CHP and Verilog Modeling of Asynchronous Processes

1
CHP and Verilog Modeling of Asynchronous Processes

• Peter A. Beerel
• University of Southern California

2
Outline

• Weak Condition Half Buffer Template
• CHP and Verilog
• Precharge Half and Full Buffer Template
• CHP and Verilog
• Verilog Modeling Issues
• Conditional Reads / Writes
• Performance (Forward Backward Latency)
• Modeling larger blocks
• Top-down design in Verilog

3
Four-phase Protocol

• Two-phases active communication
• Two-phases Return to zero phases

4
Asynchronous Functional Blocks
F
Output Channels (R)
Input Channels (L)

• Functionality
• Read a subset of input channels
• Waits for input channels to have data tokens
• Compute F and write to a subset of output
  channels
• Waits for output channels to be reset
• Acknowledges input channels
• Resets output channels
• Upon being acknowledged

5
Fine Grain Pipelining
F
Output Channels (R)
Input Channels (L)

• Basic Idea
• Each stage very small
• Fast latency
• Two gate delays forward latency
• One dynamic gate plus the inverter
• Fast cycle time
• 10-18 gate delays depending on template
• Achieves 700 in 0.25 micron technology

6
Weak Condition Half Buffer (Lines)

• Weak Condition
• Validity of outputs implies validity of inputs
• Inputs consumed -gt can assert acknowledgement
• Reset of outputs implies reset of inputs
• Inputs reset -gt can de-assert acknowledgement

Re
Le
L0
C
R0
Re
Le
Bank of C-latches
R
L
R1
C
L1
WCHB 1-of-N Buffer
WCHB 1-of-2 Buffer (optimized)
7
CHP Behavioral Description of WCHB

• Ra L R? La ? Ra L R? La?
• Interpretation Repeat idefinitely
• Ra L wait for right channel to be reset
  and new token to arrive on left channel
• R? send new token on left channel
• La ? acknowledge left hand side
• Ra L wait for right hand side to
  acknowledge and left hand side to reset
• R? Lower right hand side acknowledge
• La ? Lower left acknowledge
• Initial Condition
• Ra La 0 L R reset

8
Verilog Psuedocode for WCHB

• Initial
• La 0 R space
• Always
• Begin
• Fork
• Wait negedge (Ra)
• Wait posedge (L0) or posedge(L1) / assuming
  dual rail /
• Join
• R lt- Func( L )
• La 1
• Fork
• Wait posedge(Ra)
• Wait pngedge(L0) or nedgedge (L1 0)
• Join
• Reset R
• La 0
• End

9
Verilog Psuedocode for WCHB

• Alternative wait on condition rather than events
• Wait tests and stalls until condition is
  satisfied
• Need not worry about missing events
• Always
• Begin
• Wait (Ra 0)
• Wait (L0 1 or L11) / assuming dual rail
  /
• R lt- Func( L )
• La 1
• Wait (Ra 1)
• Wait (L0 0 and L1 0)
• Reset R
• La 0
• End

10
Precharge Half-Buffer (Lines)

• Goals
• Use pre-charge logic and an input completion
  detector instead of weak-condition logic
• Requires 2 guard transistors (Pc and Eval) in
  Function blocks
• Removes many P-transistors in pull-up and
  pull-down

Pc
Eval
C
Re
Le
Rx
Pc
Eval
Pull-down Logic
RCD
LCD
L
F
R
L
Function block schematic for each output rail
11
CHP Behavioral Description of PCHB

• Ra L R? La ? Ra R? L La?
• Interpretation Repeat idefinitely
• Ra L wait for right channel to be reset
  and new token to arrive on input channel
• R? send new token on output channel
• La ? acknowledge to input
• Ra R ? wait for output channel to
  acknowledge before resetting outputs
• L La ? wait for input channel to reset
  before resetting acknowledge
• Initial Condition
• Ra La 0 L R reset
• Increase parallelism over WCHB
• Output hand side resets without waiting for input
  side reset

12
Verilog Psuedocode for PCHB

• Initial
• La 0 R space
• Always
• Begin
• Wait Ra 0
• Wait (L0 1 or L1 1) / assuming dual
  rail /
• R lt- Func( L)
• La 1
• Wait Ra 1
• Reset R
• Wait (L0 0 and L1 0)
• La 0
• End

13
CHP Behavioral Description of PCFB

• Ra L R? La ? ( Ra R? ), (L
  La?)
• Interpretation Repeat idefinitely
• Ra L wait for right channel to be reset
  and new token to arrive on input channel
• R? send new token on output channel
• La ? acknowledge to input
• (Ra R ?), L La ?) wait for output
  channel to acknowledge before resetting outputs
  and concurrently wait for input channel to reset
  before resetting acknowledge
• Initial Condition
• Ra La 0 L R reset
• Increase parallelism over PCHB
• Input and output handshake completes concurrently
• New token can arrive on inputs while output
  channel still busy
• Slack 1 instead of ½.

14
Verilog Psuedocode for PCFB

• Initial
• La 0 R space
• Always
• Begin
• Wait Ra 0
• Wait (L0 1 or L1 1) / assuming dual
  rail /
• R lt- Func( L) La 1
• Fork
• Begin
• Wait Ra 1 Reset R
• End
• Begin
• Wait (L0 0 and L1 0) La 0
• End
• Join
• End

15
Conditional Reading and Writing

• Conditional Reading of Input Channels
• Le generation modified
• Need one Le per input rail
• Acknowledge only input channel that is read
• Control signals need to be part of Le logic
• Conditional Writing of Output Channels
• Skip circuitry
• Generate extra N1 output that is not routed out
  but goes to completion detection
• Modify circuitry so that you dont wait for reset
  of output channels that were not written

16
Conditional Join A Merge Circuit
17
Verilog Psuedocode for PCHB Join

• Initial
• La 0 R space
• Always
• Begin
• Wait Ra 0
• Wait (S0 1 or S1 1) / assuming dual
  rail /
• If S0 1
• Wait L1
• R lt- L1 / psuedocode must be expanded /
• La 1 Sa 1
• Else
• Wait L2
• R lt- L2 / psuedocode must be expanded /
• La 1 Sa 1
• Wait Ra 1 Reset R
• Fork
• Begin Wait (L0 0 and L1 0) La 0 End
• Begin Wait (S0 0 and S1 0) Sa 0 End
• Join

18
Conditional Fork A Split Circuit
19
Verilog Psuedocode for PCHB Split

• Initial
• La 0 R space
• Always
• Begin
• Wait (Rxa 0 and Rya 0)
• Wait (S0 1 or S1 1) / assuming dual
  rail /
• Wait (L0 1 or L1 1) / assuming dual
  rail /
• If S0 1
• Rx lt- L / psuedocode must be expanded /
• La 1 Sa 1 Wait Rxa 1 Reset Rx
• Else
• Ry lt- L / psuedocode must be expanded /
• La 1 Sa 1 Wait Rya 1 Reset Ry
• Wait (L0 0 and L1 0) La 0
• Wait (S0 0 and S1 0) Sa 0
• End

20
Modeling Delays of PCHB in Verilog

• Begin
• Wait Ra 0
• Wait (L0 1 or L1 1) / assuming dual
  rail /
• Forward_latency R lt- Func( L)
• Lack_delay La 1
• Wait Ra 1
• Precharge_delay Reset R
• Wait (L0 0 and L1 0)
• Lackreset_delay La 0
• End
• Delay Interpretations
• Lack_delay RCD C-element
• Assumes LCD lt Forward_latency RCD
• Lackreset_delay Max(RCD, LCD) C-element
• Which one of the max depends on arrival time of
  L

21
Local Cycle Time of PCHB
C
C
C
RCD
LCD
RCD
LCD
RCD
LCD
F1
F2
F3

• Maximum of
• 3 Evaluations 1 RCD 1 C-element 1 Precharge
  1 RCD 1 C-element
• 2 Evaluations 1 RCD 1 C-element 1 Precharge
  1 LCD 1 C-element
• 1 Evaluation 1 RCD 1 C-element 1 Precharge
  1 RCD 1 C-element
• 1 Evaluation 1 LCD 1 C-element 1 Precharge
  1 RCD 1 C-element

22
Cycle time of PCHB in Verilog

• Begin
• Wait Ra 0
• Wait (L0 1 or L1 1) / assuming dual
  rail /
• Forward_latency R lt- Func( L)
• Lack_delay La 1
• Wait Ra 1
• Precharge_delay Reset R
• Wait (L0 0 and L1 0)
• Lackreset_delay La 0
• End
• Cycle Time is Max of
• 3 Forward_latency Lack_delay
  Precharge_delay Lackreset_delay
• 2 Forward_latency Lack_delay Precharge_delay
  Lackreset_delay
• Forward_latency Lack_delay Precharge_delay
  Lackreset_delay
• Backward latency Cycle_time Forward_latency
  (?)

23
Modeling Larger Blocks in Verilog

• Asynchronous Matrix Multiply Example
• y30 0, i 0
• Mulin?x
• i lt 3 -gt
• y30 y30 coeff(j) x
• i i 1
• i 3 -gt
• Accout30 ! (y30 coeff(j) x
  )
• i 0, y30 0

24
Matrix Multiply in Verilog Psuedocode

• Initial
• Begin
• y30 0 i 0 MulinAck 0 Accout space
• End
• Always
• Begin
• Wait AccoutAck 0 Wait (Valid(Mulin)) x
  ChannelTypetoInt(Mulin)
• Fork
• Begin
• If (i lt 3)
• y30 coeff(j) x i
• Else
• Begin
• Accout30 InttoChannelType(y30
  coeff(j) x )
• i 0, y30 0
• Wait AccoutAck 1 Accout30 space
• End
• End
• Begin

25
Issues with Matrix Multiply

• Model not pipelined
• Presented model is a full buffer
• No further pipelining described
• Real Implementation
• Possibly much finer grain pipelined
• Created by top-down design methodology
• Presented model can be used to check functional
  correctness of more detailed designs
• But not performance due to lack of pipelining

26
Top-Down Refinement
Test Bench
Behavioral Non-Pipelined Model
Fork
Comparator
Structural Pipelined Model
27
Top-Down Design in Verilog/Cadence

• Verilog
• Channels must be precisely defined at all levels
• 32 bit bus implementation decision must be made
  early
• Sixteen 1-of-4 channels OR
• Thirty-two 1-of-2 channels
• Little support for abstract channel types
• Also a limitation of Cadence (?)
• Conversion to and from internal data
  representation needs to be done for every block
• No clean method
• Functions can be defined but must be included in
  each module that uses it
• VHDL is somewhat more powerful and can handle
  these issues much better
