Site Assessment

1

• Site Assessment

Prepared by Cornell Cooperative Extension
and Cornells Urban Horticulture Institute for
the NYS Department of Conservation and FEMA
2
The Planting Process
Plant Selection
Transplanting Techniques
Site Assessment
Site Modification
3
Course Overview

• Core Curriculum
• Workshops to develop assessment skills
• Tours to hone site assessment skills
• Role-playing scenarios
• Case studies
• Take-home reference resources

4
Site Assessment

• A methodical inspection of a site in order to
  learn more about the sites ability to support
  healthy plant growth.

5
(No Transcript)
6
(No Transcript)
7
Site Assessment an important managment tool

• Enhances your professional status
• Improves customer satisfaction
• Enhances your profitability
• lowers replacement costs
• maximizes worker productivity

8
Case Study

• Planting Costs 10,000
• Replacement Budget 2,500
• Replace 20 Sugar Maples 20 x 200 4,000
• Replacement budget -2,500
• Loss on the job ???????
• Alternative site assessment notes difficult
  growing conditions and plant selection is changed
  to use a more site-tolerant species

9
Benefits of Site Assessment

• Instills positive image about the
  professionalism of your services
• Increases profits
• Increases customer satisfaction
• Thriving plantings reflect well on your company
  and industry as a whole

10
Basic Requirements for Plant Growth

• Oxygen
• Water
• Light
• Minerals
• Carbon Dioxide
• Appropriate Temperatures

11
Roots--General Morphology

• Roots extend 2.5-3 times the crown radius
• Most roots (gt60) located outside the drip line
• Tap roots rarely present in mature trees
• Water and nutrients absorbed by root hairs
• Root hairs primarily located in top 6 of soil
• gt95 of roots are found in the top 3 of soil

12
Root Functions

• Absorb water and nutrients
• Provide stability
• Synthesize plant hormones
• Store energy produced by plant

13
Shoot Functions

• Photosynthesis
• Transport sugars from source to sink
• Synthesizes plant hormones

14
Summary of Plant Structure and Functions

• All plants have certain basic requirements for
  healthy plant growth
• Different species will be differently able to
  tolerate different growing conditions
• Most tree roots are located in the top 18 of
  soil and extend 2-3 times the crown radius

15
Factors to Consider

• Climate and Microclimate
• Structural factors limiting canopy and rooting
  space
• Soil Factors
• Existing vegetation
• Design factors
• Legal factors

16
Climate

• USDA Hardiness Zone
• Precipitation

5b
6a
6b
7a
3b
4a
4b
5a
17
Microclimate Site Specific

• Sunlight
• Rereflected heat
• Wind
• Frost Pockets

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Rereflected Heat
Increases temperature Decreases humidity
Increases water stress
23
(No Transcript)
24
Structural Factors Limiting Canopy and Rooting
Space

• Above Ground
• Determine amount of canopy space available
• Note location and height of overhead wires
• Below Ground
• Call UFPO to locate underground utilities
• Buried debris may alter soil characteristics and
  limit rooting space

25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
Soil Factors

• Soil Texture
• Soil pH
• Soil Compaction
• Soil Disturbance
• Effective Rooting Depth and Volume
• Drainage and Aeration
• Topography
• Soil Cover
• Soil Contaminants

30
Soil Texture

• Amount of Sand, Silt and Clay in a Soil

0
100
Percent Silt
Percent Clay
Clay
Silty clay
Sandy clay
Silty clay loam
Clay loam
Sandy clay loam
Loamy sand
Loam
Sandy loam
Silt loam
Sand
100
0
Silt
100
0
Percent Sand
31
(No Transcript)
32
Properties of Soils of Different Textures
Soil Texture Sand Loam Clay Susceptibili
ty to Compaction limited moderate high Nutrient
Holding limited moderate high Capacity to
high Available Water 7 16 11 ( of
volume) Infiltration Rate high moderate low
33
(No Transcript)
34
(No Transcript)
35
Growth Increment
36
Soil Structure
Good Structure
Poor Structure
Macropores
Macropores
Micropores
Micropores
Soil Particles
Soil Particles
37
(No Transcript)
38
Effects of Compaction on Soil

• Soil structure is destroyed
• Soil drains slowly and is often anaerobic
• Compacted soil physically impedes root growth and
  results in the containerization of roots

39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
Soil Compaction and Construction

• Soil structure is slow to form, but quick to
  destroy
• The first pass of heavy machinery causes the most
  damage
• Plan ahead to preserve soil structure

43
(No Transcript)
44
How Much Soil Does a Tree Need?

• 2 cubic feet of soil for every 1 square foot of
  crown projection

Crown projection
45
(No Transcript)
46
(No Transcript)
47
Salt Injury to Plants

• Excessive salt levels in the soil
• Limits water and nutrient uptake by roots
• Increases likelihood of soil compaction
• Chloride accumulates in toxic levels in plant and
  leads to marginal leaf scorch
• Salt spray damage
• Buds and tips of plant have greater likelihood of
  freeze damage

48
(No Transcript)
49
(No Transcript)
50
Analyzing Existing Vegetation

• Identify plant species
• Note any indications of plant stress
• Determine annual growth increment of existing
  trees
• Check for salt injury
• Look for mechanical damage
• Note presence of any noxious weeds

51
Indications of Plant Stress

• Small, scorched or off-color foliage
• Early fall color or leaf drop
• Tip dieback
• Presence of insects or disease
• Suckering from the trunk

52
(No Transcript)
53
(No Transcript)
54
Design Factors

• Landscape Function
• aesthetics
• screening or enhancement of views
• reinforcing public or private space
• Circulation
• Pedestrian and vehicular traffic patterns
• events that increase people pressure

55
Legal Factors

• Establish property boundaries, easements and
  right-of-ways
• Determine if site is within a special
  jurisdiction
• historic preservation areas
• community ordinances
• tree preservation districts
• Determine permitting process
