PROGRAMS IN HOMELAND SECURITY AT DIMACS

1
PROGRAMS IN HOMELAND SECURITY AT DIMACS
Fred S. Roberts DIMACS Director
2
THE FOUNDING OF DIMACSTHE NSF SCIENCE AND
TECHNOLOGY CENTERS PROGRAM

• The STC program was launched by the White House
  and the National Academy of Sciences in 1988 in
  order to increase the economic competitiveness of
  the U.S.
• NSF ran a nationwide competition. The rules
• cutting edge research
• education and knowledge transfer
• university-industry partnerships

3
THE FOUNDING OF DIMACS

• Because of the increasing importance of discrete
  mathematics and theoretical computer science,
  especially in the fields of telecommunications
  and computing, four institutions, Rutgers and
  Princeton Universities and ATT Bell Labs and
  Bell Communications Research (Bellcore) each
  developed strong research groups in these fields.
• Under the leadership of Rutgers, they came
  together to found DIMACS and entered the STC
  competition.
• There were more than 800 preproposals more than
  300 proposals, in all fields of science 11
  winners.

4
The DIMACS Partners Today
Rutgers University Princeton University ATT
Labs Bell Labs (Lucent Technologies) NEC
Laboratories America Telcordia Technologies Affil
iates Avaya Labs HP Labs IBM Research Microsoft
Research Stevens Institute of Technology
5
WHO IS DIMACS?

• There are about 250 scientists affiliated with
  DIMACS and called permanent members.
• Most are from the partner and affiliated
  organizations.
• They include many of the worlds leaders in
  discrete mathematics and theoretical computer
  science and their applications.
• They also include statisticians, biologists,
  psychologists, chemists, epidemiologists, and
  engineers.
• None are paid by DIMACS, but they join in DIMACS
  projects.

6
Outline A Selection of DIMACS Projects

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

7
The Bioterrorism Sensor Location Problem
8

• Early warning is critical in defense against
  terrorism
• This is a crucial factor underlying the
  governments plans to place networks of
  sensors/detectors to warn of a bioterrorist
  attack

The BASIS System Salt Lake City
9
Locating Sensors is not Easy

• Sensors are expensive
• How do we select them and where do we place them
  to maximize coverage, expedite an alarm, and
  keep the cost down?
• Approaches that improve upon existing, ad hoc
  location methods could save countless lives in
  the case of an attack and also money in capital
  and operational costs.

10
Two Fundamental Problems

• Sensor Location Problem
• Choose an appropriate mix of sensors
• decide where to locate them for best protection
  and early warning

11
Two Fundamental Problems

• Pattern Interpretation Problem When sensors set
  off an alarm, help public health decision makers
  decide
• Has an attack taken place?
• What additional monitoring is needed?
• What was its extent and location?
• What is an appropriate response?

12
The SLP What is a Measure of Success of a
Solution?

• A modeling problem.
• Needs to be made precise.
• Many possible formulations.

13
The SLP What is a Measure of Success of a
Solution?

• Identify and ameliorate false alarms.
• Defending against a worst case attack or an
  average case attack.
• Minimize time to first alarm? (Worst case?
  (Average case?)
• Maximize coverage of the area.
• Minimize geographical area not covered
• Minimize size of population not covered
• Minimize probability of missing an attack

14
The SLP What is a Measure of Success of a
Solution?

• Cost Given a mix of available sensors and a
  fixed budget, what mix will best accomplish our
  other goals?

15
The SLP What is a Measure of Success of a
Solution?

• Its hard to separate the goals.
• Even a small number of sensors might detect an
  attack if there is no constraint on time to
  alarm.
• Without budgetary restrictions, a lot more can be
  accomplished.

16
The Sensor Location Problem

• Approach is to develop new algorithmic methods.
• We are building on approaches to other modeling
  problems, seeing if they can be modified in the
  sensor location context.
• This is a multi-criteria modeling problem and it
  seems hopeless to try to find optimal solutions
• We will be happy with efficient algorithms that
  find good solutions

17
Algorithmic Approaches I Greedy Algorithms
18
Greedy Algorithms

• Find the most important location first and locate
  a sensor there.
• Find second-most important location.
• Etc.
• Builds on earlier mathematical work at Institute
  for Defense Analyses (Grotte, Platt)
• Steepest ascent approach.
• No guarantee of optimal or best solution.
• In practice, gets pretty close to optimal
  solution.

19
Algorithmic Approaches II Variants of Classic
Location and Clustering Methods
20
Algorithmic Approaches II Variants of Classic
Location and Clustering Methods

• Location theory locate facilities (sensors) to
  be used by users located in a region.
• Cluster analysis Given points in a metric space,
  partition them into groups or clusters so points
  within clusters are relatively close.
• Clusters correspond to points covered by a
  facility (sensor).

21
Variants of Classic Location and Clustering
Methods

• k-median clustering Given k sensors, place them
  so each point in the city is within x feet of a
  sensor.
• Complications More dimensions location affects
  sensitivity, wind strength enters, sensors have
  different characteristics, etc.
• This higher-dimensional k-median clustering
  problem is hard! Best-known algorithms are due to
  Rafail Ostrovsky.

22
Variants of Classic Location and Clustering
Methods

• Further complications make this even more
  challenging
• Different costs of different sensors
• Restrictions on where we can place different
  sensors
• Is it better to have every point within x feet of
  some sensor or every point within y feet of at
  least three sensors (y gt x)?

• Approximation methods due to Chuzhoy,
  Ostrovsky, and Rabani and to Guha, Tardos, and
  Shmoys are relevant.

23
Algorithmic Approaches III Variants of Highway
Sensor Network Algorithms
24
Variants of Highway Sensor Network Algorithms

• Sensors located along highways and nearby
  pathways measure atmospheric and road conditions.
• Muthukrishnan, et al. have developed very
  efficient algorithms for sensor location.
• Based on bichromatic clustering and
  bichromatic facility location (color nodes
  corresponding to sensors red, nodes corresponding
  to sensor messages blue)

25
Variants of Highway Sensor Network Algorithms

• These algorithms apply to situations with many
  more sensors than the bioterrorism sensor
  location problem.
• As BT sensor technology changes, we can envision
  a myriad of miniature sensors distributed around
  a city, making this work all the more relevant.

26
Algorithmic Approaches IV Building on Equipment
Placing Algorithms
27
Building on Equipment Placing Algorithms

• The Node Placement Problem is problem of
  determining locations or nodes to install certain
  types of networking equipment.
• Coverage and cost are a major consideration.
• Researchers at Telcordia Technologies have
  studied variations of this problem arising from
  broadband access technologies.

28
The Broadband Access Node Placement Problem

• There are inherent range limitations that drive
  placement.
• E.g. customer for DSL service must be within xx
  feet of an assigned multiplexer.
• Multiplexer sensor.
• Problem solved using dynamic programming
  algorithms.
• (Tamra Carpenter, Martin Eiger,David Shallcross,
  Paul Seymour)

29
The Broadband Access Node Placement Problem
Complications

• Restrictions on types of equipment that can be
  placed at a given node.
• Constraints on how far a signal from a given
  piece of equipment can travel.
• Cost and profit maximization considerations.
• Relevance of work on general integer programming,
  the knapsack cover problem, and local access
  network expansion problems.

30
The Pattern Interpretation Problem
31
The Pattern Interpretation Problem

• It will be up to the Decision Maker to decide how
  to respond to an alarm from the sensor network.

32
The Pattern Interpretation Problem

• Little has been done to develop analytical models
  for rapid evaluation of a positive alarm or
  pattern of alarms from a sensor network.
• How can this pattern be used to minimize false
  alarms?
• Given an alarm, what other surveillance measures
  can be used to confirm an attack, locate areas of
  major threat, and guide public health
  interventions?

33
The Pattern Interpretation Problem (PIP)

• Close connection to the SLP.
• How we interpret a pattern of alarms will affect
  how we place the sensors.
• The same simulation models used to place the
  sensors can help us in tracing back from an alarm
  to a triggering attack.

34
Approaching the PIP Minimizing False Alarms
35
Approaching the PIP Minimizing False Alarms

• One approach Redundancy. Require two or more
  sensors to make a detection before an alarm is
  considered confirmed.

36
Approaching the PIP Minimizing False Alarms

• Portal Shield requires two positives for the
  same agent during a specific time period.
• Redundancy II Place two or more sensors at or
  near the same location. Require two proximate
  sensors to give off an alarm before we consider
  it confirmed.
• Redundancy drawbacks cost, delay in confirming
  an alarm.

37
Approaching the PIP Using Decision Rules

• Existing sensors come with a sensitivity level
  specified and sound an alarm when the number of
  particles collected is sufficiently high above
  threshold.

38
Approaching the PIP Using Decision Rules

• Alternative decision rule alarm if two sensors
  reach 90 of threshold, three reach 75 of
  threshold, etc.
• One approach use clustering algorithms for
  sounding an alarm based on a given distribution
  of clusters of sensors reaching a percentage of
  threshold.

39
Approaching the PIP Using Decision Rules

• When sensors are to be used jointly, the rules
  for tuning each sensor should be optimized to
  take advantage of the fact that each is part of a
  network.
• The optimal tuning depends on the decision rule
  applied to reach an overall decision given the
  sensor inputs.

40
Approaching the PIP Using Decision Rules

• Prior work along these lines in missile detection
  (Cherikh and Kantor)

41
Approaching the PIP Using Decision Rules

• Most work has concentrated on the case of
  stochastic independence of information available
  at two sensors clearly violated in BT sensor
  location problems.
• Even with stochastic independence, finding
  optimal decision rules is nontrivial.
• Recent promising approaches of Paul Kantor study
  fusion of multiple methods for monitoring message
  streams.

42
Approaching the PIP Spatio-Temporal Mining of
Sensor Data
43
Approaching the PIP Spatio-Temporal Mining of
Sensor Data

• Sensors provide observations of the state of the
  world localized in space and time.
• Finding trends in data from individual sensors
  time series data mining.
• PIP detecting general correlations in multiple
  time series of observations.
• This has been studied in statistics, database
  theory, knowledge discovery, data mining.
• Complications proximity relationships based on
  geography complex chronological effects.

44
Approaching the PIP Spatio-Temporal Mining of
Sensor Data

• Sensor technology is evolving rapidly.
• It makes sense to consider idealized settings
  where data are collected continuously and
  communicated instantly.
• Then, modern methods of spatio-temporal data
  mining due to Muthukrishnan and others are
  relevant.

45
Approaching the PIP Triggering Other Methods of
Surveillance

• One type of BT surveillance cannot be considered
  in isolation.
• Question How can the pattern of sensor warnings
  guide other biosurveillance methods?
• Increased syndromic surveillance?
• Change threshold for alarm in syndromic
  surveillance?
• Increased attention to E.R. visits in a certain
  region?

46
Approaching the PIP Triggering Other Methods of
Surveillance

• Decreased threshold for alarm from subway worker
  absenteeism levels?

47
Approaching the PIP Triggering Other Methods of
Surveillance

• If there is an initial alarm, each sensor may be
  read more often.
• How do we pick the sensors to read more
  frequently?
• This is adaptive biosensor engagement.
• Methods of bichromatic combinatorial optimization
  may be relevant.
• As for the SLP, sensors get one color, sensor
  messages another.
• Relevance of work of Muthukrishnan.

48
Outline

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

49
Port of Entry Inspection Algorithms
In collaboration with Los Alamos National
Laboratory
50
Port of Entry Inspection Algorithms

• Goal Find ways to intercept illicit nuclear
  materials and weapons destined for the U.S. via
  the maritime transportation system
• Aim Develop decision support algorithms that
  will help us to optimally intercept illicit
  materials and weapons
• Find inspection schemes that minimize total
  cost including cost of false positives and
  false negatives

51
Sequential Decision Making Problem

• Stream of entities arrives at a port
• Decision Maker needs to decide which to inspect,
  which to subject to increasingly stringent
  inspection based on outcomes of previous
  inspections
• Our approach decision logics and combinatorial
  optimization methods
• Builds on approach of Stroud
• and Saeger and large literature
• in sequential decision making.

52
Sequential Decision Making Problem

• Entities arriving to be classified into
  categories.
• Simple case 0 ok, 1 suspicious
• Observations are made.
• Inspection scheme specifies which observations
  are to be made based on previous observations
• Entities have attributes a0, a1, , an, each in a
  number of states
• Sample attributes
• Does ships manifest set off an alarm?
• Does container give off neutron or Gamma emission
  above threshold?
• Does a radiograph image come up positive?
• Does an induced fission test come up positive?

53
Sequential Decision Making Problem

• Simplest Case Attributes are in state 0 or 1
• Then Entity is a binary string like 011001
• Then Classification is a decision function F
  that assigns each binary string to a category.
• If there are two categories, 0 and 1, F is a
  boolean function.
• F(000) F(111) 1, F(abc) 0 otherwise
• This classifies an entity as positive iff it has
  none of the attributes or all of them.

54
Sequential Decision Making Problem

• Different problems depending on whether or not F
  is known. Assume first that F is known.
• Given an entity, test its attributes until know
  enough to calculate the value of F.
• An inspection scheme tells us in which order to
  test the attributes to minimize cost.
• Even this simplified problem is hard
  computationally.

55
Binary Decision Tree Approach

• We assume we have sensors to measure presence or
  absence of attributes.
• Build a tree
• Nodes are sensors or categories (0 or 1)
• Label nodes with atrribute the sensor measures
  for or the number of the category
• Category nodes are leaves of the tree nodes
  with only one neighbor
• Two arcs exit from each sensor node, labeled left
  and right.
• Take the right arc when sensor says the attribute
  is present, left arc otherwise

56
Binary Decision Tree Approach

• We reach category 1 from the root only through
  the path a0 to a1 to 1.
• Thus, an entity is classified in category 1 iff
  it has both attributes.
• The binary decision tree corresponds to the
  boolean function F(11) 1, F(10) F(01) F(00)
  0.

Figure 1
57
Binary Decision Tree Approach

• We reach category 1 from the root by
• a0 L to a1 R a2 R 1 or
• a0 R a2 R1
• An entity is classified in category 1 iff has
• a1 and a2 and not a0 or
• a0 and a2 and possibly a1.
• Corresponding boolean function F(111) F(101)
  F(011) 1, F(abc) 0 otherwise.

Figure 2
58
Binary Decision Tree Approach

• This binary decision tree corresponds to the same
  boolean function
• F(111) F(101) F(011) 1, F(abc) 0
  otherwise.
• However, it has one less observation node. So, it
  is more efficient if all observations are equally
  costly and equally likely.

Figure 3
59
Binary Decision Tree Approach

• Even if the boolean function F is fixed, the
  problem of finding the optimal binary decision
  tree for it is NP-complete.
• For small n, can try to solve it by brute force
  enumeration.
• But even for n 4, not practical. (n 4 at Port
  of Long Beach-Los Angeles)
• Seeking heuristic algorithms, approximations to
  optimal.
• Making special assumptions about the boolean
  function F.
• Example For so-called monotone boolean
  functions, integer programming formulations give
  promising heuristics.

60
Cost Functions

• Above analysis Only uses number of sensors
• Using a sensor has a cost
• Unit cost of inspecting one item with it
• Fixed cost of purchasing and deploying it
• Delay cost from queuing up at the sensor station
• How many nodes of the decision tree are actually
  visited during average inspection? Depends on
  distribution of entities.

61
Cost Functions

• Cost of false positive Cost of additional tests.

• If it means opening the container, its very
  expensive.
• Cost of false negative Complex issue.

62
Complications

• Sensor errors probabilistic approach
• More than two values of an attribute (present,
  absent, present with 75 probability, )
• Partially defined boolean functions (inferring
  the boolean function from observations)
• In this case, machine learning approaches are
  promising
• Bayesian binary regression
• Splitting strategies
• Pruning learned decision trees

63
Outline

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

64
Monitoring Message Streams Algorithmic Methods
for Automatic Processing of Messages
65
OBJECTIVE
Monitor huge communication streams, in
particular, streams of textualized communication
to automatically detect pattern changes and
"significant" events
Motivation monitoring email traffic, news,
communiques, faxes, voice intercepts (with speech
recognition)
66
TECHNICAL APPROACHES

• Given stream of text in any language.
• Decide whether "new events" are present in the
  flow of messages.
• Event new topic or topic with unusual level of
  activity.
• Initial Problem Retrospective or Supervised
  Event Identification Classification into
  pre-existing classes. Given example messages on
  events/topics of interest, algorithm detects
  instances in the stream.

67
TECHNICAL APPROACHES SUPERVISED FILTERING

• Batch filtering Given examples of relevant
  documents up front.
• Adaptive filtering Examples accumulated need to
  decide if will bother analyst for guidance pay
  for information about relevance as process moves
  along.

68

• MORE COMPLEX PROBLEM PROSPECTIVE DETECTION OR
  UNSUPERVISED FILTERING
• Classes change - new classes or change meaning
• A difficult problem in statistics
• Recent new C.S. approaches
• Semi-supervised Learning
• Algorithm suggests a possible new event/topic
• Human analyst labels it determines its
  significance

69
COMPONENTS OF AUTOMATIC MESSAGE PROCESSING

• (1). Compression of Text increase speed, reduce
  memory/disk use
• (2). Representation of Text convert text to
  form amenable to computation and statistical
  analysis
• (3). Matching Scheme compute similarity between
  texts
• (4). Learning Method create profiles of
  events/topics from known examples.
• (5). Fusion Scheme -- combine multiple filtering
  techniques to increase accuracy.

70
COMPONENTS OF AUTOMATIC MESSAGE PROCESSING - II

• These distinctions are somewhat arbitrary.
• Many approaches to message processing overlap
  several of these components of automatic message
  processing our techniques usually address more
  than one component.
• Project Premise Existing methods dont exploit
  the full power of the 5 components, synergies
  among them, and/or an understanding of how to
  apply them to text data.

71
COMPONENTS OF AUTOMATIC MESSAGE PROCESSING - III

• Our approach is to develop/explore methods for
  each component and then to combine them.
• In the first phase of the project, we did over
  5000 complete experiments with different
  combinations of methods.

72
Nearest Neighbor (kNN) Classifiers

• Route message by
• Finding k most similar training messages
  (neighbors)
• Assign to classes that are most common among
  neighbors (using weighting by distance)
• kNN classifiers studied since 1958, for text
  since early 90s
• Moderately effective for text has been
  considered inefficient finding neighbors is slow
• But, finding neighbors only needs to be done once
• No matter how many classes (even if huge)
• So for large number of topics, maybe more
  efficient than one-classifier-per-topic approaches

73
Speeding up kNN

• Can finding neighbors be made fast enough to make
  kNN practical?
• Worked on fast implementation
• Store text and classes sparsely (Representation)
• Store class labels sparsely
• Arrange computations to do work proportional only
  to number of class labels in neighbors, not total
  number of classes
• Search engine heuristics use the in-memory
  inverted file (Matching)
• Use inverted file (group by word, not by
  document)
• Retain only high impact terms within each
  document, or within each inverted list
• Compute similarities using only inverted lists
  for the few words occurring in test document

74
kNN Results

• Great reduction in size of inverted index and
  speed of classification
• Slight additional cost in effectiveness
• Effectiveness slightly below our best methods
  (Bayesian probit and logistic classifiers)
• Compressed index 90 smaller than original index
  w/only 7-12 loss in effectiveness (macro-F1)
• Approximate matching is 10 to 100 times faster w/
  only 2-10 loss in effectiveness (macro-F1)
• Ours are first large scale experiments on search
  engine heuristic for neighbor lookup in kNN
• Partnership between theoreticians and
  practitioners.

75
Bayesian Methods

• Bayesian statistical methods place prior
  probability distributions on all unknowns, and
  then compute posterior distribution for the
  unknowns conditional on the knowns.

Thomas Bayes
76
Bayesian Methods

• Zhang and Oles (2001) developed an efficient
  optimization algorithm for logistic regression
  (10,000 dimensions) and achieved excellent
  predictive performance.
• The Bayesian approach explicitly incorporates
  prior knowledge about model complexity
  (regularization)
• We extended the Bayesian approach to incorporate
  a prior requirement for sparsity.
• Logistic regression has one parameter per
  dimension our sparse model sets many of these to
  zero handles hundreds of thousands of parameters
  efficiently.
• Resulting sparse models produce outstanding
  accuracy and ultra-fast predictions with no
  ad-hoc feature selection

77
Bayesian Methods Sample Results

• We have implemented several efficient variants,
  e.g., probit,informative priors.
• Publicly released software over 1000 downloads
• Compared to Zhang Oles, our implementation
• Eliminates ad hoc feature selection
• Often uses less than 1 of the features at
  prediction time
• Is publicly available
• Accuracy as good as the best results ever
  published.
• In sum, we have a sparseness-inducing Bayesian
  approach that produces dramatically simpler
  models with no loss in accuracy

78
Streaming Data Analysis

• Motivated by need to make decisions about data
  during an initial scan as data stream by
• Recent development of theoretical CS algorithms
• Algorithms motivated by intrusion detection,
  transaction applications, time series
  transactions

79
Streaming Text Data Historic Data Analysis

• The accumulation of text messages is massive over
  time
• A lot of streaming research is focused on
  on-going or current analyses
• It is a great challenge to use only summarized
  historic data and see if a currently emerging
  phenomenon had precursors occurring in the past
• We are working on a novel architecture for
  historic and posterior analyses via small
  summaries - sketches

80
Streaming Analysis Tool CM Sketch

• Theoretical We have developed the CM Sketch that
  uses (1/e) log 1/d space to approximate data
  distribution with error at most e, and
  probability of success at least 1-d.
• All other previously known sample or sketch
  methods use space at least (1/e2).
• CM Sketch is an order of magnitude better.
• Practical Few 10's of KBs gives accurate
  summary of large data Create summaries of data
  that allow historic queries to find
• Heavy Hitters (Most Frequent Items)
• Quantiles of a Distribution (Median, Percentiles
  etc.)
• Finding items with large changes

81
Outline

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

82
Large-scale Automated Author Identification
83
Statistical Analysis of Text

• Statistical text analysis has a long history in
  literary analysis and in solving disputed
  authorship problems
• First (?) is Thomas C. Mendenhall in 1887

84

• Hamilton versus Madison the Federalist Papers
• Mosteller and Wallace (1963) used Naïve Bayes
  with a Poisson and Negative Binomial model
• Good predictive performance

85
Some Background

• Identification technologies important for
  homeland security and in the legal system
• Author attribution for textual artifacts using
  topic independent stylometric features has a
  long history
• Historical focus on small numbers of authors and
  low-dimensional representations via function words

86
Author ID Project Objectives

• Application of state-of-the-art statistical and
  computing technologies to authorship attribution
• Work with very high-dimensional document
  representations
• Focus on providing working solutions to
  particular problems

87
Author ID Project Focus

• Goal Identification of Authors From Large
  Collection of Objects
• traditional disputed authorship (choose among k
  known authors)
• clustering of putative authors (e.g., internet
  handles termin8r, heyr, KaMaKaZie)
• document pair analysis Were two documents
  written by the same author?
• odd-man-out Were these documents written by one
  of this set of authors or by someone else?

88
Representation

• Long tradition in stylometry that seeks a small
  number of textual characteristics that
  distinguish the texts of authors from one another
  (Burrows, Holmes, Binongo, Hoover, Mosteller
  Wallace, McMenamin, Tweedie, etc.)
• Typically use function words (a, with, as,
  were, all, would, etc.) followed by PCA cluster
  analysis
• Function words aim to be topic-independent
• Hoover (2003) shows that using all high-frequency
  words does a better job than function words alone

89
Idiosyncratic Usage

• Idiosyncratic usage less formalized in the
  literature (misspellings, repeated neologisms,
  etc.) but apparently useful. For example,
  Fosters unmasking of Klein as the author of
  Primary Colors
• Klein and Anonymous loved unusual adjectives
  ending in -y and inous cartoony, chunky,
  crackly, dorky, snarly,, slimetudinous,
  vertiginous,
• Both Klein and Anonymous added letters to their
  interjections ahh, aww, naww.
• Both Klein and Anonymous loved to coin words
  beginning in hyper-, mega-, post-, quasi-, and
  semi-, more than all others put together
• Klein and Anonymous use riffle to mean rifle
  or rustle, a usage for which the OED provides no
  instance in the past thousand years

90
Odd-Man Out

• Were these documents written by one of this set
  of authors or by someone else?
• Training data contains documents by given set of
  authors
• Test data contains documents by some set of
  authors including some not in original set
• Bayesian hierarchical model incorporates prior
  knowledge that model parameters for different
  authors differ from each other
• Initial success on small-scale simulated examples
• Generalizations for more than one new author

91
Some Results

• Created largest-ever (?) feature set including
  function words, suffixes, POS tags, lengths,
  spelling errors, common English errors,
  grammatical errors, phrases, idiosyncratic usage,
  ngrams, etc.
• Extensive experiments for 1-of-K and
  odd-man-out
• New 1.2 million message Listserv corpus, 82,000
  authors

92
Some Results - II

• Developed general purpose feature
  extraction software for author attribution
• Bayesian Multinomial Regression Software extends
  our highly scalable, sparse, BBR software (MMS
  Project) to the multi-class case

93
Outline

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

94
Special Focus on Computational and Mathematical
Epidemiology
smallpox
95
Components of a Special Focus

• Working Groups
• Tutorials
• Workshops
• Visitor Programs
• Graduate Student Programs
• Postdoc Programs
• Dissemination

96
A Sampling of Working Groups

• WGs on Large Data Sets
• Adverse Event/Disease Reporting, Surveillance
  Analysis
• Data Mining and Epidemiology
• WGs on Analogies between Computers and Humans
• Analogies between Computer Viruses/Immune Systems
  and Human Viruses/Immune Systems
• Distributed Computing, Social Networks, and
  Disease Spread Processes

97
WGs on Methods/Tools of Theoretical CS

• Phylogenetic Trees and Rapidly Evolving Diseases
• Order-Theoretic Aspects of Epidemiology
• WGs on Computational Methods for Analyzing Large
  Models for Spread/Control of Disease
• Spatio-temporal and Network Modeling of Diseases
• Methodologies for Comparing Vaccination
  Strategies

98
WGs on Mathematical Sciences Methodologies

• Mathematical Models and Defense Against
  Bioterrorism
• Predictive Methodologies for Infectious Diseases
• Statistical, Mathematical, and Modeling Issues in
  the Analysis of Marine Diseases

99
Workshops on Modeling of Infectious Diseases
A Sampling of Workshops

• The Pathogenesis of Infectious Diseases
• Models/Methodological Problems of Botanical
  Epidemiology
• WS on Modeling of Non-Infectious Diseases
• Disease Clusters

100
Workshops on Evolution and Epidemiology

• Genetics and Evolution of Pathogens
• The Epidemiology and Evolution of Influenza
• The Evolution and Control of Drug Resistance
• Models of Co-Evolution of Hosts and Pathogens

101
Workshops on Methodological Issues

• Capture-recapture Models in Epidemiology
• Spatial Epidemiology and Geographic Information
  Systems
• Ecologic Inference
• Combinatorial Group Testing

102
Outline

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

103
The DIMACS Working Group on Adverse Event/Disease
Reporting, Surveillance, and Analysis
104
Working Group on Adverse Event/Disease Reporting,
Surveillance, and Analysis

• Health surveillance a core activity in public
  health
• Concerns about bioterrorism have attracted
  attention to new surveillance methods
• OTC drug sales
• Subway worker absenteeism
• Ambulance dispatches
• Spawns need for novel statistical methods for
  surveillance of multiple data streams.
• WG coordinated closely with National Syndromic
  Surveillance Conferences

105
New Data Types for Public Health Surveillance

• Managed care patient encounter data
• Pre-diagnostic/chief complaint (text data)
• Over-the-counter sales transactions
• Drug store
• Grocery store
• 911-emergency calls
• Ambulance dispatch data
• Absenteeism data
• ED discharge summaries
• Prescription/pharmaceuticals
• Adverse event reports

106
Farzad Mostashari
107
New Analytic Methods and Approaches

• Spatial-temporal scan statistics
• Statistical process control (SPC)
• Bayesian applications
• Market-basket association analysis
• Text mining
• Rule-based surveillance
• Change-point techniques

108
SubGroup on Privacy Confidentiality of Health
Data

• Privacy concerns are a major stumbling block to
  public health surveillance, in particular
  bioterrorism surveillance.
• Challenge produce anonymous data specific enough
  for research.
• Exploring ways to remove identifiers (s.s. ,
  tel. , zip code) from data sets.
• Exploring ways to aggregate, remove information
  from data sets.
• Partnerships with cryptographers
• Exploring methods of combinatorial optimization

109
Outline

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

110
Bioterrorism Working Group
anthrax
111
Bioterrorism Working Group

• Biosurveillance
• Evolution
• Modeling Bioterror Response Logistics
• Computer Science Challenges
• Agroterrorism

112
Modeling Bioterror Response Logistics

• Exploring Discrete Optimization/Queueing
• size of stockpiles of vaccines
• allocation of medications
• analysis of bottlenecks in treatment facilities
• transportation schedules

1947 smallpox vaccincation queue NYC
113
Agroterrorism

• Subgroup just starting
• Interest in plant diseases
• Partnership with the National Plant Diagnostic
  Network
• Emphasis on Data Mining and Epidemiology

114
Outline

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

115
Working Group on Modeling Social Responses to
Bioterrorism

• Models of the spread of infectious disease
  commonly assume passive bystanders and rational
  actors who will comply with health authorities.
• It is not clear how well this assumption applies
  to situations like a bioterrorist attack using
  smallpox or plague.

116
Working Group on Modeling Social Responses to
Bioterrorism

• Interdisciplinary group is discussing
  incorporating social behavior into models,
  building models of public health decisionmaking,
  risk communication.
• Some Issues
• Movement
• Compliance
• Rumor
• Subcultural differences
• Indirect economic effects
• Social stigmata
• Panic

How do you measure the indirect cost of an
attack?
117
Outline

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

118
Predicting Disease Outbreaks from Remote Sensing
and Media Data
Outbreaks of disease in other parts of the world
have the capacity to affect the security of the
US
Joint project with Imaging Science and
Information Systems Center at Georgetown Universit
y Medical School (ISIS Center)
119
Predicting Disease Outbreaks from Remote Sensing
and Media Data

• Recent work has shown that its possible to
  predict disease outbreaks in distant parts of the
  world using remotely sensed satellite data.
• SARS and heightened avian flu in the Pacific Rim
  appeared following temperature anomalies in
  China.
• Could we have anticipated this
• given enviro-climatic information?

120
Predicting Disease Outbreaks from Remote Sensing
and Media Data

• Rift Valley Fever epidemic in 1997/8 in East
  Africa occurred following heavy flooding related
  to El Nino
• Flooding in Venezuela in 1995 resulted in a
  multi-pathogen outbreak.

121
Predicting Disease Outbreaks from Remote Sensing
and Media Data

• Indications and warnings can alert US responders
  to bioevents in faraway places.
• Disease that can result in social disruptions can
  be detected in open source media reports even if
  there is no official reporting of this.

122
Predicting Disease Outbreaks from Remote Sensing
and Media Data

• A model developed at the ISIS Center at
  Georgetown predicts social disruptions due to
  disease based on keyword hit counts from
  text-based sources (media reports).
• DIMACS Project goal Use media model to develop
  ways to predict social disruptions from disease
  from remote sensing enviro-climatic data.
• We will be using remote sensing data indicating
  increased Normalized Difference Vegetation Index
  (NDVI).

123
Predicting Disease Outbreaks from Remote Sensing
and Media Data

• Project Premise We can use enviro-climatic
  indices such as NDVI coupled with disease-related
  social disruption predictors from media data
  delayed by several months to validate the
  enviro-climatic indicators as predictors.
• Approach Machine Learning
• Project waiting to get started

124
Predicting Disease Outbreaks from Remote Sensing
and Media Data

• The approach is similar to ones used by members
  of the DIMACS team to estimate probability of a
  match between remotely sensed signals and a
  signature that has been observed before. This
  work has been applied to face recognition and
  explosive detection.

125
Outline

• Bioterrorism Sensor Location
• Port of Entry Inspection Algorithms
• Monitoring Message Streams
• Author Identification
• Computational and Mathematical Epidemiology
• Adverse Event/Disease Reporting/Surveillance/Analy
  sis
• Bioterrorism Working Group
• Modeling Social Responses to Bioterrorism
• Predicting Disease Outbreaks from Remote Sensing
  and Media Data
• Communication Security and Information Privacy

126
Special Focus on Communication Security and
Information Privacy
127
Special Focus on Communication Security and
Information Privacy

• Working Groups
• Privacy-Preserving Data Mining
• Usable Privacy and Security Software
• Data De-Identification, Combinatorial
  Optimization, Graph Theory, and the Stat-OR
  Interface
• Intrusion Detection and Network Security
  Management Systems

128
Special Focus on Communication Security and
Information Privacy

• A Selection of Workshops
• Software Security
• Applied Cryptography and Network Security
• Large-scale Internet Attacks
• Mobile and Wireless Security
• Security of Web Services and E-Commerce
• Database Security Query Authorization and
  Information Inference

129
Working Group on Analogies between Computer
Viruses and Biological Viruses

• Can ideas for defending against biological
  viruses lead to ideas for defending against
  computer viruses?
• Concern about large gap between initial time of
  attack and implementation of defensive strategies
• Public health approach Once a virus has
  infected a machine, it tries to connect it to as
  many computers as possible, as fast as possible.
  A throttle limits rate at which a computer can
  connect to new computers.

130
(No Transcript)
