Welcome to the Mac OS X v.10.3.x Training

1
Welcome to the Mac OS X v.10.3.x Training
2
(No Transcript)
3
Your Desktop
4
The Menu Bar
5
Apple menu

• Main system menus
• Replaced Special menu from Mac OS 9 and earlier

6
Application menu

• Tells what application is currently active
• Set preferences in this menu
• Quit application from this menu

7
File menu

• Main general functions menu of applications and
  Finder

8
Edit menu

• Use to edit document

9
View menu

• Change how Desktop and Finder windows are viewed
• Clean up a window or the desktop

10
Go menu

• Purpose is self-explanatory
• Use to connect to servers/shared folders

11
Window menu

• Displays what windows are open
• Very useful if have many windows open in an
  applications
• Use in correlation to Expose to keep track of
  open windows/apps

12
Help menu

• Self-explanatory
• Mac Help is a great resource for learning about
  and how to do things with Mac OS X

13
Display menu

• Use to change the resolution and color display of
  your computer
• To show menu on menu bar, go to System
  Preferences --gt Displays

14
Volume menu

• Set sound level of computer
• Show menu on menu bar by going to System
  Preferences --gt Sound

15
Date Time menu

• Self-explanatory
• Can view as digital or analog (hour/minute hands)
  clock
• Can get to Date Time System Preference pane by
  clicking/holding down on the time

16
Switch User menu

• Neat feature new to OS X.3
• Allows users to login without logging out other
  users
• turned on in System Preferences --gt Accounts --gt
  Login Options

View of computer switching to new user
17
The Dock
18
Left-side Dock

• For Applications
• Similar to Launcher in OS 9
• Black triangle under icon shows what is open

19
Right-side Dock

• For Documents, Folders, open Finder windows
• Trash Can located here

20
Dock Divider Line

• ctrl-click to open dock menu
• option-click allows you to slide Dock to make
  bigger or smaller

21
Application Dock menu

• Quit the application
• Holding option gives ability to force quit
• Show what documents are open in the application
• Locate the actual application
• Hide the application

22
Finder
23
Windows Panes
24
Icon view

• This the default view
• Most Mac users are familiar with this view from
  OS 9 and older

25
List view

• Most Mac users are familiar with this view from
  previous OSes
• Shows details about items in a folder or volume

26
Column view

• New to OS X
• Allows you to view contents of several folders at
  once, in same hierarchy

27
Sidebar

• Lists typical important folders and volumes for
  easy access
• Can be hidden

28
Sidebar hidden

• To hide sidebar, click on circle in middle of
  line dividing sidebar from main window, then
  slide to the left

29
Macintosh HD

• Unlike previous Mac OSes, OS X needs to keep the
  root of the hard drive clean
• Only certain folders should exist at this level
• Everything has its place and everything needs to
  be in its place

30
Macintosh HD root view
Typical HD
Clean HD
31
Useful Finder info

• Help menu
• Find menu options
• Empty trash
• Ctrl (or right-click) menu

32
Help menu Viewer

• Very useful to learn about various aspects of OS X

33
Find File Options

• 3 ways to find files, and Sherlock isnt one of
  them
• File--gtFind
• apple-F
• Finder window Search tool

Find menu
Search tool
34
Find File Windows-Find menu option or apple-F
Find window from Find menu
Find Results window from Find menu
35
Find File Windows -Finder window Search tool
Search tool options -click the magnifying
glass to show menu
Find Results window from Search tool
36
Empty the Trash

• Finder --gt Empty Trash or shift-apple-delete

or
Click and hold on Docks Trash icon menu appears
37
Ctrl-click Menu

• Ctrl-click on Desktop
• Can right-click if have 2-button mouse

38
Home Folder

• Location for each users Desktop, documents,
  preferences, etc.
• Not accessible by other users
• This is where you put your stuff

39
Home Folder

• Desktop - what you see on your desktop
• Documents - where all your documents should be
• Library - your preferences, settings, etc.
• Movies, Music, Pictures - to store those items
• Public - accessible by other users
• Sites - your personal web site

40
Home folder path

• Macintosh HD --gt Users --gt your username
• Shared folder is for sharing items with other
  local users

41
(No Transcript)
42
Finder Preferences

• Finder --gt Preferences...
• Used to change how Finder looks and works

43
View Preferences

• Use to modify Finder windows
• View --gt Show view options
• Can change each individual folder or all at same
  time, including putting pictures in background

44
Window Toolbar Preferences

• View --gt Customize Toolbar...
• Used to change tools available at top of each
  Finder window

45
System Preferences

• Controls nearly everything on your Mac
• Replaces Preferences and Control Panels in
  previous Mac OSes

46
Access to System Preferences

• Apple --gt System Preferences...
• On the Dock
• In the Applications folder

47
System Preferences
48
System Preferences
Appearance

• Changes various details of the GUI

49
System Preferences
Desktop Screen Saver

• Use to change the desktop picture
• Be careful of how often you have picture change,
  can slow down computer performance
• Use to set a screen saver though not needed with
  todays screens

50
System PreferencesDock

• Use to modify Dock settings
• Can also access these settings from the Apple
  menu, and by ctrl-click on the Dock divider line

51
System PreferencesExpose

• Use to set how windows can be hidden/shown, and
  set hot corners for various purposes

52
System PreferencesInternational

• Use to set primary language used by computer
• Use to set how numbers/dates are shown
• Use to determine what languages are available
  with the keyboard

53
System PreferencesSecurity

• Use to secure home folder, set passwords on
  various functions
• Use with extreme caution if you forget your
  password, all is lost!

54
System PreferencesCDs DVDs

• Use to set how Finder handles CDs and DVDs

55
System PreferencesDisplays

• Use to set display resolution, colors, geometry
• Can have display options shown on menu bar -
  helpful if you have programs that require
  different resolutions, or use a projector

56
System PreferencesEnergy Saver

• Use to set energy saving options
• The settings you see here will work for most
  situations

57
System Preferences Energy Saver (cont).

• Use to schedule when to shut down or put computer
  to sleep

- Use to set how computer handles power
failures, other power issues
58
System PreferencesKeyboard Mouse

• Use to set how keyboard and mouse respond
• Also, shows shortcut keystrokes for various
  commands
• Can create own shortcuts here

59
System PreferencesPrinter Fax

• Use to set default printer
• Can share printer
• Set up computer as a fax machine. Need phone line
  connection.

60
System PreferencesSound

• Use to set sounds, volumes used by computer
• Set how sound is put out by computer
• Set how computer receives sound

61
System Preferences.Mac

• .Mac is an online service provided by Apple
• It gives you online storage space, a website, and
  various other services
• Cost is determined by services you sign for

62
System PreferencesNetwork

• Used to set up how you connect to a
  network/internet
• Can set which devices are used to connect to a
  network
• Can setup different locations with individual
  configurations for each -ideal if you use your
  computer in different buildings, or between home
  and school

63
System Preferences Network (cont.)

• To configure a device, click on it, choose it in
  the Show menu.
• Set up the IP address, AppleTalk, etc. from this
  window
• Set up different locations by choosing New
  Location from Location menu

64
System PreferencesNetwork (cont.)

• Can access this preference from the Apple menu
• Can change locations from the Apple menu

65
System PreferencesQuicktime

• Use to set various settings for Quicktime
• Only need to set connection speed - set to
  Intranet/LAN for school settings

66
System PreferencesSharing

• Set up computer name
• Set up various ways to share files with users on
  network
• Set up printer sharing
• Set up Apple Remote Desktop

67
System Preferences Sharing (cont.)

• Apple Remote Desktop is the OS X version of
  Network Assistant
• Can control virtually every aspect of client
  computer from a remote location
• Way cool in a lab setting!

68
System PreferencesAccounts

• Set up user accounts
• Set access privileges for individual users
• Set start up items - must be logged in as the
  user to set this up

69
System PreferencesAccounts (cont.)

• Set up Log in Options
• This includes Automatic login, and enabling Fast
  User Switching

70
System PreferencesAccounts (cont.)

• To have an item, such as a network volume, open
  when you log in
• Click the Startup Items tab
• Click the tab
• In popup window, find and select the item to open
  at startup then click Add

71
System PreferencesAccounts (cont.)

• Use Security to set up additional computer
  administrators - good to have a back door
• If use FileVault, do not forget the password! You
  will lose everything!

72
System PreferencesAccounts (cont.)

• Use Limitations to set limits on what users can
  or cannot do. Very useful in classroom or lab
  settings.

73
System PreferencesClassic

• Classic is an emulator of OS 9, so can run older,
  non-OS X native applications
• Can set to start at login
• Can set virtual memory of Classic apps -
  Virtual memory settings not needed for OS X
  applications

74
System PreferencesDate Time

• Set the time and date
• Below are typical settings for Blackfoot School
  District 55, since we have our own time server

75
System PreferencesSoftware Update

• Use to keep Apple software up-to-date
• Important security updates available through
  Software Update
• Can set schedule when to look for updates

76
System PreferencesSpeech

• Set voice commands
• Set voice computer uses to talk
• Great for learning or physically disabled students

77
System PreferencesStartup Disk

• Use to set the disk and OS the computer will boot
  up from.
• Network Startup is used if have a Netboot
  server/image set up

78
System PreferencesUniversal Access

• Set various view options for seeing, hearing,
  physically impaired students
• Students like to play with some of these
  settings, so check here first if monitor seems
  messed up.

79
Applications
80
Applications installed with Mac OS X

• iCal - a calendaring program
• Can be set up to sync with a PDA device
• Can be set up to display on the internet
• Can share calendars with other iCal users

81
Applications installed with Mac OS X

• iChat - Apples instant messaging app.
• Uses AOLs AIM network, and Apples Rendezvous
  network
• Can do voice and video live chats
• Can be helpful for contact between the office and
  classrooms

82
Applications installed with Mac OS X

• iMovie - video editing app
• Has many great editing features, templates
• If have a DVD-burner, can export to iDVD and
  create menu, etc for DVDs

83
Applications installed with Mac OS X

• iPhoto - photo editing software
• Can import directly from a camera
• Basic editing capabilities - great red-eye
  reduction!
• Other neat features

84
Applications installed with Mac OS X

• iTunes - music app
• Import music from CDs
• Play music on CDs
• Create own albums for specific purposes

85
Applications installed with Mac OS X

• Safari - Apples internet browser

86
Safari (cont.)

• Can set to block popup ads
• Can set to open new windows or tabs
• Can customize menu bar

87
Safari (cont.)
- Set the home page - Decide where to save
downloads - Enable java and block pop ups
88
Safari (cont.)

• Enable tabs so can keep track of open web sites

89
Applications installed with Mac OS X

• Sherlock - Internet search engine, and so much
  more ...

90
Force-quit applications

• When a program doesnt respond, can force quit
  the program
• No longer have to restart after force-quit
• 3 ways to force-quit
• Press apple-shift-esc
• Apple--gtForce Quit...
• Option-click application icon on Dock

91
Opening documents in another application

• Can decide what application will open a certain
  document
• 3 ways to get to Open with window
• In Finder, File--gt Open with...
• In Get Info window
• Ctrl-click (or right-click) on document

92
Saving Documents

• When saving documents, by default the application
  will save it to your Documents folder
• To save elsewhere, click the Where drop down
  menu, or the triangle next to the Save As line,
  then scroll to where you want to save

93
Connecting to Servers

• Chooser no longer exists
• Connect to servers 2 ways
• Go --gt Connect to Server...
• Open Finder window, select Network icon in side
  bar

94
Connect to Server menu

• Go --gt Connect to Server...
• Type in server name or IP address and click
  Connect

95
Connect to Server menu (cont.)

• Authenticate in popup window
• Select share to mount from next popup window
• Click OK

96
Connect to Server menu (cont.)

• Shared folder icon will appear on desktop and in
  Finder window

97
Finder Network Access

• Open a Finder window
• Click the Network icon in side bar

Available workgroups, domains, servers will
appear in window
98
Finder Network Access(cont.)
- Most Apple servers appear in Local folder -
Windows servers appear in their domain or
workgroup folder

• Navigate to server
• Double-click on icon, or click connect (if in
  column view)

99
Finder Network Access(cont.)

• Authenticate in popup window
• Select share in Finder window

- window for connecting to Windows servers
100
Setting up Printers

• Since there is no Chooser, printers are set up in
  Printer Setup Utility
• Printer Setup Utility is found in Applications
  --gt Utilities

101
Setting up Printers (cont.)

• When first open utility, asked to set up a
  printer
• Pop up window lists ways to connect to a printer
• Most reliable is through IP printing
• AppleTalk or Rendezvous may also be used

102
Setting up Printers (cont.)

• Once printer is selected, select the printer
  maker and model type to load the correct drivers

- When finished, click Add
103
Setting up Printers (cont.)

• Can change name of printer (locally, not on
  printer itself), and other default settings in
  Printer Info
• To see Printer Info, click once on the printer,
  then either press apple-i, or go to Printer --gt
  Get Info

104
Classic - Mac OS 9 Emulator

• Allows you to run pre-Mac OS X applications
• Set up through System Preferences
• Acts like a second computer
• Have to set up printers through Chooser
• Uses same IP address as OS X

105
Classic - Mac OS 9 Emulator (cont.)

• Startup looks like the familiar startup window
• When running Classic apps, Apple menu and Finder
  windows change to Classic style

106
Burning CDs DVDs

• Depending on the type of drive you have, you
  potentially can burn CDR, CDRW, DVD-R, DVD-RW
  discs
• Simplest way is to insert CDR, name it, drag
  items to be copied onto CDR, then drag CDR to
  Trash can. Click Burn when asked.

- Its suggested if you plan to do a lot of
burning, to buy a commercial burning program,
such as Roxios Toast Titanium
107
Burning CDs DVDs Demo
108
Get Info Window

• Has become a powerful tool
• Can set what application(s) open a document
• Set who has privileges to view, open, change
  documents, folders, applications
• Change icon of an application, document, folder,
  or volume

109
Get Info Window (cont.)

• Change ownership or group access if want to lock
  out other users, or give them access to files,
  documents, or applications
• Be careful with how you change ownership, because
  you can cause the computer to not work anymore,
  or lock yourself out of the computer

110
Get Info Window (cont.)

• Change permissions to determine what different
  users and groups can do with a file, folder, or
  application
• Be careful in what you change and how because you
  can lock yourself out of your own computer

111
Fonts

• Can have a nearly unlimited number of fonts
• Stored in 3 locations
• Home--gtLibrary --gt Fonts (for your use only)
• Macintosh HD --gt Library --gt Fonts (for every
  users use)
• Macintosh HD --gt System --gt Library --gt Fonts
  (for OS use)
• Font Book helps to organize your fonts
• Can import fonts
• Decide who gets to use which fonts
• Much more!

112
Fonts - The Movie
113
Q A

• review any topic we covered
• cover anything we didnt get to in the training
