Proposed NSLS X13B Microdiffraction Instrument

1
Proposed NSLS X13B Microdiffraction
Instrument Source Optics James M.
Ablett National Synchrotron Light Source
2
NSLS 2.8 GeV X-ray Storage Ring
3
X13 Straight-Section
EPW
MGU
4
NSLS 'Hard' X-Ray Sources
1st Harmonic
?MGU
? IVUN
X17 Wiggler
2nd Harmonic
X21 / X25 Wigglers
Log Brightness ( ph / sec / mm2 /mrad2 / 0.1
BW / 300 mA)
3rd Harmonic
X13 Wiggler
NSLS Bending Magnet
Photon Energy keV
5
X13 Undulator Source
The Mini-Gap Undulator MGU the brightest
source of hard x-rays (E 3.7 keV 16 keV) at
the NSLS. MGU parameters 54
pole, 1.25 cm period At a gap of 3.3 mm ,
Magnetic field 0.92 Tesla and Deflection
Parameter, K1.07 Fundamental _at_ 3.7 keV,
4x1017 ph/sec/mm2/mrad2/0.1BW/300mA
6
MGU Spectral Measurements (August 2002
Ablett,Berman)
MGU Brightness Magnetic Gap3.3 mm
MGU Tuning Curves
18
8x1017
Calculated
6x1017
17
Experiment
16
4x1017
Brightness (ph/sec/mm2/mrad2/0.1BW/300mA)
LogBrightness (ph/sec/mm2/mrad2/0.1BW/300mA)
15
2x1017
14
0
12
14
16
10
8
6
4
2
2
6
10
14
18
Photon Energy keV
Photon Energy keV
7
Current X13B Beamline Status
monochromator
hutch
27
24
20
15
12
numbers (in meters )indicate distance from center
of X13 straight-section, where MGU is located.
8
Specifications

• The X13B microdiffraction instrument will be
  modular and compactin design, which will make
  available a variety of x-ray optics forthe
  experimentalist.
• Focused X-ray Beams on the micron-length scale
  and below,
• together with low and high x-ray divergence will
  be available with these optics.These will be
  mounted on a motorized rails and will bereadily
  accessible.
• Pink Beam (Laue) and Monochromatic modes of
  operationwill be available.- Energy tunability
  will be accomplished through a 4 bounce
  monochromator.

9
X13B Microdiffraction Instrument Layout
x-ray microfocusing optics
detector circle
four-bounce mono tank
vibration isolation table
diffractometer
vibration isolation table
24
27
26
25
Distance from MGU source meters
10

• Suite of Optics offered
• Pin Holes
• Capillaries
• KB Mirrors
• Zone Plates
• Planar Refractive Lenses (Current RD)

11

• Key Features
• Achromatic - Energy independent focusing-pink
  beam and monochromatic modes
• Accurate Elliptical Figures Achievable (either by
  bending ormetal deposition ) Small Spot Sizes
• High Reflectivity at Grazing Incidence Angles

Kirkpatrick-Baez Elliptical Mirrors
Heavy metal
Polished spherical Silicon substrate
12
X13B Microprobe
differentially-deposited elliptical KB optics
have been used at X13Bduring the past few years,
designed primarily for high-pressure x-ray
spectroscopy.
Vertical blade scan current derivative
Horizontal blade scan current derivative
9 microns FWHM
3 microns FWHM
blade position microns
blade position microns
13
X13B Microprobe
14
Calcium K? Fluorescence Mapping of Osteoarthritic
Bone
1.
3.7 mm
3.
1.
2.
2.
3.3 mm
3.
15
Preliminary KB layout
25 m to MGU source
2cm
incident x-rays
focal position
3cm
10 cm
Expected Parameters 1 micro-radian figure
error Spot size 0.7 x 2 micron2 Divergence
1mrad (v) x 7 mrad(h) 8 keV, 6x109 ph/sec Gain
5x104
With Figure Error (1 micro-radian)
16
X13B Microprobe RD Efforts -Planar Refractive
Lenses (K. Evans-Lutterodt, J.M. Ablett)
Intensity arb. Unit
Position mm
17
Summary A state-of-the-art hard x-ray
microdiffraction instrumentis proposed for NSLS
mini-gap undulator beamline X13B.It will offer
a variety of x-ray microfocusing optics micron
scale spatial resolution and below high and
low divergence. Big-beam (unfocused )
mode. Pink Beam and Monochromatic Modes of
Operation. Simultaneous fluorescence and
diffraction information.
