHz
  • Heterostructure Barrier Varactor Diodes acting as
    triplers deliver about 9mW at 248 GHz.

12
Crossed Waveguide Frequency Multiplier Ref. Golio
13
Varactor Devices
  • Lower frequencies reversed biased semiconductor
    abrupt p-n juction diodes made from GaAs or Si.
  • Higher frequencies Schottky diodes
    (metal-semiconductor junction diodes
  • High frequencies and power handling
    heterostructure barrier varactor several
    barriers stacked epitaxially

14
Tunnel Diode
  • To achieve microwave capability
  • Device dimensions must be reduced
  • Parasitic capacitance and resistance must be
    minimized.
  • Tunnel diode
  • Associated with a quantum tunneling phenomenon
  • Tunneling time is very short permitting its use
    well into the millimeter region
  • Used for low power microwave application
  • Local oscillator, detectors, mixers, frequency
    locking circuit
  • Low cost, light weight, high speed, low-power
    operation, low noise

15
Tunnel Diode
  • In classical case, particle is reflected if Elt
    potential barrier height of V0
  • In quantum case particle has a finite probability
    to transmit or tunnel the potential barrier
  • Single p-n junction which has both p n sides
    heavily doped?depletion regions very narrow and
    tunneling distance is small 50 to 100 Å
  • (1 Å 10-8 cm10-4 ?m)
  • High dopings cause Fermi levels within allowable
    bands

16
p-n junction
17
Tunnel Diode- abrupt junctions of heavily doped
p n semiconductor material pn1019
18
Tunnel Diode
  • 1) For zero bias - electrons tunneled through
    narrow barrier at equal rates in each direction.
    Net current zero.
  • 2) Small forward bias - electrons at bottom of
    conductor band on n side are are raised to energy
    levels corresponding to unoccupied energy levels
    on the p side. Therefore, tunneling current in
    forward direction with increases with bias.

19
Tunnel Diode
  • 3) For still larger bias, more and more electrons
    are raised to levels lying opposite the forbidden
    band on p side to which to which no tunneling is
    possible therefore the current reduces with
    increasing bias.
  • 4) As bias increases further, the current remains
    small until minority carrier injection similar to
    conventional diodes predominates.

20
Tunnel Diode
  • 5) with reverse as an increasing number of
    electrons on the p side find themselves opposited
    allowed and empty levels in the conduction band
    on the n side therefore tunneling increases
    rapidly with increasing bias.

21
Application of Negative Resistance Devices
Note negative resistance
22
Tunnel Diode
Note that small changes in ?VB result in large
changes in i hence VRL
Negative Resistance Devices I V, 180? out
of phase I2R ?power absorbed, but if R ? R
then power generated
23
(No Transcript)
24
(No Transcript)
25
Summary of Tunnel Diode
  • Quantum Tunneling Phenomena
  • Tunneling time short - mm waves
  • Low-power applications
  • n-p sides so heavily doped that the fermi levels
    lie within the conduction and valence bands
  • Good for extreme speed
  • Rate of tunneling can change as fast as energy
    levels can be shifted
  • Devices such as transistors give more power, but
    traditionally have suffered in speed due to rate
    of diffusion of charge changing.

26
Solid-State Device Power Output vs Frequencyref
Sze and modifiedby Tian
27
Transistors
  • Bipolar (Homojunction)
  • Inexpensive, durable, integrative, relatively
    high gain
  • Bipolar (Heterojunction)
  • High speed switching
  • Field Effect Transistors
  • Junction
  • MESFET, MOSFET, High Electron Mobility (HEMT)
  • Av as well as Qc, better efficiency, lower noise
    figure, higher speed, high input impedance

28
(No Transcript)
29
pnp transistor with all leads grounded ref.
Sze
30
pnp transistor in the active mode of
operation ref. Sze
31
Various current components in a p-n-p transistor
under the active mode of operation. ref. Sze
32
Bipolar Transistor Gain (f)
33
Bipolar Transistor Gain (f) cont.
34
Bipolar Transistor High Freq.
35
Bipolar Transistor Gain (f)
36
Field-Effect Transistors
  • Advantages
  • 1) Voltage gain and current gain (simultaneously)
  • 2) Higher efficiency compared to bipolar
  • 3) Lower Noise Figure
  • 4) Higher fmax and consequently higher operating
    frequency
  • 5) High input resistance, up to several Meg

37
Field-Effect Transistors
V is changed by Vgs to change channel size
reverse bias between Source and gate to adjust
channel forward bias between source and Drain for
current flow (majority carrier)
38
Field-Effect Transistors
39
Field-Effect Transistors
  • To get larger output powers use larger gate
    widths
  • 1W / 1 mm gate width
  • Single gate width 250 to 500 ?m
  • Use multiple gates (12) to increase power

40
Technology Alternatives - 1 Ref MPD, Nov 2002,
Amcom Communications
  • Material technologies (GaAs, Si, SiGe)
  • Process technologies (Epitaxy, Implant)
  • Device technologies (BJT, HBT, MESFET, HEMT)
  • Power levels less than 1 W
  • BJT, HBT (use single polarity supply and offer
    cost advantages at these power levels)
  • GaAs, MESFETs, pHEMTs (better linearity and
    efficiency)

41
Technology Alternatives - 2 Ref MPD, Nov 2002,
Amcom Communications
  • High power levels above 10 W
  • Si LDMOS (attractive at frequencies below 2 GHz)
  • Wide band gap devices such as SiC, MESFETs, GaN,
    HEMTs (higher power, higher voltage and
    promising linearity performance)

42
Terrestrial wireless systems Ref MPD, Nov 2002,
Amcom Communications
  • Broadband internet access operate in the
    frequency range of 1 6 GHz.
  • Low cost subscriber units less than 1 W transmit
    power SiGe, GaAs HBT, MESFET and pHEMT MMICs.
  • Higher power (2-10 W) GaAs FTE, pHEMT (optimize
    RF power output and best linearity performance
    over the specific band of interest while keeping
    the cost low)

43
(No Transcript)
