Geographic Information Systems for Business Applications

1
Geographic Information Systems for Business
Applications
Brian E. Mennecke Iowa State University
2
"If you will have a young man to put his travel
into a little room, and in short time to gather
much, this you must do ... let him carry with
him also some map or book describing the country
where he travelleth, which will be a good key to
his inquiry..." (Sir Frances Bacon, Essay 18,
Of Travel, 1625).
3
What is a GIS
A geographic information system (GIS) is a
computer-based information system that provides
tools to collect, integrate, manage, analyze,
model, and display data that is referenced to an
accurate cartographic representation of objects
in space. (Mennecke, Dangermond, Santoro, Da
rling, Crossland, 1995).
4
The Objectives for this Presentation

• For you to
• understand what a GIS is and what it can do
• understand how a GIS can be used to analyze and
  interpret data so that YOU can identify
  applications for this technology

• understand the underlying cartographic principles
  that make a GIS work and

• understand issues associated with locating,
  preparing, and importing map and attribute data.

5
Cartographic Terminologyand Principles

• Types of Maps
• GIS Data
• Layering
• Coordinates
• Projections
• Scale

6
Types of GIS Data

• Attribute Data
• Stored in dBase Tables (e.g., .DBF )
• Map Data
• Stored in Shape files (e.g., .SHP)
• Areas
• Lines
• Points

7
Types of Maps

• A Range-Filled Thematic Map

8
Types of Maps

• A Dot Density Thematic Map

9
Types of Maps

• A Bivariate Thematic Map

10
GIS Layers Data
11
Coordinates

• The Cartesian coordinate system

12
Coordinates

• The Cartegraphic System for the Earth
• Lines of Latitude (running east-west app. 69
  miles)

• Lines of Longitude (running north-south)

13
Projections

• Projections are methods by which features on a
  sphere (the earth) can be represented on a flat
  surface (a paper map)

14
Types of Projections

• The Robinson Projection

15
Types of Projections

• The Mercatur Projection

16
Types of Projections

• The Albers Conformal Projection

17
What About Scale?

• Scale is the ratio of the distances of objects
  represented on the map to the actual distances of
  these objects on the earths surface

18
Small Scale Maps

• Smaller scale maps represent the map objects with
  a larger ratio (1250,000)

19
Large Scale Maps

• Large scale maps represent the map objects with a
  smaller ratio (e.g., 110,000)

20
GIS Start to Finish

• Step 1 Define Your Objectives
• Step 2 Acquire the Required Data
• Step 3 Preprocess Data
• Step 4 Data Management and Analysis
• Step 5 Generate Output

21
Defining Your Objectives

• Identify who your user is
• Identify her needs
• Defines goals and objectives based on user needs

22
Acquire the Required Data

• Acquire Attribute Data
• In house
• From Vendors
• Acquire Map Data
• In House
• Digitize Maps
• Create Maps using GPS
• From Vendors
• Census data (e.g., Topologically Integrated
  Geographic Encoding and Referencing or TIGER
  Files)

23
What is TIGER? Topologically Integrated
Geographic Encoding and Referencing System

• TIGER Content
• Streets and their names
• Lakes, streams, and their names
• Railroads
• Geographic entity boundaries and names
  (governments, census tracts, census blocks, etc.)


• Housing unit locations
• Key geographic locations (airports, schools,
  etc.)

• ZIP Codes and address ranges for city-style
  addresses


24
The Digitizing Process
A GPS System
25
Preprocess Data

• Import Data
• For example, TIGER line files may need to be
  converted into TIGER Boundary Files

• Data from a spreadsheet needs to be imported into
  ArcViews table format

• Correct Errors
• Build Custom Areas/Features
• Geocode Data

26
Data Management and Analysis

• Manage the Data
• Work with table elements
• Consider the data in light of the organizational
  data schema

• Consult with other users
• Analyze the Data
• Redefine existing features
• Examine relationships

27
Generate Output

• Print paper maps
• Export map images to other applications
• Export map or table data to other data management
  applications

• Build interactive web maps

28
GIS Software Vendors

• Environmental Systems Research Institute
  (ArcGIS)

• InterGraph Corporation (GeoMedia)
• MapInfo Corporation (MapInfo)
• Microsoft (MapPoint2004)

29
GIS Applications

• Map Creation
• Report Preparation
• Facilities Management
• Analysis of Employer/Employee Demographics
• Transportation Issues
• Strategic Planning
• Decision Making

30
Location Based Services

• Location-based services incorporate information
  about the user's location into the provision of
  products or services. These include

• Locator services (e.g., wheres the closest
  ATM?)

• Navigation systems (e.g., in the car or on your
  PC)

• M-commerce applications (e.g., proximity alerts,
  closest service, mobile advertizing)

31
So, Why Use SL for Education?

• Theoretical and Practical Considerations
• A spatial domain
• Space as an organizing principal
• Spatial exploration
• Build and design objects and actions
• The domain of the Avatar
• Interactions with avatars create a rich
  communication and collaborative experience

• Avatars and the extended self

32
A Look Ahead

• 3-D Content is everywhere
• Millsberry, Webkinz, Clubpenguin, VMK, and other
  kid-focused MUVEs abound

• Richer, natural forms of collaboration in 3-D
  spaces are coming

• Google Streetview

33
Potential GIS Benefits

• Improved Decision Making
• Reduced Errors
• Reduced Risks
• Improved Management and Control
• Improved Service to Clients
