Introduction to Cryptography

1
Introduction to Cryptography

• --- Foundations of information security ---
• Lecture 7

2
Outline

• Why study cryptology?
• Basic terms, notations and structure of
  cryptography
• Private public key cryptography examples
• Modern secret key ciphers usage and methodology
• Encryption and possible attacks
• Secret key ciphers design
• Slides 23 to 26 for additional information (and
  reading)

3
Why Study cryptology(1)
A
B
Intruder
Communications security
4
Why Study cryptology(2)
Customer
Merchant
TTP
Electronic Commerce Security
5
Why Study cryptology(3)
A
B
LEA
Law enforcement
6
The Basic Problem

• We consider the confidentiality goal
• Alice and Bob are Friends
• Marvin is a rival
• Alice wants to send secret messages (M1,M2,) to
  Bob over the Internet
• Rival Marvin wants to read the messages (M1,M2,)
  - Alice and Bob want to prevent this!
• Assumption The network is OPEN Marvin is able
  to eavesdrop and read all data sent from Alice to
  Bob.
• Consequence Alice must not send messages
  (M1,M2,) directly they must be scrambled or
  encrypted using a secret code unknown to Marvin
  but known to Bob.

7
Cryptography
plaintext (data file or messages) encryption c
iphertext (stored or transmitted
safely) decryption plaintext (original data
or messages)
8

Private key cipher
Encryption
Decryption
Encrypted message (ciphertext)
Encrypted message (ciphertext)
E
Alice
D
Bob
key
Message (cleartext, plaintext)
Message (cleartext,plaintext)
9
Basic terms

• Cryptology (to be very precise)
• Cryptography --- code designing
• Cryptanalysis --- code breaking
• Cryptologist
• Cryptographer cryptanalyst
• Encryption/encipherment
• Scrambling data into unintelligible to
  unauthorised parties
• Decryption/decipherment
• Un-scrambling

10
Types of ciphers

• Private key cryptosystems/ciphers
• The secret key is shared between two parties
• Public key cryptosystems/ciphers
• The secret key is not shared and two parties can
  still communicate using their public keys

11
Examples of Messages

• Types of secret Messages Alice might want to
  send Bob (in increasing length)
• Decision (yes/no), eg. as answer to the question
  Are we meeting tomorrow?
• Numerical Value, eg. as answer to the question
  at what hour are we meeting?
• Document
• Software,
• Images etc.

12
Concepts

• A private key cipher is composed of two
  algorithms
• encryption algorithm E
• decryption algorithm D
• The same key K is used for encryption
  decryption
• K has to be distributed beforehand

13
Notations

• Encrypt a plaintext P using a key K an
  encryption algorithm E C E(K,P)
• Decrypt a ciphertext C using the same key K and
  the matching decryption algorithm D P D(K,C)
• Note P D(K,C) D(K, E(K,P))

14
The Caesar cipher (e.g)

• The Caesar cipher is a substitution cipher, named
  after Julius Caesar.
• Operation principleeach letter is translated
  into the letter a fixed number of positions after
  it in the alphabet table.
• The fixed number of positions is a key both for
  encryption and decryption.

15
The Caesar cipher (cntd)
K3
Outer plaintext
Inner ciphertext
16
An example

• For a key K3,plaintext letter
  ABCDEF...UVWXYZciphtertext letter
  DEF...UVWXYZABC
• Hence TREATY IMPOSSIBLEis translated
  into WUHDWB LPSRVVLEOH

17
Breaking classic ciphers

• With the help of fast computers, 99.99 ciphers
  used before 1976 are breakable by using one of
  the 4 types of attacks (described later).
• Modern cluster computers and future quantum
  computers can break several existing ciphers due
  to the power of such computers.

18
Breaking the Caesar cipher

• By trial-and error
• By using statistics on letters
• frequency distributions of lettersletter percent
  A 7.49B 1.29C 3.54D 3.62E 14.00...
  ...............................

19
Toy example of private key cryptography (TPC)

• Assume that a message is broken into 64-bit
  blocks and each 64-bit block of plaintext is
  encrypted separately
• Key space are combinations of numerical digits
  max 7 digits-
• (eg key 1 or key 1,3, or key
  1,4,2).
• Assume that all 8 bits of a byte is used and key
  digits start from left to right.
• Encryption Each plaintext block is first shifted
  by the number of binary digits before the last
  non-zero digit of the key. It is then
  exclusive-ored with the key starting from the
  first byte of the block, repeatedly to the end of
  the block (the key moves a distance of its size
  from left to right of the plaintext block).
• Decryption do the reverse of encryption the
  cipher-text is exclusive-ored and then shifted.

exclusive or
20
Using TPC

• Use TPC to encrypt the plaintext 12345, key
  1,4,2
• Use TPC to encrypt the plaintext TREATY
  IMPOSSIBLE key 4
• Use TPC to encrypt the plaintext 100 dollars,
  key 2,4

21
Principles of Private Key Encryption

• Devise cryptographic algorithms
• a set of fast functions (E1, E2, E3, ..En) that
  when in turn applied to an input (initial or
  intermediate input) will produce a more
  potentially scrambled output.
• and a set of functions (D1,D2,D3, .. Dn) that
  when in turn applied to the cipher text (final or
  intermediate) will produce the original input
  text.
• Devise algorithms, tests and proofs to validate
  your cryptographic algorithms
• Analysing algorithms.
• Tests with powerful computers such as
  specialised, parallel, cluster, or quantum
  computers.
• Mathematical proofs.

22
Toy example of public key cryptography

• Definition The multiplicative inverse of x with
  modulo n is y such that (xy) mod n 1
• E.gx3 n10, gt y7 since (37) mod 10
  1
• The above multiplicative inverse can be used to
  create a simple public key cipher either x or y
  can be thought of as a secret key and the other
  is the public key. Let x 3, y 7, n 10, and
  M be the message
• M 4
• 34 mod 10 2 (ciphertext) - encrypting
• 27 mod 10 4 M (message) - decrypting
• M 6
• 36 mod 10 8
• 87 mod 10 6 M (message)

23
What is PKE used for?

• Private Key Encryption (PKE) can be used
• Transmitting data over an insecure channel
• Secure stored data (encrypt store)
• Provide integrity check
• (Key Mes.) -gt MAC (message authentication
  code)

24
Morden Cryptography applications

• Not just about confidentiality!
• Integrity
• Digital signatures
• Hash functions
• Fair exchange
• Contract signing
• Anonymity
• Electronic cash
• Electronic voting
• Etc.

25
Modern private key ciphers

• DES (US, 1977) (3DES)
• key -- 56 bits, plaintext/ciphertext -- 64 bits
• LOKI (ADFA, Australia, 1989)
• key, plaintext/ciphertext -- 64 bits
• FEAL (NTT, Japan, 1990)
• key -- 128 bits, plaintext/ciphertext -- 64 bits
• IDEA (Lai Massey, Swiss, 1991)
• key -- 128 bits, plaintext/ciphertext -- 64 bits
• SPEED (Y Zheng in 1996)
• Key/(plaintext/ciphertext) -- 48,64,80,,256 bits
• AES (Joan Daemen Vincent Rijmen 2000)
• Key/(plaintext/ciphertext) -- 128, 192 and 256
  bits

26
General approaches to Cryptography

• There are two general encryption methods Block
  ciphers Stream ciphers
• Block ciphers
• Slice message M into (fixed size blocks) m1, ,
  mn
• Add padding to last block
• Use Ek to produce (ciphertext blocks) x1, , xn
• Use Dk to recover M from m1, , mn
• E.g DES, etc.
• Stream ciphers
• Generate a long random string (or pseudo random)
• called one-time pad.
• Message one-time pad (exclusive or)
• E.g EC4

27
Design of Private Key Ciphers(1)

• A Cryptographic algorithm should be efficient for
  good use
• It should be fast and key length should be of the
  right length e.g. not too short
• Cryptographic algorithms are not impossible to
  break without a key
• If we try all the combinations, we can get the
  original message
• The security of a cryptographic algorithm depends
  on how much work it takes for someone to break it
• E.g If it takes 10 mil. years to break a
  cryptographic algorithm X using all the computers
  of a state, X can be thought of as a secure one
  reason cluster computers and quantum computers
  are powerful enough to crack many current
  cryptographic algorithms.

28
Design of Private Key Ciphers(2)

• Encryption Algorithm Design
• Should the strength of the algorithm be included
  in the implementation of the algorithm? Should we
  hide the algorithm?
• Should the block size be small or large?
• Should the keyspace be large?
• Should we consider other search rather than
  brute-force search?
• Should we consider the hardware technology?

29
4 types of cryptanalysis

• Depending on what a cryptanalyst has to work
  with, attacks can be classified into
• ciphertext only attack
• known plaintext attack
• chosen plaintext attack
• chosen ciphertext attack (most severe)

30
4 types of attacks

• Ciphertext only attack
• the only data available is a target ciphertext
• Known plaintext attack
• a target ciphertext
• pairs of other ciphertext and plaintext (say,
  previously broken or guessing)

31
4 types of attacks

• Chosen plaintext attacks
• a target ciphertext
• can feed encryption algorithm with plaintexts and
  obtain the matching ciphertexts
• Chosen ciphertext attack
• a target ciphertext
• can feed decryption algorithm with ciphertexts
  and obtain the matching plaintexts
