Time Series

1
Time Series

• Math 419/592
• Winter 2009
• Prof. Andrew Ross
• Eastern Michigan University

2
Overview of Stochastic Models
3
But first, a word from our sponsor

• Take Math 560
• (Optimization)
• this fall!
• Sign up soon or it will disappear

4
Outline

• Look at the data!
• Common Models
• Multivariate Data
• Cycles/Seasonality
• Filters

5
Look at the data!

• or else!

6
Atmospheric CO2
Years 1958 to now vertical scale 300 to 400ish
7
(No Transcript)
8
Ancient sunspot data
9
Our Basic Procedure

• Look at the data
• Quantify any pattern you see
• Remove the pattern
• Look at the residuals
• Repeat at step 2 until no patterns left

10
Our basic procedure, version 2.0

• Look at the data
• Suck the life out of it
• Spend hours poring over the noise
• What should noise look like?

11
One of these things is not like the others
12
Stationarity

• The upper-right-corner plot is Stationary.
• Mean doesn't change in time
• no Trend
• no Seasons (known frequency)
• no Cycles (unknown frequency)
• Variance doesn't change in time
• Correlations don't change in time
• Up to here, weakly stationary
• Joint Distributions don't change in time
• That makes it strongly stationary

13
Our Basic Notation

• Time is t, not n
• even though it's discrete
• State (value) is Y, not X
• to avoid confusion with x-axis, which is time.
• Value at time t is Yt, not Y(t)
• because time is discrete
• Of course, other books do other things.

14
Detrending deterministic trend

• Fit a plain linear regression, then subtract it
  out
• Fit Yt mt b,
• New data is Zt Yt mt b
• Or use quadratic fit, exponential fit, etc.

15
Detrending stochastic trend

• Differencing
• For linear trend, new data is Zt Yt Yt-1
• To remove quadratic trend, do it again
• Wt Zt Zt-1Yt 2Yt-1 Yt-2
• Like taking derivatives
• Whats the equivalent if you think the trend is
  exponential, not linear?
• Hard to decide regression or differencing?

16
Removing Cycles/Seasons

• Will get to it later.
• For the next few slides, assume no cycles/seasons.

17
A brief big-picture moment

• How do you compare two quantities?
• Multiply them!
• If theyre both positive, youll get a big,
  positive answer
• If theyre both big and negative
• If one is positive and one is negative
• If one is bigpositive and the other is
  smallpositive

18
Where have we seen this?

• Dot product of two vectors
• Proportional to the cosine of the angle between
  them (do they point in the same direction?)
• Inner product of two functions
• Integral from a to b of f(x)g(x) dx
• Covariance of two data sets x_i, y_i
• Sum_i (x_i y_i)

19
Autocorrelation Function

• How correlated is the series with itself at
  various lag values?
• E.g. If you plot Yt1 versus Yt and find the
  correlation, that's the correl. at lag 1
• ACF lets you calculate all these correls. without
  plotting at each lag value.
• ACF is a basic building block of time series
  analysis.

20
Fake data on bus IATs
21
Properties of ACF

• At lag 0, ACF1
• Symmetric around lag 0
• Approx. confidence-interval bars around ACF0
• To help you decide when ACF drops to near-0
• Less reliable at higher lags
• Often assume ACF dies off fast enough so its
  absolute sum is finite.
• If not, called long-term memory e.g.
• River flow data over many decades
• Traffic on computer networks

22
How to calculate ACF

• R, Splus, SAS, SPSS, Matlab, Scilab will do it
  for you
• Excel download PopTools (free!)
• http//www.cse.csiro.au/poptools/
• Excel, etc do it yourself.
• First find avg. and std.dev. of data
• Next, find AutoCoVariance Function (ACVF)
• Then, divide by variance of data to get ACF

23
ACVF at lag h

• Y-bar is mean of whole data set
• Not just mean of N-h data points
• Left side old way, can produce correlgt1
• Right side new way
• Difference is End Effects
• Pg 30 of Peña, Tiao, Tsay
• (if it makes a difference, you're up to no good?)

24
Common Models

• White Noise
• AR
• MA
• ARMA
• ARIMA
• SARIMA
• ARMAX
• Kalman Filter
• Exponential Smoothing, trend, seasons

25
White Noise

• Sequence of I.I.D. Variables et
• meanzero, Finite std.dev., often unknown
• Often, but not always, Gaussian

26
AR AutoRegressive

• Order 1 YtaYt-1 et
• E.g. New (90 of old) random fluctuation
• Order 2 Yta1Yt-1 a2Yt-2 et
• Order p denoted AR(p)
• p1,2 common gt2 rare
• AR(p) like p'th order ODE
• AR(1) not stationary if agt1
• EYt 0, can generalize

27
Things to do with AR

• Find appropriate order
• Estimate coefficients
• via Yule-Walker eqn.
• Estimate std.dev. of white noise
• If estimated agt0.98, try differencing.

28
MA Moving Average

• Order 1
• Yt b0et b1et-1
• Order q MA(q)
• In real data, much less common than AR
• But still important in theory of filters
• Stationary regardless of b values
• EYt 0, can generalize

29
ACF of an MA process

• Drops to zero after lagq
• That's a good way to determine what q should be!

30
ACF of an AR process?

• Never completely dies off, not useful for finding
  order p.
• AR(1) has exponential decay in ACF
• Instead, use Partial ACFPACF, which dies after
  lagp
• PACF of MA never dies.

31
ARMA

• ARMA(p,q) combines AR and MA
• Often p,q lt 1 or 2

32
ARIMA

• AR-Integrated-MA
• ARIMA(p,d,q)
• dorder of differencing before applying ARMA(p,q)
• For nonstationary data w/stochastic trend

33
SARIMA, ARMAX

• Seasonal ARIMA(p,d,q)-and-(P,D,Q)S
• Often S
• 12 (monthly) or
• 4 (quarterly) or
• 52 (weekly)
• Or, S7 for daily data inside a
  week
• ARMAXARMA with outside explanatory variables
  (halfway to multivariate time series)

34
State Space Model, Kalman Filter

• Underlying process that we don't see
• We get noisy observations of it
• Like a Hidden Markov Model (HMM), but state is
  continuous rather than discrete.
• AR/MA, etc. can be written in this form too.
• State evolution (vector) St F St-1 ht
• Observations (scalar) Yt H St et

35
ARCH, GARCH(p,q)

• (Generalized) AutoRegressive Conditional
  Heteroskedastic (heteroscedastic?)
• Like ARMA but variance changes randomly in time
  too.
• Used for many financial models

36
Exponential Smoothing

• More a method than a model.

37
Exponential Smoothing EWMA

• Very common in practice
• Forecasting w/o much modeling of the process.
• At forecast of series at time t
• Pick some parameter a between 0 and 1
• At a Yt (1-a)At-1
• or At At-1 a(error in period t)
• Why call it Exponential?
• Weight on Yt at lag k is (1-a)k

38
How to determine the parameter

• Train the model try various values of a
• Pick the one that gives the lowest sum of
  absolute forecast errors
• The larger a is, the more weight given to recent
  observations
• Common values are 0.10, 0.30, 0.50
• If best a is over 0.50, there's probably some
  trend or seasonality present

39
Holt-Winters

• Exponential smoothing no trend or seasonality
• Excel/Analysis Toolpak can do it if you tell it a
• Holt's method accounts for trend.
• Also known as double-exponential smoothing
• Holt-Winters accounts for trend seasons
• Also known as triple-exponential smoothing

40
Multivariate

• Along with ACF, use Cross-Correlation
• Cross-Correl is not 1 at lag0
• Cross-Correl is not symmetric around lag0
• Leading Indicator one series' behavior helps
  predict another after a little lag
• Leading means coming before, not better than
  others
• Can also do cross-spectrum, aka coherence

41
Cycles/Seasonality

• Suppose a yearly cycle
• Sample quarterly 3-med, 6-hi, 9-med, 12-lo
• Sample every 6 months 3-med, 9-med
• Or 6-hi, 12-lo
• To see a cycle, must sample at twice its freq.
• Demo spreadsheet
• This is the Nyquist limit
• Compact Disc samples at 44.1 kHz, top of
  human hearing is 20 kHz

42
The basic problem

• We have data, want to find
• Cycle length (e.g. Business cycles), or
• Strength of seasonal components
• Idea use sine waves as explanatory variables
• If a sine wave at a certain frequency explains
  things well, then there's a lot of strength.
• Could be our cycle's frequency
• Or strength of known seasonal component
• Explainscorrelates

43
Correlate with Sine Waves

• Ordinary covar
• At freq. Omega,
• (means are zero)
• Problem what if that sine is out of phase with
  our cycle?

44
Solution

• Also correlate with a cosine
• 90 degrees out of phase with sine
• Why not also with a 180-out-of-phase?
• Because if that had a strong correl, our original
  sine would have a strong correl of opposite sign.
• Sines Cosines, Oh Mycombine using complex
  variables!

45
The Discrete Fourier Transform

• Often a scaling factor like 1/T, 1/sqrt(T),
  1/2pi, etc. out front.
• Some people use i instead of -i
• Often look only at the frequencies
• k0,...,T-1

46
Hmm, a sum of products

• That reminds me of matrix multiplication.
• Define a matrix F whose j,k entry is
• exp(-ijk2pi/T)
• Then
• Matrix multiplication takes T2 operations
• This matrix has a special structure, can do it in
  about T log T operations
• That's the FFTFast Fourier Transform
• Easiest if T is a power of 2

47
So now we have complex values...

• Take magnitude argument of each DFT result
• Plot squared magnitude vs. frequency
• This is the Periodogram
• Large value that frequency is very strong
• Often plotted on semilog-y scale, decibels
• Example spreadsheet

48
Spreadsheet Experiments

• First, play with amplitudes
• (1,0) then (0,1) then (1,.5) then (1,.7)
• Next, play with frequency1
• 2pi/8 then 2pi/4
• 2pi/6, 2pi/7, 2pi/9, 2pi/10
• 2pi/100, 2pi/1000
• Summarize your results for yourself. Write it
  down!
• Reset to 2pi/8 then play with phase2
• 0, 1, 2, 3, 4, 5, 6...
• Now add some noise to Yt

49
Interpretations

• Value at k0 is mean of data series
• Called DC component
• Area under periodogram is proportional to
  Var(data series)
• Height at each pointhow much of variance is
  explained by that frequency
• Plotting argument vs. frequency shows phase
• Often need to smooth with moving avg.

50
What is FT of White Noise?

• Try it!
• Why is it called white noise?
• Pink noise, etc. (look up in Wikipedia)

51
Filtering part 1

• Zero out the frequencies you don't want
• Invert the FT
• FT is its own inverse! Not like Laplace
  Transform.
• This is frequency-domain filtering
• MP3 files filter out the freqs. you wouldn't
  hear
• because they're overwhelmed by stronger
  frequencies

52
Filtering part 2

• Time-domain filtering example spreadsheet
• Smoothing moving average
• Filters out high frequencies (noise is high-freq)
• Low-pass filter
• Detrending differencing
• Filters out trends and slow cycles (which look
  like trends, locally)
• High-pass filter
• Band-pass filter
• Band-reject filter (esp. 12-month cycles)

53
Filtering

• Time-domain filter's freq. response comes from
  the FT of its averaging coefficients
• Example spreadsheet
• This curve is called the Transfer Function
• Good audio speakers publish their frequency
  response curves

54
Long-history time series

• Ordinary theory assumes that ACF dies off faster
  than 1/h
• But some time series don't satisfy that
• River flows
• Packet amounts on data networks
• Connected to chaos fractals

55
Bibliography

• Enders Applied Econometric Time Series
• Kedem Fokianos Regression Models for Time
  Series Analysis
• Pena, Tao, Tsay A Course in Time Series
  Analysis
• Brillinger lecture notes for Stat 248 at UC
  Berkeley
• BrillingerTime Series Data Analysis and Theory
• Brockwell Davis Introduction to Time Series
  and Forecasting

56
1 real way, 2 fake ways
