Speculations on the Future of Water and Food Security

1
Speculations on the Future of Water and Food
Security

• Ismail Serageldin
• IFPRI
• 29 March 2004

2
Outline

• How Scarce Is Water?
• How Much for Agriculture?
• Climate Change And Its Impact
• Problems, Approaches and Reforms
• The Role Of Science
• Rebuilding Social Structures Empowerment Is Key
• Envoi

3
IFPRIs Excellent Work

• 2020 exercise
• M. Rosegrant, X. Cai and S. Cline, World Water
  and Food to 2025 Dealing with Scarcity, 2002
• IWMIs work
• World Vision exercise, 2000.
• Tokyo Club debates 2002-2004
• Others

4
How Scarce Is Water?
5
Fresh water is precious
6
Fresh Water Is Only 2.5 of All Water
Only 2.5 is fresh water
97.5 is salt water
7
Two thirds of that is locked in Glaciers and Ice
Caps
8
2/3 of the remaining part is lost to
Evapotranspiration
9
That leaves only 40,700 KM3 Potentially Available
to people
10
Of that 20 are too remote
11
Of the accessible part 3/4 come as floods and are
not readily useable
12
With dams, etc. Total water available to humans
sustainably is about 12,500 km3
Of the 80 or 32,900 km3 accessible
1/4 available sustainably
3/4 floods
8,200
Dams, etc.
4,300
12,500 km3
13
Total water available sustainably 12,500 km3
14
Total water available sustainably 12,500 km3

• About 35 directly used by people
• About 19 used instream (to dilute pollution,
  sustain fisheries, maintain wetlands, etc)
• Therefore, more than 50 or 6,250 km3 is
  currently used

15
Per Capita Availability Shows Huge Variation
Country/region
Water availability
gt 10,000 m3/year
North America
Egypt
1,100
Jordan
260
Syrias water table has been declining one meter
every year for the past 30 years!
16
Regional per capita availability of water is
declining
000 m3
16
Africa
14
12
10
World
8
Asia
6
4
2
MENA
0
1960
1990
2025
17
Current Mismanagement
18
Fragmentation by Use

• In each country at least 6, and sometimes as much
  as twenty, agencies are involved with water
  management

19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
International fragmentation

• About 260 river basins are shared by two or more
  countries, highlighting the need for
  collaboration in water management

25
(No Transcript)
26
Water Use And The Environment
27
Rising Water Use

• In The 20th Century,
• Population Grew Three-fold,
• But
• Water Use Grew Six-fold!

28
Human Activity Has Had an Impact on Both the
Hydrological Cycle and the Quality of Water
29
Three Gorges Construction
30
Storage Capacity in cu.m. / person

• USA 7000
• Australia 5000
• So. Africa 700
• Ethiopia 25
• Kenya 4

31
The Yellow river did not reach the sea 220 days
in 1997!
32
In the last 100 years 50 of the worlds wetlands
have been lost to development.
33
(No Transcript)
34
Water Budgets

• Global
• 97 Salt Water
• 3 Fresh Water
• Freshwater
• 87 Not Accessible
• 13 Accessible
• MENA
• 1 of Accessible Freshwater
• 5 of World Population

35
(No Transcript)
36
(No Transcript)
37
How Much for Agriculture?
38
INDUSTRY
RESERVOIR LOSSES
MUNICIPAL
AGRICULTURE
39
5
INDUSTRY
6
MUNICIPAL
89
AGRICULTURE
Source World Bank WDI 2002
40
(No Transcript)
41
(Liters/day)
Domestic
Food Production
42
One Calorie One Liter
43
(No Transcript)
44
Underground water is being mined at unsustainable
rates and 10 of world grain production depends
on unsustainable aquifer withdrawals.
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
Irrigated Agriculture in Developing Countries

• Today accounts for
• 40 of all crop production
• 60 of cereals
• Over the next 30 years, to meet the demands of a
  larger world population, we must increase
• arable irrigated land by 22, and
• water withdrawals by 14

51
(No Transcript)
52
Water Use Efficiency
53
Water Use Efficiency in Agriculture is Low
54
(No Transcript)
55
Many Transfers

• From main Source to Irrigation System (T-1)
• From Irrigation to local canal (T-2)
• From Local canal to field (T-3)
• From Field to plant (T-4)
• Plant uptake (T-5)

56
Water Use Efficiency (T-1) x (T-2) x (T-3) x
(T-4) x (T-5)
57
Water Use Efficiency 0.8 x 0.8 x 0.8 x 0.8 x
0.8 0.33
58
Water Use Efficiency 0.9 x 0.9 x 0.9 x 0.9 x
0.9 0.59
59
Quality and Quantity of WaterPollution Reduces
Available/useable water
60
Pollution!
61
(No Transcript)
62
Freshwater Fish Are Going Extinct at Five Times
the Rate of Marine Fish Species
63
(No Transcript)
64
Changing the Way We Manage Water
65
Workable Approaches
66
(No Transcript)
67
More Crop Per Drop!
68
Crop yield per unit of waterwheat kg/cu.m
2.2
0.8
0.3
RAINFED
IRRIGATED
SUPPLEMENTAL IRRIGATION
Source ICARDA
69
(No Transcript)
70
Increasing Water Use Efficiency

• Reuse of drainage water from irrigated fields (as
  in Egypt)
• Better management of the System (less losses)
• More efficient delivery techniques
• More appropriate cropping patterns
• Precision farming on water use

71
Water is re-used multiple times
72
Increasing Water Use Efficiency

• Reuse of drainage water from irrigated fields (as
  in Egypt)
• Better management of the System (less losses)
• More efficient delivery techniques
• More appropriate cropping patterns
• Precision farming on water use

73
(No Transcript)
74
(No Transcript)
75
Increasing Water Use Efficiency

• Reuse of drainage water from irrigated fields (as
  in Egypt)
• Better management of the System (less losses)
• More efficient delivery techniques
• More appropriate cropping patterns
• Precision farming on water use

76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
Increasing Water Use Efficiency

• Reuse of drainage water from irrigated fields (as
  in Egypt)
• Better management of the System (less losses)
• More efficient delivery techniques
• More appropriate cropping patterns
• Precision farming on water use

80
Selecting The Most Appropriate Cropping Patterns
81
Increasing Water Use Efficiency

• Reuse of drainage water from irrigated fields (as
  in Egypt)
• Better management of the System (less losses)
• More efficient delivery techniques
• More appropriate cropping patterns
• Precision farming on water use

82
Precision Farming
83
Increasing Water Use Efficiency

• Reuse of drainage water from irrigated fields (as
  in Egypt)
• Better management of the System (less losses)
• More efficient delivery techniques
• More appropriate cropping patterns
• Precision farming on water use

84
Reforms
85
Reforms

• IWRM
• More efficient use of water
• Promoting P4
• New water (Alternative sources)
• Regional and international cooperation

86
(No Transcript)
87
(No Transcript)
88
Reforms

• IWRM
• More efficient use of water
• Promoting P4
• New water (Alternative sources)
• Regional and international cooperation

89
Reforms

• IWRM
• More efficient use of water
• Promoting P4
• New water (Alternative sources)
• Regional and international cooperation

90
P4 People Public Private Partnerships

• Putting people first
• Mobilizes stakeholders and involves them in the
  design and implementation of the PPP
• Recognizes community action

91
Reforms

• IWRM
• More efficient use of water
• Promoting P4
• New water (Alternative sources)
• Regional and international cooperation

92
New Water Sources(US cents /cu.m)

• Reduce demand 10 - 70
• leakage repair 10 - 70
• Desalination 20 - 40
• (brackish water)
• Wastewater reuse 10 50
• (Only for irrig. some industry)
• Desalination 50 90
• (sea water)

Source World Bank est. 2003 in WB,from scarcity
through reform to Security, for WWF3, Kyoto Japan
2003, p.13
93
Using Treated Wastewater
Sorghum and Topinambur irrigated with Treated
Wastewater in Sorbulak area, Kazakhstan
Courtesy ICARDA
94
Reforms

• IWRM
• More efficient use of water
• Promoting P4
• New water (Alternative sources)
• Regional and international cooperation

95
Reforms

• IWRM
• More efficient use of water
• Promoting P4
• New water (Alternative sources)
• Regional and international cooperation

96
Essential Questions

• Always ask
• Who pays?
• Who benefits?
•
• Always trace the shifting and incidence of
  taxation and subsidies

97
Climate Change And Its Impact
98
(No Transcript)
99
Ozone Hole, 1998 image
100
Hottest Year on Record?
101
Hottest Year on Record?
102
La Nina in the Pacific
103
Hurricane Bonnie
104
(No Transcript)
105
Extreme Variability Africas Burden
Kenya Annual Rainfall Variation about the Average
160
140
120
100
80
60
1956
1958
1960
1962
1964
1966
1968
1970
1972
1974
1976
1978
1980
106
Climate Variability (Change?)Index of Rainfall
in Sahel 1941-1990
Source Departure from standard deviation
Climate Prediction Center 1991, Prrsentation by
South Africa at Camdessus Panel meetings
107
Climate Variability (Change?)Index of Rainfall
in Sahel 1941-1990
Source Departure from standard deviation
Climate Prediction Center 1991, Prrsentation by
South Africa at Camdessus Panel meetings
108
(No Transcript)
109
(No Transcript)
110
(No Transcript)
111
Vulnerability Of The Poor

• The Ability To Accumulate Capital Is Reduced
  (Selling Off Assets In A Downturn)
•
• Overall Economic Growth Is Reduced (Less Poverty
  Reduction)
•
• Rebuilding Social Structures empowerment Is Key

112
(No Transcript)
113
(No Transcript)
114
(No Transcript)
115
(No Transcript)
116
(No Transcript)
117
(No Transcript)
118
Food Production and Global Environmental Issues
Land degradation
Climate change
Food supply and demand
Biodiversity loss
Unsustainable forestry
Source The World Bank and the Global
Environment, A progress report, adapted from
Watson, et. al. 1998.
119
In General

• Climate change will increase variability of
  weather phenomena
• Generally mean declining rain-fall over the
  long-term
• Increase vulnerability of poor farmers in the
  arid and semi-arid zones

120
Questions on Dams
121
(No Transcript)
122
(No Transcript)
123
(No Transcript)
124
(No Transcript)
125
(No Transcript)
126
(No Transcript)
127
(No Transcript)
128
(No Transcript)
129
(No Transcript)
130
The Role Of Science
131
Science Can Help

• Agriculture
• Water purification and waste management
• Environmental management (new Industries)

132
Science Can Help

• Agriculture
• Water purification and waste management
• Environmental management (new Industries)

133
Traditional Wisdom and Modern Science
134
The Genetic Imperative
135
Harnessing the Genetics Revolution

• Going beyond marker-assisted selection, tissue
  culture and genetic maps
• Recognizing the new revolution in genomics, and
  QTL analysis
• Selecting for valuable genes, and not only on
  phenotype

136
(No Transcript)
137
Major Effort at Developing Better Suited Plants

• Drought tolerance
• General resistance to stresses
• Salt water plants? Halophytes, Mangroves, etc.

138
(No Transcript)
139
(No Transcript)
140
(No Transcript)
141
(No Transcript)
142
Why Not Super Upland Rice by 2020?
143
(No Transcript)
144
(No Transcript)
145
(No Transcript)
146
(No Transcript)
147
Science Can Help

• Agriculture
• Water purification and waste management
• Environmental management (new Industries)

148
(No Transcript)
149
The Biotechnology RevolutionPromise and Peril
150
(No Transcript)
151
(No Transcript)
152
(No Transcript)
153
Science Can Help

• Agriculture
• Water purification and waste management
• Environmental management (new Industries)

154
Oil Dispersing ChemicalsTokyo Bay, July 1997
155
Opens Amazing New Possibilities
156
Here industrial biotechnology can be very helpful
157
Benefits of Industrial Biotechnology

• Compared to traditional industrial processes it
  is more efficient, renewable and cleaner
  (improvements include from 3 to 10 times
  reduction in waste)

158
New paradigm of research in industrial
biotechnology

• Gene shuffling and biochip screening
• Enormous new power
• Faster, cheaper better designed products

159
Gene Shuffling As a Research Strategy

• Basically it uses the way nature works, and
  accelerates it
• We can do in one week what natural processes
  would do in one million years
• Where nature screens by the local environment, we
  screen by desirable traits
• The systems power is when we combine the
  laboratory shuffling with the huge diversity
  available in nature

160
(No Transcript)
161
Biochips
162
Testing with biochips
163
Biochips

• Useful to find out which genes are turned on when
  we look for high producing strains
• Biochips can now assay tens of thousands of
  reactions at single go
• Move to wafers of biochips, now in development,
  could lift that number up to 60 million probes!

164
IPR and Lawsuits
165
New paradigm is affecting all aspects of industry

• The preparation of industrial enzymes a-la-carte
• The acceleration of drug design and testing
• And so much more

166
The power of the new technologies

• Old paradigm of site directed mutagenesis you
  could develop 3-6 new protein molecules per month
• Now we can produce 100,000 different protein
  molecules per day
• To analyze this huge diversity we screen them
  through biochips, and select for the desirable
  traits

167
(No Transcript)
168
The key and the effect of the new technologies

• The breakthroughs are robotic screening and small
  (chip) size. The two tools work in concert.
• We now are convinced that we can make any
  industrial enzyme needed at an industrial scale.

169
(No Transcript)
170
Exciting applications

• Industrial enzymes are an environmentally
  friendly Clean Technology because they are
  biodegradable, a renewable resource, energy
  efficient, recycle and reduce waste and replace
  harsh chemicals
• Industrial enzymes have demonstrable benefits in
  detergents, textiles, baking, animal feed and
  biofuel

171
Examples of dramatic changes (due to new
enzymatically based processes)

• Textile treatments 10 times savings in use of
  caustic soda and 2.5 times in water
•
• Antibiotic production over five times savings in
  solvents, environmentally problematic chemicals,
  steam, CO2 emissions and waste water.

172
And This Is Just the Beginning
173
Also The Science of Remote Sensing!
174
Remote Sensing As a Tool
175
From Global to Local

• Remote sensing and fast computers make it
  possible to link global data bases to local
  realities
• Enormous increases in precision NRM

176
Desertification
In one year (1984-1985), Saharas boundary
shifted 110 km decreasing an area 724,000 sq. km
(21.3 times the Netherlands)
177
(No Transcript)
178
Challenges Human Activity and Ecosystem Linkages

• Spatial
• Location-specific

179
Remote Sensing Makes Detailed Ecological Analysis
Possible
180
Urbanization Can Also Be Tracked
181
Remote Sensing and Water

• Classical approaches
• Large variations
• Depend on quality data (e.g. stream flow)
• Systemic measurements at regular intervals
  difficult
• Remote sensing
• Strategic, precise information
• Water availability at basin level
• Better understanding of systems at low cost

182
Irrigation in the Desert
183
Evaluating water resources

• Combining satellite estimates with ground-based
  rainfall data
• Allows volumetric estimates of water outflow
• Vital for planning water at the basin level

(Total kg/m3, June to November, 1999)
184
Measuring total evaporation_at_ 1 km resolution,
Jun-Nov 99

• Map answers the question where is water being
  consumed?
• Helps water resource planners allocate water and
  manage its distribution
• Information that can be used by poor farmers

(Total mm, June to November, 1999)
185
Precision Farming
186
Technology Upgrades
187
Understanding and Predicting the Weather
188
Envoi
189
We Need a Collaborative Approach Among Science
Organizations for a Systematic Attention to Water
and Development Issues
190
International Agencies (UNU, CGIAR Especially
ICARDA) and Regional Institutions Must Work
Together to Harness Science for Water and
Development Issues
191
Innovate! Unleash the Creativity of the
Various Actors!
192
It Can Be Done!
193
(No Transcript)
194
(No Transcript)
195
(No Transcript)
196
(No Transcript)
197
Towards Better Tomorrows
198
(No Transcript)
199
(No Transcript)
200
(No Transcript)
201
(No Transcript)
202
(No Transcript)
203
(No Transcript)
