Biomass Boiler Kings Park Nursery

1
Biomass BoilerKings ParkNursery
Kevin Smith Energy Surveyor Building Services
2
Kings Park Nursery Biomass Boiler

• What Is A Biomass Boiler?
• Biomass is living and dead bio material such as
  wood.
• A biomass boiler uses wood chips as a fuel to
  provide space and water heating.
• Although carbon emissions (CO2) are produced the
  plants and trees absorbed an equal amount during
  their life Carbon Neutral.
• Plants and trees actually give off carbon if left
  to decay naturally!

3
Kings Park Nursery Biomass Boiler

• Why The Kings Park Biomass Boiler
• Kings Park (KP) Nursery supplies plants and
  flowers for civic functions and the many councils
  parks. The large green houses require continuous
  heating.
• Bournemouth BC Parks department produces an
  excess of wood chippings from operations free
  supply of fuel.
• The existing boilers are coming to the end of
  their useful life.

4
Kings Park Nursery Biomass Boiler
Heated Glass House
5
Kings Park Nursery Biomass Boiler
Existing gas fired boilers
6
Kings Park Nursery Biomass Boiler

• Why The Kings Park Biomass Boiler
• The nursery currently consumes annually
• Gas 330,000kwh (9,000)
• Producing 63 tonnes of CO2.
• Rising energy costs.
• Great savings to be made in both cost and CO2!!

7
Kings Park Nursery Biomass Boiler
Proposed Location good access.
8
Kings Park Nursery Biomass Boiler
The Fuel Wood Chips

• The quality of the wood chip is crucial.
• Low cost wood chips sized at
• chipping stage.
• Must have less than 30 moisture
• but not too dry.
• Ash produced is low 1.

9
Kings Park Nursery Biomass Boiler
The Fuel Purchased wood pellets

• Wood chip can be purchased
• Costs around 5 pence /kwh
• Compares to
• Oil 11p/kwh
• Storage required for wood chip

10
Kings Park Nursery Biomass Boiler

• The System Overview
• The proposed installation is a 300kw boiler.

11
Kings Park Nursery Biomass Boiler

• The System Overview
• The boiler which includes the stack will be about
  28m from the site boundary.
• Height of the chimney stack will be approximately
  6 to 7m.
• Requires a three phase electrical supply 32
  Amps.

12
Kings Park Nursery Biomass Boiler
The System Overview The proposed boiler site -
note two levels.
13
Kings Park Nursery Biomass Boiler

• The System Overview
• Wood chips will be delivered and loaded into a
  storage bunker on a lower level.
• The bunker will hold around 5 tonnes of wood
  chip.
• The wood chip will be motor fed into the boiler.
• Will use between 15 and 132 Kg/hour wood chip.
• The boiler produces very little emissions
  mainly steam.

14
Kings Park Nursery Biomass Boiler
The System Overview
15
Kings Park Nursery Biomass Boiler

• The System Overview
• Hot water from the boiler will be pumped to a
  heat exchanger.
• The heat exchanger transfers heat from the boiler
  to the glass house heating pipes.
• The heat exchanger used to isolate the new pipe
  work from the old preventing contamination.

16
Kings Park Nursery Biomass Boiler

• Costs
• Biomass Boiler
• 55,500
• Heating System - includes pipe work and controls

• 36,800
• Other Works - Feasibility, Structural and
  Commissioning.
• 58,700
• Total 151,000

17
Kings Park Nursery Biomass Boiler

• Thank You For Listening.
• And Thank you to the Bruce Boucher
  Consultancy.
• Questions?
