QoS Research in MONET Group

1
QoS Research in MONET Group

• Klara Nahrstedt
• klara_at_cs.uiuc.edu
• http//cairo.cs.uiuc.edu
• Multimedia Operating and Network System Group
  (MONET)

2
Ubiquitous/Pervasive Computing Environment

• Shared Networks, Servers and Clients
• Intelligence Devices
• QoS Requirements

Smart Devices Attached to Network
3
Problem Statement

• Application Domain Multimedia applications such
  as Distributed Visual Tracking and Video on
  Demand
• Application Requirements Application Quality of
  Service (QoS) such as tracking precision, desired
  frame rate, bounded end-to-end delay, minimal
  loss rate of APDUs, minimal jitter and sync skew
  between APDUs
• Goal Support End-to-end application QoS over
  shared resources

4
Research Approach

• Exploration of Different Approaches
• Adaptation-based Approach
• no support of QoS in networks or in OS
• development of adaptive middleware
• development of cross-layer adaptation
• Reservation-based Approach
• support of QoS in networks and through OS
  extension
• development of QoS-aware resource management
• Hybrid Approach
• support of QoS through QoS compilation and
  service composition for minimal end-to-end QoS
  setup
• support of run-time adaptive techniques

5
QoS Research Projects

• Adaptive Application Control
• Omni-directional camera control
• Distributed visual tracking
• Mobile Applications
• Focus-oriented applications
• MiddlewareCommunication
• Adaptive middleware with adaptive and fuzzy
  control approach
• Adaptive comm. Framework
• QoS compilation and service composition
• Service level routing
• QoS and Security
• Quality of Protection Mgt

• QoS in resource management
• Dynamic Soft Real-Time (DSRT) CPU management
• Adaptive Cross-layer Design of Mobile Systems
• QoS-aware resource mgt within 2K system and Gaia
  system
• Service Management within Gaia system 2kQ
• QoS in networks
• QoS routing (distributed, hierarchical, source,
  multicast)
• QoS mappings and signaling at edge devices
• QoS management in MANET
• Configurability management

6
Distributed Omni-directional Visual Tracking
System

• Omni-directional Camera

Gateway
Tracking Client
Moving Object
Shared Fast Ethernet
Camera Server
7
Distributed Visual Tracking
Line Tracker
SSD Tracker
Corner Tracker
Tracked Moving Object
Development Environment Windows NT 4.0, ORBacus
3.1.3 as CORBA platform, Sun Java 2, Visual C
6.0 for Distributed Visual Tracking Tracking
Algorithms from Xvision Project (G. Hager/Yale
University)
8
Visual Tracking Application

• Multiple Tracking Capabilities
• Visual tracking
• Camera tracking/movement (right/left)
• Camera switching
• Trade-offs between Application QoS
• flexible application
• one important QoS - tracking precision
• other QoS can be degraded (f. size, f. rate,..)

9
Adaptive Middleware
App1
App2
App1
App2
App T3
App T1
App T2
App T3
App T1
App T2
Configurator/App1
Configurator/App1
Configurator/App2
Configurator/App2
Negotiator
Middleware
Middleware
Negotiator
Adapt/Observe for CPU
Adapt/Observe for Net
Adapt/Observe for CPU
Adapt/Observe for Net
OS and Resource Management

OS and Resource Management

Transport Protocols
Transport Protocols

• Server Site

Client Site
Data Transfer
10
Application/System Interface

• Probing and profiling services for establishment
  of configuration profiles needed in the adaptive
  control framework (CPU probing, network probing,
  application probing)
• Benchmarking service for establishing relations
  between application QoS and system QoS
• Integration of adaptive control and fuzzy control
  frameworks as foundation of middleware adaptation
• Application-aware communication framework driven
  by system QoS

11
2K/Gaia/Smart Rooms with QoS
12
Gaia Multimedia Support

• QoS-Aware Programming Environment (Q-Compiler)
• Run-Time Services
• Focus-Aware Video-on-Demand System
• Mobile Media with Quality of Protection
• Software Real-Time Information Embedding into
• HDTV Streams
• QoS Management Services
• Dynamic Soft Real-Time Scheduler (DSRT)
• Resource Monitoring Service
• Peer-to-Peer Systems

13
Gaia Multimedia Support

• Run-Time Services
• Focus-Aware Video-On-Demand System
• Mobile Media with Quality of Protection
• Software Real-Time Information Embedding
• into HDTV Streams

development
QoS-Aware Programming Environment (Q-Compiler)

• QoS Management Services
• Dynamic Soft Real-Time Scheduler (DSRT)
• Resource Monitoring Service

deployment
Peer-to-Peer Systems
14
Multimedia Support in Gaia Architecture
Applications
Application Framework
Context File System
Context Service
Component Repository
Presence Service
Space Repository
Component Management Core
15
QoS-Aware Programming Environment (Metadata QoS
Compilation)
Gaia Services
QoS Specifications
DSRT Server
Environment-Independent and Environment-Dependent
Compilations
Component Resource Probing
16
Pre-Defined Metadata Compilation

• Common and Actual Ontology Translation,
• Two Common Ontology Translation,
• Intermediate Representation Translation

(4) Component Resource Translation
17
Focus-Aware Video-on-Demand System
Focused VoD Client With Higher Quality
VoD Client With Lower Quality
Remote Control via Handheld Device
18
Mobile Media with Quality of Protection
Mobile Video and Audio Between PC and
Handheld device
19
Software Real-time Information Embedding into
HDTV Streams
Stars1.mpg
Down-scaled football game
Bin Yu
20
QoS-aware Resource Management

• QoS-aware CPU Management (DSRT)
• CPU broker, CPU classes, smart probing
• QoS-aware Memory Management
• memory broker to allow pin memory
• QoS-aware Communication Management
• comm. broker for access of net. reservation
• QoS Proxy
• coordination of resource brokers, QoS translation
• IntermProxy
• media scaling, media transcoding
• Adaptive Cross-layer Design of Mobile OS

21
DSRT QoS Provision via Reservation
No QoS guarantee, best-effort
QoS guarantee w/ reservation
Resource contention
22
QoS-aware CPU Management
Execution Phase
Probing Phase
Reservation Phase
Scheduling
Probe
Admission Control
Extract Reservation
Monitor/ Conformance Test
Contract
Processor Binding
Adaptation
SRT Process
Adjusted Contract
23
Application/System Interface CPU Service Classes
Service Classes
Specification Parameters
Guaranteed
PCPT (Periodic Constant Processing Time)
P Period PPT Peak Processing Time
PPT
SPT
PVPT (Periodic Variable Processing Time)
P Period SPT Sustainable Processing Time PPT
Peak Processing Time BT Burst Tolerance
ACPU (Aperiodic Constant Processing Utilization)
PPU
PPU Peak Processing Utilization
Relative Deadline PPT Peak Processing Time
Event
PPT
24
Smart Probing for Reservation Control

• Goal Extract a reservation.
• Determine the most suitable Service Class
• Need
• Processor usage is hardware dependent.
• Processor usage is input dependent.

Estimate a Reservation
Processor Usage
Conformance Test ?
Iteration Number
25
Experimental Result
SRT2 MPEG player with P50ms.
SRT1 MPEG player With P100ms
26
Distributed Resource Monitoring Service
Server
27
Distributed Resource Monitoring Service
Client
28
Peer-to-Peer Systems

• Peers communicate DIRECTLY
• Peers act as both CLIENTS and SERVERS
• NO CENTRALIZED structure
• Research QoS-aware Service Composition and
  Service Routing

29
QoS in Networks

• QoS Routing services and protocols
• Hierarchical network scheduling supporting hard
  QoS, soft QoS and best effort flows
• Differentiated Routing
• QoS in BGP Protocol
• QoS Translation and signaling protocols in edge
  device design for heterogeneous networks
• Adaptive Cross-layer Design of MANET Protocols

30
QoS Routing in Internet

• Ticket-based Routing
• Distributed Routing with Imprecise Information
• QoS-based Multicast Routing
• QoS-based Traffic Aggregation in Hierarchical
  Routing
• Hierarchical Network Scheduling (hard QoS flows,
  soft QoS flows, BE flows)
• Differentiated Routing
• QoS in BGP Protocol

31
Simulation Results
Imprecision Rate 50
32
Edge Device Design

• QoS Mappings between RSVP/IntServ and underlying
  data link networks (CBR/ATM, rt-VBR/ATM,
  rt-ABR/ATM, cable)
• End-to-end Signaling Protocols (different
  signaling directions, RSVP/receiver-initiated,
  ATM/sender-initiated, cable/asymmetric)

33
Cross-Layer Design in MANET
34
Multimedia Security

• Real-time Video and Audio Watermarking in VOD
  multicast systems
• Ownership and Customer Protection
• Real-time Encryption
• Collusion Issues and Key Distribution in VOD
  multicast systems

35
Summary

• Research in end-to-end QoS for wired and wireless
  networks
• Investigation of high-end and low-end multimedia
  applications
• Research of QoS in distributed systems
  (middleware), OS, and networks
• Broader consideration of QoS performance,
  Quality of Protection, and availability
• Starting to consider fault-tolerance and their
  coexistence gt moving towards trust
