Application of Proper Scoring Rules to CostWeighted Classification

1
Application of Proper Scoring Rules to
Cost-Weighted Classification

• Yi Shen
• Department of Statistics
• University of Pennsylvania

2
Outline

• Introduction of cost-weighted classification.
• Review of logistic regression and potential
  problems.
• New weighting schemes by using tailored loss
  functions (proper scoring rules).
• Application to real world data sets.
• From logistic regression to boosting.
• Conclusion.

3
Cost-Weighted Classification

• In a two-class classification problem, we observe
  (x1,y1),,(xn,yn). The response Y takes two
  values, for example, diseased or not, default or
  not. For the purpose of modeling, we label ys as
  0 or 1. The xi are features of the ith subject,
  for example, education, capital gain, etc.
• The goal is to predict the value of the response
  given the values of features. Thus one needs to
  find a classification rule, f(x), that divides
  the feature space into two parts.

4
Cost-Weighted Classification

• Given a classification rule, one might make two
  types of mistakes
• When the true class label is 0, he classifies it
  as 1, which is called
• class 0 misclassification
• When the true class label is 1, he classifies it
  as 0, which is called
• class 1 misclassification

5
Cost-Weighted Classification

• In a cost-weighted classification problem, we
  associate different costs with the two types of
  misclassification. For example, it is more
  expensive to miss a bankruptcy or a severely
  diseased patient.
• Let c1 be the cost for class 1 misclassification,
  c0 be the cost for class 0 misclassification.
• In the ordinary classification, c1 and c0 are set
  to be equal.
• Now the goal is to find a classification rule
  such that the overall cost is minimized.

6
The Optimal Classification Rule (Bayes Rule)

• Theoretically, the best classification is made
  according to the posterior probability p(Y1x)
  which we write p(x) from now on.
• For a cost-weighted classification problem, the
  optimal classification rule is to classify as
  class 1 if p(x) gt c0 /(c1c0), otherwise
  classify as class 0.
• W.l.o.g. assume c1c0 1. Hence we are
  interested in estimating

• p(x) c0
• In reality, p(x) is unknown and needs to be
  estimated from data. We denote the estimate of
  p(x) as q(x).

7
Logistic Regression

• Logistic regression is a generalized linear model
  in which
• The above transformation is called the logistic
  link.
• The link function maps the probability scale to
  the modeling scale.

• Logistic regression tries to minimize the
  negative
• log-likelihood of a Bernoulli distribution

(Log-loss)
8
Logistic Regression

• Logistic regression is equivalent to an
  iteratively reweighted least squares which
  minimizes
• where is the estimated variance
• of a Bernoulli distributed variable.

9
Logistic Regression

• The data points at the two tails are weighted
  more than those in the middle.

10
Logistic Regression

• When the model assumption is not true, the
  weighting scheme from the logistic regression may
  suffer.

• D. Hand et al. (2003) illustrates this
• problem with an artificial example in
• which the true p(x) is not globally linear
• in x, yet p(x) c is linear for all c.

11
Hands Example

• 50 class 1 and 50 class 0.

• Linear functions
• can describe all boundaries p(x) c.

• But NO single linear function
• can describe all of them!

12
Hands Example

• In Hands example,
• p(x) X2 / (X1X2).
• p(x) c implies
• (1 c) X2 c X1

13
Hands Example

• Logistic regression will suffer
• since it tries to fit a single linear
• function to the boundaries!

14
Hands Example
Logistic regression has a problem estimating p(x)
0.3 and p(x) 0.5
15
Another Example

• 80 class 1 and 20 class 0.

• p(x) 5X2 / (X1 5 X2)

• logistic regression induces bias even in
  estimating
• p(x) .5

16
How to fix it?

• Recall Each probability boundary is linear.

• Idea
• Tailor the fitted linear function to a
  specific level,
• and ignore the others!

17
Modification of Logistic Regression

• Recall logistic regr. upweights extreme qs.

• Idea upweight the points with q(x) near c0 !

18
New Weighting Schemes

• Our goal is to design iteratively reweighted
  least squares with new weights

19
New Weighting Schemes(Method 1)

• Let
• where
• Nice when a b 0, the weight function is
  equivalent to the weight in logistic regression.


20
New Weighting Schemes(Method 1)

• We focus the weight function on C0 by

21
New Weighting Schemes(Method 1)
22
New Weighting Schemes(Method 1)

• The weight is the density function of a Beta
  distribution with parameter a and b, where a
  and b are greater than 0.
• The mean of the Beta distribution is
• The constraint () suggests setting the mean of
  the Beta distribution to c0 .

• As a and b goes to infinity, the weight
  function puts
• all the mass on q c0 .

23
New Weighting Schemes (Method 2)

• Scheme 2
• where

24
New Weighting Schemes(Method 2)
C0 .3
25
New Weighting Schemes(Method 2)

• When a 0 and c0 .5, it is equivalent to the
  weight function in logistic regression.
• The weight function is a density when a is
  greater than 0. Its mean is c0 .
• As a goes to infinity, the weight function puts
  all the mass on q c0 .

26
Properties of the Weight Functions

• The weight functions define a family of loss
  functions that share a property which we motivate
  now.
• Recall that in logistic regression we minimize
  the negative log-likelihood

27
Properties of the Weight Functions

• Minimize the conditional expected loss w.r.t. q

For given p, logistic regression tries to
minimize q. If no predictors are present, the
solution should be
q p

• Indeed setting L / q 0
• implies that the minimum is achieved at q p.

28
Properties of the Weight Functions

• Any loss L(pq) that satisfies such a property
  is called

proper scoring rule
29
Structures of Proper Scoring Rules

• Let
• L1 (1-q) denotes the loss associated with
  classification into class 1 it is monotone
  decreasing in q.
• L0 (q) denotes the loss associated with the
  classification into class 0 it is monotone
  increasing in q.

30
Structure of Proper Scoring Rules

• Assume the losses L1(1-q) and L0(q) are
  differentiable. They form a proper scoring rule
  if and only if they satisfy

31
Implementation of the IRLS for the tailored loss

• We want to minimize the empirical loss
• where

• The optimization is still equivalent to IRLS

32
Experiments

• Hands Example
• Training set size 2000

33
Experiments

• Unbalanced design of Hands example.
• Training set size 2000

34
Experiments(Pima Indians diabetes)

• Pima Indians diabetes. 752 instances, 9
  features, 35 1s.

• Buja etal(2001) found that BODY MASS
• and PLASMA are the two most
• dominating predictors.

• They also found that that p(x) has the
• similar characteristic as that in the
• Hands example.

35
Experiments
The highlights represent slices with
near-constant estimated class 1 probability p c
e lt plt c e. The values of c in the slices
increase left to right and top to bottom. The
class 1 probabilities were estimated with
20-nearest-neighbor estimates. Glyphs open
circles no diabetes, class 0filled circles
diabetes, class 1 small gray dots points
outside the slice
36
Experiments

• Using IRLS with tailored loss, we have

37
Experiments

• German credit data 1000 instances, 20
  attributes, Y good credit or not.

• For c0 1/6, 5-CV test error

38
Experiments

• Adult income data14 features, response Annual
  income exceeds 50k or not.(25 1s)
• Training set size30562, test set size15060.

39
Experiments

• For c0 .2,

40
Experiments

• For c0 .8,

41
From Logistic Regression to Boosting

• Boosting by Freud and Schapire (1996) has
  achieved great success in machine learning for
  classification problems.

• It combines a group of weak learners
• (classifiers) with a weighted voting
• scheme so that a strong learner
• (classifier) is obtained.

42
From Logistic Regression to Boosting

• Suppose the response y is labeled 1 or 1, i.e,
• y 2y-1. The popular version of the
  Adaboost algorithm is
• 1. Initialize F(x) 0 and weights wi 1/n, i
  1,,n.
• 2. From t 1,,T
• (a) Fit a weak classifier ft(x) -1,1 to
  the weighted training data..
• (b) Compute weighted misclassification
  rate for ft(x )
• (c) Change weights
• 3. Final classifier

and
43
Boosting As a stagewise Additive Fitting

• In Friedman, Hastie, Tibshirani (2000), boosting
  is viewed as an stagewise additive fitting
  which exploits IRLS-like steps to minimize the
  exponential loss
• The update is
• where usually ft(x) is taken as stumps or
  shallow trees.

44
Boosting As a stagewise Additive Fitting

• Boosting is a stagewise fitting as opposed to
  stepwise fitting

• In stagewise fitting, Fold is not updated
• while in stepwise fitting, it will.

45
Exponential Loss Can Be Mapped to A Proper
Scoring Rule

• Exponential loss can be decomposed to a proper
  scoring rule and a link function

46
Logit-Boost

• FHT(2000) proposed a stagewise additive fitting
  algorithm to minimize the negative log-likelihood.

47
Cost-weighted Boosting

• Again, for cost weighted classification, we could
  optimize the tailored losses with

48
Experiments

• Artificial data 2000 instances.
• Class 1 and Class 0 have equal margin, i.e, there
  are 50 class 1 and 50 class 0.
• Suppose we are interested in estimating
• p(x) .3.

49
Experiments

• t50.

Logloss
Method1
Method2
50
Experiments

• t300, overfitting.

Logloss
Method1
Method2
51
Experiments

• Test set size 10000, test error

t
52
Experiments

• Pima Indian diabetes (using all features)

C0.2
C0.8
53
Experiments

• German Credit data

54
Experiments

• Adult income

C0.8
C0.2
55
Conclusion

• Logistic regression has potential problems for
  cost-weighted classification.

• Reweighting with proper scoring rules
• helps us stay more focused on the
• classification boundary.

• Reweighting could be extended to
• semiparametric modeling like boosting.
