Fault Tolerance Computing

1
Fault Tolerance Computing

• Adnan Agbaria

2
System Model and Basic Concepts
3
Staff

• Dr. Adnan Agbaria
• adnan_at_il.ibm.com
• Office Hours
• Right after the class
• Monday 830-1000
• Course URL
• http//cs.haifa.ac.il/courses/ftc

4
Materials

• Textbooks
• Distributed Systems 2nd edition Sape Mullender
  (Editor), ACM Press Frontier Series, Addison
  Wesley
• K. Berman. Building Secure and Reliable Network
  Applications. Manning Publishing Company and
  Prentice Hall, December, 1996.
• J.-C. Laprie. Dependability Basic Concepts and
  Terminology. Springer_Verlag, 1992.
• P. Jalote. Fault Tolerance in Distributed
  Systems. Prentice-Hall, Inc., 1994.
• Research papers
• See the list at the web site

5
Grading and Prerequisites

• Grading
• Participation 20
• Presentation 40
• Home Assignments 40
• Prerequisites
• Operating systems
• Networking
• Algorithms

6
Course Outline

• Definition and basic concepts
• Replications
• Group Communication and Virtual Synchrony
• Consensus and Byzantine Agreement
• Checkpoint/Restart Basic concepts
• Distributed Checkpointing

7
Course Outline (Contd)

• Student presentations Replications
• Student presentations Failure detection
• Student presentations Group communication and
  virtual synchrony
• Student presentations Distributed checkpointing
• Network computer security and intrusion tolerance

8
Student Presentations

• Every student should send me an email
• Two preferred papers to present
• 1st paper is the most wanted!
• Each presentation is
• 30 min presentation
• 15 Q and A
• Homework questions may include materials from the
  presentations as well as from the lecturers
  presentations.

9
Outline

• Motivation
• Concepts, definitions, notations, and system
  model
• Fault model
• Synchronous and asynchronous models
• Time in distributed systems

10
Motivation

• The system downtime cost is very high
• 4 billions annually the estimated cost of
  system downtime in North American companies
  (source Computer Economics Infocorp.
  Consulting)
• Availability is still low
• "despite the Internet driving a significantly
  increased desire for continuous availability,
  through 2005, fewer than 20 percent of
  mission-critical Web-based applications will
  achieve it. Around 40 percent will achieve high
  availability at lower cost" (Source The Gartner
  Group)

11
Motivation (Contd)

• The impact of failures is VERY costly.
• In terms of money, time, and lives.
• Examples bank, air control, telephone systems,
  weather forecasting, etc.
• There is no way to prevent failures
• So what we can do Fault tolerance
• Goals
• High availability and reliability.
• Ways
• Fault tolerance

12
Distributed System - Definition

• A distributed system consists of a collection of
  autonomous computers, connected through a network
  and distribution middleware, which enables
  computers to coordinate their activities and to
  share the resources of the system, so that users
  perceive the system as a single, integrated
  computing facility.

13
Why Distributed Systems?

• Information and Hardware Sharing
• Scalability
• Availability
• Fault Tolerance
• Price/performance

14
Types of Distributed Systems

• Client/Server
• Web (HTTP), NFS, Automatic Teller Machines
• Group computing
• Distributed/replicated servers
• Pub/sub and messaging based system
• Collaborative computing (CSCW)
• Teleteaching, telemedicine, video-conferencing,
  Lotus Notes, shared windows sessions
• Parallel (cluster) computing in distributed
  environments
• Message passing interface (MPI)
• Distributed Shared Memory

15
System Model

• Distributed system with n processes,
• Denoted by P1, P2,,Pn
• Each process has local memory and CPU.
• Processes communicate via asynchronous network by
  send/receive events.
• Processes are asynchronous too
• Dont share a global clock.

16
Basic Events
Computation
Send(M)
Network
Receive(M)
Recovery
17
A Drawing Conception
P1
m2
m3
m1
P2
18
Fault Tolerance

• Hardware, software and networks fail!
• Source of failures
• Human, radiation, etc.
• There are
• Intentional faults Mainly caused by attacks,
  viruses/worms, etc.
• Non-intentional faults Mainly caused due to
• Bugs in the code
• Incorrect configuration and deployment
• Environment
• The rate of failures is still too high
• Impossible to prevent failures!
• So, What we can do?

19
Fault Tolerance (Contd)

• Distributed systems must maintain availability
  even at low levels of hardware/software/network
  reliability.
• Fault tolerance is achieved, mainly, by
• Recovery
• Recover the machine, system, or application upon
  any failure
• Failures should be detected.
• Where to recover from?
• Start everything from scratch, or
• Restart from a pre-captured state.
• Cost and performance

20
Fault Tolerance (Contd)

• Redundancy
• If one component fails, there is a spare to take
  over.
• How the spare knows when to take over?
• How often we update the spare?
• How many spare do we need?
• Cost and performance.
• Self stabilization
• If the system is in a faulty state, it should
  detect and go back to the normal state.
• How does the system do that?
• We are not consider this technique in the course.

21
Reliability

• Means that the system is continuously produce
  correct services.
• The reliability R(t) of a system SYS can be
  expressed as
• R(t) Prob(SYS is fully functioning in 0,t)
• A metric for reliability R(t) is MTTF, the Mean
  Time To Failure

22
Availability

• Means that the system produces services when it
  is required from authorized use
• The availability A(t) of a system SYS can be
  expressed as
• A(t) Prob(SYS is fully functioning at time t)
• A metric for the average, steady-state
  availability is

23
Failure, Error, and Fault

• Failure transition from proper to improper
  service
• Error that part of system state that is liable
  to lead to subsequent failure
• Fault the hypothesized cause of error(s)

Activation
Propagation
Causation
Fault
Error
Failure
Fault
24
Failure Types

• Crash Fail-stop mode. The process does not
  active
• Omission Fail to send/receive a message
• Transit Temporally failure that may affect the
  system functionality
• Byzantine Exhibits random behavior of the
  process
• Malicious Intention failure that usually caused
  by attacks

25
Means to attain Availability and Reliability

• Fault prevention
• Try to prevent faults before happening.
• Examples
• Using of strongly-typed programming language
• Firewalls for preventing intrusions (for
  intrusion tolerance)
• Fault tolerance
• Handling failures and trying to continue provide
  correct functionality.
• Examples
• Checkpoint/Restart, Replication, and
  Self-Stabilization.
• Replication with Byzantine Agreement (for
  intrusion tolerance)
• Fault Detection
• Detecting and removing the faults.
• Examples
• Timeout-based detection This is for detecting
  crash failure.
• Anomaly-based detection Intrusion Detection
  Systems (IDSs)

26
Correct vs. Faulty

• Look at a complete run (execution)
• external observers view
• A process that does not fail in a run is correct
  in that run
• Otherwise, the process is faulty in the run
• a process that fails any time in the run is
  faulty throughout the entire run

27
Threshold Failure Model

• t out of n processes may fail
• t is usually given as a function of n, e.g.,
• t lt n
• 2t lt n
• 3t lt n

28
Examples
29
A Database System

• Transactions
• Initiate a connection with the bank server and
  ask for a financial transaction on your account.
• The Server update the database.
• The Server send a confirmation message to the
  user.

2
3
1
30
A Database System (Contd)

• Possible Failures
• The server may crash
• One of the connection may be down (cut).

2
3
1
31
Synchronous vs. Asynchronous

• Synchrony assumptions
• Message latency is bounded
• Processes have synchronized clocks
• Processing times are bounded
• Asynchrony no assumptions
• Asynchronous models are more practice.
• The Internet is an asynchrony system.

32
Example The Coordinated Attack Problem

• Definition
• Two armies (red and blue) surround a town.
• The two armies want to coordinate to attack the
  town,
• Victory is achieved if and only if two armies
  attack simultaneously. Otherwise, the attack army
  will be defeated.
• The generals (red and blue) communicate by
  messengers.
• messengers can be captured (message loss) and/or
  can take arbitrarily long.

33
The Coordinated Attack Problem (Contd)

• There is no solution for the problem in the
  asynchronous model.
• There is a solution in the synchronous model (?)
• Can we add some requirements in the asynch model
  to solve the problem?

34
Time in Distributed Systems

• Logical time
• Causality
• Similar to visible knowledge that advances at the
  speed of light
• Wall clock time / real time / global time
• Clock skew
• The rate in which local clocks drift w.r.t. each
  other. Depends on clocks quality, but also on
  temperature, magnetic field, etc.
• It is possible to obtain time from GPS, or radio
  clocks, but the latency (both of the signal and
  handling the signal inside the computer) can vary
  a bit. Also, may not be available when there is
  no line of site to the sky.
