Lecture 35 Stellar Remnants

1
Lecture 35Stellar Remnants
2
Neutron Stars

• Supernova remnant
• Tightly packed neutron core.
• Size 20 km (small asteroid or city)
• Mass 1.4-3 M?
• Density very high
• 1 tsp. gt 100,000,000 tons on Earth.
• Rotates many times per second
• Conservation of Angular Momentum

3

• Strong magnetic field
• When star collapses, magnetic field is
  concentrated.

4
Neutron Star -- HST
5
Pulsars

• 1967 Jocelyn Bell
• Observed object emitting pulses of radio waves.
• Pulses repeated every 1.34 seconds

6

• 100s more have been found.
• Some pulse in optical, X-rays, or gamma rays.
• Periods 0.03-0.3 sec.
• Some associated with supernova remnants.

7
Crab Nebula
8
Crab Pulsar
9

• Hewitt proposed it is a rapidly rotating neutron
  star beaming radiation.
• Magnetic pole and rotational axis not quite lined
  up.
• Strong magnetic field.
• Charged particles at poles of magnetic fields and
  emit large amounts of energy.

Lighthouse Model
10

• Not all neutron stars are seen to pulse
• Beam may not be pointed at the Earth
• Unknown if all neutron stars are pulsars

11
Formation of Black Holes

• If core of star has M gt3 M? the neutron pressure
  cannot hold up the core
• Nothing known left to stop collapse.
• Becomes a singularity -- object with infinite
  density and infinitely small size.

12
Why are Black Holes Black?

• Escape velocity velocity needed to escape the
  gravitational pull of an object.
• On Earth 11 km/s
• As size decreases, gravity on the surface of the
  star increases so a larger velocity is needed to
  escape surface.
• When the escape velocity at the surface becomes
  greater than the speed of light no light can
  escape.

13
Schwarzschild Radius
Radius an object needs at which the escape
velocity on the surface would be greater than the
speed of light.
Black Hole Light cannot escape surface (c ?
escape velocity)
Radius ? Schwarzschild Radius
14
Event Horizon

• If BH is smaller than Schwarzchild Radius, the
  distance from the BH at which light cannot escape
  event horizon.
• No events or communication inside the event
  horizon can be observed.

Event Horizon
Light cannot escape
Black Hole
Light can escape
15
Properties of Black Holes

• All matter warps space.
• Like weight on rubber sheet.

16
Evidence for Black Holes

• Isolated black holes are hard to observe.
• No light emitted.
• Can observe Gravitational Lensing

17
Evidence for Black Holes

• Can observe how BHs gravity affects nearby
  objects.
• Unseen companion
• Accretion disk
• X-ray emission

18
Cygnus X-1
19
Black Holes in Galaxies

• BHs may have formed in center when galaxy formed.
• Mass of billions of stars in size of SS (Keplers
  3rd Law).
• Black hole likely in center of the Milky Way.

20
Black Hole -- HST
21
Traveling into a Black Hole -- Tidal Forces

• Very strong.
• Difference in forces of gravity on near and far
  side would pull object apart.

22
Time Dilation

• From outside, observer sees clock on board tick
  more and more slowly than outside of craft.
• Closer to black hole, the slower time appears to
  run.
• At event horizon, clock appears to stop!
• Never see craft fall into BH

23

• BUT person on board craft would not notice any
  change
• Why? If light used as clock, it would have lower
  frequency
• Result of General Relativity

24
Inside of a Black Hole

• Scientists to not know for sure what is inside of
  a black hole.
• Theories of physics break down for such high
  densities.
• Hard to make new model since BH cannot be
  observed.
