The Large Binocular Telescope:

1
The Large Binocular Telescope a laboratory for
image reconstruction
M. Bertero DISI Universita di Genova
Pisa October 12, 2005
2

• Joint work with
• Barbara Anconelli - Genova
• Patrizia Boccacci - Genova
• Marcel Carbillet - Nice
• Serge Correia - Potsdam
• .Gabriele Desiderà - Genova
• Henri Lanteri - Nice

3
Outline

• - The Large Binocular Telescope (LBT)
• - Restoration of LBT images
• - The standard approach
• - Correction for boundary effects
• - Super-resolution
• - A general approach
• - Objects with high dynamic range
• - Concluding remarks

4
The Large Binocular Telescope (LBT) 1/7

• The LBT, under construction on the top of Mount
  Graham, Arizona, is a new-conception telescope,
  consisting of
• two 8.4 m mirrors, with the centers at a
  distance of 14.4 m
• a very advanced multi-conjugate AO system
  (adaptive secondaries, pyramid sensors, etc.)
• One of the instruments will be a Fizeau
  interferometer for the combination of the images
  of the two mirrors.
• http//lbtwww.arcetri.astro.it
• First mirror already installed and alluminized
• Second mirror transported from the Mirror Lab to
  Mount Graham
• First interferometric light 2007 2008 (?)

5
The Large Binocular Telescope (LBT) - 2/7
The structure pre-assembled in Milan, June 2001
The enclosure on the top of Mount Graham, Arizona
6
The Large Binocular Telescope (LBT) - 3/7
LINC/NIRVANA (Lbt Interferometric Camera /
Near-IR-Visible Adaptive iNterfermeter for
Atronomy) is the German-Italian beam combiner for
LBT. Will combine the radiation from the two 8.4
m primary mirrors in a Fizeau mode, allowing
true imagery. Will operate at wavelengths between
0.6 and 2.4 microns. The first camera will cover
10 arcsec with a pixel size of about 5 mas in
K-band (2048 x 2048 pixels). Multiconjugate AO
correction is over a field of about 2 arcmin so
that even larger images will be possible in the
future (24000 x 24000 ?).
7
The Large Binocular Telescope (LBT) 4/7
In case of perfect circular mirrors, perfect
interferometer, no atmosphere, the Point Spread
Function (PSF) of LBT is given by (we assume that
the telescope is aligned in the x-direction)
First zero in the x-direction x1 l/2B First
zero in the h-direction h1 1.22 l/D .
8
The Large Binocular Telescope 5/7
x,h - plane
u,v - plane
9
The Large Binocular Telescope 6/7
8.4 m
22.8 m
Imaging with LINC/NIRVANA with a few
observations at different parallactic angles and
suitable reconstruction algorithm, the image, as
seen by a 22.8-m telescope, can be reconstructed
!
10
The Large Binocular Telescope 7/7






incoherent sum
NO !
11
Restoration of LBT images 1/4
In the case of LINC/NIRVANA the image restoration
problem consists in estimating a unique
high-resolution image from p images gj,
corresponding to p different orientations of the
baseline, being given the corresponding PSFs Kj
and backgrounds bj. Therefore it is a problem of
multiple images deconvolution. Accuracy and
resolution are strongly related to the coverage
in the u,v plane. In astronomy the most
frequently used restoration method is an
iterative method known as RL-method (Richardson,
1972 Lucy, 1974) in the case of deconvolution
problems, it coincides with the ML-EM method
(Shepp and Vardi, 1982), proposed in tomography.
12
Restoration of LBT images 2/4
Model for the p images acquired by LINC/NIRVANA
CCD camera (based on Snyder et al, 1993) for
j1,....,p
gj,s(n) number of photons coming from the
source Poisson process with expected value (A
jf)(n) (K jf)(n) (K j PSF of the j-th
baseline orientation, f(n) expected value of
the number of photons emitted at pixel n)
gj,b(n) number of photons due background
emission, etc Poisson process with (constant)
expected value bj rj(n) read-out noise due
to the amplifier realization of an independent
Gaussian process with expected value c and
standard deviation s .
13

Restoration of LBT images 3/4

• Summary of the main features of astronomical
  images
• - Bandlimiting (the support of the FT in the
  u,v-plane is bounded)
• - Background due to sky emission (to be
  estimated)
• Contamination by both Poisson and Gaussian
  noise (whose statistical parameters can be
  estimated)
• - High Dynamic range (very often orders of
  magnitudes between the brightness of different
  objects in the field of view)

14
Restoration of LBT images 4/4
Properties to be satisfied by the restored
images - Nonnegativity (assuming an estimate of
the background) - Conservation of the total
flux - Correct estimation of the relative local
fluxes (relative magnitude of stars
photometry) - Correct estimation of the relative
angular separation (astrometry)
15
The standard approach 1/5
In the case of images dominated by photon noise,
the read-out noise can be neglected and the
likelihood function is given by
To maximize this function is equivalent to
minimize the Kullback-Leibler directed distance
or Csiszár I-divergence measure of the
discrepancy between the detected images g j
and the computed images A j f b j (j1,...,p)
16
The standard approach 2/5

• If we denote by AjT the transposed matrices, the
  standard EM-method becomes
• initialize with f(0) gt 0
• given f(k), compute f(k1) by

Again it is assumed that each PSF is normalized
in such a way that the sum of its pixel values is
one. The method is slow and computationally heavy.
17
The standard approach 3/5
The iterates converge, for any initial guess, to
a minimum point of the I-divergence the minimum
may not be unique and may be corrupted by strong
noise propagation. Each iterate is
non-negative. The total flux is correctly
reproduced (exactly in the case of zero
background). In the case of sparse and resolved
objects (systems of isolated stars at an angular
distance greater than the diffraction limit) the
photometric (relative magnitudes) and astrometric
(relative angular separations) parameters are
correctly given. In the case of diffuse objects
the iterates have a semi-convergent behaviour.
18
The standard approach 4/5
The analogy between LBT-images and projections
in tomography suggests the extension to LBT
(Bertero and Boccacci, 2000) of the OSEM (Ordered
Subsets Expectation Maximization) method (Hudson
and Larkin, 1994)
The computational cost per iteration is reduced
by a factor of about 4/(3p1).
19

The standard approach 5/5
Reconstruction of a diffuse object
image with PSF _at_ 60 deg.
original object
reconstruction
0.7
20
Correction for boundary effects 1/4
When the object extends beyond the boundary of
the FOV, the FFT-based methods are equivalent to
use periodic boundary conditions hence they
introduce discontinuities at the boundary, which,
in the deconvolved image, produce Gibbs
oscillations, also called ripples. A simple
method has been proposed, which consists in
reconstructing the object over a domain broader
than the FOV, hence without introducing
artificial boundary conditions. One can apply the
Richardson-Lucy (or OSEM) method to this problem
the use of FFT is still possible using arrays
2Nx2N and extending the detected images by zero
padding. The results are quite satisfactory.
21
Correction for boundary effects 2/4
Scheme of the approach bottom left the array
of the RLM a-factors bottom right the windowed
weights, defining the reconstruction region
22
Correction for boundary effects 3/4
The modified OSEM algorithm is as follows (the
bar denotes 2Nx2N arrays
23
Correction for boundary effects - 4/4
OSEM
Ideal PSFs
SR70
SR26
New method
24
Super-resolution 1/6

• In astronomy the term denotes any method able to
  provides a resolution better than the diffraction
  limit
• if l is the wavelenght the limit is
  - l/D in the
  case of a single mirror with diameter D
• - l/B in the case of LBT with maximum
  baseline B.
• the amount of super-resolution is controlled by
• the angular Space Bandwidth product (SBP),
  given by the ratio between the angular size of
  the object and the diffraction limit
• Signal-to-noise ratio (SNR) the amount of
  super-resolution increases with increasing SNR

25
Super-resolution 2/6
The standard restoration method implements the
constraint of non-negativity as well as a
constraint on the total flux of the object and
therefore it already provides a moderate amount
of super-resolution. However the crucial
constraint is on the support of the object. It
can be implemented by using a localization
property of the algorithm due to the
multiplicative structure of the algorithm, if
the initial guess is zero in one pixel, all the
iterates are zero in that pixel. If the domain of
the object is known, one can initialize the
algorithm with the characteristic function of the
domain.
26
Super-resolution 3/6

• construction of a mask matrix with values 0 or
  1
• 1 where the image resulting from the first step
  is greater than a fixed treshold given percent
  of the image maximum value
• 0 elsewhere.

Result of the first step
Mask
27
Super-resolution 4/6

• RL restoration initialized with the mask of the
  domain as estimated in step 1.
• smaller number of iterations (250-5000)
• can already provide a super-resolved image but
  the photometry may not be correct

OS-EM 5000 iter
Result of the second step
Result of the first step
28
Super-resolution 5/6

• If the photometry is not correct the first two
  steps are used to estimate the positions of the
  two stars

• solution of a least-squares problem , where the
• unknowns are the magnitudes of the stars

original difference of magnitude
difference of magnitude after step 3
29
Super-resolution 6/6
Minimum separation limit in the case of binaries
with the same magnitude
number of iterations Step 1 10000 Step2
2505000
we use a circular mask with diameter
30
A general approach 1/9

• LINC/NIRVANA will require a broad spectrum of
  image restoration methods designed for different
  purposes
• quick-look methods, to be routinely used for a
  first inspection of the observed astronomical
  object possibly very efficient even if not very
  accurate
• ad hoc methods for the restoration of objecs
  with specific features (high dynamic range, low
  photon counting, edges,..)

It should be interesting to have a general
approach for the minimization of a broad class of
functionals with the constraints of nonnegativity
and flux conservation (L1-norm). We investigate
the extension of an approach proposed by Lanteri
et al. (2001-2002).
31
A general approach 2/9
Minimization of functionals of the following
type J(f,g) J0(Afg) m JR(f) , where the
first term is a discrepancy between detected and
computed data and the second term a
regularization functional, with the additional
constraints
The constant c can be chosen in such a way that
the flux of the restored object is consistent
with the fluxes of the detected images (constant
backgrounds)
32
A general approach 3/9
The approach relies on the Split Gradient Method
(Lanteri et al. 2002), i. e. on the following
decompositions of the gradients
where U, V are nonnegative arrays (V positive).
It is obvious that these decompositions always
exist even if they are not unique. For practical
applications their explicit expressions as
functions of f and g g1, ., gp are needed.
The approach is basically a descent method.
33
A general approach 4/9
The basic algorithm is as follows
a and w are relaxation parameters a is the step
in the descent direction it can be chosen in
order to assure nonnegativity and convergence.
34
A general approach 5/9
In the particular case of step 1, the algorithm
takes a very simple form
convergence is not guaranteed (even if it has
been proved in particular cases) but
nonnegativity is automatic ! By taking into
account the structure of the discrepancy
functional in the multi-images case, one gets
35
A general approach 6/9
The dependence of the algorithm on the
multi-images suggests the following general
OS-version
In such a way each iteration has the same
computational cost of a single-image iteration.
36
A general approach 7/9
Two examples
- Poisson noise
In the case m0 one obtains the OS-EM algorithm.
- Gauss noise
In the case m0 one obtains an OS version of ISRA
(Iterative Space Reconstruction Algorithm) with
the addition of background contribution.
37
A general approach 8/9
Possible regularizations
D is a matrix with nonnegative entries. Example
the discrete Laplacian D 4(I-D)
38
A general approach 9/9
As an example we obtain an acceleration of the
OSEM (Ordered Subsets Expectation Maximization)
method (Hudson and Larkin, 1994) derived from
Tanaka, 1982
Computational cost per iteration reduced by a
factor 4/(3p1) with w2, reduction of the
number of iterations by a factor 2.
39
Objects with high dynamic range 1/5 A
model of young binary star (simulation based on
observations of the GG Tau system)
40
Objects with high dynamic range 2/5
One possible approach can be provided by an
adaptive penalization of the I-divergence
(Geman and Mac Clure, 1987)
Penalization is obtained by means of a
semi-convex functional (the Hessian is bounded
from below) the result is a Tikhonov
regularization in regions where f(n) is small
with respect to h and no regularization in
regions where f(n) is large with respect to h in
these regions the EM algorithm is dominating.
Uniqueness of the minimum is not guaranteed. The
previous iterative algorithm becomes very simple.
41
Objects with high dynamic range 3/5
In the case of single image the algorithm is as
follows
42
Objects with high dynamic range 4/5
Iterates of the OSEM method (linear scale)
Without Regularization
K100
K finale
With Regularization
43
Objects with high dynamic range 5/5
Without Reg.
SR26
Ideal PSFs
SR70
With Reg.
44
Concluding remarks

• AIRY , version 3.0 http//dirac.disi.unige.it

• A sample of open problems
• Specific methods for the reconstruction of faint
  objects in these cases the photon noise may be
  comparable to the (Gaussian) read-out noise so
  that both Poisson and Gauss statistics must be
  taken into account.
• - Development of wavelet based methods taking
  into account the different angular scales of
  astronomical objects.
• Development of powerful acceleration methods,
  for instance along the lines of the Biggs-Andrews
  approach (MATLAB).
• Domain decomposition methods for large scale
  images or space-variant PSFs.

45
References
LBT site http//lbtwww.arcetri.astro.it 1 M.
Bertero and P. Boccacci, 1998, Introduction to
Inverse Problems in Imaging, IOP, Bristol 2 M.
Bertero, and P. Boccacci, 2000, Application of
the OS-EM method to the restoration of LBT
images, Astron. Astrophys. Suppl. Ser., 144,
181-186 3 M. Bertero, and P. Boccacci, 2000,
Image restoration methods for the Large Binocular
Telescope, Astron. Astrophys. Suppl. Ser., 147,
323-332 4 S. Correia, M. Carbillet, P.
Boccacci, M. Bertero, and L. Fini, 2002,
Restoration of interferometric images I. The
software package AIRY, Astron. Astrophys., 387,
733-743 5 M. Carbillet, S. Correia, P.
Boccacci, and M. Bertero, 2002, Restoration of
interferometric images II. The case-study of the
Large Binocular Telescope, Astron. Astrophys.,
387, 744-757
46
6 D. L. Snyder, A. M. Hammoud, and R. L. White,
1993, Image recovery from data acquired with a
charged-coupled -device camera, 1993, J. Opt.
Soc. Am., A-10, 1014-1023 7 W. H. Richardson,
1972, Bayesian-based iterative method of image
restoration, J. Opt. Soc. Am., 62, 55-59 8 L.
Lucy, 1974, An iterative technique for the
rectification of observed distribution, Astron.
J., 79, 745-754 9 L. A. Shepp and Y. Vardi,
1982, Maximum likelihood reconstruction for
emission tomography, IEEE Trans. Med. Imaging, 1,
113-122 10 A. R. De Pierro, 1987, On the
convergence of the iterative image space
reconstruction algorithm for volume ECT, IEEE
Trans. Med. Imaging, 6, 124-125 11 H. Lanteri,
M. Roche, and C. Aime, 2002, Penalized maximum
likelihood image restoration with positivity
constraints multiplicative algorithms, Inverse
Problems, 18, 1397-1419
