Using Templates for Generalization in RESOLVE

1
Using Templates for Generalization in RESOLVE

• Annatala Wolf
• 222 Lecture 1

2
Templates

• A template is a definition for a type thats
  missing a key piece of information the names of
  one or more classes it uses. In order to create
  objects of a templates type, you have to
  instantiate it first, by filling it in to
  complete the template.
• In this course, we use templates to design
  components that will work with many different
  types of data. This is what templates are
  typically used for in C, and what generics (a
  similar paradigm) are used for in Java and C.

3
Unconventional Use

• We will also use templates to decouple component
  dependencies, for example, by plugging in which
  version of a kernel we want to use.
• This is not typically how things are done in C.
  Usually, you would use something called
  polymorphism to accomplish the same task (though
  the task is important, however you do it).
• The downside to this strategy is complex error
  messages that come from mistakes in template
  instantiations and from errors involving template
  types and/or kernel Representations.

4
Instantiation

• When you fill in a template, this is called
  instantiating the template. To do this, you
  have to plug a class name (a type) into each
  template slot.
• Until you instantiate a template, you cant use
  it to make objects. For example, Set is a
  template parameterized by Item. You cant make a
  Set object until you fill in what Item type the
  Set will hold.

5
Instantiation in Resolve/C

• Normally, templates are filled in directly when
  they are used to declare objects, like so
• // typical usage, but not in Resolve/C
• SetltTextgt myTextSet
• However, in this class we will instantiate
  templates in a way that creates a new type you
  can use just like any non-template type. We
  always do this at the top of the file, after the
  include statements.

6
Template Expectations

• We dont expect you to write template
  declarations, since the way we use them in this
  course is unusual and complicated.
• However, you do need to be able to instantiate
  templates (fill them in). You should know the
  syntax for instantiation in case you need to fill
  in a template on a test. It will also help you
  in Lab 2, where you can instantiate your own
  concrete instances.

7
Template Declaration (Simplified)
Item a template parameter to Sequence_Kernel_3

• concrete_template lt
• concrete_instance class Item, ...
• / Other template parameters go here too.
  There are typically a bunch, since we
  use templates to decouple everything, so
  an actual declaration is complex. But
  you wont ever have to read or write one. /
• gt
• class Sequence_Kernel_3
• implements
• abstract_instance Sequence_Kernel ltItemgt,
• encapsulates
• concrete_instance Rep
• / the operation bodies go here /

the name of this concrete template class
the abstract class (the specification) this class
implements, with Item plugged in
8
Template Instantiation (Client)

• include CT/Set/Set_Kernel_1a_C.h
• concrete_instance
• class Set_Of_Text
• instantiates
• Set_Kernel_1a_C ltTextgt

what we want to call the new type were creating
the concrete type were plugging into the
template parameter for Item
the name of the concrete template we are
instantiating
9
Using Templates

• Once youve instantiated your Set_Of_Text, you
  can use it just like any other type.
• object Set_Of_Text myHappySet
• object Text name Double Rainbow
• myHappySet.Add(name)
• The abstract specification in Set_Kernel will
  describe what a Set does, in terms that make
  sense no matter what type is plugged into Item.

10
Four Component Types

• Abstract Instance (e.g. AM_PM_Clock_Kernel)
• Prototype and formal description of contract for
  a particular kind of object
• Abstract Template (e.g. Set_Kernel)
• Prototype and formal description of contract for
  a parameterized kind of object (described in
  general)
• Concrete Instance (e.g. AM_PM_Clock_Kernel_1)
• Implementation code for an abstract instance or,
  the result of instantiating a concrete template
  by filling in the template parameters
• Concrete Template (e.g. Set_Kernel_1)
• Implementation code for an abstract template
  (written in a general way, so it can work with
  whatever Item is)

11
Combining Instantiations

• concrete instance
• class Set_Of_Integer
• instantiates
• Set_Kernel_1a_C ltIntegergt
• // Now that Set_Of_Integer is a concrete
  instance,
• // it can fill a template just like any other
  type!
• concrete instance
• class Power_Set
• instantiates
• Set_Kernel_1a_C ltSet_Of_Integergt

12
Containers

• Many libraries for C and Java maintain
  collection objects designed to hold a dynamic
  number of items in some fashion. These
  collections are usually designed to hold many
  different kinds of items.
• In Resolve/C we call our collection objects
  containers. Common examples of Resolve/C
  containers
• Sequence totally ordered, random-access
• Set unordered, named access
• Queue totally ordered, FIFO-based access

13
Sequence

• Intuitively, a sequence is like a flexible array.
• You can insert in the middle. Elements to the
  right all move down one position, and it gets
  longer.
• You can remove from the middle elements to the
  right move back one position, and it gets
  shorter.
• You cant go past the end of the sequence.
• Mathematically, sequence is modeled by string of
  Item.
• The default value is the empty string ltgt
• We describe position from left to right lt0, 1,
  2gt
• Item is the template parameter. A given
  sequence can only hold elements of a single type.

14
Sequence Kernel Operations

• Add(pos, x)
• requires 0 pos self
• Remove(pos, x)
• requires 0 pos lt self
• Accessor pos
• requires 0 pos lt self
• Length()
• requires true
• (in other wordsno requires clause)

15
SequenceltCharactergt ? Text

• There is one key difference between a Sequence of
  Character and a Text object Add(pos, x) consumes
  x for Sequence, and preserves x for Text.
• The reason why has to do with how we move
  information around in Resolve/C, and the fact
  that Item could be anything, including something
  we cant copy. With Text, we know we can copy
  its elements (Character is copyable). But we
  want to write Sequence so it will work with any
  type, even one that cant be copied. Hence, it
  must be consumes.

16
Reading Specifications

• global_procedure Smooth (
• preserves Sequence_Of_Integer s1,
• produces Sequence_Of_Integer s2
• )
• /!
• requires
• s1 gt 0
• ensures
• s2 s1 - 1 and
• for all i, j integer,
• a, b string of integer
• where (s1 a ltigt ltjgt b)
• (there exists c, d string of
  integer
• (s2 c lt(ij)/2gt d and c
  a))
• !/

Eep! Im scared!
17
Breaking The Specification Down

• Sequence is modeled by string of Item (in this
  case, Integer), so s1 and s2 will be type string
  of integer in the spec.
• /!
• s2 s1 - 1 and
• for all i, j integer,
• a, b string of integer
• where (s1 a ltigt ltjgt b)
• (there exists c, d string of
  integer
• (s2 c lt(ij)/2gt d and c
  a))
• !/

Part 1
Part 2
18
The easy part

• // requires s1 gt 0
• // ensures s2 s1 - 1 ...
• This tells us s2 will be one item shorter than
  s1. It makes sense, since s1 cant be empty.
• So if s1 has one item in it, s2 must be the empty
  string. But for longer s1 values, we need more
  information.
• Since s2 is produces-mode, all of its values will
  have to come from s1, somehow.

19
Quantifiers For All

• When we model strings of items, frequently we
  will want to talk about what happens throughout
  the entire string. In this case, we are talking
  about all possible ways that you can arrange s1,
  so that there is an ltigt next to a ltjgt all
  consecutive pairs i j.
• The strings a and b are merely placeholders. It
  doesnt matter what they containtheyre just
  there so we can say lets talk about consecutive
  pairs of integers in s1.
• for all i, j integer,
• a, b string of integer
• where (s1 a ltigt ltjgt b) ...

20
Vacuously True

• If there are no integers and strings that make
  the statement true, then the spec tells us
  nothing. Its already vacuously true because
  there are no cases for us to test.
• This could only happen when s1 lt 2. But we
  already know what happens when s1 1, and s1
  cant be 0, so were good.
• for all i, j integer,
• a, b string of integer
• where (s1 a ltigt ltjgt b) ...

we need at least two integers in the string for
this case to happen
21
Quantifiers There Exists

• With there exists, were usually making some
  assertion about the state of an object. Here, we
  say what the value of s2 has to be, based on the
  value of s1.
• there exists c, d string of integer
• (s2 c lt(ij)/2gt d and c a)

this part tells us what we should find in s2
this part tells us where it should be in the
string
22
What are the values?

• The values in s2 are just the smoothed (averaged)
  values of each pair of integers. This is why s2
  is one shorter than s1. For example, if there
  are six integers in s1, there are only five
  consecutive pairs.
• s2 c lt(ij)/2gt d

each integer in s2 is the average of two
consecutive integers from s1
23
Where do the values go?

• By adding some information about those
  placeholder string variables, we can describe
  exactly how the two strings match up.
• Can you figure out how they line up? (Hint
  Just ignore b and d!)
• s1 a ltigt ltjgt b
• s2 c lt(ij)/2gt d
• c a

24
The Meaning of Smooth( )

• The procedure simply averages the consecutive
  values of s1, and produces s2 with the averaged
  values in the same order in which the pairs
  appeared in s1.
• This spec is a good example because its about
  the hardest thing you would be expected to read
  and interpret. Dont let quantifiers scare you.
  Most of the string variables we create with
  quantifiers are only there as placeholders, so we
  can talk about multiple cases at the same time.

25
Recursively-Defined Specifications

• global_procedure Weird(alters Sequence_Of_Integer
  switch)
• /! requires
• (switch mod 2) 0
• ensures
• switch SWITCH(switch)
• math_function SWITCH(string of integer s) string
  of integer
• if s 0 then SWITCH(s) empty string
• else if s 2 then there exists a, b
  integer
• where (s ltagt ltbgt and SWITCH ltbgt
  ltagt)
• else
• there exists a, b integer t string of
  integer
• where (s ltagt ltbgt t and
• SWITCH(s) ltbgt ltagt
  SWITCH(t))
• !/

A math_function is just a piece of a
specification. It is used to make specs easier
to read. It is not code. You cant make a
call to SWITCH(s).
26
The Specification for Weird( )

• requires
• (switch mod 2) 0
• The sequence must contain an even number of
  integer elements.
• ensures
• switch SWITCH(switch)
• Weird(switch) will alter the sequence you pass it
  by doing whatever SWITCH describes.

27
Interpreting SWITCH(s)

• SWITCH changes one string of integer into a
  different string of integer.
• math_function SWITCH(string of integer s) string
  of integer
• if s 0 then SWITCH(s) empty string
• else if s 2 then there exists a, b
  integer
• where (s ltagt ltbgt and SWITCH(s) ltbgt
  ltagt)
• else
• there exists a, b integer t string of
  integer
• where (s ltagt ltbgt t and
• SWITCH(s) ltbgt ltagt
  SWITCH(t))

case 1 s 0
case 2 s 2
case 3 other
28
SWITCH(s) Case 1

• If you SWITCH(lt gt), it returns lt gt. In other
  words, it does not change s when s is the empty
  string of integer.
• if s 0 then
• SWITCH(s) empty string

29
SWITCH(s) Case 2

• If s has two elements, SWITCH(s) returns a string
  consisting of those same two integer elements, in
  reverse order.
• else if s 2 then
• there exists a, b integer where
• (s ltagt ltbgt and
• SWITCH(s) ltbgt ltagt)

30
Limiting Complexity

• It turns out that SWITCH(s) doesnt make any
  sense at all when the length of s is odd. But
  thats okay, because were only using it to
  describe what happens when the length of s is
  even.
• In other words, we dont need to bother reasoning
  about cases that wont come up.

31
SWITCH(s) Case 3

• If s has more than two elements, we call the
  first two a and b. We reverse these two, then
  recurse to append SWITCH(t), where t is the rest
  of the string.
• Its safe, since s is even implies s-2 is
  even.
• else there exists a, b integer
• t string of integer where
• (s ltagt ltbgt t and
• SWITCH(s) ltbgt ltagt SWITCH(t))

32
The Meaning of SWITCH(s)

• Given a string of integer of even length, SWITCH
  takes every two integers and swaps them, like so
• SWITCH(lt 1, 2, 3, 4, 5, 6 gt) lt 2, 1, 4, 3, 6, 5
  gt
• Recursive descriptions are often the easiest way
  to describe things in math. Youll need to read
  them to understand the contracts for Lab 1.
• Note just because a spec is recursive doesnt
  mean you need to use recursion to write code that
  implements it. Weird() would be both simpler and
  more efficient if written iteratively.

33
Set

• Intuitively, a set is like a bunch of different
  items in a bag.
• A set is only determined by its elementsit
  doesnt contain (or more precisely, doesnt
  remember or understand) duplicate items.
• The items are not ordered.
• Mathematically, a Set is modeled by set of Item.
• The default value is the empty set
• A set is an unordered container. The RESOLVE
  Set component also requires that all elements
  be of the same type (Item).

34
Set Kernel Operations

• Add(x)
• requires x ? self
• Remove(x, x_copy)
• requires x ? self
• Remove_Any(x)
• requires self gt 0
• Is_Member(x)
• requires true
• Size()
• requires true

35
Why restrict Add?

• The restriction on Add(x) for Set (you can only
  add elements to a set if theyre not in the set
  already) seems unusual. From a math standpoint,
  it might make more sense to have a set ignore
  duplicate entries, than require that the client
  never add duplicates.
• However, this restriction does make sense from a
  design-by-contract perspective. If we prohibit
  the addition of duplicates, this allows us to
  implement Set Kernel in a lot of different ways,
  some of which are much more efficient than the
  alternative approach.

36
Why does Remove take two Items?

• Set is designed to work with any type (though it
  includes a special restriction that Item must
  implement Is_Equal_To).
• If the type Set holds is very large, you might
  have a use for both the key x you pass to
  Remove(x, x_copy), and the copy x_copy that gets
  yanked out of the Set. It returns the copy to
  you just in case you need it, e.g., if copying
  Item is expensive or difficult.
• However, most of the time youll just want to
  make a throw-away variable for x_copy.

37
Example of Set Math Operations

• Let A 1, 2 B 2, 3
• Element (the member is in the set)
• 1 ? A 3 ? A
• Subset (all members of one set are in the other)
• ? A 1 ? B 1, 2 ? A
• Union (the combined contents of two sets, like
  OR)
• A ? B 1, 2, 3
• Intersection (the overlap between two sets, like
  AND)
• A ? B 2
• Set Difference (elements in one set that arent
  in another)
• A\B 1 (sometimes written A-B)
• Power Set (the set of all subsets of a set)
• P(A) , 1, 2, 1, 2

38
Why are these not part of Set_Kernel?

• The purpose of a kernel is to provide a minimal
  set of operations needed to examine and change
  the abstract state space of an object.
• Kernel operations must provide the ability to
  build any possible legal object of that type, and
  the ability to identify and change an unknown
  objects contents.
• Set_Kernel doesnt include Union and Intersection
  because you dont need them to create and change
  a given set. You can build these operations
  later, using the operations the Kernel gives you.

39
Iterating With Sets

• The process of iterating through an unordered
  collection in Resolve relies on using the Kernel
  operations (Remove_Any(x), for Sets) to dump out
  the contents into a temporary object, so you can
  remember what youve seen and what you havent.
• Once youve gone through all the items, the
  original Set will be empty, and the temporary Set
  will be full. A swap will then restore the
  original Set, preserving it.

40
Practice Using Sets

• Lets build a function that takes two
  Set_Of_Integer objects (instantiated from
  SetltIntegergt) and returns a Boolean value for the
  subset operator.
• (A ? B means all elements of A are also elements
  of B.)
• Get into teams of two to four.
• When writing code, remember to use object
  Set_Of_Integer to create a new empty set that
  can hold Integers, if you need one.
• Eventually well learn how to do this kind of
  extension for ANY type of Set, but for this test
  well just use Set_Of_Integer.

41
Templating and Prototype

• include CT/Set/Set_Kernel_1a_C.h
• concrete instance
• class Set_Of_Integer
• instantiates
• Set_Kernel_1a_C ltIntegergt
• global_function Boolean Is_Subset(
• preserves Set_Of_Integer subset,
• preserves Set_Of_Integer superset
• )
• /!
• ensures
• Is_Subset
• for all i integer
• where i is in subset
• (i is in superset)
• !/

if the name of the function appears in its spec,
this means the value that gets returned
put another way, returns false iff (if and only
if) subset has something superset doesnt
42
Is_Subset

• global_function_body Boolean Is_Subset(
• preserves Set_Of_Integer subset,
• preserves Set_Of_Integer superset
• )
• object catalyst Set_Of_Integer subset_seen
• object Boolean answer true
• // check each element from subset to see if
  its in superset
• while (subset.Size() gt 0)
• object catalyst Integer elem
• subset.Remove_Any(elem)
• if (not superset.Is_Member(elem))
• answer false
• subset_seen.Add(elem) // hold on to
  what weve
• // already
  iterated through
• subset subset_seen // now, we can
  restore subset

43
Planning in Is_Subset

• Note that we started by setting our answer to
  true. This is a good choice, because in the case
  that we have nothing to test (because subset is
  empty), result is vacuously true.
• When we set the answer to false, it has no way to
  change back again. As soon as we find a
  counterexample, we have our answer.
• However, we cant return as soon as we find such
  a counterexample! We have to iterate through the
  rest of the set so that we can restore it to its
  original value. Planning to return at the end of
  the function avoids error.

44
Queue

• Intuitively, a queue is like data waiting in
  line. The data waiting the longest is the next
  available.
• A queue is useful for handling data in the order
  that it arrives or is stored (oldest item first)
• Sometimes this is called FIFO (first in, first
  out)
• Mathematically, a queue is modeled by string of
  Item.
• The default value is the empty string ltgt
• This is the same model as Sequence! The data is
  represented the same way abstractly.
• The difference is how you access the data (what
  operations you have available to you).
• The head (current) is the leftmost member ltA,
  Bgt

45
Arbitrary Notation

• We model Queue abstractly by setting the head of
  the queue to be the left side.
• Removing an object x removes the head
• Dequeue(x) ensures (q ltxgt q)
• Inserting an object x concatenates onto the tail
• Enqueue(x) ensures (q q ltxgt).
• This choice was made since English reads from
  left to right, but its arbitrary. Queue would
  work the same way if we reversed all of its specs.

46
Queue Kernel Operations

• Enqueue(x)
• requires true
• Dequeue(x)
• requires self gt 0
• Accessor current
• requires self gt 0
• Length()
• requires true

47
Practice Using Queues

• Lets write an operation to find both the min and
  max value in a Queue. (Hint you dont need to
  make a new Queue!)
• global_procedure Find_Min_And_Max (
• preserves Queue_Of_Integer values,
• produces Integer min,
• produces Integer max,
• )
• /!
• requires
• values gt 0
• ensures
• max is in values and
• min is in values and
• for all i integer
• where (i is in values)
• (max i and min i)
• !/

48
Find_Min_And_Max

• global_procedure_body Find_Min_And_Max (
• preserves Queue_Of_Integer values,
• produces Integer min,
• produces Integer max )
• object Integer counter
• min valuescurrent
• max valuescurrent
• while (counter lt values.Length())
• object catalyst Integer last
• values.Dequeue(last)
• values.Enqueue(last)
• if (max lt valuescurrent)
• max valuescurrent
• if (min gt valuescurrent)
• min valuescurrent
• counter

49
Planning in Find_Min_And_Max

• Notice that we copy a value from the queue (which
  must exist, since its required to be nonempty)
  into min and max at the outset. This ensures we
  dont accidentally produce a number that isnt in
  the queue.
• A common approach might involve checking the
  dequeued item, rather than using current.
  Theres nothing wrong with this approach, but
  its helpful to see how useful current can be.
  With some operations, it can provide significant
  clarity, and save time.

50
Queue Rotation

• I like to call a Dequeue of an element, followed
  by an Enqueue of the same element, a rotation of
  a Queue.
• Since Queue is last-in, first-out, this preserves
  order. If you rotate a Queue a number of times
  equal to the length of the Queue, it restores the
  Queue to its original values
• original lt1, 2, 3gt (the queue has
  three elements)
• one rotation lt2, 3, 1gt
• two rotations lt3, 1, 2gt
• three rotations lt1, 2, 3gt (the original order
  is restored)
• This lets us easily iterate through a Queue while
  preserving it, without the need for a separate
  Queue.

51
Uses for Sequence, Set, Queue

• Sequence is useful when you need to keep
  something in order as you insert new elements
  into the middle
• an outline, when you need to edit things in the
  middle
• a list of items you want insertion sort to keep
  in order
• Set is useful when you need to test a binary
  condition over a group of items
• a set of keywords, so you can check if a word is
  a keyword
• a set of filenames, so you know which files are
  up-to-date
• Queue is useful when you want to process things
  in the order you encounter them
• a queue of print jobs waiting to print, oldest
  job first
• a queue of chores that need to be done, oldest
  job first

52
Record

• Intuitively, Record is like a single row in a
  data-base table (Anna Wolf, 123456789,
  Gemini)
• Mathematically, Record is modeled by n-tuple of
  objects, where n is an integer between 1 and 10.
• Record is a client template that allows different
  types to be stored together in the same object.
• Each field of a Record (piece of tuple) has its
  own type.
• The default value of a Record is a tuple
  consisting of the default values of all of its
  fields ( d1, d2, d3)
• For example, the default value of
• RecordltInteger, Text, Queue_Of_Textgt ( 0, ,
  ltgt)
• RecordltReal, Boolean, Real, Charactergt ( 0.0,
  false, 0.0, \0)

53
Interesting Record Facts

• In most cases, its better create a new component
  than make a Record. This is because its useful
  to have not only data held in a package, but also
  the algorithms that handle the data.
• Theres a special version of Record found inside
  Kernels, called Representation. Its used to
  hold the Kernels data members. Representation
  works just like Record.
• Record is a Resolve/C foundation type(and so
  is Representation).

54
Instantiating Record

• To instantiate a record, you must fill in the
  template AND name the fields
• concrete instance
• class Nickname_And_Grade
• instantiates
• Record lt
• Text,
• Integer
• gt
• field_name (Nickname_And_Grade, 0, Text,
  nickname)
• field_name (Nickname_And_Grade, 1, Integer,
  grade)

our name for the new Record type
the field types you can put from 1 to 10 types
here
a field_name must be declared for each field,
once the Record is instantiated (usually done
right after instatiation)
55
Instantiating Record

• Before using a Record, you must name each field.
• The index is the position the field appeared at
  in the instantiation, as an integer starting from
  0.
• The fieldname is the only thing you control.
  Everything else is pulled from the instantiation.
• field_name (Nickname_And_Grade, 0, Text,
  nickname)
• field_name (Nickname_And_Grade, 1, Integer,
  grade)

the fieldname you want to use to access the
field at that index
name of the Record type
index of the field
the type of the field at that index
56
Record Details

• Once you instantiate Record and name its fields,
  each fieldname has a type permanently associated
  with it.
• Making a new Record will create one new object
  for each of its fields, and those objects will be
  of their default types. Similarly, clearing a
  Record resets each of its objects to their
  default types.
• Record is not a collection object! A Record is a
  single tuple. It always has something inside it,
  and only stores one group of fields.

57
Combining Record Instantiations

• concrete instance
• class Full_Name field_name(Full_Name,
  ...
• instantiates
• Record lt
• Text, ... 0, Text,
  first_name)
• Text ... 1, Text,
  last_name)
• gt
• concrete_instance
• class Name_And_Grade field_name(Name_And_G
  rade, ...
• instantiates
• Record lt
• Full_Name, ... 0, Full_Name,
  name)
• Integer ... 1, Integer,
  grade)
• gt

58
Using Record

• Records only operation is Accessor
• fieldname (returns a reference to named field)
• The only legal thing you can put in Records
  Accessor is a fieldname you have already defined.
• Since Accessor returns a reference, you can use
  it just like its a variable. In other words, if
  you create a Full_Name object called student,
  then you just created two Text objects, called
  studentfirst_name and studentlast_name.

59
Examples Using Record

• object Name_And_Grade student
• object Name_And_Grade other_student
• object Set_Of_Name_And_Grade course
• studentnamefirst_name Early
• studentnamelast_name Cuyler
• studentgrade 3
• student other_student
• course.Add(other_student)

60
Unrolling Expressions

• Its important that you be able to unroll an
  expression to figure out the types of its terms.
• Consider a Queue_Of_Name_And_Grade object called
  foo. Can you identify all of the types here?
• foocurrentnamelast_name

61
Identifying All of the Types

• foocurrentnamelast_name

Queue_Of_Name_And_Grade
keyword
field_name
Name_And_Grade
Full_Name
Text
